Operating instructions Model-No.: JK 126 / 42-4 HT & JK 126 / 42-4 HT AC Ergoline Inspiration 550 Hybrid Technology Ergoline Planet Fitness 42/4 Hybrid Light Technology 1019103-00A / us / 04.2019...
Page 2
The right to make technical changes in regard to the figures and information contained in this instruction manual is reserved! NOTE The illustrations and texts apply to Ergoline Inspiration 550 and Ergoline Planet Fitness 42/4, even if only one is shown. 2/98...
Table of Contents Table of Contents What certain words and signs mean (Glossary) ......6 Definitions ..................6 Warning signs ................. 7 Symbols on the device ..............9 What this device is ..............11 Guidelines ..................11 Export .................... 11 Scope of delivery ................
Page 4
Table of Contents Vibra Shape (vibration plate) ............39 Foreseeable misuse ..............40 Obligations of the studio operator..........40 Staff training .................. 40 Risks of using this device ............41 Benefits of using this device ............42 How to decide to use this device ..........43 What to do before the treatment ..........
Page 5
Table of Contents 12.16.6 Cleaning or replacing lamps in the base ........72 12.16.7 Cleaning or replacing the lamps in the side section ...... 73 12.16.8 Cleaning or replacing lamps in the canopy ........73 12.16.9 Cleaning or replacing the lamps and filter panels in the shoulder tanner ..........
What certain words and signs mean (Glossary) What certain words and signs mean (Glossary) Definitions Studio operator People who provide tanning devices to users on a commercial basis. The studio operator is trained to operate and maintain the device and is responsi- ble for the orderly operation of the device as well as compliance with the maintenance intervals.
What certain words and signs mean (Glossary) Warning signs Danger notices, nonobservance will lead to death or serious injury: DANGER! Type and source of danger, e.g. 'DANGER – High volt- age!' Description of the consequences, e.g. 'You can be killed or injured by an electric shock!' Countermeasures: –...
Page 8
What certain words and signs mean (Glossary) Caution notices, nonobservance can lead to less than serious injury or damage of property. CAUTION! Unauthorized lamps! The word 'Caution' together with the warning sign points out that less than serious injury can be expected here. Countermeasures: –...
What certain words and signs mean (Glossary) Symbols on the device The following symbols are displayed on the device: Manufacturer, company address Type BF applied part Follow Operating Instructions. Where there are great differences in temperature between the transport route and the installation site the device may not be put into operation immediately after being set up.
Page 10
What certain words and signs mean (Glossary) Recyclable material. Production year, month and day Quantity Article Number/Reference Number Serial Number Unique Device Identification Healthcare Barcode Polystyrene Cardboard Mixed paper Steel Wood Permitted air pressure during transport and storage. 10/98...
What this device is What this device is Guidelines This product is in conformity with the performance standards for sunlamp products under 21 CFR 1040.20, FDA and listed with ETL to UL 482 and CAN/CSA 22.2 No. 224. Export This device is exclusively intended for use in the USA and Canada and may not be exported to other countries and operated there! The manufacturer assumes no liability whatsoever in the event of non-compliance.
What this device is Options Ergoline Inspiration 550 Hybrid Technology 1. Central exhaust air socket 2. Audio system (with Voice Guide) 3. Headphone connection 4. AUX connection 14/98...
Page 15
What this device is Ergoline Planet Fitness 42/4 Hybrid Light Technology 1. Central exhaust air socket 2. Audio system (with Voice Guide) 3. Headphone connection 4. AUX connection Exhaust option As an optional comfort feature, your device can be equipped with an exhaust duct which allows the warm air from the device to be ducted outside of the room or building.
What this device is NOTE: Always consult a licensed heating, ventilation, and air- conditioning (HVAC) Technician when considering the option to exhaust the warm air from your device. They can help you decide if an exhaust is best for you specificlocation.
What this device is Installation location This sunlamp product is suitable for tanning salons, fitness studios or similar installation locations. You may find detailed information on installation and setting up in the Installa- tion Instructions (see folder Technical Documentation). 3.8.1 Ventilation NOTICE Danger of failure!
What this device is 3.8.2 Setup location WARNING! Sudden movements and malfunctions! Crushing hazard. – The device is not suitable for operation in mobile facili-ties (ships, buses, trains). CAUTION! Danger of overheating by obstruction of the air routing! Any liability is excluded in case of damage or injury proven to be the result of the use of non-genuine spare parts.
What this device is Strong Radio Frequency (RF) emitters! Please do not install or operate the device in close proximity to strong Radio Frequency (RF) emitters such as metal detectors or electromagnetic anti-theft systems. Please inform the installation personal of any existing RF emitting systems prior to installation.
What this device is Signs and stickers on the device Signs which warn of danger areas or give important information on compo- nents are attached to the device. Ensure that the instruction signs are always clearly recognizable and easily legible. Any missing instruction signs or stick- ers must be replaced.
Page 21
What this device is 3: Standards 4: Warning sticker UV radiation (801140-..) 5: Sticker 'Follow Operating Instructions' (1014232-..) 6: Age warning label (1508746-..) The sticker is mounted on the front panel. 04/2019 1019103-00A Operating instructions – 21/98...
Page 22
What this device is 7: Air conditioning sticker (1002243-..), (option) 13435 / 0 The sticker is mounted on the air conditioning. 8: 'Remove lattice' sticker 11978 / 0 The sticker is mounted on the rear panel. 22/98...
Page 23
What this device is 9: Ballast support warning sticker (1003399-..) The sticker is mounted on the power unit support. 04/2019 1019103-00A Operating instructions – 23/98...
Page 24
What this device is 10: Controller connections sticker (843147-..) The sticker is mounted on the controller support. 11: Sticker ESD (85662-..) The sticker is mounted on several places in the device. 24/98...
Page 25
What this device is 12: USA mains connection sticker (801046-..) The sticker is mounted on the left side panel. 13: Canada warning sticker (801371-..) The sticker is mounted on the rear panel. 04/2019 1019103-00A Operating instructions – 25/98...
Page 26
GENESIS Type U and Type R HYBRID Performance 160W, GENESIS Type U and Type R HYBRID Performance 180W and Ergoline ULTRA 520W (high-pressure / facial tanner) and GENESIS Type R HYBRID 8W (low-pressure / facial tanner) lamps that are comliance with FDA`s or other recognized equivalent policy on lamp compatibility.
Page 27
What this device is 16: Lamp cover base sticker (801139-..) The sticker is mounted on the lamp cover foot end. 17: Warning sticker crushing hazard (1015567-..) 18: OEM parts sticker (801138-..) The sticker is mounted on the bottom of the bed base. 19: AQUA MIST sticker (801211-..) Not applicable for this device.
What this device is 3.10 Technical data 3.10.1 Power rating, electrical specifications and noise level JK 126 / 42-4 HT AC Power consumption rating: 11,200 W Rated frequency: 60 Hz Rated voltage: 230 V 3 phase 230 V 2 phase Rated fuses: 40 amp 3-pole 80 amp 2-pole...
Page 29
What this device is JK 126 / 42-4 HT Power consumption rating: 10,000 W Rated frequency: 60 Hz Rated voltage: 230 V 3 phase 230 V 2 phase Rated fuses: 40 amp 3-pole 60 amp 2-pole Classification: Type BF applied part lying surface (PMMA) Power supply: 4 x THHN AWG 10...
What this device is 3.10.2 Dimensions B = 56 13/16 in 1,443 mm H = 52 1/16 in 1,322 mm B - = 60 4/16 in 1,530 mm H1 = 66 11/16 in 1,694 mm B1 = 32 11/16 in 830 mm H2 = 17 2/16 in 435 mm...
Power Control Order-no. UV high pressure lamps 520 W 400 W / 320 W 12645-.. Ergoline ULTRA 520 W Filter panels Ultra Performance 862H 1004204-.. UV low pressure lamps 0.31 m 1510958-.. Genesis Type R Hybrid 8W Starter S10 (4-65 W) 10047-..
What this device is 3.10.5 Spare parts JK 126 / 42-4 HT & JK 126 / 42-4 HT AC 19083 / 0 Number Description Order-no. Partition 1013961-.. Filter 52104-.. Filter mat 1013452-.. Protective goggles 84592-.. AUX cable 1001855-.. Allen-key 83828-.. For more spare parts, contact Customer Service (see page 2).
Why you use it Why you use it Intended use This sunlamp product is intended exclusively for aesthetic tanning of the human skin, for one person at a time, at the age of 18 or above. Skin condition You may benefit from the use of this device if you tan in natural sunlight (skin types III, IV and V), ...
Who cannot use it Who cannot use it Prohibited usage 5.1.1 Tanning system/Beauty system WARNING! UV radiation Danger of skin and eye injuries or skin diseases! The following people must not use the device: People under 18 years of age ...
What you must do to avoid serious harm What you must do to avoid serious harm General DANGER – HIGH VOLTAGE! You can be killed or injured by an electric shock! Assembly and electrical connection must comply with na- tional and local regulations. –...
What you must do to avoid serious harm WARNING! Danger of ultraviolet radiation. Ultraviolet radiation - follow instructions. Failure to use protective eyewear may result in severe burns or other eye injury - if discomfort develops, discontinue use and consult a physician. –...
What you must do to avoid other harm What you must do to avoid other harm General WARNING! Infections can be transferred through skin contact. All items/equipment components, with which the user can come into contact during tanning, must be cleaned and disinfected after every tanning session: –...
What you must do to avoid other harm Foreseeable misuse The following uses of the device are explicitly prohibited: Only one person at a time may use the device. People with body weight of more than 330 lbs (150 kg) may not use the ...
Risks of using this device Risks of using this device WARNING! Danger through ultraviolet radiation! Danger of skin and eye injuries or skin diseases! This sunlamp product must not be used on individuals who have had skin cancer or have a family history of skin cancer. Persons repeatedly exposed to ultraviolet sunlamp products must be ...
Benefits of using this device Benefits of using this device This device serves the purpose of aesthetic tanning for one adult person with skin suitable for tanning. Different tanning results can be achieved in varying strength tanning devices. This is due to the different strength UV lamps and the different UV-A and UV-B proportions of the UV radiation.
How to decide to use this device How to decide to use this device This device is intended only for commercial use and not for private use. Some people are not permitted to use the device, see chapter 5. The device may not be used by people with reduced physical, sensory or mental capabilities or who have insufficient experience and/or knowledge without supervision.
What to do before the treatment What to do before the treatment Please check for any conditions that may prohibit the use of this device – see chapters 5, 6, 8, 10. Make-up in the tanning device Please do not wear make-up. Clean skin absorbs UV light better. A wide variety of materials is found in cosmetics.
How to use this device How to use this device 12.1 How to set this device up After commissioning and cleaning/disinfection, the device is ready for opera- tion. See chapter 12.5. 12.2 How to make sure the device works Before using the device, check for damage to filter panels and acrylic panels. 12.3 How to use it to treat your condition No other persons are permitted inside the cabin while the device is in...
GENESIS Type U and Type R HYBRID Performance 160W, GENESIS Type U and Type R HYBRID Performance 180W and Ergoline ULTRA 520W (high-pressure / facial tanner) and GENESIS Type R HYBRID 8W (low-pressure / facial tanner) lamps that are comliance with FDA`s or other recognized equivalent policy on lamp compatibility.
How to use this device 12.5 How to operate the device 19148 / 0 12.5.1 Control Center Not applicable for this device. 12.5.2 User settings overview Not applicable for this device. 1019103-00A 04/2019 Operating instructions – 47/98...
How to use this device 12.6.1 Navigation During the tanning session, functions may be activated or deactivated via the control panel inside the device. All of the pictograms displayed on the screen are illuminated in default mode after the device starts up. The relevant pictogram will start to flash after a device function has been selected.
How to use this device 12.6.2 Description Function Pictogram selectionl / Description / Display Information Button sequence Lamps START/STOP The tanning time continues to Switches the lamps on / run if the lamps are switched off during the tanning session off during tanning session.
How to use this device 12.8 Selection of the application Not applicable for this device. 12.9 Sun Select setting with the outer interface Not applicable for this device. 12.10 Measurement (automatic mode) Not applicable for this device. 04/2019 1019103-00A Operating instructions – 51/98...
How to use this device 12.11 Connections MP3 player and smartphone (optional) WARNING! Danger of hearing damage! Using earphones or headphones at high volume can result in permanent hearing damage. – Do not set the volume too high. CAUTION! The heat might damage your MP3 player or smartphone! –...
How to use this device 12.12 How to use NOTE: Before use the device must always be cleaned and disinfect- ed! See chapter 12.15 How to clean/disinfect. 12.12.1 How to start The device is started automatically with a timer. NOTE: See separate document 'Timer Control Module' #1008370-..
How to use this device 12.12.3 How to stop The tanning session ends automatically after the preset time has run down. The internal body cooling fan continues to run for approx. three (3) minutes to sufficiently cool the device. – To interrupt a tanning session, press and hold button START/STOP anytime during a session.
How to use this device 12.14 Safety instructions for clean- ing/disinfection and maintenance DANGER – HIGH VOLTAGE! You can be killed or injured by an electric shock! During maintenance and service work there is a risk of touching live parts and receiving a fatal electric shock. –...
Page 56
How to use this device WARNING! Injuries and damage due to improper maintenance! If the maintenance intervals for the UV lamps are exceeded or incompatible UV lamps are installed, the share of harmful UV radiation may increase. Sunburn and other skin damage may result.
Page 57
How to use this device Acrylic panel NOTICE Cosmetics may cause cracks to form on the surface! Over the long-term cosmetics or sunscreens cause damage (e.g. crack for- mation on the surface). – Ensure that cosmetics and sunscreens are removed before tanning. The acrylic panels for the tanning devices are produced of acrylic glass de- veloped especially for this application.
How to use this device 12.15 How to clean/disinfect WARNING! Infections can be transferred through skin contact. All items/equipment components, with which the user can come into contact during tanning, must be cleaned and disinfected after every tanning session: – Protective goggles –...
How to use this device 12.15.1 Cleaning and disinfection of surfaces Acrylic panel NOTICE Do not rub with a dry cloth – danger of scratching! – Failure to observe this voids all warranty claims. Acrylic panels (3) & (7) referenced in section 12.15.2 'Clean- ing/disinfection plan' These panels are not in direct contact with the user, however they can become soiled if the user inadvertently touches them.
How to use this device 12.15.2 Cleaning/disinfection plan 19152 / 0 Component Interval Activity See page Acrylic panel Cleaning and disinfection Air nozzles Cleaning and disinfection Display unit Cleaning and disinfection Handle Cleaning and disinfection Protective goggles Cleaning and disinfection AUX cable Cleaning and disinfection 3, 7...
How to use this device 12.16 How to maintain 12.16.1 Technical modifications The device has been constructed in accordance with current safety regula- tions. The illustrations and specifications on these instructions are subject to technical modifications which are required in order to improve the device. Unauthorized modifications and changes to the device and its control unit are prohibited.
Page 62
How to use this device Maintenance performed by the studio operator or a JK Factory Certified Technician 19153 / 0 Component Interval Activity page Facial tanner, Replace UV high pressure lamps Facial tanner, Replace low pressure lamps Starter, canopy Replace (facial tanner UV low pressure lamps) Partition...
How to use this device Maintenance performed by authorized, trained and qualified staff WARNING! Danger to persons from maintenance work that has not been carried out! If maintenance work is not carried out, it can lead to material damage or personal injuries! –...
Page 64
How to use this device The service kit is fitted on the inside of the front panel. – Opening the bed base: see page 67. – Remove service kit from support. – Use the cushion as scratch prevention when opening the canopy panel. Lift up the acrylic panel and remove the partition –...
Page 65
How to use this device – Raise the partition with the suction cup. – Remove the partition. The assembly is the same process in reverse order. When assembling the device please note: – Clean the partition. – Hold the partition with a cloth in order to prevent finger prints. Remove the canopy panel –...
Page 66
How to use this device The canopy panel must be completely removed from the device in order to replace the lower, long low pressure lamps. – Undo the cable tie and unplug the connector. – Remove the canopy panel with the aid of a helper. When assembling the device please note: –...
Page 67
How to use this device Open the bed base – Raise the acrylic panel and grasp the recessed grip. – Lift up the bed base. The assembly is the same process in reverse order. WARNING! Crushing hazard when closing the bed base! Fingers can be jammed.
How to use this device 12.16.4 Instructions for replacing the lamps WARNING! Danger of burns from hot lamps and device parts! If the tanning device was operated before being switched off and opened, lamps and housing parts may be hot. –...
Page 69
How to use this device Low pressure lamps WARNING! Danger of burns from hot lamps and device parts! If the tanning device was operated before being switched off and opened, lamps and housing parts may be hot. – Before replacing lamps or other spare parts, wait until lamps and metal parts of the device have cooled down sufficiently.
Page 70
How to use this device WARNING! Danger of burns from hot lamps and device parts! If the tanning device was operated before being switched off and opened, lamps and housing parts may be hot. – Before replacing lamps or other spare parts, wait until lamps and metal parts of the device have cooled down sufficiently.
Page 71
How to use this device High pressure lamps and filter panels WARNING! Danger of burns from hot lamps and device parts! If the tanning device was operated before being switched off and opened, lamps and housing parts may be hot. –...
How to use this device – Only touch new lamps in the handling zone. – Test the safety switch to ensure that it works. The safety switch ensures that the device switches off in the event of a faulty filter panel or when a filter panel is missing. –...
How to use this device The assembly is the same process in reverse order. When assembling the device please note: – Clean the partition. – Hold the partition with a cloth in order to prevent finger prints. 12.16.7 Cleaning or replacing the lamps in the side section Not applicable for this device.
How to use this device – Remove the two upper low pressure lamps in the canopy so that you can then access the facial tanner's low pressure lamp starter. Replacing lamps: see page 69. Replacing starters: see page 70. UV high pressure lamps and filter panels: see page 71. When assembling the device please note: –...
How to use this device – Remove the cover. Replacing lamps: see page 69. Replacing starters: see page 70. The assembly is the same process in reverse order. 12.16.11 Cleaning or replacing the canopy accent lighting * Contact the customer service if the accent lighting in the canopy fails. 12.16.12 Cleaning or replacing the front panel accent lighting...
How to use this device – Remove the filters. – Clean the filters wet or dry. Dry cleaning: Vacuum cleaner (depending on the degree of soiling) Wet cleaning: Use water and detergent or put in a dish-washer NOTICE! The device may be damaged by moisture! The cleaned filters must be dry before they are replaced.
How to use this device – Dry or moist clean the filter mat or replace with new ones. Dry cleaning: Vacuum cleaner (depending on the degree of soiling) Moist cleaning: Water and detergent – Do not clean in the dish-washer! NOTICE! The device may be damaged by moisture! The cleaned filter must be dry before they are replaced.
Page 78
How to use this device – Bring the condensation tank forwards. – Disconnect the hose on the condensation tank. – Empty the condensation tank. – Remove the cover. – Remove the filter from the holder. – Clean the filter moist or dry: Dry cleaning: Vacuum cleaner (depending on the degree of soiling) Moist cleaning: Water and detergent –...
Page 79
How to use this device – Clean the filters wet or dry. Dry cleaning: Vacuum cleaner (depending on the degree of soiling) Wet cleaning: Use water and detergent or put in a dish-washer – Use a fin comb to clean the air conditioning's dirty cooling fins. NOTICE! The device may be damaged by moisture! The cleaned filters must be dry before they are replaced.
How to use this device – Connect the condensation tank to the hose. – Replace the condensation tank. – Close the bed base. 12.16.17 AQUA / AROMA SYSTEM maintenance Not applicable for this device. 12.17 How to store the device 12.17.1 Decommissioning The device must be disconnected from the power supply in order to tempo-...
Page 81
How to use this device Packaging All packaging consists of 100 % recyclable materials. Disposal of old devices The device has been manufactured using recyclable materials. The JK Corpo- rate Group will provide you with information on the content or potential haz- ards of the materials used.
What to do when things go wrong What to do when things go wrong WARNING! Failure to use protective eyewear may result in severe burns or other eye injury. If discomfort develops, discontinue use and consult a physician. – A person who does not tan in the sun most likely will not tan from the use of this device.
What to do when things go wrong NOTE: Occasionally, persons using the tanning device will experi- ence a slight reddening of the skin – usually in small patches – after the second or third session. This redness is often accompanied by an itching sensation. This may be nothing more than a very limited heat 'rash' caused by heat from the lamps within the device.
How we studied this device How we studied this device The system is built to the state of the art and the applicable safety regulations. We reserve the right to make technical changes which are necessary to im- prove the system or a system component even if they deviate from pictures and information in these instructions.
Appendix Appendix 16.1 JK 126 / 42-4 HT & JK 126 / 42-4 HT AC: EMC information 16.1.1 Table 201: Guidelines and manufacturer's declaration – Electromagnetic emissions The tanning system has been designed for use in the electromagnetic envi- ronment specified below. The device operator must ensure that it is used in such an environment.
Appendix 16.1.2 Table 202: Guidelines and manufacturer's declaration – Electromagnetic interference The tanning system has been designed for use in the electromagnetic environment specified below. The device operator must ensure that it is used in such an environment. Interference IEC 60601 - Defined Electromagnetic immunity tests...
Appendix 16.1.3 Table 204: Guidelines and manufacturer's declaration – Electromagnetic interference The tanning system has been designed for use in the electromagnetic envi- ronment specified below. The device operator must ensure that it is used in such an environment. Interference IEC 60601 - Defined Electromagnetic environment –...
Appendix 16.1.4 Table 206: Recommended safe distances between portable and mobile HF communi- cations equipment and JK 126 / 42-4 HT & JK 126 / 42-4 HT AC JK 126 / 42-4 HT & JK 126 / 42-4 HT AC has been designed for use in an electromagnetic environment in which the radiated HF interference is con- trolled.
JK-Products, Inc. – Limited Warranty JK-Products, Inc. – Limited Warranty JK-Products, Inc. warrants its products to be free from defects in materials and workmanship under intended normal use as described in the unit's Oper- ation and Instruction Manual, for a period of three (3) years from date of sale. This Limited Warranty applies only to the original purchaser of the equipment through JK-Products, Inc.
JK-Products, Inc. – Limited Warranty 17.1 Limited Acrylic Warranty JK Products, Inc. warrants its acrylic sheets to be free from defects in material and workmanship, under intended normal use, for a period of one (1) year from date of sale of the tanning bed or 1,200 hours of operation whichever comes first.
JK-Products, Inc. – Limited Warranty 17.2 Warranty Claims 17.2.1 Policy & Procedures 1. When to file a Warranty Claim: In the event that your tanning system is not functioning properly under intend- ed normal use as described in the unit's Operation and Instruction Manual, you may then have established cause to file a Warranty Claim.
JK-Products, Inc. – Limited Warranty You must comply to the instructions and warnings under chapter: 4.1 Intended use 5.1 Prohibited usage 6.1 What you must do to avoid serious harm Any other use shall be considered improper. The manufacturer cannot be held liable for damage or injuries resulting from misuse.
Page 94
JK-Products, Inc. – Limited Warranty There are no warranties which extend beyond the description on the face hereof. There is no express or implied warranty of fitness or merchantability. The remedies provided in this limited warranty are the exclusive remedies provided to the purchaser by Global Service USA and are provided in substi- tution of all other remedies.
