YESTERDAY
TODAY
20280 Cab for Bobcat MT100
PARTS LIST – ASSEMBLY INSTRUCTIONS
IMPORTANT!
READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE
THE RIGHT SIDE OF THE CAB IS DETERMINED FROM THE OPERATOR'S
POSITION
CAUTION!
REMOVE THE VINYL COVER FOR TRANSPORT IN AN OPEN TRUCK OR
TRAILER
202801224
1
Advertisement
Related Manuals for Original Tractor Cabs 20280
Summary of Contents for Original Tractor Cabs 20280
- Page 1 YESTERDAY TODAY 20280 Cab for Bobcat MT100 PARTS LIST – ASSEMBLY INSTRUCTIONS IMPORTANT! READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE THE RIGHT SIDE OF THE CAB IS DETERMINED FROM THE OPERATOR’S POSITION CAUTION! REMOVE THE VINYL COVER FOR TRANSPORT IN AN OPEN TRUCK OR...
- Page 2 WARNING 1. This cab is designed to provide foul weather protection only. It does not provide protection from noise, exhaust fumes, chemicals or injury from collision, rollover or other accidents. 2. Do not operate machine in confined areas without proper ventilation. 3.
- Page 3 LIMITED WARRANTY SNOW REMOVAL EQUIPMENT CABS COVERED BY WARRANTY ORIGINAL TRACTOR CAB CO., INC., (the "Company") warrants to the owner that each new product listed below is merchantable and free of defects in workmanship and material. During the warranty period, the dealer from whom the product was bought, or the Company, will provide, free of charge, parts and the shipping costs of parts necessary to correct any defect in workmanship and material.
- Page 4 Carton Contents: Cab #20280 for Bobcat MT100 PART # KEY # DESCRIPTION 20281 RH Rear Receiver 20282 LH Rear Receiver 20283 Front Receiver 20284 Lower Rear Post 20285 RH Side Post 20286 LH Side Post 20287 RH Curved Front Bow...
- Page 5 Use the Figure below to identify the steel parts...
- Page 6 Use the Figure below to identify the hardware ¼” x 3/4” ¼” Nylock ¼” x 1-1/4” Bolt Bolt 1/2”-13 x 1-1/2” Bolt 1/2” ¼” x 1” Lockwasher Bolt Weight Plate Spacer...
- Page 7 Step 1; See Figure 1 and 1A: Step 2; See Figure 2 and 2A: Install RH & LH Rear Receiver (1&2) Install the Front Receiver (3) A. Place the LH Rear Receiver over the A. Remove the two bolts shown in holes shown in Figure 1, Reference A.
- Page 8 Step 3; See Figure 3 and 3A: Step 4; See Figure 4, 4A and 4B: Install the Lower Rear Posts (4) Install the RH & LH Side Posts (5&6) and Upper Rear Posts (11) A. Insert a 1/4”-20 x 1-1/4” bolt through the hole in the Lower Rear Post, add a A.
- Page 9 Step 5; See Figure 5 and 5A: Install the RH & LH Curved Front Bow (7&8) and the Lower Front Crossbar (9) A. Insert a 1/4”-20 x 1” bolt through the lower front crossbar, the tab on the LH Side Post then the LH Curved Front Bow as shown in Figure 5.
- Page 10 Step 6; See Figure 6, 6A, 6B and 6C: Install the Curved Bow Extensions (12) and the Top Crossbars (13) A. Insert a 1/4”-20 x 1” bolt through one end of a Top Crossbar, the Upper Rear post then a curved bow extension as shown in Figure 6.
- Page 11 Step 7; See Figure 7: Install the Upper Front Crossbar (10) A. Place two 1/4”-20 x 3/4” bolts through the holes in the Upper Front Crossbar then in the tabs on the Curved Front Bows. B. Add nylock nuts but do not fully tighten.
- Page 12 Step 9; See Figure 9, 9A, 9B, 9C, 9D, 9E, 9F and 9G: Install the RH & LH Lower Skirt (15+16) A. Feed the bottom on the RH Side Skirt behind the RH Rear Receiver and attach the velcro as shown in Figure 9. B.
- Page 13 Figure 9F Figure 9D Figure 9G Figure 9E...
- Page 14 Step 10; See Figure 10, 10A, 10B, 10C and 10D: Install the Foam Pad Package and the Cab Shell (14) A. Install the Foam Padding onto the frame as shown in Figure 10. B. Place the Cab Shell over the frame then connect the velcro flap around the Crossbar as shown in Figure 10A.
- Page 15 For Replacement Parts and Accessories Contact: Original Tractor Cab Co., Inc. P.O. Box 97 6849 W. Front St. Arlington, IN 46104 Phone 765-663-2214 765-663-2101 Email Sales@originalcab.com Visit us on the web to see our other products. www.originalcab.com Cabs for Lawn Tractors, Garden Tractors, Compact Tractors, Snow Blowers, Sunshades for Tractors, Mowers, &...
