Summary of Contents for Original Tractor Cabs CAB 12152
Page 1
YESTERDAY TODAY CAB #12152 for LS MT122 / 125 - New Holland Workmaster 25S PARTS LIST – ASSEMBLY INSTRUCTIONS IMPORTANT ! READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE CAUTION ! REMOVE THE VINYL PANELS FOR TRANSPORT IN AN OPEN TRUCK OR TRAILER WARNING THIS CAB WILL NOT PROTECT OPERATOR FROM INJURIES CAUSED BY ROLLOVER, COLLISION, OR OTHER ACCIDENTS...
WARNING This cab is designed to provide foul weather protection only. It does not provide protection from noise, exhaust fumes, chemicals or injury from collision, or other accidents. 1. Do not operate machine in confined areas without proper ventilation. 2. Thoroughly check area of operation before using machine. 3.
Page 3
LIMITED WARRANTY SNOW REMOVAL EQUIPMENT CABS COVERED BY WARRANTY ORIGINAL TRACTOR CAB CO., INC., (the "Company") warrants to the owner that each new product listed below is merchantable and free of defects in workmanship and material. During the warranty period, the dealer from whom the product was bought, or the Company, will provide, free of charge, parts and the shipping costs of parts necessary to correct any defect in workmanship and material.
Page 4
Carton Contents Cab #12152 for LS MT 122/125 - New Holland Workmaster 25s PART # KEY # QTY DESCRIPTION 12153 Foot, RH 12154 Foot, LH 12155 Foot Brace 10926 Front Post 10010 Front Cross Bar 10002 Top Frame Brace, RH 10003 Top Frame Brace, LH 12157...
Page 5
Assembled Frame Tools Required: Ratchet 7/16”, 1/2" Sockets 7/16”, 1/ 2” Wrenches 10mm, 13mm Socket & Wrench Needle Nose Pliers 3/32” Allen Wrenches Do not tighten bolts during assembly unless instructed to do so.
Page 6
Figure 1 Step 1; See Figure 1: Remove the handles from fenders. A. Remove the nuts from the studs that attach the handles to the fenders. Remove the handles. 1/4” x 1 1/4” fender washers B. Insert two M6 x 30 mm bolts with down through the holes.
Page 7
Figure 2 Step 2; See Figure 2: Install the right & left Foot (1 & 2) and Foot Braces (3). A. Pull the floor matt back out of the way and remove the bolts at Reference A. 9/16” x 1 1/4” B.
Page 8
Figure 3 Step 3; See Figure 3: Install Front Posts (4). 1/4” x 3/4” bolt A. Insert a outwards through the Foot Brace, the lower hole in the foot and 1/4” locknut the lower hole in the post. Add a do not tighten at this time.
Page 9
Figure 4 Step 4; See Figure 4: Install Top Frame Braces (6 & 7) and Front Panel Cross Bar (5). Note: If you are installing the Note: Bent ends of Top Frame optional safety glass windshield Braces will point rearwards and lay omit Top Frame Braces.
Page 10
Figure 5 Step 5; See Figure 5: Install right and left Rear Post Brackets (8 & 7/8” x 1/4” Spacers A. Remove the bolts at reference B. Place two over the holes. Place the right Rear Bracket over the spacers and holes. B.
Page 11
Figure 6 Step 6; See Figure 6: Install right and left Rear Posts (10 & 11). NOTE: When Rear posts are properly installed, latch plates will be to the front with the notch to the outside of the enclosure. 1/4” x 5/8” bolt A.
Page 12
Figure 7 Step 7; See Figure 7: Install right and left ROPS Brackets (12 & 13). A. Place the ROPS Bracket onto the inside of the right ROPS Bar. square “U” Bolts 5/16” lock B. Use two to attach the bracket to the ROPS. Add four nuts.
Page 13
Figure 8 Step 8; See Figure 8: NOTE: The front of the Top Frame has the “L” tabs located closest to the corners. Install the Top Frame (14). A. Place the top frame onto the bent ends of the Posts, ROPS Bracket and Top Frame Braces.
Page 14
Figure 9 Step 9; See Figure 9: Install the Doors for frame / door alignment. A. Follow the instructions in the Door Hardware Package to install the Door Bottoms and the Door Latches. B. Install, close and latch both Doors. C.
Page 15
10 A 10 B Step 10; See Figure 10 A, B, & C: Install Windshield (15) and Front Panel Vinyl (16). NOTE: If you are installing the optional glass windshield refer to the instructions ® for attaching the Velcro strip to the Front Panel Vinyl.
Page 16
11 B 11 A Step 11; See Figures 11 A & B: Install Rear Curtain (17). ® A. Place the Rear Curtain between the cab frame and ROPS. Close the Velcro flaps around the Top Frame at the back and sides. B.
Page 17
Figure 12 Step 12; See Figure 12: Install Doors and Top (22). A. Make sure that the rod sewn into the windshield is lying over the top frame. (Plastic Windshield only) Place the top over the top frame. 1/4” flat washers B.
Page 18
12167 Hardware Package (Contents Listed Below) 1/4”-20 x 5/8” Bolt 1/4”-20 x 3/4” Bolt 1/4”-20 Locknut 1/4” Flat Washer 1514 1/4” x 1 1/4” Fender Washer 4556 5/16”-18 x 2 1/2” x 3” Square “U” Bolt 60487 5/16” X 1 1/2” Fender Washer 4557 5/16”...
Page 20
Optional Cab Accessories: #10120 Safety Glass Windshield #10122 Electric Wiper # 9855 Flashing Amber Caution Light #11133 Rear View Mirror, R or L Mount #12142 Front LED Work Light Kit #12143 Rear LED Work Light Kit The Cab warranty also covers the accessories. For Replacement Parts and Accessories Contact: Original Tractor Cab Co., Inc.
Page 21
Right hand steel parts are marked with a GOLD colored...
