Kit # 60534 Door Kit for John Deere Gator XUV 835M
and 865M
PARTS LIST – ASSEMBLY INSTRUCTIONS
IMPORTANT!
READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE
CAUTION!
REMOVE THE VINYL PANELS FOR TRANSPORT IN AN OPEN TRUCK OR
TRAILER
WARNING
THIS CAB WILL NOT PROTECT OPERATOR FROM INJURIES CAUSED BY ROLLOVER,
COLLISION, OR OTHER ACCIDENTS
605341123
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 60534 and is the answer not in the manual?

Questions and answers

Related Manuals for Original Tractor Cabs 60534

Summary of Contents for Original Tractor Cabs 60534

  • Page 1 YESTERDAY TODAY Kit # 60534 Door Kit for John Deere Gator XUV 835M and 865M PARTS LIST – ASSEMBLY INSTRUCTIONS IMPORTANT! READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE CAUTION! REMOVE THE VINYL PANELS FOR TRANSPORT IN AN OPEN TRUCK OR...
  • Page 2 LIMITED WARRANTY SNOW REMOVAL EQUIPMENT CABS COVERED BY WARRANTY ORIGINAL TRACTOR CAB CO., INC., (the "Company") warrants to the owner that each new product listed below is merchantable and free of defects in workmanship and material. During the warranty period, the dealer from whom the product was bought, or the Company, will provide, free of charge, parts and the shipping costs of parts necessary to correct any defect in workmanship and material.

  • Page 3: Maintenance Instructions

    WARNING This cab is designed to provide foul weather protection only. It does not provide protection from noise, exhaust fumes, chemicals or injury from roll-over, collision, or other accidents. 1. Do not operate machine in confined areas without proper ventilation. 2.
  • Page 4 Carton Contents Kit #60534 for John Deere Gator XUV 835M and 865M Key # Part # Qty. Description 60519 Latch Plate, RH 60537 Latch Plate, LH 60517 Lower Hinge Plate, RH 60518 Lower Hinge Plate, LH 60515 Upper Hinge Plate, RH...
  • Page 5 3/8” Flat ¼” Nylock Washer #10 Flat Spacer Washer 5/16” Flat ¼” Thick 5/8” ¼” Washer Fender Flat Fender Washer Washer Washer ¼”-20 x 5/8” Bolt #10-32 x 1” M6 x 1.0 x #6-32 x 1- ¼” Flat Screw 1/2” Screw 30mm Bolt ¼”-20 x Washer...
  • Page 6 Step 1; See Figure 1: Use the parts list and Figure 1 to identify the steel parts.
  • Page 7 Step 1: See Figure 1 and 1A Install Latch Plate RH(1) and Latch Plate LH(2) A. Locate the bolt holes in the rollbar post shown at Reference A in Figure 1 B. Using two M8 x 16mm bolts, attach the Latch plate to the post. Fully tighten the bolts.
  • Page 8 Step 2; See Figure 2, 2A, 2B and 2C: Install Lower Hinge Plate RH(3), LH(4), Hinge Wrap RH(17) and LH(18) A. Using a T40 bit, remove the two bolts at Reference B in Figure 2. B. Place two M6 x 30mm bolts through two ¼”...
  • Page 9 Step 3; See Figure 3 and 3A: Install Upper Hinge Plate RH(5) and LH(6) A. Place two ¾” bolts through the holes in the Upper Hinge Plate then through the two holes in the Hinge Wrap. B. Feed the bolts through the holes at Reference C in Figure 3 then place a ¼”...
  • Page 10 Step 4; See Figure 4, 4A, 4B, 4C and Attach Door Retractor(7) onto Door Retractor Bracket(8) A. Open the cover on the Door Retractor as shown in Figure 4 B. Using a Phillips screwdriver, remove the door buffer as shown in Figure 4A. C.
  • Page 11 Step 5; See Figure 5 and 5A Step 6; See Figure 6 and 6A: Install Door Retractor(7) and Door Assemble Upper Doors(9+10) and Door Retractor Bracket(8) Bottoms(11+12) A. Place two ¾” bolts through the Door A. Locate the two holes at the front of the cab shown in Figure 5.
  • Page 12 Step 7; See Figure 7 and 7A: Install Door Latch RH(23) and Door Latch LH(24) onto Doors A. Place four #10 Flat Washers onto #10-32 x 1” Screws then install them in the four slots on the Door. B. Place a ¼” Nylon Spacer onto each bolt, then add the Door Latch as shown in Figure 7A.
  • Page 13 Step 8; See Figure 8, 8A and 8B Install Doors A. Install the Door by sliding the top hinge rod up into the Upper Hinge Plate then lower the door so the lower hinge rods drop down into the Lower Hinge Plate.
  • Page 14 Step 9; see Figure 9, 9A, 9B and 9C Install Hook Velcro Straps(21) A. Locate the hole toward the front of the cab shown in Figure 9. B. Take a ¾” bolt, add a 5/16” Flat washer then a Hook Velcro Strap. C.
  • Page 15 Step 10; See Figure 10 and 10A: Step 11; See Figure 11 and 11A: Install Loop Velcro Straps(22) Attach Door Handle(25) to Door Skin(19 +20) A. Take a ¾” bolt then add a 5/16” Flat Washer and a Loop Velcro Strap then A.
  • Page 16 Step 12; See Figure 12, 12A and 12B: Attach Door Skin(19 +20) to Door Frame A. Lay the Door Skin flat then place the Door Frame on top of it as shown in Figure 12. B. Put the threaded end of the handle through the door latch then add a 3/8”...
  • Page 17 Step 13; See Figure 13, 13A, 13B and Reinstall Door and Attach Velcro A. Reinstall the Door into the Hinge Plates. B. Attach the Velcro flap from the Hinge Wrap to the outside of the Door Skin. C. Attach the Velcro flap from the Hinge Wrap to the inside of the Door Skin.
  • Page 18 Step 14; See Figure 14: Attach Door Retractor(7) to Door Frame A. Remove the Nylock Nut and ¼” Flat Washer from the tab at the front of the door that was left loose in Step 14A. B. Place the loop from the Door Retractor onto the bolt then replace the ¼”...
  • Page 19 For Replacement Parts and Accessories Contact: Original Tractor Cab Co., Inc. P.O. Box 97 6849 W. Front St. Arlington, IN 46104 Phone 765-663-2214 765-663-2101 Email Sales@originalcab.com Visit us on the web to see our other products. www.originalcab.com Cabs for Lawn Tractors, Garden Tractors, Compact Tractors, Snow Blowers, Utility Vehicles Sunshades for Tractors, Mowers, &...
