HARD TOP SUNSHADE #4421381White / #4421380 Black
FOR:
Dixie Chopper with 2 Post ROPS
ASSEMBLY INSTRUCTIONS - PARTS LIST
! IMPORTANT !
READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE
! WARNING !
THIS CANOPY WILL NOT PROTECT THE OPERATOR FROM INJURIES CAUSED BY ROLLOVER,
COLLISION, OR OTHER ACCIDENTS
30515817
1
Advertisement
Table of Contents
Related Manuals for Original Tractor Cabs 4421381
Summary of Contents for Original Tractor Cabs 4421381
- Page 1 HARD TOP SUNSHADE #4421381White / #4421380 Black FOR: Dixie Chopper with 2 Post ROPS ASSEMBLY INSTRUCTIONS - PARTS LIST ! IMPORTANT ! READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE ! WARNING ! THIS CANOPY WILL NOT PROTECT THE OPERATOR FROM INJURIES CAUSED BY ROLLOVER, COLLISION, OR OTHER ACCIDENTS 30515817...
- Page 2 Carton Contents for Hard Top Canopy PART # KEY # QTY. DESCRIPTION 30516 Bracket 30504 Frame Brace tube 1/2” 30446 Brace tube 3/4” 30445 30517 Clamp Plastic Top #11729 White, or #10000 Black 30518 Hardware Package (Contents Listed Below) 1/4”-20 x 2 3/4” Cap Screw 5144 1/4”-20 x 3”...
- Page 3 Step 2; See Figure 2: Assemble Bracket (1) and Frame (2). Assemble the Bracket to the Rear Frame with 3/8” x 1” bolts with 3/8” flat washers over each slot. Add 3/8” lock nuts. Run the nuts most of the way down but do not tighten at this time to allow for later adjustment.
- Page 4 Step 4; See Figure 4: Insert the front half of the frame into the rear half. Figure 4 Step 5; See Figure 5: Install Top. A. Lay the Plastic Top on the Frame. Place 1/4” washers over two 1/4” x 5/8” bolts. Insert them inward through the rear holes in the top.
- Page 5 Step 6; See Figure 6: Install the Braces and Clamps. A. Turn the 5/16” x 1/2” bolts out of the weld nuts on the large Brace Tube a few turns. Insert the small Brace Tubes into the Large Brace Tubes. Place the bolt holes in the small tubes over the 1/4” x 1”...
- Page 6 Original Tractor Cab Co., Inc. P.O. Box 97 6849 W. Front St. Arlington, IN 46104 Phone 765-663-2214 Fax 765-663-2101 Email Sales@originalcab.com LIMITED WARRANTY COVERED BY WARRANTY ORIGINAL TRACTOR CAB CO., INC., (the "Company") warrants to the owner that each new product listed below is merchantable and free of defects in workmanship and material.
