YESTERDAY
TODAY
#30555 Canopy Kit for TS, TX, TE John Deere Gators
PARTS LIST – ASSEMBLY INSTRUCTIONS
IMPORTANT!
READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE
CAUTION!
REMOVE THE VINYL PANELS FOR TRANSPORT IN AN OPEN TRUCK OR
TRAILER
WARNING
THIS CAB WILL NOT PROTECT OPERATOR FROM INJURIES CAUSED BY ROLLOVER,
COLLISION, OR OTHER ACCIDENTS
Go to our YouTube Channel and watch the Installation Video.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 30555 and is the answer not in the manual?

Questions and answers

Related Manuals for Original Tractor Cabs 30555

Summary of Contents for Original Tractor Cabs 30555

  • Page 1 YESTERDAY TODAY #30555 Canopy Kit for TS, TX, TE John Deere Gators PARTS LIST – ASSEMBLY INSTRUCTIONS IMPORTANT! READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE CAUTION! REMOVE THE VINYL PANELS FOR TRANSPORT IN AN OPEN TRUCK OR TRAILER...
  • Page 2 LIMITED WARRANTY SNOW REMOVAL EQUIPMENT CABS COVERED BY WARRANTY ORIGINAL TRACTOR CAB CO., INC., (the "Company") warrants to the owner that each new product listed below is merchantable and free of defects in workmanship and material. During the warranty period, the dealer from whom the product was bought, or the Company, will provide, free of charge, parts and the shipping costs of parts necessary to correct any defect in workmanship and material.

  • Page 3: Maintenance Instructions

    WARNING This cab is designed to provide foul weather protection only. It does not provide protection from noise, exhaust fumes, chemicals or injury from roll-over, collision, or other accidents. 1. Do not operate machine in confined areas without proper ventilation. 2.
  • Page 4 Carton Contents: 30555 Canopy for John Deere Gator KEY# PART# QTY. DESCRIPTION 30558 Front Support / Windshield Frame Right 30593 Front Support / Windshield Frame Left 30559 Right Post 30560 Left Post 30561 Rear Curtain Support 30569 Rear Screen Panel...
  • Page 5 Figure 1 Step 1; See Figure 1 Removing the front hood. 1. Grab the hood from underneath the headlights and pull toward the front until the clips release. 2. Pull up and toward the front to remove the hood.
  • Page 6 Figure 2 Figure 3 Step 2; See Figure 2 & 3 Bolt Removal 1. Under the fender wells there are 3 bolts on each side. Using a 13MM socket, loosen the bolt closest to the front on each side, (Bolt #1 in Figure 2), but leave them in.
  • Page 7 Step 3; See Figure 4 & 5 Windshield Frame Figure 4 Figure 5 1. Assemble the front frame as shown in figures 4 and 5.
  • Page 8 Figure 6 Step 4; Figure 6 Installing Windshield Frame 1. Install the feet of the windshield frame in between the fender well and the frame, aligning the holes in the feet with the center hole in the fender. 2. Reinstall and tighten the 13MM bolts.
  • Page 9 Figure 7 Step 5; Figure 7 Installing Rear Posts 1. Wrap a vinyl patch around the back of the right handle and slide the right post on top of it with the slot facing the front of the vehicle. 2. While holding the post, insert the ¼” by 1 ½” bolt and add on the locknuts. Do not tighten at this time.
  • Page 10 Figure 8 Figure 9 Step 6; Figure 8 & 9 Installing Rear Curtain Support and Attaching Rear Curtain 1. Slide the square tubes inside of the posts with the bar hanging down as shown in Figure 6. 2. Flip the seats forward and install the curtain over the bar and attach the Velcro as shown in Figure 7.
  • Page 11 Figure 10 Step 7; Figure 10 Attaching Top 1. Set the top onto the posts. 2. Level the top by adjusting the left and right post and tighten the post bolts when the top is level. 3. Put flat washers in the eight ¼” by 5/8” bolts. Insert the bolts inwards through the top and frame, attach and tighten locknuts.
  • Page 12 For Replacement Parts and Accessories Contact: Original Tractor Cab Co., Inc. P.O. Box 97 6849 W. Front St. Arlington, IN 46104 Phone 765-663-2214 765-663-2101 Email Sales@originalcab.com Visit us on the web to see our other products. www.originalcab.com Cabs for Lawn Tractors, Garden Tractors, Compact Tractors, Snow Blowers, Utility Vehicles Sunshades for Tractors, Mowers, &...
