Original Tractor Cabs 12244 Assembly Instructions Manual

For kubota bx23s
Hide thumbs

Advertisement

Quick Links

Download this manual
YESTERDAY
TODAY
Cab # 12244 for Kubota BX23S
PARTS LIST – ASSEMBLY INSTRUCTIONS
IMPORTANT!
READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE
CAUTION!
REMOVE THE VINYL PANELS FOR TRANSPORT IN AN OPEN TRUCK OR
TRAILER
WARNING
THIS CAB WILL NOT PROTECT OPERATOR FROM INJURIES CAUSED BY ROLLOVER,
COLLISION, OR OTHER ACCIDENTS
Go to our YouTube Channel and watch the Installation Video.
122440921
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 12244 and is the answer not in the manual?

Questions and answers

Related Manuals for Original Tractor Cabs 12244

Summary of Contents for Original Tractor Cabs 12244

  • Page 1 YESTERDAY TODAY Cab # 12244 for Kubota BX23S PARTS LIST – ASSEMBLY INSTRUCTIONS IMPORTANT! READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE CAUTION! REMOVE THE VINYL PANELS FOR TRANSPORT IN AN OPEN TRUCK OR TRAILER WARNING THIS CAB WILL NOT PROTECT OPERATOR FROM INJURIES CAUSED BY ROLLOVER, COLLISION, OR OTHER ACCIDENTS Go to our YouTube Channel and watch the Installation Video.
  • Page 2 LIMITED WARRANTY SNOW REMOVAL EQUIPMENT CABS COVERED BY WARRANTY ORIGINAL TRACTOR CAB CO., INC., (the "Company") warrants to the owner that each new product listed below is merchantable and free of defects in workmanship and material. During the warranty period, the dealer from whom the product was bought, or the Company, will provide, free of charge, parts and the shipping costs of parts necessary to correct any defect in workmanship and material.

  • Page 3: Maintenance Instructions

    WARNING This cab is designed to provide foul weather protection only. It does not provide protection from noise, exhaust fumes, chemicals or injury from roll-over, collision, or other accidents. 1. Do not operate machine in confined areas without proper ventilation. 2.
  • Page 4 Carton Contents Cab #12244 for Kubota BX23S Key # Part # Qty. Description 12079 Foot, RH 12080 Foot, LH 10926 Front Post 12249 Front Panel Frame 10002 Top Frame Brace, RH 10003 Top Frame Brace, LH 12245 Rear Bracket, RH...
  • Page 5 Step 1; See Figure 1: Use the parts list and Figure 1 to identify the steel parts.
  • Page 6 Step 2; See Figure 2: Install Right Foot (1), Left Foot (2) and Front Panel Frame (4). A. Pull the floormats back from the front corners of the step plate. Place the Right Foot on the step plate as shown. B.
  • Page 7 Step 3; See Figure 3: Install Front Posts (3) and Right & Left Top Frame Braces (5 & 6) Note: If you are installing an optional Safety Glass Windshield, omit the Top Frame Braces 5 & 6. Note: Bent ends of Top Frame Braces will point rearwards and lay flat when properly installed.
  • Page 8 Step 4; See Figure 4: Install Right and Left Rear Brackets (7 & 8). A. Place the Right Rear Bracket over the holes at Reference A. Insert two 3/8” x 2 ¼” bolts out through the holes. Add a 3/8” nylock nut to the bottom bolt only, do not tighten at this time.
  • Page 9 Step 6; See Figure 6: Install Top Frame (13), Rear Posts RH & LH (9 & 10) and Vinyl Stays (12) A. Place the Top Frame onto the bent ends of the posts. B. Insert six ¼” x 5/8” bolts up through the Rear brackets, Front Posts and Top Frame Braces.
  • Page 10 Step 7; See Figure 7: Install the Doors for frame/door alignment. A. Follow the instructions in the Door Hardware Package to install the Door Bottoms and the Door Latches. B. Install, close and latch both Doors. C. Tighten all loose bolts from previous steps at this time.
  • Page 11 Step 9; See Figure 9 & 9A: Install Windshield (20) and Front Panel Vinyl (21). A. Place the Windshield and Front Panel Vinyl face up on a clean flat surface. Press the Velcro strips together. B. Lay the rod sewn into the top of the Windshield over the top frame.
  • Page 12 Step 10; See figure 10: Install Doors and Top (14). A. Reinstall doors and connect the Velcro strips on the lower door & front panel. B. Make sure that the rod sewn into the windshield is lying over the top frame. Place the top over the top frame.
  • Page 13 For Replacement Parts and Accessories Contact: Original Tractor Cab Co., Inc. P.O. Box 97 6849 W. Front St. Arlington, IN 46104 Phone 765-663-2214 765-663-2101 Email Sales@originalcab.com Visit us on the web to see our other products. www.originalcab.com Cabs for Lawn Tractors, Garden Tractors, Compact Tractors, Snow Blowers, Utility Vehicles Sunshades for Tractors, Mowers, &...
