- Page 1 #10121 HAND OPERATED WINDSHIELD WIPER PARTS LIST – ASSEMBLY INSTRUCTIONS IMPORTANT READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE 101211117...
- Page 2 CARTON CONTENTS#10121 HAND OPERATED WIPER PART# KEY# DESCRIPTION 9226 Handle Assembly Stem Washer, Steel Washer, Rubber Threaded Body Handle 12098 Adjustable Wiper Arm 14” Wiper Blade 12099 Step 1; See Figure 1: Install the Handle Assembly A. Install the Handle and Stem in the order shown.
- Page 3 NOTICE: Lift the lever on the Figure 2 underside of the arm to adjust the arm length as needed. Visit us on the web to see our other products. Cabs for Lawn Tractors, Garden Tractors, Compact Tractors, Snow Blowers, Utility Vehicles, & Fork Lifts, Sun Shades for tractors, mowers &...
