Original Tractor Cabs 11876 Assembly Instructions And Parts List

Cab for new holland boomer 20 & 25 tractors
Hide thumbs

Advertisement

Quick Links

Download this manual
CAB #11876
FOR
New Holland Boomer 20 & 25 Tractors
ASSEMBLY INSTRUCTIONS- PARTS LIST
IMPORTANT
READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE
CAUTION !
REMOVE THE VINYL PANELS FOR TRANSPORT IN AN OPEN TRUCK OR TRAILER
WARNING !
THIS CAB WILL NOT PROTECT OPERATOR FROM INJURIES CAUSED BY ROLLOVER,
COLLISION, OR OTHER ACCIDENTS
1
11876312

Advertisement

loading
Need help?

Need help?

Do you have a question about the 11876 and is the answer not in the manual?

Questions and answers

Related Manuals for Original Tractor Cabs 11876

Summary of Contents for Original Tractor Cabs 11876

  • Page 1 CAB #11876 New Holland Boomer 20 & 25 Tractors ASSEMBLY INSTRUCTIONS- PARTS LIST IMPORTANT READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE CAUTION ! REMOVE THE VINYL PANELS FOR TRANSPORT IN AN OPEN TRUCK OR TRAILER WARNING ! THIS CAB WILL NOT PROTECT OPERATOR FROM INJURIES CAUSED BY ROLLOVER,...

  • Page 2: Installation

    WARNING This cab is designed to provide foul weather protection only. It does not provide protection from noise, exhaust fumes, chemicals or injury from roll-over, collision, or other accidents. 1. Do not operate machine in confined areas without proper ventilation. 2.
  • Page 3 LIMITED WARRANTY SNOW REMOVAL EQUIPMENT CABS COVERED BY WARRANTY ORIGINAL TRACTOR CAB CO., INC., (the "Company") warrants to the owner that each new product listed below is merchantable and free of defects in workmanship and material. During the warranty period, the dealer from whom the product was bought, or the Company, will provide, free of charge, parts and the shipping costs of parts necessary to correct any defect in workmanship and material.
  • Page 4 Carton Contents: Cab #11801 for New Holland Boomer 20 & 25 PART # KEY # DESCRIPTION 11802 Foot, RH 11803 Foot, LH 10926 Front Post 10010 Front Cross Bar 10002 Top Frame Brace, RH 10003 Top Frame Brace, LH 11804 Rear Bracket, RH 11805 Rear Bracket, LH...
  • Page 5 Step 1; See Figure 1: Identify the steel parts by using Figure 1 as an example. Figure 1...
  • Page 6 Step 2; See Figure 2: Remove handle from left fender. A. Remove the nuts from the studs that attach the handle to the fender. Remove the handle. B. Insert two M8 x 20 mm bolts with fender washers down through the holes. Replace the nuts and tighten.
  • Page 7 Step 4; See Figure 4: Install Front Posts (3) A. Insert a bolt outwards through the lower hole in the foot and the post. Add a locknut do not tighten at this time. C. Insert a bolt outwards through the upper hole in the foot and the post.
  • Page 8 Step 6; See Figure 6: Install right and left Rear Brackets (7 & 8) A. Remove the bolts at reference B. Place the right Rear Bracket over the hole. B. Insert two M12 x 55mm bolts with 1/2” lock washers and flat washers down through the holes.
  • Page 9 Step 8; See Figure 8: Install ROPS Bracket (13). A. Place the ROPS Bracket clamps over the ROPS and hold it in place with the ends of the tube at the ends of the Rear Boxing Posts. B. Insert two 1/4” x 2 1/2” bolts in through the clamp holes.
  • Page 10 Step 10; See Figure 10: Install the Doors for frame / door alignment. A. Follow the instructions in the Door Hardware Package to install the Door Bottoms and the Door Latches. B. Install, close and latch both Doors. C. Tighten all bolts from previous steps at this time.
  • Page 11 Step 12; See Figure 12: Connect Windshield (15) and Front Panel Vinyl (16) A. Place the Windshield and Front Panel Vinyl face up on a clean flat surface. Press the ® Velcro together. NOTE: If you are installing the optional glass windshield refer to the instructions for attaching ®...
  • Page 12 Step 14; See Figure 14: Install Doors and Top (22). A. Make sure that the rod sewn into the windshield is lying over the top frame. (Plastic Windshield only) Place the top over the top frame. B. Place four ¼” flat washers over each of four bolts.
  • Page 13 For Replacement Parts and Accessories Contact: Original Tractor Cab Co., Inc. P.O. Box 97 6849 W. Front St. Arlington, IN 46104 Phone 765-663-2214 765-663-2101 Email Sales@originalcab.com Visit us on the web to see our other products. www.originalcab.com Cabs for Lawn Tractors, Garden Tractors, Compact Tractors, Snow Blowers, Utility Vehicles Sunshades for Tractors, Mowers, &...
