12317 Soft-top Kit
PARTS LIST – ASSEMBLY INSTRUCTIONS
IMPORTANT!
READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE
CAUTION!
REMOVE THE VINYL PANELS FOR TRANSPORT IN AN OPEN TRUCK OR
TRAILER
WARNING
THIS CAB WILL NOT PROTECT OPERATOR FROM INJURIES CAUSED BY ROLLOVER,
COLLISION, OR OTHER ACCIDENTS
123171222
1
Advertisement
Related Manuals for Original Tractor Cabs 12317
Summary of Contents for Original Tractor Cabs 12317
- Page 1 YESTERDAY TODAY 12317 Soft-top Kit PARTS LIST – ASSEMBLY INSTRUCTIONS IMPORTANT! READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE CAUTION! REMOVE THE VINYL PANELS FOR TRANSPORT IN AN OPEN TRUCK OR TRAILER WARNING THIS CAB WILL NOT PROTECT OPERATOR FROM INJURIES CAUSED BY ROLLOVER,...
- Page 2 LIMITED WARRANTY SNOW REMOVAL EQUIPMENT CABS COVERED BY WARRANTY ORIGINAL TRACTOR CAB CO., INC., (the "Company") warrants to the owner that each new product listed below is merchantable and free of defects in workmanship and material. During the warranty period, the dealer from whom the product was bought, or the Company, will provide, free of charge, parts and the shipping costs of parts necessary to correct any defect in workmanship and material.
-
Page 3: Maintenance Instructions
WARNING This cab is designed to provide foul weather protection only. It does not provide protection from noise, exhaust fumes, chemicals or injury from roll-over, collision, or other accidents. 1. Do not operate machine in confined areas without proper ventilation. 2. - Page 4 Carton Contents: 12317 Soft-top Kit Key # Part # Qty. Description 12318 Rail, Front & Rear 12319 Side Rail 12320 Top Bow 12321 Vinyl Top 12322 Hardware Package (contents listed below) ¼”-20 x 5/8” Bolt 0786 ¼”-20 x ¾” Bolt 0788 ¼”-20 Nylock Nuts...
- Page 5 Step 2; See Figure 2, 2A, 2B, 2C & 2D: Attach Front & Rear Rails (1) to Side Rails (2) Note: Make sure the slots in the Side Rails line up across from each other. A. Using four ¼” x 5/8” bolts and four nylock nuts, connect the Side Rails to the Front &...
- Page 6 Step 3; See Figure 3, 3A & 3B: Attach two Top Bows (3) onto frame A. Using four ¼” x 5/8” bolts and four ¼” nylock nuts, connect two Top Bows to the frame as shown in figure 3A. Do not install the third Top Bow yet.
- Page 7 Step 4; See figure 4, 4A, 4B, 4C & 4D: Front Rear Attach Vinyl Top (4) to frame A. Lay the Vinyl Top down on a table or on the ground with the Velcro side facing up. Place the frame on top of it as shown in Figure 4A.
- Page 8 Step 5; See Figure 5, 5A, 5B, 5C, 5D, 5E & 5F: Attach Soft-top Frame onto Cab Top Frame and Attach the last Top Bow A. Make sure the Windshield Rod is over the Top Frame as shown in Figure Note: If your cab has a Rear Curtain Rod, make sure it is also over the Top Frame.
- Page 9 Step 5 Continued D. Place the third Top Bow between the tabs at the back of the Top Frame and using two ¼” x ¾” bolts and two nylock nuts attach the Soft-top Frame and the Top Bow to the Top Frame as shown in Figures 5C &...
- Page 10 For Replacement Parts and Accessories Contact: Original Tractor Cab Co., Inc. P.O. Box 97 6849 W. Front St. Arlington, IN 46104 Phone 765-663-2214 765-663-2101 Email Sales@originalcab.com Visit us on the web to see our other products. www.originalcab.com Cabs for Lawn Tractors, Garden Tractors, Compact Tractors, Snow Blowers, Utility Vehicles Sunshades for Tractors, Mowers, &...
