CAB #12168
for Massey Ferguson GC 1723E, GC1725M
PARTS LIST – ASSEMBLY INSTRUCTIONS
IMPORTANT !
READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE
CAUTION !
REMOVE THE VINYL PANELS FOR TRANSPORT IN AN OPEN TRUCK OR TRAILER
WARNING
THIS CAB WILL NOT PROTECT OPERATOR FROM INJURIES CAUSED BY ROLLOVER,
COLLISION, OR OTHER ACCIDENTS
Go to our YouTube Channel and watch the Installation Video.
12168919
1
Advertisement
Related Manuals for Original Tractor Cabs 12168
Summary of Contents for Original Tractor Cabs 12168
- Page 1 YESTERDAY TODAY CAB #12168 for Massey Ferguson GC 1723E, GC1725M PARTS LIST – ASSEMBLY INSTRUCTIONS IMPORTANT ! READ THIS MANUAL CAREFULLY AND KEEP FOR FUTURE REFERENCE CAUTION ! REMOVE THE VINYL PANELS FOR TRANSPORT IN AN OPEN TRUCK OR TRAILER...
- Page 2 LIMITED WARRANTY SNOW REMOVAL EQUIPMENT CABS COVERED BY WARRANTY ORIGINAL TRACTOR CAB CO., INC., (the "Company") warrants to the owner that each new product listed below is merchantable and free of defects in workmanship and material. During the warranty period, the dealer from whom the product was bought, or the Company, will provide, free of charge, parts and the shipping costs of parts necessary to correct any defect in workmanship and material.
-
Page 3: Maintenance Instructions
WARNING This cab is designed to provide foul weather protection only. It does not provide protection from noise, exhaust fumes, chemicals or injury from collision, or other accidents. 1. Do not operate machine in confined areas without proper ventilation. 2. Thoroughly check area of operation before using machine. 3. - Page 4 Carton Contents Cab #12168 for Massey Ferguson GC 1723E, GC1725M PART # KEY # QTY DESCRIPTION 12169 Foot, RH 12170 Foot, LH 12171 Foot Brace 10926 Front Post 10010 Front Cross Bar 10002 Top Frame Brace, RH 10003 Top Frame Brace, LH...
- Page 5 Assembled Frame Tools Required: 7/16” Wrench & Socket 1/2" Wrench & Socket 12 mm Wrench 13 mm Wrench 19mm Socket & Ratchet Do not tighten bolts Needle Nose Pliers during assembly unless instructed to do so. 3/32” Allen Wrenches...
- Page 6 Figure 1 Step 1; See Figure 1: Reposition the loader control lever. A. From under the fender pull the bottom of the rubber boot over its retaining pins and lift the rubber boot up out of the way. B. Remove the bolt in the base of the lever and turn the lever so that it is leaning inward.
- Page 7 Figure 2 Step 2; See Figure 2: Install the right & left Foot & 2) and the Foot Brace (3). A. Remove the plastic button at Reference A. Lift the floor matt out of the way. 1/4”-20 x 3/4” Bolt 1/4”...
- Page 8 Figure 3 Step 3; See Figure 3: Install Front Posts (4). 1/4” x 5/8” bolt A. Insert a outwards through the lower hole in the foot and the lower 1/4” locknut hole in the post. Add a do not tighten at this time. 1/4”...
- Page 9 Figure 4 Step 4; See Figure 4: Install Top Frame Braces & 7) and Front Panel Cross Bar (5). Note: If you are installing the Note: Bent ends of Top Frame optional safety glass windshield Braces will point rearwards and lay omit Top Frame Braces.
- Page 10 Figure 5 Step 5; See Figure 5: Install right and left Rear Post Brackets & A. Remove the bolts at Reference B. Place the right Rear Post Bracket over the holes. B. Replace the bolts down through the holes. Do not tighten at this time. C.
- Page 11 Figure 6 Step 6; See Figure 6: Install right and left Rear Posts & 11) and Rear Curtain Support (12). NOTE: When Rear posts are properly installed, latch plates will be to the front with the notch to the outside of the enclosure. 1/4”...
- Page 12 Figure 7 Step 7; See Figure 7: Install the ROPS Bracket (13). 1/4”-20 x 2 1/2” A. Place the ROPS Bracket onto the ROPS Bar as shown. Insert two 1/4” locknuts. Bolts down through the clamp holes and add B. Do not tighten at this time.
- Page 13 Figure 8 Step 8; See Figure 8: NOTE: The front of the Top Frame has the Install the Top Frame (14). “L” tabs located closest to the corners. A. Place the top frame onto the bent ends of the Posts, ROPS Bracket and Top Frame Braces.
- Page 14 Figure 9 Step 9; See Figure 9: Install the Doors for frame / door alignment. A. Follow the instructions in the Door Hardware Package to install the Door Bottoms, Door Latches and the top two Door Hinges. B. Install, close and latch both Doors. C.
- Page 15 Step 10; See Figure 10 A, B, & C: Install Windshield (15) and Front Panel Vinyl (16). NOTE: If you are installing the optional glass windshield refer to the instructions ® for attaching the Velcro strip to the Front Panel Vinyl. A.
- Page 16 Figure 11 Step 11; See Figures 11: Install Rear Curtain (17). ® A. Place the Rear Curtain between the cab frame and ROPS. Close the Velcro flaps around the Top Frame at the back and sides. ® B. Close the Velcro flaps around the Rear Posts and Secure the ties to the Rear Curtain Support.
- Page 17 Figure 12 Step 12; See Figure 12: Install Doors and Top (22). A. Make sure that the rod sewn into the windshield is lying over the top frame. (Plastic Windshield only) Place the top over the top frame. 1/4” flat washers 1/4”...
- Page 18 12182 Hardware Package (Contents Listed Below) 1/4”-20 x 5/8” Bolt 1/4”-20 x 3/4” Bolt 1/4”-20 x 1” Bolt 9421 1/4”-20 x 2 1/2” Bolt 1/4”-20 Locknut 60217 1/4” Flat Washer 1514 5/16-18 x 1 1/2” Bolt 2187 60470 5/16-18 Locknut 5/16”...
- Page 19 Optional Cab Accessories: #10120 Safety Glass Windshield #10122 Electric Wiper # 9855 Flashing Amber Caution Light #11133 Rear View Mirror, R or L Mount #12142 Front LED Work Light Kit #12143 Rear LED Work Light Kit The Cab warranty also covers the accessories. For Replacement Parts and Accessories Contact: Original Tractor Cab Co., Inc.
