- Page 1 User Manual Dishwasher JGIN605E4...
- Page 2 VISIT OUR WEBSITE TO: Get usage advice, brochures, trouble shooter, service and repair information: www.juno.de/support CONTENTS 1. SAFETY INFORMATION...................2 2. SAFETY INSTRUCTIONS.................4 3. PRODUCT DESCRIPTION................6 4. CONTROL PANEL.................... 7 5. PROGRAMMES....................7 6. SETTINGS......................9 7. BEFORE FIRST USE..................12 8.
- Page 3 Children of less than 3 years of age should be kept away • from the appliance unless continuously supervised. Children should be supervised to ensure that they do not • play with the appliance. Keep detergents away from children. • Keep children and pets away from the appliance when the •...
- Page 4 The appliance is to be connected to the water mains using • the new supplied hose-sets. Old hose sets must not be reused. 2. SAFETY INSTRUCTIONS 2.1 Installation Make sure that there is access to the mains plug after the installation. •...
- Page 5 and aquastops, structural and interior WARNING! parts related to door assemblies, printed circuit boards, electronic displays, Dangerous voltage. pressure switches, thermostats and sensors, software and firmware including 2.4 Use reset software. Please note that some of • Do not put flammable products or items these spare parts are only available to that are wet with flammable products in, professional repairers, and that not all...
- Page 6 3. PRODUCT DESCRIPTION Upper spray arm Cutlery basket Lower spray arm Lower basket Filters Upper basket Rating plate The graphic is a general overview. Salt container For more details, refer to other chapters Air vent or documents provided with the Rinse aid dispenser appliance.
- Page 7 4. CONTROL PANEL On/off indicator Start button Programme marker Programme knob Indicators Delay button 4.1 Indicators Indicator Description Delay Start indicator. It is on when you set the delay start. Drying phase indicator. It is on when you select a programme with the drying phase. It flashes when the drying phase operates.
- Page 8 Programme Dishwasher load Degree of soil Programme phases • Prewash Crockery, cutlery, Normal, lightly dried- • Dishwashing 50 °C pots, pans • Intermediate rinse • Final rinse 60 °C • Drying • AirDry • Prewash Crockery, cutlery, Normal to heavy, •...
- Page 9 Water Energy Duration Programme 1)2) (kWh) (min) 0.015 The pressure and the temperature of the water, the variations of the mains supply, the options, the quantity of dishes and the degree of soil can change the values. The values for programmes other than ECO are indicative only. 5.2 Information for test institutes To receive the necessary information for conducting performance tests (e.g.
- Page 10 German French de‐ mmol/l mg/l (ppm) Clarke Water soften‐ degrees grees (°fH) degrees er level (°dH) 43 - 46 76 - 83 7.6 - 8.3 755 - 834 53 - 57 37 - 42 65 - 75 6.5 - 7.5 645 - 754 46 - 52 29 - 36...
- Page 11 Wh. The rinsing of the softener ends with a tablets only, you can deactivate the complete drain. notification for refilling the rinse aid. However, for best drying performance, always use rinse Each performed softener rinse (possible more aid. than one in the same cycle) may prolong the programme duration by another 5 minutes If standard detergent or multi-tablets without when it occurs at any point at the beginning...
- Page 12 How to deactivate AirDry The appliance must be in programme selection mode. Make sure that the programme marker on the knob is set to the on/off position. 1. To enter the user mode, press and hold . At the same time turn the knob counterclockwise until the programme marker indicates the first programme.
- Page 13 7.2 How to fill the salt container 7.3 How to fill the rinse aid dispenser 1. Turn the cap of the salt container counterclockwise and remove it. 2. Put 1 litre of water in the salt container (only for the first time). 3.
- Page 14 8.1 Using the detergent • The programme starts. • The indicator of the washing phase is • The on/off indicator and start indicator are on. Starting a programme with delay start 1. Set a programme. 2. Press to delay the start of the programme by 3 hours.
- Page 15 The function comes into operation: • When the programme is complete. If the door is opened for more than 30 • After 5 minutes if a programme was not seconds during the drying phase, the started. running programme ends. It does not happen if the door is opened by AirDry function.
- Page 16 • Detergent tablets do not fully dissolve with • Do not wash the following materials in the short programmes. To prevent detergent dishwasher: wood, horn, pewter, copper, residues on the tableware, we recommend aluminium, delicate ornamented porcelain that you use tablets with long and unprotected carbon steel.
- Page 17 10. CARE AND CLEANING 10.3 External cleaning WARNING! • Clean the appliance with a moist soft Before maintenance, deactivate the cloth. appliance and disconnect the mains plug • Only use neutral detergents. from the main socket. • Do not use abrasive products, abrasive cleaning pads or solvents.
- Page 18 4. Wash the filters. CAUTION! An incorrect position of the filters can cause bad washing results and damage to the appliance. 10.5 Cleaning the lower spray arm We recommend to clean the lower spray arm regularly to prevent soil from clogging the holes.
- Page 19 10.6 Cleaning the upper spray arm Do not remove the upper spray arm. If the 3. To install the spray arm back, press it openings in the spray arm are clogged, downwards. remove the remaining particles of soil with a thin pointed object, e.g.
- Page 20 Problem and alarm code Possible cause and solution • Make sure that the water tap is open. The appliance does not fill with water. • Make sure that the pressure of the water sup‐ • The indicator flashes 1 time ply is not too low.
- Page 21 Problem and alarm code Possible cause and solution • Switch the appliance off and on. Technical malfunction of the appliance. • The indicator flashes 12 times intermittently. • The light related to the start button flashes continuously. • Switch the appliance off and on. The level of water inside the appliance is too •...
- Page 22 WARNING! We do not recommend using the appliance until the problem has been completely fixed. Unplug the appliance and do not plug it in again until you are certain that it operates correctly. 11.1 The dishwashing and drying results are not satisfactory Problem Possible cause and solution •...
- Page 23 Problem Possible cause and solution • There is too much salt in the water used for washing. Traces of rust on cutlery. Refer to "The water softener". • Silver and stainless steel cutlery were placed together. Do not place silver and stainless steel items close to‐ gether.
- Page 24 Water supply min. 5 - max. 60 °C Cold water or hot water Capacity Place settings Refer to the rating plate for other values. If the hot water comes from alternative source of energy (e.g. solar panels), use the hot water supply to de‐ crease energy consumption.
- Page 28 156821260-A-162023...
