Generac Power Systems GP Series Diagnostic Repair Manual page 74

Section 6 Disassembly
ITEM
37 WASHER LOCK SPRING 3/8 ZC
38 SCREW HHC 3/8-24 X 15. 50
39 NUT FLANGE 5/16-18 NYLOK
40 REAR BEARING CARRIER MACHINED
41 VIB MNT 1.5 X 1.38 X 5/16-18
42 WASHER LOCK SPRING 5/ 16 ZC
43 SCREW IHHC M8-l.25 X 400 G8.8
44 REAR BEARING CARRIER COVER
45 SCREW HHTT #10-32 X 1-1/4 CZ
46 ASSY MUFFLER SI DE MOUNT 8 I 6CC PORT
47 HANGER EXHAUST FLEXIBLE EPDM
48 BRACKET EXHAUST HANGER RIGHT
49 PIN HITCH CLIP 5/16-3/8
50 CLEVIS PIN 3/8" X 1 1/4"
51 SCREW HHTT M4-0. 7 X 8 ZP
52 SCREEN SPARK ARRESTOR
53 RETAINER, SPARK ARREST SCREEN
54 SCREW HHFCS M6-I X 16 G8.8
55 HEAT SHIELD MANIFOLD 816CC
56 SENSOR OXYGEN SWITCH
57 BOLT U 5/16-18 X 1.92 W/SADDLE
58 PIPE FLEX EXHAUST, FL 48MM ID
59 ASSY WELDMENT EXHAUST MANIFOLD EPT
60 SCREW SHC M8-l.25 X 20 Cl2.9
61 GASKET EXHAUST PORT
62 NUT HEX FLANGE M5-0.8 LOCK NYLON
63 WELDMENT SIDE PANEL CNTRL
64 MODULE CO PORTGEN V2.5 EFI
65 SHROUD SIDE PANEL CONTROL
66 SCREW HHC M6-1.0 X 12 G8.8
67 DECAL BRANDING CP SIDE
68 BADGE CO-SENSE
69 CONN HSG 4POS DL SEALED SERIES
70 WIRE BUNDLE FUEL PUMP LEADS
71 NUT HEX LOCK M4 0.7 NY INS
68
DESCRIPTION ITEM DESCRIPTION
72 COVER CONTROL PANEL ALT WIRES
73 NUT HEX LOCK M5-0.8 NY INS ZINC
74 AUTOMATIC VOLTAGE REGULATOR
75 SCREW HHC M5-0.8 X 30 C8.8
76 AVR MOUNT BRACKET
77 NUT HEX FL WHIZ MS-1.25
78 CURVED HEAD M8- 1.25 X 50MM LNG
79 NUT HEX FLANGE WHIZ 5/16-18
80 CSA HI POT DECAL
81 DECAL SPARK ARRESTOR
82 DECAL FUEL OVERFLOW
83 DECAL WARN HOT EXHAUST
84 DECAL CO WARNING
85 DECAL CO-SENSE ACTION LABEL
86 DECAL DANGER & SAFETY
87 DECAL CLEAR POWERRUSH
88 DECAL START INSTRUCTIONS
89 TAG, OIL FILL TRILINGUAL
90 COVER, 30A 120/240V
91 DECAL GROUND
92 BACK BOX CONTROL PANEL
93 SNAP BUSHING 0.70 OPEN
94 SNAP BUSHING 0.50 OPEN
95 HOLDER FUSE
96 TRANSFORMER IDLE CURRENT
97 MX I 50L SLRRMNT 22- 18 12P W/OGA
98 CB 6A IP AUTO ETA 46-500-P
99 SCREW PPHM SEMS M4-0. 7 X 12
100 SCREW HHC M4-0.7 X 20 C8.8
101 SCREW HHC M5-0.8 X 10 C8.8
102 RELAY PNL 12VDC SPDT 30A
103 DIODE BRIDGE RECT 25A 1000V KBPC
104 CONN, PLUG HOUSING DUAL ROW 14 POS, UL
94V-0
105 CONDUIT FLEX 14.5MM ID NYLON 6
106 SNAP BUSHING.75 OPEN
Diagnostic Repair Manual
