Section 6 Disassembly
ITEM
177 KIT - WHEEL ASSEMBLY
178 KIT - FOOT BRACKETS
179 KIT - BATTERY ASSEMBLY
180 KIT - GROUNDING WIRE TO FRAME
181 FUEL GAGE
TORQUE SPECIFICATIONS
Flywheel nut
Cylinder head bolts
Valve cover bolts
Rocker arm jam nut
Ignition coil
Intake manifold
Exhaust manifold
Stator bolts
Rotor bolt
Spark plug
Starter bracket to block
Terminal block to alternator wires
PZ2 driver (not Philips)
Exhaust clamps to flex pipe
Iso mounts to frame
J-bolt to battery bracket
Oxygen sensor (OS)
TRIM TORQUE SPECIFICATIONS
M3-.5 Phillips Pan Head Screw Into Aluminum
M6-1 Taptite Screw Into Aluminum
M6-1 Taptite Screw Into Weldnut
M8-1.25 Taptite Screw Into Aluminum
70
DESCRIPTION
150 ft-lbs 203.3 Nm
22 ft-lbs 29.8 Nm
4.8-5.5 ft-lbs 6.5-7.4 Nm
14 ft-lbs 18.9 Nm
9 ft-lbs 12.2 Nm
14 ft-lbs 18.9 Nm
20 ft-lbs 27.1 Nm
6 ft-lbs 8.1 Nm
30 ft-lbs 40.7 Nm
15 ft-lbs 20.3 Nm
18 ft-lbs 24.4 Nm
1.6 ft-lbs 2.2 Nm
10-12 ft-lbs 13.6-16.3 Nm
8.75 ft-lbs 11.9 Nm
5-7 ft-lbs 6.7-9.5 Nm
13.2±1 ft-lbs 18±1.5 Nm
50 in-lbs 5.6 Nm
96 in-lbs 10.8 Nm
96 in-lbs 10.8 Nm
18 ft-lbs 24.4 Nm
