Section 6 Disassembly
ITEM
107 DECAL GROUND
108 NUT HEX FL WHIZ M6- 1.0
109 TAG, OIL FILL
110 DECAL START INSTRUCTIONS
111 DECAL CLEAR POWERRUSH
112 DECAL DANGER & SAFETY
113 DECAL CO-SENSE ACTION LABEL
114 DECAL CO WARNING
115 DECAL WARN HOT EXHAUST
116 DECAL SPARK ARRESTOR
117 DECAL FUEL OVERFLOW
118 CSA HIPOT DECAL
119 CLIP-J VINYL COAT 0.625 ID
120 DECAL BRANDING CP SIDE GP
121 BADGE CO-SENSE
122 SCREW HHC M6-1.0 X 12 G8.8
123 SHROUD SIDE PANEL CONTROL
124 MODULE CO PORTGEN V2.5 EFI
125 AXLE 19 DIA X 773.7 CLR ZINC
126 WASHER FLAT 3/4 STEEL ZINC
127 COTTER HAIRPIN 2.56 X 0.80
128 WHEEL 12" OD NEVERFLAT RUBBER
129 NUT HEX M8- 1.25 G8 CLEAR ZINC
130 WASHER FLAT 5/16-M8 STEEL ZINC
131 J - BOLT M8 - 1.25 X 2 2 5
132 BRACKET BATTERY
133 NUT HEX 1/4-20 STEEL
134 BOOT BATTERY CABLE
135 SCREW HHC 1/4-20 X 3/4 GS
136 BATTERY BCI GROUP UI
137 NUT HEX FL WHIZ M8 - 1.25
138 SCREW HHFC M8-1.25 X 16 C8.8
139 GUSSET FOOT 816 PORT
140 WELDMENT FOOT 816 PORT BLACK
141 VIB MOUNT-DONUT TYPE
60
DESCRIPTION ITEM DESCRIPTION
142 SCREW HHC M8- 1.25 X 30 C8.8
143 WASHER FLAT 0.3441 D X 1.0 OD STEEL
144 NUT HEX 5/ 16-18 STEEL
ITEM DESCRIPTION
145 EARTH STRAP 3/8X 3/8
146 SCREW HHC M8- 1.25 X 45 PC8.8
147 BRACKET ENGINE MOUNT 816CC PORT
148 NUT HEX FLANGE WHIZ 5/16-18
149 ENGINE GH8I6 EPT 49ST WO/COOLER
150 NUT HEX LOCK M6
151 ENGINE CONTROL MODULE-46 PIN EFI
152 GASKET EXHAUST PORT
153 SCREW SHC M8-l.25 X 20 Cl2.9
154 ASSY WELDMENT EXHAUST MANIFOLD EPT
155 PIPE FLEX EXHAUST, FL 48MM ID
156 SENSOR OXYGEN SWITCHING 12MM HEX
157 HEAT SHIELD MANIFOLD 816CC
158 SCREW HHFCS M6-I X 16 G8.8
159 SCREEN SPARK ARRESTOR
160 RETAINER, SPARK ARREST SCREEN
161 SCREW HHTTM4-0.7X8ZP
162 CLEVIS PIN 3/8" X 1 1/4"
163 HANGER EXHAUST FLEXIBLE EPDM
164 CABLE BATT RED
165 CABLE BATT BLACK
166 BOOT, BATTERY CABLE
167 SCREW BHFH TORX M5.5-1.59 X 15
168 ASSY GAS CAP SEALED
169 KIT - HANDLE ASSEMBLY
170 KIT - FUEL TANK ASSEMBLY
171 KIT - MUFFLER ASSY
172 KIT - ALTERNATOR ASSEMBLY
173 ASSEMBLY-ROTOR/STATOR
174 KIT - COMMON DECALS
175 CONTROL PNL ASSY
