- Page 1 Translated from German to English - www.onlinedoctranslator.com RP-700PRO o.: RP700PRO operating instructions vibrating plate www.lumag-maschinen.com...
- Page 2 IMPORTANT INSTRUCTIONS DANGER!Before assembly and before commissioning, read the entire text of the operating instructions. Use these instructions to familiarize yourself with the device, its correct use and the safety instructions. A NOTICE According to the applicable product liability law, the manufacturer of this device is not liable for damages caused to or by this device in the following cases: - improper handling,...
- Page 3 RP-700PRO 12/2 13/2 12/1 13/1...
- Page 6 13/2 13/2 12/2...
- Page 7 CONTENTS CONTENTS 1. Introduction 2. Intended use 3. Safety instructions . 1 General safety instructions . operational safety . Safety when using combustion engines . Service security . Residual risks and protective measures . Behavior in an emergency 3.7 Warning and information symbols used 4.
- Page 8 INTRODUCTION INTENDED USE 1. INTRODUCTION This manual contains information and procedures for the safe operation and maintenance of this model. For your own safety and to prevent injury, carefully read, understand, and follow the safety instructions in this manual at all times. 2.
- Page 9 SAFETY INSTRUCTIONS 3. SAFETY INSTRUCTIONS When using this vibrating plate, the following basic safety measures must be observed to protect against the risk of injury, fire and property damage. Read all of these instructions before using this appliance and keep them for future reference.
- Page 10 SAFETY INSTRUCTIONS power tool. Keep them away from your work area. 4. Store unused tools safely - When not in use, tools should be stored in a dry, high or locked place, out of the reach of children. 5. Do not overload your machine - You work better and more safely within the specified performance range.
- Page 11 SAFETY INSTRUCTIONS - However, suitable gloves and regular breaks can extend the duration of use. However, please note that personal predisposition to poor circulation and/or high grip forces when working will reduce the duration of use. 14. Check the motor device - Before further use of the power tool, protective devices or slightly damaged parts must be carefully checked to ensure that they are functioning properly and as intended.
- Page 12 SAFETY INSTRUCTIONS • ALWAYSEnsure that the side walls of trenches, pits, heaps and embankment edges are stable and do not collapse due to vibration during compaction. Be careful of the risk of falling or tipping over! • ALWAYSdemarcate the work area and keep members of the public and unauthorized personnel away.
- Page 13 SAFETY INSTRUCTIONS fatal injuries may occur. • Let the machineNOTrun indoors, in garages or enclosed areas. The engine exhaust contains poisonous carbon monoxide. Being in an atmosphere containing carbon monoxide can lead to unconsciousness and death. • Operate the deviceNOTnear an open flame. •...
- Page 14 SAFETY INSTRUCTIONS 3.5 Residual risks and protective measures Mechanical residual hazards Squeeze Careless handling of the vibrating plate can lead to serious injuries. → Be particularly careful on uneven terrain and when compacting coarse material. Make sure you have a secure footing. impact On compacted, hard or unyielding surfaces, the handles may recoil strongly.
- Page 15 SAFETY INSTRUCTIONS SYMBOLS USED Fuel is flammable. → Smoking and open fires are prohibited during work and refueling. Danger from vibration whole-body vibration Prolonged work with the vibrating plate can lead to physical impairments due to vibrations. → Take regular breaks. Other hazards Slipping, tripping or falling of persons On unstable surfaces, you may cause injury by tripping.
- Page 16 SYMBOLS USED * Keep the engine away from heat, sparks and flames. * Petrol is extremely flammable and explosive. Turn off the engine and allow it to cool before refueling. WARNING WARNING VAROVÁNÍ UWAGA COMMANDMENTS * Before commissioning, read and follow the operating instructions provided.
- Page 17 CONTROLS 4. CONTROLS vibrating plate A) Foldable guide bar B) Chassis (optionally available) C) Chassis mount (optionally available) D) Drive belt / belt guard E) Console F) Base plate G) Pathogens H) Drive motor I) Protective guard J) Suspension K) Throttle control lever L) Handle Motor ignition switch...
- Page 18 MACHINE TRANSPORT 5. MACHINE TRANSPORT WARNING Before transporting the machine or storing it indoors, allow the engine to cool down to avoid burns and the risk of fire. Furthermore, it must be ensured that persons are not endangered by the machine tipping over or slipping or by machine parts flying up or down.
- Page 19 ASSEMBLY 5.3 Storage Storing the vibrating plate for a month or longer: • Remove dirt and stones from the base plate (F). • Clean the air filter (6) or replace it if it is heavily soiled or damaged. • Clean cylinder head fins. •...
- Page 20 ASSEMBLY 6.2 Assembly - throttle cable assembly step 1 assembly step 2 Attach the throttle lever to any side of Loosen the wing screw (A) on the air filter the handlebar. housing and remove the cover. assembly step 3 assembly step 4 Loosen all screws and remove the bottom of Loosen the wing screw (B) on the air filter the air filter housing.
- Page 21 COMMISSIONING 7. COMMISSIONING DANGER Read the safety instructions carefully (see “Safety instructions”). 7.1 Recommended fuel This engine requires only regular unleaded gasoline with a research octane rating of 91 or higher. Use only fresh, clean fuel. Water or impurities in the gasoline will damage the fuel system.
- Page 22 COMMISSIONING 7.3 Starting the engine (Fig. 5 – 10) • Slide the fuel tap ( ) to the right to open it. • When cold, move the choke lever (4) to the left to “CLOSE”. • When warm, leave the choke lever (4) set to the right to “OPEN”. •...
- Page 23 COMMISSIONING MAINTENANCE A NOTICE Do not use the plate compactor on concrete or hard or tightly compacted ground surfaces. In such cases, the device will begin to impact instead of vibrating, causing damage to the plate and the motor. shaking with rubber mat (Rubber mat optionally available) By placing a rubber mat under the vibrating plate, you can prevent damage to slabs and natural stones during vibrating.
- Page 24 MAINTENANCE 8.1 Maintenance plan Please carry out and adhere to these maintenance tasks regularly to avoid damage and to ensure that the safety devices function properly. Failure to do so may result in an accident! Each After All 2 Every Daily weeks month or...
- Page 25 MAINTENANCE 8.2 Oil change oil level check (Fig. 14) Check the engine oil level with the engine stopped and level. • Remove the oil filler cap/dipstick (1 / ) and wipe it clean. • Reinsert the dipstick into the oil filler neck without screwing it in, then remove it to check the oil level.
- Page 26 MAINTENANCE Check. Replace damaged element. • Wipe dirt from the inside of the filter housing with a clean, damp cloth. • Unscrew the inner wing nut and remove the air filter elements. • Carefully remove the foam filter insert (16) from the paper filter insert (15). Check both parts for damage.
- Page 27 MAINTENANCE • Screw in the spark plug and tighten it with the spark plug wrench (20). • Place the spark plug connector onto the spark plug. A NOTICE A loose spark plug can overheat and damage the engine. And over-tightening the spark plug can damage the threads in the cylinder head.
- Page 28 MAINTENANCE clamping screw lock nut hexagon nut (+ washer) • Make sure that the clutch pulleys (b) and exciter pulleys (c) are aligned. Place a straight edge on the exciter pulley (c) and move the motor until both pulleys are parallel. •...
- Page 29 TROUBLESHOOTING 9. TROUBLESHOOTING Caused remedy Disturbance Gas regulation incorrectly Install gas regulation correctly. installed. Ground is too wet, the plate Allow drying time. Pre-feed speed is too low. The gets stuck. disk does not reach maximum Drive belt too loose, slips on Adjust or replace drive belt.
- Page 30 TECHNICAL DATA 10. TECHNICAL DATA Model: RP-700PRO drive motor: 1-cylinder 4-stroke OHV petrol engine Rated power: Engine speed: 1/min Fuel: unleaded regular gasoline Fuel tank capacity: SAE 10W- 0 or 10W- 0 Engine oil: ~ 0, Engine oil content: F7RTC or other equivalent spark...
- Page 31 WARRANTY / CUSTOMER SERVICE 11. WARRANTY / CUSTOMER SERVICE warranty The statutory warranty period is years after the date of purchase. In case of any If there are any defects in the product, please contact our customer service directly. For this purpose, we recommend that you carefully keep your purchase receipt.
- Page 32 - 19 00 9 / (0)8 71 / 9 that the product vibrating plate (compaction machine) Device type: RP-700PRO Device type: meets the essential protection requirements of the above-mentioned EC directives. Conformity is based on the following standards: 00-1: 00 00- : 00 +A1 ZEK 01.02-08/12.08...
- Page 33 ACCESORIES 13. ACCESSORIES Designation Description Order No. rubber mat, 0 x mm TGRP7 00 99 transparent RRP7 Ø 9 mm 00 00 8 wheelset...
- Page 34 COMPONENTS OF THE MACHINE 14. COMPONENTS OF THE MACHINE...
- Page 35 COMPONENTS OF THE MACHINE pathogens...
- Page 36 LVG Hartham GmbH Robert-Bosch-Ring 3 D-84375 Kirchdorf am Inn Phone: + 49 (0)85 71 / 92 556 - 0 Fax: + 49 (0)85 71 / 92 556 - 19...
