- Page 1 Translated from German to English - www.onlinedoctranslator.com VP-60 / VP-80 / VP-100 VP60 Art. No.: VP80 Art. No.: Art. No.: VP100 operating instructions vibrating plate VP-60 / VP-80 / VP-100 www.lumag-maschinen.com...
- Page 2 IMPORTANT INSTRUCTIONS DANGER!Before assembly and before commissioning, read the entire text of the operating instructions. Use these instructions to familiarize yourself with the device, its correct use and the safety instructions. A NOTICE According to the applicable product liability law, the manufacturer of this device is not liable for damages caused to or by this device in the following cases: - improper handling,...
- Page 3 CONTENTS CONTENTS 1. Introduction 2. Intended use 3. Safety instructions . 1 General safety instructions . operational safety . Safety when using combustion engines service security Residual risks and protective measures Behavior in an emergency 3.7 Warning and information symbols used 4.
- Page 4 INTRODUCTION INTENDED USE 1. INTRODUCTION This manual contains information and procedures for the safe operation and maintenance of this model. For your own safety and to prevent injury, carefully read, understand, and follow the safety instructions in this manual at all times. 2.
- Page 5 SAFETY INSTRUCTIONS 3. SAFETY INSTRUCTIONS When using this vibrating plate, the following basic safety measures must be observed to protect against the risk of injury, fire and property damage. Read all of these instructions before using this appliance and keep them for future reference.
- Page 6 SAFETY INSTRUCTIONS 3. Keep other people away - Do not allow other people, especially children and young people, to use the power tool. Keep them away from your work area. 4. Store unused tools safely - When not in use, tools should be stored in a dry, high or locked place, out of the reach of children.
- Page 7 SAFETY INSTRUCTIONS of the body parts, tickling, pain, stinging, change in skin color or skin may occur. If these symptoms are noticed, consult a doctor. - However, suitable gloves and regular breaks can extend the duration of use. However, please note that personal predisposition to poor circulation and/or high grip forces when working will reduce the duration of use.
- Page 8 SAFETY INSTRUCTIONS • ALWAYSensure that areas to be compacted do not contain live cables, gases, water or communication lines. • ALWAYSEnsure that the side walls of trenches, pits, heaps and embankment edges are stable and do not collapse due to vibration during compaction. Be careful of the risk of falling or tipping over! •...
- Page 9 SAFETY INSTRUCTIONS 3.3 Safety when using combustion engines DANGER Internal combustion engines pose a particular danger during operation and when refueling. Always read and observe the warnings in the engine manual and the additional safety instructions listed further down in this manual. Failure to observe these instructions could result in serious or even fatal injuries.
- Page 10 SAFETY INSTRUCTIONS substitute. • ALWAYSCheck the tank cap regularly for leaks. • ALWAYSClean the engine cooling fins of dirt. • The stickers on the machine warn of dangers. The machineALWAYSKeep clean and replace damaged stickers if necessary. 3.5 Residual risks and protective measures Mechanical residual hazards Squeeze Careless handling of the vibrating plate can lead to serious injuries.
- Page 11 SAFETY INSTRUCTIONS Hazards from materials and other substances contact, inhalation The exhaust fumes from the machine can cause health damage. → Only use the power tool outdoors and take regular breaks. fire, explosion Fuel is flammable. → Smoking and open fires are prohibited during work and refueling. Danger from vibration whole-body vibration Prolonged work with the vibrating plate can lead to physical impairments due...
- Page 12 SYMBOLS USED 3.7 Warning and information symbols used A NOTICE The machine is delivered without engine oil. The first thing to do before using it for the first time is to fill it with engine oil. Failure to do so can lead to irreparable damage to the engine. DANGER! * The engine exhaust contains poisonous carbon monoxide.
- Page 13 SYMBOLS USED CAUTION! * lifting point / binding point CAUTION CAUTION CAUTION CAUTION POZOR POZOR OSTROŻNIE OSTROŻNIE THROTTLE LEVER Turtle means SLOW or IDLE Rabbit means FULL MAX. MIN. SPEED or FAST NAMEPLATE Equipped with model name, year of manufacture and serial number.
- Page 14 CONTROLS 4. CONTROLS (varies depending on type and design) vibrating plate A) Foldable guide bar B) Chassis C) Chassis mount D) Drive belt / belt guard E) Console F) Base plate G) Pathogens H) Drive motor I) Protective guard J) Suspension K) Throttle control lever L) Handle...
- Page 15 Motor tank cap fuel tank throttle recoil starter air filter Engine oil filler plug (VP60) Valve cover (VP-60) Spark plug, spark plug connector muffler choke lever Engine oil filler plug with dipstick Engine oil drain plug recoil starter ignition switch...
- Page 16 MACHINE TRANSPORT 5. MACHINE TRANSPORT WARNING Before transporting the machine or storing it indoors, allow the engine to cool down to avoid burns and the risk of fire. Furthermore, it must be ensured that persons are not endangered by the machine tipping over or slipping or by machine parts flying up or down.
- Page 17 ASSEMBLY 6. ASSEMBLY 6.1 Installation of guide bracket (varies depending on type and design) 1. Fix the guide bracket (A) at the designated locations using the screws, washers and lock nuts (X). 2. Screw in both star grip screws (Y) from the outside. When shaking The guide bracket must be fixed on both sides by screwing in the star grip screws completely.
- Page 18 • Remove the engine oil filler plug on the engine. • Fill in engine oil until it is visible in the thread of the filler opening (= lower edge of the oil filler opening).Filling quantity approx. 0.35 liters (VP-60), approx. 0.60 liters (VP-80, VP100). Do not overfill!
- Page 19 COMMISSIONING engine oil engine oil filler plug Before starting the engine, check: • the engine oil level • the fuel level – the tank should be at least half full • the air filter condition • the condition of the fuel lines •...
- Page 20 COMMISSIONING 6. Set the throttle to full throttle (rabbit symbol). throttle full throttle position 7. Turn the ignition switch to “ON”. Turn on the ignition switch 8. Pull the recoil starter gently until you feel resistance, then pull the cable firmly and let it roll in slowly again.
- Page 21 COMMISSIONING 7.4 Turning off the engine 1. Set the throttle to idle (“turtle” symbol). . Turn the ignition switch to “OFF”. throttle idle position ignition switch off position 7.5 Operation Run the engine at full throttle using the throttle control lever (K). The plate will then move forwards by itself at normal speed.
- Page 22 COMMISSIONING MAINTENANCE A NOTICE Do not use the plate compactor on concrete or hard or tightly compacted ground surfaces. In such cases, the device will begin to impact instead of vibrating, causing damage to the plate and the motor. shaking with rubber mat By placing a rubber mat under the vibrating plate, you can prevent damage to slabs and natural stones during vibrating.
- Page 23 MAINTENANCE 8.1 Maintenance plan Please carry out and adhere to these maintenance tasks regularly to avoid damage and to ensure that the safety devices function properly. Failure to do so may result in an accident! Each After All 2 Daily weeks year or Task...
- Page 24 MAINTENANCE 8.2 Oil change oil level check Check the engine oil level with the engine stopped and level. 1. Remove the engine oil filler plug from the dipstick and wipe clean. . Reinsert the dipstick into the oil filler neck without screwing it in, then remove it to check the oil level.
- Page 25 10. Reinstall the protective bar. engine oil engine oil change 8.3 Air filter VP-60 The air filter is equipped with an air filter insert. Frequent cleaning of the air filter prevents carburetor malfunctions. Clean the air filter and change the air filter insert 1.
- Page 26 MAINTENANCE VP-80 / VP-100 The air filter is equipped with two air filter inserts. Frequent cleaning of the air filter prevents carburetor malfunctions. Clean the air filter and change the air filter inserts • Remove the wing nut, remove the air cleaner cover and check for holes or cracks. Replace any damaged element.
- Page 27 MAINTENANCE 8.4 Cleaning the settling cup 1. Empty the fuel tank. . Remove the air filter. . Unscrew the settling cup (18) and radial sealing ring (17), clean thoroughly in non- flammable solvent and allow to dry. 4. Screw both parts back on. 5.
- Page 28 MAINTENANCE A NOTICE A loose spark plug can overheat and damage the engine. And over-tightening the spark plug can damage the threads in the cylinder head. 8.6 Adjusting the engine speed A NOTICE Operating the disk at a higher speed than recommended in the "Technical Data" may cause disk and motor damage.
- Page 29 MAINTENANCE 10-15 mm Changing the drive belt A NOTICE (VP 80, VP 100) The drive belt tensioning screws can also be used to finely adjust the drive belt. Loosen screws 1 and 2 (on the front and back of the motor). Finely tighten the drive belt by turning the tensioning screws.
- Page 30 • Approx. 180 ml (VP-60, VP-80), approx. 220 ml (VP-100) Gear oil SAE 80W-90fill (use funnel) • Reinstall the oil drain plug together with the sealing ring.
- Page 31 TROUBLESHOOTING NOTE ON ENVIRONMENTAL PROTECTION 9. TROUBLESHOOTING Caused remedy Disturbance Gas regulation incorrectly Install gas regulation correctly. installed. Ground is too wet, the plate Allow drying time. Pre-feed speed is too low. The gets stuck. disk does not reach maximum Drive belt too loose, slips on Adjust or replace drive belt.
- Page 32 TECHNICAL DATA 11. TECHNICAL DATA Model: VP-60 VP-80 VP-100 drive motor: 1-cylinder 4-stroke OHV petrol engine Rated power: Engine speed: 1/min Fuel: unleaded regular gasoline Fuel tank capacity: SAE 10W-0 or 10W-40 Engine oil: 0.60 Engine oil content: E7RTC or other equivalent spark plug...
- Page 33 WARRANTY / CUSTOMER SERVICE 12. WARRANTY / CUSTOMER SERVICE warranty The statutory warranty period is years after the date of purchase. In case of any If there are any defects in the product, please contact our customer service directly. For this purpose, we recommend that you carefully keep your purchase receipt.
- Page 34 Designation: vibrating plate (compaction machine) Type designation: VP-60, VP-80, VP-100 meets the essential protection requirements of the above-mentioned EC directives. Conformity is based on the following standards: EN 5501 : 007, EN 61000-6-1: 007, EN ISO 744:1995, EN 500-4: 006 EN...
- Page 35 COMPONENTS OF THE MACHINE 14th BA VP-6...
- Page 36 COMPONENTS OF THE MACHINE VP-80 machine...
- Page 37 COMPONENTS OF THE MACHINE VP-80 pathogens...
- Page 38 COMPONENTS OF THE MACHINE VP-100...
- Page 40 LVG Hartham GmbH Robert-Bosch-Ring 3 D-84375 Kirchdorf am Inn Phone: + 49 (0)85 71 / 92 556 - 0 Fax: + 49 (0)85 71 / 92 556 - 19...
