- Page 1 Translated from German to English - www.onlinedoctranslator.com RP-i31DE RP-i38DE Art. No.: RPi38DE Art. No.: RPi31DE original operating instructions vibrating plate with forward and reverse motion www.lumag-maschinen.de...
- Page 2 DANGER! When delivered, the device does not contain any engine oil. Graphics, images, texts and layouts created by LUMAG GmbH are subject to copyright and the laws protecting intellectual property. Reproduction or use of such graphics, images, texts and layouts in other electronic or printed...
- Page 3 RP-i31DE, RP-i38DE STOP START ─ Type and design subject to change. ─...
- Page 4 10-15 mm...
- Page 6 CONTENTS CONTENTS 1. Introduction 2. Intended use 3. Safety instructions 3.1 General safety instructions 3.2 Operational safety 3.3 Safety when using combustion engines 3.4 Service security 3.5 Warning and information symbols used 4. Controls 5. Machine transport 5.1 Mechanical lifting 5.2 Moving the machine on the ground 5.3 Storage 6.
- Page 7 INTENDED USE SAFETY INSTRUCTIONS 1. INTRODUCTION This manual contains information and procedures for the safe operation and maintenance of this model. For your own safety and to prevent injury, carefully read, understand, and follow the safety instructions in this manual at all times. 2.
- Page 8 SAFETY INSTRUCTIONS 3.1 General safety instructions 1. Keep your work area tidy - Disorder in the work area can lead to accidents. 2. Consider environmental influences - Never operate the power tool in enclosed or poorly ventilated areas. When the engine is running, poisonous gases are produced.
- Page 9 SAFETY INSTRUCTIONS - Always open the tank cap carefully so that the existing excess pressure can be released slowly. - Be careful not to overfill the tank with fuel. If you spill fuel, remove it immediately and clean the machine. - Close the screw plug on the fuel tank tightly to prevent it from coming loose due to vibrations during work.
- Page 10 SAFETY INSTRUCTIONS Inexperienced operators must be instructed by personnel who are familiar with the machine. Only then may they operate the machine. • NEVERallow untrained personnel and persons under 18 years of age to operate this machine. The personnel operating this equipment must be familiar with the risks and dangers associated with its operation.
- Page 11 SAFETY INSTRUCTIONS • ALWAYSRead the operating instructions before operating the appliance. Instructions on dangers, warnings and precautions must be strictly observed in order to minimize the risk of personal injury, property damage and incorrect servicing. 3.3 Safety when using combustion engines Internal combustion engines pose a particular danger during operation and when refueling.
- Page 12 SAFETY INSTRUCTIONS • Damaged or worn machine partsALWAYSreplace with new original spare parts. • The stickers on the machine warn of dangers. The machineALWAYSKeep clean and replace damaged stickers if necessary. Please also observe the relevant regulations and guidelines applicable in your country.
- Page 13 Equipped with model name, year of manufacture and serial number. Please always state this information when ordering spare parts or for service information. LUMAG GmbH | Robert Bosch Ring 3 | D-84375 Kirchdorf a.Inn A NOTICE A NOTICE When delivered, the device does not contain any engine oil.
- Page 14 CONTROLS MACHINE TRANSPORT 4. CONTROLS vibrating plate (Fig. 1) A) Guide bar B) Electric start (key) C) Switch bar (forward and reverse) D) Starter battery E) Drive motor F) Console G) Filling hole for excitation oil H) base plate I) Drive belt / belt guard J) Protective frame K) Central suspension (anchor point) L) drawbar...
- Page 15 • Position the drawbar (L) vertically and allow the lock to engage. • To transport the vibration plate, only use suitable lifting equipment with a minimum load capacity of 250 kg (RP-i31DE) and 350 kg (RP-i38DE). • Secure the machine on the transport vehicle against rolling, slipping or tipping over and additionally lash it to the protective frame.
- Page 16 For this engine onlydiesel fuel required (do not use BIO diesel). Only use fresh, clean fuel. Water or impurities in the fuel will damage the fuel system. (Fig. 4) tank volume: 3.5 liters (RP-i31DE) 4.5 liters (RP-i38DE) DANGER Refuel in a well-ventilated area with the engine stopped. If the engine has been running immediately before, allow it to cool down first.
- Page 17 • Remove the oil filler cap screw (6) on the engine. • Fill in engine oil until it is visible in the thread of the filler opening (= lower edge of the oil filler opening). Capacity approx. 1.1 liters (RP-i31DE) and 1.6 liters (RP-i38DE). Do not overfill! Before starting work and after 4 hours of use, check: •...
- Page 18 COMMISSIONING DANGER If you attempt to start the engine again, wait until it stops. The vibration starts when the engine starts up. A NOTICE Do not operate the decompression lever while the engine is running. 6. Bring the engine to maximum speed. 7.
- Page 19 OPERATION 6.6 Switching off the engine (Fig. 8) When operations are interrupted or after work has finished, protect the starter key from unauthorized access. A NOTICE Never stop the engine using the decompression lever, as this will inevitably cause damage to the decompression device.
- Page 20 OPERATION MAINTENANCE The work area must first be cleared of obstacles and tripping hazards must be eliminated. Extreme caution is required on uneven terrain, in narrow pits and when compacting coarse material to avoid becoming trapped and losing control of the machine. Make sure you have a secure footing! Use the machine in such a way that hand injuries caused by solid objects are avoided.
- Page 21 MAINTENANCE 8. MAINTENANCE Only carry out maintenance work when the engine is switched off. Legal regulations must be observed for the handling and disposal of used oil, filters and cleaning agents. Protect the starter key from unauthorized access. Disconnect the negative terminal of the battery. After completing maintenance, check that all tools have been removed from the engine and all guards have been replaced.
- Page 22 MAINTENANCE Each After All 2 Every Daily weeks month or year or Task before first every 100 every 300 Operation 20 hours 50 hours Hours Hours check / adjust V-belt change Re-grease the drawbar and transport lock check pathogen oil change battery - Visual inspection for obvious...
- Page 23 MAINTENANCE • Place a sufficiently large container under the oil drain plug to collect the used oil. • To drain the oil, remove the oil filler cap (6) and the oil drain plug (5). • Allow all oil to drain off, lifting the machine slightly at the back if necessary. DANGER! Used engine oil must be disposed of in an environmentally friendly manner.
- Page 24 MAINTENANCE The machine must be level and parked. Tensioning / changing the drive belt (Fig. 11) 1. Loosen the 2 screws (y) on the belt guard (I) and remove the belt guard upwards. 2. Check belt tension. 3. Re-tighten the drive belt (a) if the belt gives way by more than 10-15 mm (thumb pressure).
- Page 25 MAINTENANCE • Remove the screw on the filling hole (G). • Remove drain plug (X). • Drain the transmission oil into a suitable shallow container. DANGER Used engine oil must be disposed of in an environmentally friendly manner. We recommend that you hand over used oil in a closed container to a recycling center or a collection point for used oil.
- Page 26 MAINTENANCE risk of chemical burns Wear protective gloves and eye protection, as battery acid is highly corrosive. Avoid tipping over batteries. warning Batteries should never be exposed to direct sunlight. disposal Only dispose of batteries in the designated containers or collection points. Never dispose of batteries in household waste.
- Page 27 TROUBLESHOOTING ENVIRONMENT A NOTICE Replace a defective battery only with an identical or equivalent battery. maintenance Keep the battery clean and dry Clean the battery only with a damp cloth, do not use a wire brush. Protect the battery from cooling down too much Check battery and connections for tightness.
- Page 28 TECHNICAL DATA 10. TROUBLESHOOTING Caused remedy Disturbance Gas regulation incorrectly Install gas regulation correctly installed Soil is too wet, the plate gets pre- and allow drying time stuck Rewind speed is too low. The disk does not reach the Drive belt too loose, slips on Adjust or replace drive belt.
- Page 29 WARRANTY / GUARANTEE / CUSTOMER SERVICE 11. TECHNICAL DATA Model: RP-i31DE RP-i38DE type drive motor: Air-cooled single-cylinder four-stroke diesel engine with electric start displacement: Rated power: 3600 Engine speed: 1/min Fuel: Diesel Fuel tank capacity: SAE 10W-30 / SAE 10W-40 Engine oil: ~ 1.1...
- Page 30 Please clearly label the shipping box with the SERVICE NUMBER to ensure quick identification. Warranty work is only carried out by our LUMAG service workshop. Defects that occur within the warranty period due to material or manufacturing errors must be remedied by repair if they have arisen despite proper operation and care of the machine.
- Page 31 Fax: 0049 / (0)8571 / 92 556-19 that the product vibrating plate (compaction machine) Device type: RP-i31DE, RP-i38DE Device type: complies with the essential protection requirements of the above-mentioned EC Directives. Person authorized to compile the technical documentation: Christopher Weißenhorner The declaration of conformity refers only to the machinery in the condition in which it was placed on the market;...
- Page 32 COMPONENTS OF THE MACHINE 14. COMPONENTS OF THE MACHINE RP-i31DE...
- Page 33 COMPONENTS OF THE MACHINE...
- Page 34 COMPONENTS OF THE MACHINE RP-i38DE...
- Page 35 COMPONENTS OF THE MACHINE...
- Page 36 LUMAG GmbH Robert-Bosch-Ring 3 D-84375 Kirchdorf a.Inn Telephone: +49 8571 / 92556-0 Fax: +49 8571 / 92556-19 www.lumag-maschinen.de Status: 04/2015 - RPi31DE, RPi38DE_v2...
