ST STM32N6570-DK User Manual page 25

8.6
STLINK-V3EC USB Type-C
The USB connector (CN6) is used to connect the embedded STLINK-V3EC to the PC for programming and
debugging purposes.
Pin number
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
8.7
ARDUINO
The ARDUINO
®
ARDUINO Uno revision 3 standard. Most shields designed for ARDUINO
board.
Important:
The STM32 microcontroller I/Os are 3.3 V compatible instead of 5 V for ARDUINO
UM3300 - Rev 1
®
connector (CN6)
Figure 17. STLINK-V3EC connector (CN6) front view
Table 15. STLINK-V3EC connector (CN6) pinout
Description
GND
NC
NC
VBUS_STLK
CC1 (STLINK MCU PC3)
D+ (STLINK MCU PB15)
D- (STLINK MCU PB14)
NC
VBUS_STLK
NC
NC
GND
®
Uno V3 connectors (CN7, CN8, CN11, and CN12)
®
Uno V3 connectors ((CN7, CN8, CN11, and CN12) are female connectors compatible with the
Pin number
B1
B2
B3
B4 VBUS_STLK
B5 CC2 (STLINK MCU PC4)
B6 D+ (STLINK MCU PB15)
B7 D- (STLINK MCU PB14)
B8
B9 VBUS_STLK
B10
B11
B12
®
Uno V3 fit the STM32N6570-DK
®
Uno
UM3300
Board connectors
Description
GND
NC
NC
NC
NC
NC
GND
page 25/49
