Figure 4.
STM32N6570-DK PCB layout top view
User
Reset
Tamper
button
button
button
(B2)
(B4)
TAG footprint
(CN1)
Hardware layout and configuration
Power status
LED
(B1)
(LD3)
User LEDs:
Green (LD1)
Red (LD2)
UM3300
Microphone daughterboard
connector
(CN5)
page 9/49
