ST STM32N6570-DK User Manual page 10

Power supply
select
(JP2)
MIPI20
(CN10)
SD card socket
(CN13)
UM3300 - Rev 1
Figure 5. STM32N6570-DK PCB layout bottom view
MEMs microphone STLINK-V3EC USB Type-C
(U13) (CN6)
USB1
®
USB Type-C USB Type-A
(CN18) (CN17)
®
USB2 Ethernet
RJ45
(CN16)
UM3300
Hardware layout and configuration
ARDUINO ®
connectors
(CN7, CN8, CN11,
and CN12)
Flash memory
(U25)
PSRAM
(U26)
Camera connector
(CN14)
page 10/49
