Dakota Digital LAT-NR281 Installation Instructions

Led tail lights for 1967-68 firebird

Download this manual

MAN# 650200

Kit Includes:

Installation:

1. Remove the original bulb sockets.

2. Remove the tail light housing hardware so the housing can be removed from the car. Remove

the housings from the vehicle carefully so the body gaskets are not damaged.

3. Next remove the lens to gain access to the housing. There are four screws that hold the lens in

place, remove the screws and separate the lens carefully.

4. Now is a good time to clean the lens and housing. If lenses are in bad shape a new set is

recommended.

INSTALLATION INSTRUCTIONS

LAT-NR281

LED Tail Lights for 1967-68 Firebird.

MAN# 650200

Need help?

Do you have a question about the LAT-NR281 and is the answer not in the manual?

Page 1 INSTALLATION INSTRUCTIONS LAT-NR281 LED Tail Lights for 1967-68 Firebird. MAN# 650200 Kit Includes: Installation: 1. Remove the original bulb sockets. 2. Remove the tail light housing hardware so the housing can be removed from the car. Remove the housings from the vehicle carefully so the body gaskets are not damaged.
Page 2 5. Remove the round mounting plate from the bottom of the LED assembly. It is attached with two lock nuts. 6. Pass the wires through the housing where the original bulb and socket were. Set the LED assemblies into the housing so the two studs extend out the hole in the bottom of the housing. 7.
Page 3 This Warranty is in lieu of all other expressed warranties or liabilities. Any implied warranties, including any implied warranty of merchantability, shall be limited to the duration of this written warranty. No person or representative is authorized to assume, for Dakota Digital, any liability other than expressed herein in connection with the sale of this product.
