Dakota Digital LED Tail Lights LAT-NR160 Installation Instructions

Led tail lights for ‘64-’66 chevelle, ’71-’72 chevelle, ’66-’67 nova, and ‘66 lemans

MAN#650158:B

Kit Includes:

'64 Chevelle '65 Chevelle

1. Remove the tail light lens.

2. Remove the light bulb.

3. Remove the original bulb connector from the back side of the housing. The housing may need

to be removed from the car on the '71-'72 Chevelle.

INSTALLATION INSTRUCTIONS

LAT-NR160

LED Tail Lights for '64-'66 Chevelle, '71-'72 Chevelle,

'66-'67 Nova, and '66 Lemans

'66 Chevelle

'71-'72 Chevelle '66-67 Nova '66 Lemans

MAN#650158:B

Table of Contents

Do you have a question about the LED Tail Lights LAT-NR160 and is the answer not in the manual?

Page 1 MAN#650158:B Kit Includes: Installation: ‘64 Chevelle ‘65 Chevelle 1. Remove the tail light lens. 2. Remove the light bulb. 3. Remove the original bulb connector from the back side of the housing. The housing may need to be removed from the car on the ’71-’72 Chevelle. INSTALLATION INSTRUCTIONS LAT-NR160 LED Tail Lights for ‘64-’66 Chevelle, ’71-’72 Chevelle,...
Page 2 4. Now is a good time to clean the lens and housing. If lenses are in bad shape a new set is recommended. 5. Remove the screw and aluminum back plate from the back of the new LED assembly. LED assembly (attached to the assembly) 6.
Page 3 8. Secure the back plate with the supplied screw and washer. 9. Make sure the original lens gasket is in place and then replace the tail light lens. Tighten the screws down carefully. 10. Start by cutting off the existing light socket as it will not be used. Do not strip wires. Trim the wires from LED assembly to appropriate length once mounted, making sure wires are routed cleanly and securely.
Page 4 This Warranty is in lieu of all other expressed warranties or liabilities. Any implied warranties, including any implied warranty of merchantability, shall be limited to the duration of this written warranty. No person or representative is authorized to assume, for Dakota Digital, any liability other than expressed herein in connection with the sale of this product.
