Dakota Digital LED Tail Lights LAT-NR100 Installation Instructions

Led tail lights for 1967-68 ss and 1970-73 camaro.

Download this manual

MAN# 650153

Kit Includes:

Installation:

67-68 SS Camaro

1. Remove the tail light assembly from the vehicle by removing the original bulb sockets from the

housing. Then remove the housing hardware so it can be removed from the car. Remove the

housings from the vehicle carefully so the housing to body gaskets are not damaged.

2. Next remove the lens.

The 67-68 Camaro has six screws that hold the housing halves together which will need to be

removed to gain access to lens.

The 70-73 Camaro lens has tabs locking it into the plastic housing. Pry the tabs gently with a

screwdriver to remove lens.

INSTALLATION INSTRUCTIONS

LAT-NR100

LED Tail Lights for 1967-68 SS and 1970-73 Camaro.

70-73 Camaro

MAN# 650153

Page 1 MAN# 650153 Kit Includes: Installation: 67-68 SS Camaro 1. Remove the tail light assembly from the vehicle by removing the original bulb sockets from the housing. Then remove the housing hardware so it can be removed from the car. Remove the housings from the vehicle carefully so the housing to body gaskets are not damaged.
Page 2 3. Now is a good time to clean the lens and housing. If lenses are in bad shape a new set is recommended. If you are installing this kit into a 67-68 Camaro skip ahead to step 5. For the 70-73 Camaro, some of the hardware will need to be changed out for proper mounting bracket 4.
Page 3 7. Feed the wires through the larger hole in the mounting plate. Guide the mounting plate to the bottom of the housing. The flat side of the mounting plate should be down and the side with the slight raised center should go up into the housing. This will align the mount in the original housing.
Page 4 This Warranty is in lieu of all other expressed warranties or liabilities. Any implied warranties, including any implied warranty of merchantability, shall be limited to the duration of this written warranty. No person or representative is authorized to assume, for Dakota Digital, any liability other than expressed herein in connection with the sale of this product.
