Canon imagePROGRAF iPF6300 Service Manual page 8

•
Automatic cutting settings (for rolls)
•
Borderless printing (for rolls)
•
Paper feed amount
•
Printhead height
•
Vacuum strength
•
Maximum ink usage
Click [Add Custom Paper] Click [Add Custom Paper]
F. High-precision Mechanical Structures
The imagePROGRAF iPF6350/6300 printers have a newly designed
reinforced frame for quieter operation, which minimizes vibration during
printing and improves ink drop placement accuracy, and integrity. This
enhancement also improves color registration which yields higher precision
print evenness.
G. Control Panel
The imagePROGRAF iPF6350/6300 printers have a large, bright, and easy-
to-read LCD screen to display illustrations, ink levels, menu settings, and
other information. The screen displays navigation functions with illustrated
instructions, so that users need only follow easy steps to load paper,
replace ink tanks, or do other operations. The operation panel is now easier
to use with separate larger labeled, FEED, CUT, LOAD, and NAVIGATE
buttons.
H. Gigabit Ethernet
The imagePROGRAF iPF6350/6300 printers support Gigabit Ethernet
printing. This provides for fast transfer of large amounts of data for high-
volume jobs.
imagePROGRAF iPF6350/6300 Service Guide
Rev. 0
MCT top screen MCT top screen
Perform media parameter addition, editing, and deletion. Perform media parameter addition, editing, and deletion.
And, export or import registered media information. And, export or import registered media information.
Sub rail
Main rail
Rail stay
Reinforcing board added
補強板 補強板
imagePROGRAF iPF6350/6300 Service Guide
Custom paper menu Custom paper menu
16-point adjustment
Main stay Main stay
March 2010
Page 3
