II. Design Features
A. Image Processing Technology
The imagePROGRAF iPF6350/6300 printers incorporate new technology
for the creation of high-precision color conversion that offers far-reaching
improvements in color reproduction and gradation. This enables smooth
gradations to be reproduced with excellent matching precision, under
controllable conditions, and with little tone jump.
B. High Precision Print Modes
Two print output options have been added to the Printer Driver to give users
in proofing and photography environments more detailed choices when
creating prints.
The high-precision printing mode for photographs delivers output with less
graininess, enhanced glossiness, sharper blacks and deeper dark tones.
The high-precision printing mode for text and fine lines reduces excessive
thickness in text ad fine lines while reducing the representation of colors
produced.
C. Printhead (PF-05)
D. LUCIA EX Pigment Ink Set
LUCIA EX is a 12-color pigment ink set. The yellow pigments allow for a
higher saturation of yellow and results in a wider gamut in reds and greens.
New polymer encapsulation to all colors and blacks allow for better pigment
particle adhesion to media and to each other. This adhesion results in
superior scratch resistance. Polymer with gliding characteristics results in
minimal gloss differential between colors and less bronzing. Beading that
creates dots is also prevented.
E. Media Configuration Tool (MCT)
The Media configuration Tool bundled with the LUCIA EX models,
strengthens support for 3
paper when the options are correctly configured. This version also adds
features for adjusting, registering, and distributing the names and various
media parameters for 3
parameters can be distributed to other computers or imagePROGRAF
printers. The following setting can be configured using the media parameter
adjustment features:
•
Media weight and thickness
•
Ink drying time (for rolls)
imagePROGRAF iPF6350/6300 Service Guide
Rev. 0
imagePROGRAF iPF6350/6300 Service Guide
The PF-05 Printhead has a new nozzle shape, but the
same density as before.
channel, 15,360 nozzles total. Printhead PF-05 has a new
orifice shape, which minimizes satellite ink and produce
cleaner lines and text.
rd
party media. It supports superior printing on this
rd
party media. Additionally, added or edited
There are 2,560 nozzles per
