Refer to the "Quick Start Guide" packaged with the printer and the Service
Manual for complete unpacking, installation, reinstallation, and space
requirements.
C. Estimated Installation Times
Estimated installation times shown are based on an out-of-box main unit
installation that can be achieved by service personnel.
Included in the calculation of the estimated installation time are the following:
• Unpacking and positioning the printer (main unit) on a stand or table
• Installing the printheads, ink tanks, and connecting the power cable
• Checking the printer operation, and adjusting printing position
• Connecting the printer to a computer and installing the printer driver and
software
Excluded in the calculation of the estimated installation time is the following:
• Power outlet preparation
• Installation space preparation
Table 7 - Estimated Installation Time
imagePROGRAF iPF6350/6300 Main Unit (with Stand)
Printhead PF-05
Ink Tanks (time includes installation of all 12 ink tanks)
Installation times shown above are the estimated times required for
installation starting from an unpacked condition. It is calculated based on
man-hours.
imagePROGRAF iPF6350/6300 Service Guide
Rev. 0
imagePROGRAF iPF6350/6300 Service Guide
Length
Length
Approx.46.34"(1,177
Description Estimated Time
25 minutes
5 minutes
25 minutes
