- Page 1 KVM switch and rackmount screen technology User Manual 21.5” FHD 1920 x 1080 LCD RM-F21R-V 1U LCD Console Drawer Options : - HDMI / SDI - Full Range KVM - DC power...
- Page 2 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
- Page 3 Contents < Part. 1 > RM-F21 Package Content Structure Diagram & Dimension P.1 - 2 Installation P.3 - 4 Connection < Part. 2 > Specif cations / OSD Product Specifi cations P.6 - 7 Keyboard / Mouse Specifi cations P.8 - 10 On-screen Display Operation ( OSD ) P.11 - 12 <...
- Page 4 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
- Page 5 < Part 1 > < 1.1 > Package Content RM-F21 RM-F21 unit X 1 - CX-6 6ft DVI-D console cable X 1 - Power cord X 1 - M6 screw, cage nut & cup washer X 8 The above package content is only for the single console models. It varies with options such as KVM, SDI, HDMI &...
- Page 6 < 1.2 > Dimension Front View Rear View Power DVI-D KB / MS UNIT : mm Side View 1mm = 0.03937 inch Top View Product Dimension Packing Dimension Gross Model (W x D x H) (W x D x H) Weight Weight 441.6 x 670 x 44 mm...
- Page 7 < 1.3 > Installation - How to install Installation Slides RM-F21 Step ■ Insert the left and right rear mounting brackets into the LCD console drawer. Step ■ Measure the depth of the front and rear mounting rails. ■ Align each rear mounting bracket to a suitable length. Step Complete the installation ■...
- Page 8 Flip up the LCD to a suitable angle. ■ Operate the LCD console drawer. - Right Side Open ■ at the end of the model no. Flip up LCD from the side RM-F21R-V sample : Panel Left Right Front Side UM-CV-751-F121-Q316V1...
- Page 9 < 1.4 > Connection to USB Server via CX-6 cable LCD Console Drawer Power DVI-D KB / MS DVI-X DVI-D console cable DVI-D USB server < 1.4 > Connection to external KVM via DVI-X cable LCD Console Drawer Power DVI-D KB / MS DVI-X DVI-D console cable...
- Page 10 < Part 2 > < 2.1 > Product Specif cations Manufacturer Panel Panel Size ( diagonal ) 21.5-inch Widescreen TFT color LCD Display pixel ( dots x lines ) 1920 x 1080 Brightness ( typ. ) Contrast Ratio ( typ. ) 1000:1 Color 16.7 M...
- Page 11 RM-F21 Physical Product ( W x D x H ) 441.6 x 670 x 44 mm Specif cation 17.4 x 26.4 x 1.73 inch Packing ( W x D x H ) 595 x 860 x 140 mm 23.4 x 33.9 x 5.5 inch Net Weight 14.7 kgs / 32.3 lbs Gross Weight...
- Page 12 < 2.2 > Standard Keyboard / Mouse Specif cations G keyboard integrated with touchpad G keyboard integrated with trackball Key force 55 ± 5g Travelling distance 3 ± 0.3mm Switch life > 10 million life cycle time OS support Windows / Linux / Unix / Mac OS Supporting layouts America United States...
- Page 13 < 2.2 > MAC Keyboard / Mouse Options RM-F21 MAC keyboard integrated with touchpad MAC keyboard integrated with trackball F8 F8 F8 F8 Supporting layouts America United States How to Use "MAC" Keyboard Keyboard Features Decrease display brightness Fast-forward Increase display brightness Mute sound Mission control * Only works with OS X Lion...
- Page 14 < 2.2 > SUN Keyboard / Mouse Options S keyboard integrated with touchpad S keyboard integrated with trackball Ca ps Scro ll Comp ose Ca ps Scro ll Comp ose S keyboard integrated with touchpad / trackball ■ Incorporates SUN keys, including Stop, Cut, Paste, Compose, Copy and Help ■...
- Page 15 < 2.3 > On-screen Display Operation ( OSD ) RM-F21 Membrane Switch Function Turn the monitor on or off Display the OSD menu Act as an Enter key to select screen setting options Scroll through menu options and adjust the displayed control Exit the OSD screen Go back to the previous on-screen sub-menu or main menu...
- Page 16 < 2.3 > On-screen Display Operation ( OSD ) OSD Conf guration Page Image: for the brightness, contrast, color temp, red, green, and blue Geometry: for the auto adjust, H position, V position, phase and clock Video: for the colour, tint, sharpness, noise reduction, DCDi and TV Setup Audio: for volume, bass, treble, balance, AVL and mute Misc:...
- Page 17 < Part 3 > < 3.1 > Options : 3G / HD / SD-SDI input RM-F21 Austin Hughes’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with CyberView Full HD 1080p and ultra high resolution 1920 x 1200 LCD displays, Austin Hughes provides a SDI input module without using additional space or power and it comes standard with a 2-year warranty.
- Page 18 < 3.2 > Options : - HDMI ( HDMI 1.3, CEA-861-D ( 1 ) For HDMI option, DVI-D input will be removed. ( 2 ) In some circumstances, if the user connects the LCD to PC via HDMI port for video and audio signals, the LCD may display incorrectly on a full screen.
- Page 19 Product Dimension Packing Dimension Model Net Weight Gross Weight (W x D x H) (W x D x H) 441.6 x 770 x 44 mm 595 x 860 x 140 mm 15.5 kg 21.4 kg RM-F21 with KVM 17.4 x 30.3 x 1.73" 23.4 x 33.9 x 5.5”...
- Page 20 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. UM-CV-751-F121-Q316V1 www.rackmountsales.com...
