1.
Loosen the 4 cover screws and take off
the cover of GV-Cloud Bridge Pro.
3.
Flip the mounting plate and attach it to the self-prepared SSD with 4 of the supplied
screws.
4.
Turn over the SSD and mounting plate
assembly so that the SSD is on top, and
connect the SATA Power Cable from the
system board to the SSD.
6.
Fasten the cover back onto the housing to complete the SSD installation.
2.
Connect the SATA Power Cable to the
GV-Cloud Bridge Pro system board.
5.
Install the mounting plate to the mounting
standoffs using 4 of the supplied screws.
9
