3 Overview
3
4
Description
No Name
The Red LED indicates the power is supplied.
1. LED
The Green LED indicates a network is connected.
Insert a Micro SD card (SDHC / SDXC / UHS-I, Class 10, Linux ext4
2. Memory Card
format). To format a SD card, see 13 Storage.
Connect to up to 8 GV-DFK1355 readers via the RS-485 interface. See
3. RS-485
12.5 RS-485 and 11.2 Connecting to GV-Cloud Access Control.
Not functional
4. USB
Hold and press the button for 10 ~ 15 seconds to load the default. To
restore to default settings using the Web interface, see 12.6
5. Default
Maintenance.
6. LAN/PoE Connect to a network or power over Ethernet.
Connect to power.
7. DC 12V
IMPORTANT: The device can only accept one power source, either a PoE power supply or a
DC power adapter. Connecting two power sources simultaneously can damage the device.
Note: The device also supports SSD storage. To install a SSD, see 6 Installing a SSD.
