5 Connecting to PC
There are two options for powering and connecting GV-Cloud Bridge Pro to a computer. Only
one of the two ways can be utilized at once.
1. Connect an optional GV-PA301 PoE Adapter to the PC via the LAN port (see No. 7, 3
Overview) to receive power over Ethernet.
2. Use an optional power adapter to power on the device. Connect to network via the LAN
port (No. 7, 3 Overview).
IMPORTANT: GV-Cloud Bridge Pro can only accept one power source, either a PoE power
supply or a DC power adapter. Connecting two power sources simultaneously can damage
the device.
6 Installing the SSD
To install an SSD in GV-Cloud Bridge Pro using the optional SSD mounting kit, follow the
steps below.
The SSD mounting kit
1. SATA Power Cable
3. SATA Data Cable
Note: The optional SSD mounting kit is required to install the SSD drive.
2. Mounting Plate
4. Screws
x 4, x 4
