  • Page 1 FusionServer 2288H V7 Server Technical White Paper Issue Date 2024-11-21 xFusion Digital Technologies Co., Ltd.
  • Page 2 Notice In this document, "xFusion" is used to refer to "xFusion Digital Technologies Co., Ltd." for concise description and easy understanding, which does not mean that "xFusion" may have any other meaning. Any "xFusion" mentioned or described hereof may not be understood as any meaning other than "xFusion Digital Technologies Co., Ltd.", and xFusion Digital Technologies Co., Ltd.
  • Page 3 About This Document Purpose This document describes the appearance, features, performance parameters, and hardware and software compatibility of FusionServer 2288H V7, so that users can have an in-depth and detailed understanding of FusionServer 2288H V7. Intended Audience This document is intended for pre-sales engineers.
  • Page 4 1 and 2, 24 x 2.5" drive pass- through configuration (3 x RAID controller cards), and 25 x 2.5" drive EXP configuration. 2023-06-21 This issue is the first official release. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 5 5.5.1.3 12 x 3.5" Drive Pass-Through Configurations...................45 5.5.1.4 12 x 3.5" Drive EXP Configurations ....................53 5.5.1.5 16 x 2.5" Drive Pass-Through Configuration ..................57 5.5.1.6 24 x 2.5" Drive Pass-Through Configurations...................59 Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 6 8.2 Maintenance and Warranty........................115 9 System Management ....................116 10 Certifications ......................118 11 Waste Product Recycling ..................120 A Appendix ........................121 B Glossary ........................148 C Acronyms and Abbreviations ..................151 Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 7 Technical White Paper 1 Overview Overview FusionServer 2288H V7 is a new-generation 2U 2-socket rack server designed for the Internet, Internet Data Center (IDC), cloud computing, enterprise business, and telecom. This product is ideal for IT core services, cloud computing, virtualization, high- performance computing, distributed storage, big data processing, enterprise or telecom applications, and other complex workloads.
  • Page 8 ⚫ and availability. The server uses hot-swappable SAS/SATA drives. SAS/SATA drives support ⚫ RAID 0, 1, 1E, 10, 5, 50, 6, and 60, depending on the RAID controller card used. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 9 Supports secure boot based on the chip-level Root of Trust (RoT) and provides ⚫ the level-by-level verification function starting from the hardware trusted root, building a complete secure boot chain. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 10 ⚫ dissipation and reduces system power consumption. The server is protected with power capping and power control measures. ⚫ Staggered spinup of drives reduces the server boot power consumption. ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 11 Intrusion sensor NOTE The air duct cannot be installed on a server configured with built-in drives or built-in cards. Front-drive backplane Left mounting ear plate Front drives Right mounting ear plate Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 12 Note 2: On the drive assembly, a red mark indicates that the assembly is hot- ⚫ swappable, and a triangular mark indicates the removal direction of the hot- swappable assembly. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 13 CPU 1 and CPU 2 each support one OCP 3.0 NIC. The PCIe slot bandwidth is scalable to x16. The BMC card integrates the BMC management chip and provides external ⚫ video graphic array (VGA), management network port, and serial port. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 14 5.5 Storage 5.6 Network 5.7 I/O Expansion 5.8 PSUs 5.9 Fan Modules 5.10 LCD 5.11 Boards 5.1 Front Panel 5.1.1 Appearance 8 x 2.5" drive configuration ⚫ Figure 5-1 Front view Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 15 Slide-out label plate (with an SN label) 12 x 3.5" drive configuration ⚫ Figure 5-3 Front view Drive Slide-out label plate (with an SN label) 24 x 2.5" drive configuration: ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 16 25 x 2.5" drive configuration ⚫ Figure 5-5 Front view Drive Slide-out label plate (with an SN label) 5.1.2 Indicators and Buttons Indicator and Button Positions 8 x 2.5" drive configuration ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 17 Health status indicator Power button/indicator Fault diagnosis LED FlexIO card 1 presence FlexIO card 2 presence indicator indicator iBMC direct connect management port indicator 12 x 3.5" drive configuration ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 18 Health status indicator Power button/indicator Fault diagnosis LED FlexIO card 1 presence FlexIO card 2 presence indicator indicator iBMC direct connect management port indicator 25 x 2.5" drive configuration ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 19 Blinking green at 0.5 Hz: The FlexIO card is ⚫ detected but is not powered on. ⚫ Blinking green at 2 Hz: The FlexIO card is detected and has just been inserted. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 20 (local PC): port indicator Off: No terminal is connected. ⚫ ⚫ Blinking green at short intervals for 3 seconds and then off: The port is disabled. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 21 USB 3.0 port iBMC direct connect management port VGA port 12 x 2.5" drive configuration (4 x SAS/SATA + 8 x NVMe) ⚫ Figure 5-12 Ports on the front panel Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 22 VGA port 24 x 2.5" drive configuration ⚫ Figure 5-14 Ports on the front panel USB 3.0 port iBMC direct connect management port VGA port 25 x 2.5" drive configuration ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 23 For details about how to ⚫ connect a USB device to the iBMC direct connect management port, see the iBMC User Guide. USB port USB 3.0 Used to connect to a USB 3.0 Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 24 I/O module 1 I/O module 2 I/O module 3 PSU 2 PSU 1 (Optional) FlexIO card 2 NOTE The FlexIO card slots support only OCP 3.0 NICs. (Optional) FlexIO card 1 Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 25 The FlexIO card slots support only OCP 3.0 NICs. For details about the OCP 3.0 NIC, see 5.6.1 OCP 3.0 NIC. ⚫ The figure is for reference only. The actual configuration may vary. ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 26 Figure 5-19 Indicators on the rear panel Data transmission status Connection status indicator indicator for the for the management management network port network port Serial port indicator UID indicator NOTE Reserved and unavailable currently Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 27 ⚫ Off: The device is not being located. Blinking or steady blue: The device is ⚫ being located. NOTE You can control the UID indicator status by Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 28 Socket for PSU 2 4-GPU model ⚫ Figure 5-21 Ports on the rear panel Management network port Serial port VGA port USB 3.0 port Socket for PSU 1 Socket for PSU 2 Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 29 You can select the PSUs as required. NOTE When determining the PSUs, ensure that the rated power of the PSUs is greater than that of the server. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 30 Figure 5-22 Positions of the processors 5.4 Memory 5.4.1 DDR5 Memory 5.4.1.1 Memory Identifier You can determine the memory module properties based on the label attached to the memory module. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 31 10: SPD versions from Byte 192 to Byte 447 Temperature grade Extended temperature grade ⚫ (XT): 0° C to 95° C (32° F to 203° F) ⚫ Normal temperature grade Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 32 DIMM031(L) E (primary) DIMM040(E) DIMM041(M) F (primary) DIMM050(F) DIMM051(N) G (primary) DIMM060(G) DIMM061(O) H (primary) DIMM070(H) DIMM071(P) CPU 2 A (primary) DIMM100(A) DIMM101(I) B (primary) DIMM110(B) DIMM111(J) C (primary) DIMM120(C) Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 33 "Search Parts" in the compatibility list on the technical support website. The maximum number of memory modules supported depends on the memory ⚫ module type and number of ranks. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 34 The memory modules configured must be DDR5 RDIMMs. ⚫ The memory modules must be configured with the same number of ranks. ⚫ Install filler memory modules in vacant slots. ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 35 2 processors: When 48 GB DIMMs are configured, only 16 DIMMs and insertion methods ⚫ are supported. When 96 GB DIMMs are configured, only 16 and 32 DIMMs and insertion methods are supported. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 36 FusionServer 2288H V7 Server Technical White Paper 5 Hardware Description Figure 5-25 DDR5 memory module installation guidelines (one processor) Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 37 FusionServer 2288H V7 Server Technical White Paper 5 Hardware Description Figure 5-26 DDR5 memory module installation guidelines (two processors) Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 38 FusionServer 2288H V7 Server Technical White Paper 5 Hardware Description Figure 5-27 DDR5 memory module installation guidelines (one HBM processor) Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 39 ⚫ Memory Single Device Data Correction (SDDC) ⚫ Failed DIMM Isolation ⚫ Memory Thermal Throttling ⚫ Command/Address Parity Check and Retry ⚫ Memory Demand/Patrol Scrubbing ⚫ Memory Data Scrambling ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 40 3 by default. ⚫ NVMe drive: CPU pass- through 8 x 2.5" drive Front drive: SATA ⚫ ⚫ pass-through 8 x 2.5" drive: PCH Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 41 ⚫ ⚫ 2: 8 x 2.5" 8 x 2.5" plug-in drives + 4 x RAID Slots 0 − GPUs controller to 7 card support only The PCIe SAS/SA plug-in RAID Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 42 Drive numbering of the 8 x 2.5" drive pass-through configuration 1 in Table 5-7 ⚫ Figure 5-29 Drive numbering Table 5-8 Drive numbering Drive No. Drive Number Displayed on the iBMC WebUI Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 43 Drive numbering of the 8 x 2.5" drive pass-through configuration 2 in Table 5-7 ⚫ Figure 5-30 Drive numbering Table 5-9 Drive numbering Drive No. Drive Number Displayed Drive Number Identified on the iBMC WebUI by the RAID Controller Card Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 44 Figure 5-31 Drive numbering Table 5-10 Drive numbering Drive No. Drive Number Displayed on the iBMC WebUI Drive numbering of the 8 x 2.5" drive pass-through configuration 4 in Table 5-7 ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 45 ⚫ NVMe) in Table 5-7 Figure 5-33 Drive numbering Table 5-12 Drive numbering Drive No. Drive Number Displayed Drive Number Identified on the iBMC WebUI by the RAID Controller Card Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 46 Table 5-13 Drive numbering Drive No. Drive Number Displayed on the iBMC WebUI Drive numbering of the configuration 2: 8 x 2.5" drives + 4 x GPUs in Table 5-7 ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 47 Slots 0 − 1 (4 x SATA + through to 3 8 x NVMe) support NVMe ⚫ only drive: CPU SATA pass- drives. through Slots 4 − to 7 support only Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 48 − through to 3 configuration support ⚫ NVMe only drive: CPU SATA pass- drives. through Slots 4 − to 7 support only SATA/N drives. Slots 8 − to 11 support Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 49 Drive numbering of the 12 x 2.5" drive (4 x SATA + 8 x NVMe) pass-through ⚫ configuration 1 and 12 x 2.5" drive (4 x SATA + 8 x NVMe) + 4 x GPU configuration 1 in Table 5-15. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 50 Drive numbering of the 12 x 2.5" drive (4 x SATA + 8 x NVMe) pass-through ⚫ configuration 2 and 12 x 2.5" drive (4 x SATA + 8 x NVMe) + 4 x GPU configuration 2 in Table 5-15. Figure 5-37 Drive numbering Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 51 3.5" through to 11 support Slots 40 NVMe − ⚫ only and 41 drive: CPU SATA support pass- drives. only through SATA drives. I/O module ⚫ 3: 4 x 2.5" Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 52 SATA SATA pass- drives. drives. through Slots 8 I/O module − ⚫ to 11 3: 4 x 2.5" support Slots 44 − only to 47 SATA/N support only drives. NVMe Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 53 RAID controller card. This section uses the drive numbers identified by a RAID controller card that adopts the default cabling described in "Internal Cabling" in the server Maintenance and Service Guide. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 54 Figure 5-38 Drive numbering (I/O module 1 configured with 2.5" drives) Figure 5-39 Drive numbering (I/O module 1 configured with 3.5" drives) Table 5-19 Drive numbering Drive No. Drive Number Displayed on the iBMC WebUI Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 55 Drive numbering of the 12 x 3.5" drive pass-through configuration 2 in Table 5-18 ⚫ Figure 5-40 Drive numbering Table 5-20 Drive numbering Drive No. Drive Number Displayed Drive Number Identified on the iBMC WebUI by the RAID Controller Card Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 56 WebUI by the RAID Controller Card Drive numbering of the 12 x 3.5" drive pass-through configuration 1 (4 x NVMe) ⚫ in Table 5-18 Figure 5-41 Drive numbering Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 57 Table 5-21 Drive numbering Drive No. Drive Number Displayed on the iBMC WebUI Drive numbering of the 12 x 3.5" drive pass-through configuration 2 (4 x NVMe) ⚫ in Table 5-18 Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 58 5 Hardware Description Figure 5-42 Drive numbering Table 5-22 Drive numbering Drive No. Drive Number Displayed Drive Number Identified on the iBMC WebUI by the RAID Controller Card Note Note Note Note Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 59 1 (2 x 3.5) drive: 4 x drive: 1 x configuration 3.5" RAID Slots 0 Slots 40 − − controller to 11 and 41 Slots 36 − card support support to 39 Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 60 RAID controller card that adopts the default cabling described in "Internal Cabling" in the server Maintenance and Service Guide. Drive numbering of the 12 x 3.5" drive EXP configuration 1 in Table 5-23 ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 61 Technical White Paper 5 Hardware Description Figure 5-43 Drive numbering Table 5-24 Drive numbering Drive No. Drive Number Displayed Drive Number Identified on the iBMC WebUI by the RAID Controller Card Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 62 Drive numbering of the 12 x 3.5" drive EXP configuration 2 in Table 5-23 ⚫ Figure 5-44 Drive numbering Table 5-25 Drive numbering Drive No. Drive Number Displayed Drive Number Identified on the iBMC WebUI by the RAID Controller Card Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 63 5.5.1.5 16 x 2.5" Drive Pass-Through Configuration Drive Configurations Table 5-26 Drive configurations Configuratio Front Drive Rear Drive Built-in Drive Drive Management Mode 16 x 2.5" drive Front drive 2 x PCIe ⚫ ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 64 Drive numbering of the 16 x 2.5" drive NVMe hard RAID configuration (16 x ⚫ NVMe) inTable 5-26. Figure 5-45 Drive numbering Table 5-27 Drive numbering Drive No. Drive Number Displayed on the iBMC WebUI Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 65 NVMe drives. ⚫ For details about the optional components, consult the local sales representative or see "Search Parts" in the compatibility list on the technical support website. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 66 Table 5-28 Figure 5-46 Drive numbering Table 5-29 Drive numbering Drive No. Drive Number Displayed Drive Number Identified on the iBMC WebUI by the RAID Controller Card Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 67 NVMe 24 x 2.5" drive: PCH configuration pass- Slots 0 − 1 (8 x SATA + through to 3 16 x NVMe) support NVMe ⚫ only drive: CPU SATA pass- Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 68 3 by only default. NVMe drives. NVMe ⚫ drive: CPU Slots 12 − pass- to 15 through support only SAS/SA drives. Slots 16 − to 23 support only NVMe drives. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 69 RAID controller card that adopts the default cabling described in "Internal Cabling" in the server Maintenance and Service Guide. Drive numbering of the 24 x 2.5" drive NVMe configuration 1 (8 x SATA + 16 x ⚫ NVMe) in Table 5-30 Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 70 FusionServer 2288H V7 Server Technical White Paper 5 Hardware Description Figure 5-47 Drive numbering Table 5-31 Drive numbering Drive No. Drive Number Displayed on the iBMC WebUI Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 71 16 x NVMe) in Table 5-30 Figure 5-48 Drive numbering Table 5-32 Drive numbering Drive No. Drive Number Displayed Drive Number Identified on the iBMC WebUI by the RAID Controller Card Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 72 Drive numbering of the 24 x 2.5" drive NVMe configuration 3 in Table 5-30 ⚫ Figure 5-49 Drive numbering Table 5-33 Drive numbering Drive No. Drive Number Displayed on the iBMC WebUI Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 73 Technical White Paper 5 Hardware Description Drive Number Displayed on the iBMC Drive No. WebUI Drive numbering of the 24 x 2.5" drive NVMe configuration 4 in Table 5-30 ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 74 Technical White Paper 5 Hardware Description Figure 5-50 Drive numbering Table 5-34 Drive numbering Drive No. Drive Number Displayed Drive Number Identified on the iBMC WebUI by the RAID Controller Card Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 75 Slots 42 − slot 3 by and 43 default. support ⚫ NVMe only drive: CPU SAS/SA pass- through drives. ⚫ I/O module 3: 4 x 2.5" Slots 44 − Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 76 RAID controller card that adopts the default cabling described in "Internal Cabling" in the server Maintenance and Service Guide. Drive numbering of the 25 x 2.5" drive EXP configuration in Table 5-35. ⚫ Figure 5-51 Drive numbering Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 77 FusionServer 2288H V7 Server Technical White Paper 5 Hardware Description Table 5-36 Drive numbering Drive No. Drive Number Displayed Drive Number Identified on the iBMC WebUI by the RAID Controller Card Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 78 Data on the secondary drive is being Hz synchronously rebuilt. Red steady on A drive in a RAID array is removed. Steady on Red steady on The drive is faulty. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 79 Table 5-39 NVMe drive indicator description (VMD function disabled) Activity Indicator Fault Indicator Description (Green) (Red/Blue) The NVMe drive is not detected. Steady on The NVMe drive is detected and operating properly. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 80 PCIe expansion slots. The server with four GPUs on the rear panel supports up to six standard PCIe ⚫ expansion slots (four FHFL dual-slot GPUs and two FHHL standard PCIe cards). Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 81 − and one PCIe riser card is used, slots 4 and 5 are unavailable. I/O module 3 provides slots 7 and 8. − 4-GPU model ⚫ Figure 5-55 PCIe slots Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 82 PCIe riser card 1 of I/O module 1/2 ⚫ Provides PCIe slots 1, 2, and 3 when installed in I/O module 1. − Provides PCIe slots 4, 5, and 6 when installed in I/O module 2. − Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 83 Provides PCIe slots 1 and 2 when installed in I/O module 1. − Provides PCIe slots 4 and 5 when installed in I/O module 2. − Figure 5-58 PCIe riser card 2 PCIe riser card 3 of I/O module 1/2 ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 84 PCIe riser card 4 of I/O module 1/2 ⚫ Provides PCIe slot 3 when installed in I/O module 1. − Provides PCIe slot 6 when installed in I/O module 2. − Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 85 Provides PCIe slot 5 when installed in I/O module 2. − Figure 5-61 PCIe riser card 5 PCIe riser card 1 of I/O module 3 ⚫ Provides PCIe slots 7 and 8 when installed in I/O module 3. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 86 Provides PCIe slots 11 and 12 when installed in the card slot-4CHP − connector (J12). Provides PCIe slots 13 and 14 when installed in the card slot-4CHP − connector (J10). Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 87 4-GPU built- in adapter board. Provides PCIe slot 4 when installed in the card slot-4CHP connector (J10). − Provides PCIe slot 9 when installed in the card slot-4CHP connector (J12). − Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 88 Provides PCIe slot 1 when installed in the card slot-4CHP connector (J11). − Provides PCIe slot 7 when installed in the card slot-4CHP connector (J13). − Figure 5-66 PCIe riser card 3 Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 89 FHFL module 2 x16 (x Slot 5 PCIe 5.0 CPU 2 Port 1A FHFL x16 (x PCIe Slot 2 PCIe 5.0 CPU 1 Port 3A FHFL riser card x16 (x Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 90 PCIe 4.0 CPU1 Port 1A OCP 3.0 card 1 x16 (x8, specificat , x8 ions + x8 FlexIO PCIe 4.0 CPU2 Port 3A OCP 3.0 card 2 x16 (x8, specificat Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 91 GPU board module PCle 4 x GPU Slot PCIe 4.0 Port3A/ FHFL riser card built-in 4/slot 9 x16 (x16) 1/CPU 2 Port5A 2 of the adapter rear GPU board module Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 92 -vvv command. If the OS does not support the lspci command by default, obtain the pci-utils package from the yum source and install it to make the OS support the command. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 93 Supports N+1 redundancy. The server runs properly when one fan fails. ⚫ Supports intelligent fan speed adjustment. ⚫ Fan modules of the same part number (P/N code) must be used in a server. ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 94 IP address of the iBMC management network port on the server. The LCD and the server iBMC form an LCD subsystem. The LCD directly obtains device information from the iBMC. The LCD subsystem does not store device data. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 95 Table 5-42 Parameters on the LCD home screen Functions Status Displays the port 80 status, serial number, component status, and component alarms of the server. Monitor Displays the current power, CPU temperature, and inlet Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 96 Displays the IP address and Media Access Control (MAC) address of the iBMC management network port, device SNs, asset information, and firmware version. Setting Sets the IP address of the iBMC management network port. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 97 VROC key connector connector (LIQUID (VROC KEY/J6066) CONN/J6078) Cell battery holder (U6222) CPU 2 UBC DD connector (UBCDD2-7/J6053) OCP 3.0 NIC 2 connector RAID & M.2 mezzanine (OCP2 CONN/J6073) card signal connector Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 98 Intrusion sensor connector CPU 2 southbound UBC (INTRUDER CONN/S2) connector (UBC2-4/J45) CPU 2 southbound UBC CPU 2 southbound UBC connector (UBC2-3/J44) connector (UBC2-2/J41) CPU 2 southbound UBC CPU 2 northbound UBC Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 99 2.5" drive pass-through configuration 2, 8 x 2.5" drive + 4 x GPU configuration 1, and 8 x 2.5" drive + 4 x GPU configuration 2 in section 5.5.1.1 8 x 2.5" Drive Pass-Through Configurations. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 100 This backplane is supported by 8 x 2.5" drive pass-through configuration 3 and 8 x 2.5" drive pass-through configuration 4 in section 5.5.1.1 8 x 2.5" Drive Pass- Through Configurations. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 101 Power connector (HDD_POWER/J21) mini-SAS HD connector Slots 0 to 3 (PORT A/J6) mini-SAS HD connector Slots 4 to 7 (PORT B/J7) 8 x 2.5" drives NVMe backplane (supporting hard RAID) ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 102 Slot 4~7 12 x 2.5" drive pass-through configuration (4 x SAS/SATA + 8 x NVMe) ⚫ backplane All drive configurations in 5.5.1.2 12 x 2.5" Drive Pass-Through Configurations support this backplane. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 103 HD connector Slots 4 to 7 (PORT B/J601) 12 x 3.5" drive pass-through backplane ⚫ All drive configurations in 5.5.1.3 12 x 3.5" Drive Pass-Through Configurations support this backplane. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 104 (UBC1/J1) UBC connector 2 Slots 10 and 11 (UBC2/J2) 12 x 3.5" drive EXP backplane ⚫ All drive configurations in 5.5.1.4 12 x 3.5" Drive EXP Configurations support this backplane. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 105 UBC connector (J1) 24 x 2.5" drive NVMe backplane ⚫ All drive configurations in 5.5.1.7 24 x 2.5" Drive NVMe Configurations support this backplane. Figure 5-78 24 x 2.5" drive NVMe backplane Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 106 UBC connector 2-D Slots 6 and 7 (UBC2-D/J4) mini-SAS HD connector Slots 12 to 15 (PORT B/J14) UBC connector 1-F Slots 22 and 23 (UBC1-F/J12) 24 x 2.5" drive pass-through backplane ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 107 Fan connector (FAN2/J6) Fan connector (FAN3/J5) Fan connector (FAN4/J4) 5.11.4 Adapter Board Built-in 4-card module adapter board ⚫ Figure 5-80 Built-in 4-card module adapter board Card slot-4CHP connector Power connector Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 108 (UBCDD1-8-1/J3) (UBCDD1-8-2/J4) UBC connector 3 (UBC1- UBC connector 4 (UBC1- 3/J5) 4/J6) UBC connector 5 (UBC2- UBC connector 6 (UBC2- 3/J8) 4/J7) UBC connector 7 UBC connector 8 (UBCDD2-8-2/J20) (UBCDD2-8-1/J9) Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 109 The maximum thermal design power is 385W. ⚫ NOTE The preceding information is for reference only. For details, see "Search Parts" in the compatibility list on the technical support website. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 110 If the BIOS is in legacy mode, the 4K drive cannot be used as the boot drive. Network OCP 3.0 NICs provide network expansion capabilities. Supports two OCP 3.0 NICs, which can be configured ⚫ as required. ⚫ Supports orderly hot swap. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 111 If both the front and rear VGA ports are connected to ⚫ monitors, only the monitor connected to the front VGA port displays information. System management ⚫ UEFI ⚫ iBMC Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 112 90% RH with 24° C (75.2° F) maximum dew point (ASHRAE Classes A4 compliant) Air volume 120 cubic feet per minute (CFM) to 320 CFM ≤ 3050 m (10,006.56 ft) Operating altitude Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 113 LpAm: 42.3 dBA − ⚫ Operating: LWAd: 6.0 Bels − LpAm: 44.6 dBA − NOTE Actual sound levels generated during operation vary depending on the configuration, load, and ambient temperature. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 114 See Figure 6-1 for methods in measuring physical ⚫ dimensions of the chassis. The measuring method for chassis with 3.5" drives and that ⚫ for chassis with 2.5" drives are the same. The chassis with Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 115 Packaging materials: 5 kg (11.03 lb) ⚫ Power consumption The power consumption parameters vary with hardware configurations (including the configurations complying with EU ErP). For details, see Power Calculator on the technical support website. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 116 If the customer has requirements on hardware performance consistency, specify ⚫ the specific configuration requirements (for example, specific drive models, RAID controller cards, or firmware versions) in the presales phase. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 117 Do not carry the weight that exceeds the maximum load per person allowed by ⚫ local laws or regulations. Before moving a device, check the maximum device weight and arrange required personnel. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 118 Fasten the strap buckle and ensure that the ESD wrist strap is in contact with your skin. Insert the ground terminal attached to the ESD wrist strap into the jack on the grounded cabinet or chassis. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 119 Ground a device before powering it on. Otherwise, high voltage leakage current ⚫ may cause device damage. Transportation Precautions Improper transportation may damage equipment. Contact the manufacturer for precautions before attempting transportation. Transportation precautions include but are not limited to: Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 120 General Administration of Quality Male: 15/33.08 ⚫ Supervision, Inspection and Quarantine Female: 10/22.05 ⚫ of the People's Republic of China (AQSIQ) For more information about security instructions, see the server Safety Information. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 121 For details about maintenance, visit the Technical Support Website > Service Support Center > Customer Support Service. For details about warranty, visit the Technical Support Website > Service Support Center > Warranty. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 122 Security management methods ⚫ Software image backup improves system security. Even if the running − software completely breaks down, the system can be started from the backup image. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 123 License management allows advanced features to be used by authorized users. The advanced edition of the iBMC provides the following features: Use Redfish to deploy the OS. − Use Redfish to collect raw data for intelligent diagnosis. − Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 124 EN IEC 63000:2018 ErP: Commission Regulation (EU) No 2019/424 UKCA Safety: EN 62368-1:2014+A11:2017 EMC: ETSI EN 300 386 V2.1.1:2016 ETSI EN 300 386 V1.6.1:2012 EN 55032:2015+A1:2020 CISPR 32:2015+A1:2019 EN IEC 61000-3-2:2019+A1:2021 Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 125 EN 55024:2010+A1:2015 CISPR 24:2010+A1:2015 RoHS: BS EN IEC 63000:2018 ErP: Commission Regulation (EU) No 2019/424 China GB 17625.1-2022 GB 4943.1-2022 GB/T 9254.1-2021 (Class A) FCC PART 15 Japan VCCI VCCI 32-1 Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 126 Technical White Paper 11 Waste Product Recycling Waste Product Recycling If you have xFusion products at the end of their lifecycle and need xFusion's product recycling service, contact xFusion technical support. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 127 Figure A-1 Chassis head label Nameplate Certificate Quick access tag Product SN NOTE For details, see A.2 Product SN Slide-out label plate Product SN NOTE The location of the slide-out label Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 128 A.1.1.1 Nameplate Figure A-2 Sample nameplate Table A-1 Nameplate description Description Server model NOTE For details, see A.4 Nameplate. Device name Power supply requirements Enterprise standard number Vendor information Certification marks Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 129 No. barcode Figure A-4 Certificate number example Table A-3 Certificate number description Description P: a fixed value for this digit Z: a fixed value for this digit Y: a server ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 130 Letters J to N indicate 18:00 to 22:00. Letters P to Q indicate 23:00 to 24:00. ⚫ Serial number (two characters) Manufacturing serial number (five characters) A.1.1.3 Quick Access Label Figure A-5 Quick access label example Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 131 QR codes of technical resources. The pictures are for reference only. For details, see the actual product. The quick start guide is optional. For details, see the actual product. ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 132 SN ID (two characters), which is 21. Material identification code (eight characters), that is, the processing code. Vendor code (two characters), that is, the code of the processing place. Year and month (two characters) Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 133 Digits 1 to 9 indicate years 2001 to 2009 respectively. − Letters A to H indicate years 2010 to 2017 respectively. − Letters J to N indicate years 2018 to 2022 respectively. − Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 134 Description QR code. For details, see Figure A-12. BOM code (10 digits). Product model (13 characters). Product SN (12 characters). For details, see Table A-8. RoHS compliance code (one character). Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 135 Table A-9 QR code scanning result example description Description Fixed representation symbol (three characters). Product SN (12 characters). For details, see Table A-8. Data identifier for the material code (two characters). BOM code (10 digits). Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 136 NICs 6434/64 rate is whose ⚫ greater rate is CPUs than 25 greater Gbit/s than 10 CPUs are not Gbit/s with supporte are not supporte greater ⚫ PCIe than 205 Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 137 ⚫ ⚫ ⚫ ⚫ drives + 4 x configur configur with supporte supporte GPUs ations ations configuratio greater supporte supporte than 250 W are supporte ⚫ cards are not supporte Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 138 NICs supporte whose rate is ⚫ OCP 3.0 greater NICs than 100 whose Gbit/s rate is are not greater supporte than 25 Gbit/s are not supporte PCIe ⚫ NICs whose Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 139 /A100 HDDs supporte supporte through CPUs configuratio cards NVMe are not drives CPUs supporte are not with supporte greater 6434/64 ⚫ than 250 The A2 ⚫ W are CPUs Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 140 NICs in 4 x whose 3.5" rate is drives or greater 4-card than 100 module Gbit/s are not configur supporte 6434/64 ⚫ CPUs CPUs with greater than 205 W are Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 141 ⚫ OCP 3.0 configur than 205 NICs W are whose rate is supporte greater d when than 100 the built- Gbit/s in 4 x are not 3.5" supporte drives or Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 142 SAS/SATA supporte supporte CPUs than 185 + 16 x with W are NVMe) greater supporte than 250 W are ⚫ cards supporte are not supporte ⚫ A16/A40 /A100 Rear ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 143 250 than 185 W are W are supporte supporte A16/A40 A16/A40 ⚫ ⚫ /A100 /A100 cards cards are not are not supporte supporte Rear Rear ⚫ ⚫ Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 144 ⚫ in 4-card than 205 cards ⚫ Rear module W are are not drives supporte are not configur supporte supporte d when Rear ⚫ the built- Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 145 W are supporte d when the built- in 4-card module configur 25 x 2.5" ⚫ 6434/64 ⚫ ⚫ 6434/64 ⚫ CPUs ⚫ drive EXP with supporte configuratio CPUs cards CPUs Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 146 Gbit/s ⚫ 6434/64 are not supporte CPUs Superca ⚫ CPUs pacitors with are not supporte greater than 205 ⚫ 6434/64 W are CPUs supporte d when CPUs the built- with Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 147 The server supports a variety of Reliability, Availability, and Serviceability (RAS) features. You can configure these features for better performance. For details about RAS features, see the Sapphire Rapids Platform Server RAS Feature Technical White Paper. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 148 The value is 1 or CPUN Memory Status of the memory Memory module corresponding to the CPU corresponding to CPU N N indicates the CPU number. The value is 1 or Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 149 The value is 1 or CPUN INFAON Temp CPU INFAON CPUN temperature N indicates the CPU number. The value is 1 or CPUN VCCFA Temp CPU VCCFA temperature CPUN Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 150 Disks Temp Maximum drive Drive temperature PowerN PSU input power PSU N N indicates the PSU number. The value is 1 or FANN F Speed Fan speed Fan module N Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 151 RiserN Card Entity presence Riser card N N indicates the riser card slot number. The value ranges from 1 to 5. RiserN 12V 12 V voltage supplied by Mainboard Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 152 Status of the M.2 drive on M.2 adapter card the riser card AreaIntrusion Listening to the Mainboard unpacking action OCP$ OP Temp OCP card optical module OCP 3.0 NIC temperature Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 153 Operation log full or events being cleared Sec. Log Full Security log full or events being cleared Host Loss System monitoring software (BMA) link loss detection ProductID Status Product identification status Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 154 B.2 F-J Gigabit Ethernet (GE) An extension and enhancement of traditional shared media Ethernet standards. It is compatible with 10 Mbit/s and 100 Mbit/s Ethernet and complies with IEEE 802.3z standards. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 155 A storage technology that combines multiple physical independent disks drives into a logical unit for the purposes of data (RAID) redundancy and performance improvement. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 156 A unit defined in International Electrotechnical Commission (IEC) 60297-1 to measure the height of a cabinet, chassis, or subrack. 1U = 44.45 mm (1.75 in). UltraPath A point-to-point processor interconnect developed by Interconnect (UPI) Intel. Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 157 Advanced Encryption Standard New Instruction Set Address Resolution Protocol Advanced Vector Extensions backup battery unit BIOS Basic Input/Output System baseboard management controller China Compulsory Certification calendar day Conformite Europeenne Common Information Model command-line interface Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 158 European Telecommunication Standards C.2 F-J FB-DIMM Fully Buffered DIMM Fiber Channel Federal Communications Commission FCoE Fibre Channel over Ethernet File Transfer Protocol Gigabit Ethernet GPIO General Purpose Input/Output Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 159 Internet Group Message Protocol IOPS input/output operations per second Internet Protocol Intelligent Power Capability IPMB Intelligent Platform Management Bus IPMI Intelligent Platform Management Interface C.3 K-O keyboard, video, and mouse Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 160 Network Controller Sideband Interface Open Compute Project C.4 P-T PCIe Peripheral Component Interconnect Express power distribution unit physical layer PMBUS power management bus Power OK pulse-width modulation Preboot Execution Environment Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 161 LAN SONCAP Standards Organization of Nigeria-Conformity Assessment Program solid-state drive Streaming SIMD Extension TACH tachometer signal Turbo Boost Technology Trusted Computing Group trusted cryptography module total cost of ownership Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 162 Voluntary Control Council for Interference by Information Technology Equipment Video Graphics Array VLAN virtual local area network voltage regulator-down VROC Virtual RAID on CPU WEEE waste electrical and electronic equipment WSMAN Web Service Management Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 163 FusionServer 2288H V7 Server Technical White Paper C Acronyms and Abbreviations Issue 10 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
