FusionServer 5288 V6 Server
Technical White Paper
Issue
04
Date
2022-06-25
xFusion Digital Technologies Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FusionServer 5288 V6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for xFusion Digital Technologies FusionServer 5288 V6

Summary of Contents for xFusion Digital Technologies FusionServer 5288 V6

  • Page 1 FusionServer 5288 V6 Server Technical White Paper Issue Date 2022-06-25 xFusion Digital Technologies Co., Ltd.
  • Page 2 Notice In this document, "xFusion" is used to refer to "xFusion Digital Technologies Co., Ltd." for concise description and easy understanding, which does not mean that "xFusion" may have any other meaning. Any "xFusion" mentioned or described hereof may not be understood as any meaning other than "xFusion Digital Technologies Co., Ltd.", and xFusion Digital Technology Co., Ltd.

  • Page 3: Table Of Contents

    FusionServer 5288 V6 Server Technical White Paper Contents Contents About This Document ........................v 1 Overview ............................7 2 Features ............................8 3 Physical Structure ........................11 4 Logical Structure ......................... 13 5 Hardware Description ........................ 15 5.1 Front Panel .................................. 16 5.1.1 Appearance ................................
  • Page 4 5.5.1 Drive Configurations ............................... 40 5.5.2 Drive Numbering ..............................46 5.5.3 Drive Indicators ............................... 70 5.5.4 RAID Controller Card ............................. 72 5.6 Network ..................................73 5.6.1 OCP 3.0 Network Adapter ............................73 5.7 I/O Expansion ................................73 5.7.1 PCIe Cards ................................73 5.7.2 PCIe Slots ................................

  • Page 5: About This Document

    Technical White Paper About This Document About This Document Purpose This document describes the FusionServer 5288 V6 rack server in terms of features, structure, specifications, and component hardware and software compatibility. Intended Audience This document is intended for pre-sales engineers.
  • Page 6 FusionServer 5288 V6 Server Technical White Paper About This Document Change History Issue Release Date Change Description 2022-06-25 ⚫ Added a figure that shows how to measure dimensions. ⚫ Upgrades the standards of CE, UKCA, and CCC certifications in the chapter 10 Certifications.

  • Page 7: Overview

    1 Overview Overview FusionServer 5288 V6 (5288 V6) is a new-generation 4U dual-socket or single-socket storage server designed for media and entertainment, and finance fields. The 5288 V6 is ideal for applications such as cold data storage, video surveillance, cloud storage, and big data processing.

  • Page 8: Features

    FusionServer 5288 V6 Server Technical White Paper 2 Features Features Performance and Scalability ⚫ ® ® Powered by the third-generation Intel Xeon Scalable Ice Lake processors, the server provides up to 40 cores, 3.6 GHz frequency, a 60 MB L3 cache, and up to three 11.2 GT/s UPI links between the processors, which deliver supreme processing performance.
  • Page 9 FusionServer 5288 V6 Server Technical White Paper 2 Features ⚫ Flexible drive configurations meet a variety of business requirements and ensure high elasticity and scalability of storage resources. ⚫ The use of 12 Gbit/s SCSI (SAS) serial connection for internal storage provides 2x data transmission rate than the use of 6 Gbit/s SAS connection, maximizing the performance of I/O-intensive applications.
  • Page 10 FusionServer 5288 V6 Server Technical White Paper 2 Features ⚫ The secure boot based on the chip RoT implements level-by-level firmware verification starting from the hardware RoT and builds a complete secure boot chain. ⚫ The trusted platform module (TPM) and trusted cryptography module (TCM) provide advanced encryption functions, such as digital signatures and remote authentication.

  • Page 11: Physical Structure

    FusionServer 5288 V6 Server Technical White Paper 3 Physical Structure Physical Structure Figure 3-1 Physical structure Rear drive I/O module 1 I/O module 2 Rear-drive backplane Chassis I/O module 3 Supercapacitor holder Air duct Intrusion sensor NOTE The air duct cannot be installed on a server with built-in drives.
  • Page 12 FusionServer 5288 V6 Server Technical White Paper 3 Physical Structure Front drive Right mounting ear plate Fan module Fan module brackets Processor heat sink Processor Cable organizer Mainboard Memory TPM/TCM Screw-in RAID controller OCP 3.0 network adapter card BMC card...

  • Page 13: Logical Structure

    FusionServer 5288 V6 Server Technical White Paper 4 Logical Structure Logical Structure Figure 4-1 Logical structure ⚫ ® ® The server supports one or two third-generation Intel Xeon Scalable Ice Lake processors. ⚫ The server supports up to 32 memory modules.
  • Page 14 FusionServer 5288 V6 Server Technical White Paper 4 Logical Structure ⚫ The LBG-R Platform Controller Hub (PCH) is integrated on the mainboard to support five USB 3.0 ports. ⚫ The BMC management chip integrated on the mainboard supports a video graphic array (VGA) port, a management network port, and a serial port.

  • Page 15: Hardware Description

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Hardware Description 5.1 Front Panel 5.2 Rear Panel 5.3 Processors 5.4 Memory 5.5 Storage 5.6 Network 5.7 I/O Expansion 5.8 PSUs 5.9 Fan Modules 5.10 Boards 2022-06-25...

  • Page 16: Front Panel

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description 5.1 Front Panel 5.1.1 Appearance Figure 5-1 Front view Drive Slide-out label plate (with an SN label) 5.1.2 Indicators and Buttons Indicator and Button Positions Figure 5-2 Indicators and buttons on the front panel...
  • Page 17 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description FlexIO card 1 presence FlexIO card 2 presence indicator indicator iBMC direct connect management port indicator Indicator and Button Descriptions Table 5-1 Description of indicators and buttons on the front panel...
  • Page 18 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Silkscreen Indicator and Description Button ⚫ Off: The device is not being located. ⚫ Blinking or steady blue: The device is being located. UID button: ⚫ You can control the UID indicator status by pressing the UID button or using the iBMC.

  • Page 19: Ports

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description 5.1.3 Ports Port Positions Figure 5-3 Ports on the front panel USB 3.0 port iBMC direct connect management port VGA port Port Description Table 5-2 Ports on the front panel...
  • Page 20 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Port Type Quantity Description Note protocol is port NOTE supported. Only local PCs running Windows 10 are supported. ⚫ To log in to the iBMC from the local PC, enter https://IP address...

  • Page 21: Rear Panel

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description 5.2 Rear Panel 5.2.1 Appearance Figure 5-4 Rear view I/O module 1 (Optional) FlexIO card 1 NOTE The FlexIO card slot supports only OCP 3.0 network adapters. I/O module 2...

  • Page 22: Indicators And Buttons

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description 5.2.2 Indicators and Buttons Indicator Positions Figure 5-5 Indicators on the rear panel Data transmission status Connection status indicator of indicator of the management the management network port network port...
  • Page 23 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Silkscreen Indicator Description ⚫ Off: The device is not being located. ⚫ Blinking or steady blue: The device is being located. NOTE You can control the UID indicator status by pressing the UID button or using the iBMC.

  • Page 24: Ports

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description 5.2.3 Ports Port Positions Figure 5-6 Ports on the rear panel Management network port Serial port VGA port USB 3.0 port Socket for PSU 1 Socket for PSU 2 Port Description...

  • Page 25: Processors

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Port Type Quantity Description VGA port DB15 Used to connect a display terminal, such as a monitor or KVM. USB port USB 3.0 Used to connect to a USB 3.0 device.

  • Page 26: Memory

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-7 Processor positions 5.4 Memory 5.4.1 DDR4 Memory 5.4.1.1 Memory ID You can determine the memory module properties based on the label attached to the memory module. 2022-06-25...

  • Page 27: Memory Subsystem Architecture

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-8 Memory identifier Description Example Capacity ⚫ 16 GB ⚫ 32 GB ⚫ 64 GB ⚫ 128 GB ⚫ 256 GB Number of ranks ⚫ 1R: single-rank ⚫ 2R: dual-rank ⚫...
  • Page 28 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Table 5-5 Memory channels Channel Memory Slot CPU 1 A (primary) DIMM000(A) DIMM001(I) B (primary) DIMM010(B) DIMM011(J) C (primary) DIMM020(C) DIMM021(K) D (primary) DIMM030(D) DIMM031(L) E (primary) DIMM040(E) DIMM041(M) F (primary)

  • Page 29: Memory Compatibility

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Channel Memory Slot H (primary) DIMM170(H) DIMM171(P) 5.4.1.3 Memory Compatibility Observe the following rules when configuring DDR4 memory modules: ⚫ A server must use DDR4 memory modules of the same part number (P/N code), and the memory speed is the minimum value of the following items: ⚫...

  • Page 30: Dimm Installation Rules

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Table 5-6 DDR4 memory specifications Parameter Specifications Capacity per DDR4 memory module (GB) Type RDIMM RDIMM RDIMM LRDIMM Rated speed (MT/s) 3200 3200 3200 3200 Operating voltage (V) Maximum number of DDR4...

  • Page 31: Memory Installation Positions

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description − Each processor supports four integrated memory controllers (IMCs), and each IMC has two channels for installing memory modules. The installed memory modules must be identical in size and organization.
  • Page 32 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-10 DDR4 memory module installation guidelines (1 processor) 2022-06-25...
  • Page 33 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-11 DDR4 memory module installation guidelines (2 processors) 2022-06-25...

  • Page 34: Memory Protection Technologies

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description 5.4.1.6 Memory Protection Technologies The following memory protection technologies are supported: ⚫ ⚫ Memory Mirroring ⚫ Memory Single Device Data Correction (SDDC) ⚫ Failed DIMM Isolation ⚫ Memory Thermal Throttling ⚫...

  • Page 35: Memory Subsystem Architecture

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Description Example Component Intel Optane Persistent Memory 8089-A2-2008-00002461 Model NMB1XXD512GPSU4 Capacity (GB) ⚫ ⚫ ⚫ SN QR code 8089-A2-2008-00002461 5.4.2.2 Memory Subsystem Architecture The server provides 32 memory slots. Each processor integrates eight memory channels, and each memory channel supports only one PMem module.

  • Page 36: Memory Compatibility

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Channel Memory Slot DIMM101(I) B (primary) DIMM110(B) DIMM111(J) C (primary) DIMM120(C) DIMM121(K) D (primary) DIMM130(D) DIMM131(L) E (primary) DIMM140(E) DIMM141(M) F (primary) DIMM150(F) DIMM151(N) G (primary) DIMM160(G) DIMM161(O) H (primary)

  • Page 37: Dimm Installation Rules

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Total memory capacity = Total capacity of all PMem modules (The DDR4 memory modules are used as the cache and therefore are not calculated as memory capacity.) For details about the AD and MM modes, see FusionServer PMem 200 User Guide.

  • Page 38: Memory Installation Positions

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description On the same server, it is recommended that the ratio of the DDR4 memory capacity to the PMem capacity be 1:4 to 1:16. 5.4.2.5 Memory Installation Positions A server supports a maximum of 16 PMem modules. The PMem modules must be used with the DDR4 memory modules.
  • Page 39 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-14 PMem module installation guidelines (1 processor) Figure 5-15 PMem module installation guidelines (2 processors) 2022-06-25...

  • Page 40: Memory Protection Technologies

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description 5.4.2.6 Memory Protection Technologies The following memory protection technologies are supported: ⚫ PMem module Error Detection and Correction ⚫ PMem module Device Failure Recovery (SDDC) ⚫ PMem module Package Sparing (DDDC) ⚫...
  • Page 41 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Configuration Front Drive Rear Drive Built-in Drive Drive Management Mode drives. ⚫ I/O module 3: 4 x 2.5" − Slots 44 to 47 support only NVMe drives ⚫ Rear drives (12 x 3.5"):...
  • Page 42 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Configuration Front Drive Rear Drive Built-in Drive Drive Management Mode (12 x 3.5"): − Rear slots 24 to 35 support only SAS/SA drives. Single-RAID ⚫ Front drive ⚫ I/O module ⚫...
  • Page 43 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Configuration Front Drive Rear Drive Built-in Drive Drive Management Mode ⚫ ⚫ ⚫ ⚫ Single-RAID Front drive I/O module Built-in SAS/SATA configuration 4 (24 x 3.5"): 1: 2 x 2.5"...
  • Page 44 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Configuration Front Drive Rear Drive Built-in Drive Drive Management Mode ⚫ I/O module − 2: 2 x 2.5"/2 screw-in x 3.5" RAID controlle − Slots 42 r card and 43...
  • Page 45 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Configuration Front Drive Rear Drive Built-in Drive Drive Management Mode ⚫ I/O module PCIe 3: 4 x 2.5" RAID controlle − Slots 44 r card to 47 manages support SAS/SA...

  • Page 46: Drive Numbering

    The drive numbers identified by the RAID controller card vary depending on the cabling of the RAID controller card. The drive numbers identified by the RAID controller card in this section are provided based on the default cabling described in "Internal Cabling" in FusionServer 5288 V6 Server Maintenance and Service Guide. ⚫...
  • Page 47 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-16 Drive slot numbers (3.5" drives in I/O module 1 and I/O module 2) 2022-06-25...
  • Page 48 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-17 Drive slot numbers (2.5" drives in I/O module 1 and I/O module 2) Table 5-10 Slot numbers Drive Number Identified Drive Number Identified Drive No. by the iBMC...
  • Page 49 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Drive No. Drive Number Identified Drive Number Identified by the iBMC by the RAID Controller 2022-06-25...
  • Page 50 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Drive No. Drive Number Identified Drive Number Identified by the iBMC by the RAID Controller ⚫ Single-RAID configuration For details, see single-RAID configuration 3 in 5.5.1 Drive Configurations. 2022-06-25...
  • Page 51 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-18 Drive slot numbers (3.5" drives in I/O module 1 and I/O module 2) 2022-06-25...
  • Page 52 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-19 Drive slot numbers (2.5" drives in I/O module 1 and 3.5" drives in I/O module Table 5-11 Slot numbers Drive No. Drive Number Identified Drive Number Identified by the iBMC...
  • Page 53 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Drive No. Drive Number Identified Drive Number Identified by the iBMC by the RAID Controller 2022-06-25...
  • Page 54 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Drive No. Drive Number Identified Drive Number Identified by the iBMC by the RAID Controller Note Note Note Note ⚫ Note: If the slot is configured with a SAS/SATA drive, the RAID controller card can manage the drive and allocate a number to the drive.
  • Page 55 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-20 Drive slot numbers (2.5" drives in I/O module 1 and 3.5" drives in I/O module 2022-06-25...
  • Page 56 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-21 Drive slot numbers (2.5" drives in I/O module 1 and I/O module 2) Table 5-12 Slot numbers Drive No. Drive Number Identified Drive Number Identified by the iBMC...
  • Page 57 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Drive No. Drive Number Identified Drive Number Identified by the iBMC by the RAID Controller 2022-06-25...
  • Page 58 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Drive No. Drive Number Identified Drive Number Identified by the iBMC by the RAID Controller Note Note Note Note ⚫ Note: If the slot is configured with a SAS/SATA drive, the RAID controller card can manage the drive and allocate a number to the drive.
  • Page 59 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-22 Drive slot numbers (3.5" drives in I/O module 2) 2022-06-25...
  • Page 60 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-23 Drive slot numbers (2.5" drives in I/O module 2) Table 5-13 Slot numbers Drive Number Identified Drive Number Identified Drive No. by the iBMC by the RAID Controller...
  • Page 61 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Drive No. Drive Number Identified Drive Number Identified by the iBMC by the RAID Controller 2022-06-25...
  • Page 62 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Drive No. Drive Number Identified Drive Number Identified by the iBMC by the RAID Controller ⚫ Dual-RAID configuration For details, see dual-RAID configuration 2 in 5.5.1 Drive Configurations. 2022-06-25...
  • Page 63 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-24 Drive slot numbers (3.5" drives in I/O module 2) 2022-06-25...
  • Page 64 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-25 Drive slot numbers (2.5" drives in I/O module 2) Table 5-14 Slot numbers Drive No. Drive Number Identified Drive Number Identified by the iBMC by the RAID Controller...
  • Page 65 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Drive No. Drive Number Identified Drive Number Identified by the iBMC by the RAID Controller 2022-06-25...
  • Page 66 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Drive No. Drive Number Identified Drive Number Identified by the iBMC by the RAID Controller Note Note Note Note ⚫ Note: If the slot is configured with a SAS/SATA drive, the RAID controller card can manage the drive and allocate a number to the drive.
  • Page 67 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-26 Drive slot numbers (3.5" drives in I/O module 2) 2022-06-25...
  • Page 68 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-27 Drive slot numbers (2.5" drives in I/O module 2) Table 5-15 Slot numbers Drive Number Identified Drive Number Identified Drive No. by the iBMC by the RAID Controller...
  • Page 69 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Drive No. Drive Number Identified Drive Number Identified by the iBMC by the RAID Controller 2022-06-25...

  • Page 70: Drive Indicators

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Drive No. Drive Number Identified Drive Number Identified by the iBMC by the RAID Controller 5.5.3 Drive Indicators SAS/SATA Drive Indicators Figure 5-28 SAS/SATA drive indicators Table 5-16 SAS/SATA drive indicators...
  • Page 71 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description NVMe Drive Indicators Figure 5-29 NVMe drive indicators ⚫ If the VMD function is enabled and the latest VMD driver is installed, the NVMe drives support surprise hot swap. Table 5-17 NVMe drive indicators (VMD enabled)

  • Page 72: Raid Controller Card

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Activity Indicator Fault Indicator Description (Green) (Yellow) Blinking at 0.5 Hz The NVMe drive has completed the hot swap process and is removable. Steady on/Off Steady on The NVMe drive is faulty.

  • Page 73: Network

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description ⚫ Contact your local sales representative or see "Search Parts" in the Compatibility Checker to determine the components to be used. ⚫ For details about the RAID controller card, see V6 Server RAID Controller Card User Guide.

  • Page 74: Pcie Slots

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description 5.7.2 PCIe Slots PCIe Slots Figure 5-31 PCIe slots ⚫ I/O module 1 provides slots 1, 2, and 3. If a two-slot PCIe riser module is used, slot 1 is unavailable.
  • Page 75 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-32 PCIe riser module 1 ⚫ PCIe riser module 2 (for T4 GPU cards only) − It provides PCIe slots 1, 2, and 3 when being installed in I/O module 1.
  • Page 76 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description ⚫ PCIe riser module 3 (universal) − Provides PCIe slots 2 and 3 when installed in I/O module 1. − Provides PCIe slots 5 and 6 when installed in I/O module 2.
  • Page 77 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-35 PCIe riser module 4 ⚫ 2 x 2.5" drives + PCIe riser module − Provides PCIe slot 3 when installed in I/O module 1. − Provides PCIe slot 6 when installed in I/O module 2.
  • Page 78 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-36 2 x 2.5" drives + PCIe riser module ⚫ PCIe riser module 6 It provides PCIe slots 7 and 8 when being installed in I/O module 3. Figure 5-37 PCIe riser module 6 ⚫...

  • Page 79: Pcie Slot Description

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-38 PCIe riser module 7 5.7.3 PCIe Slot Description The PCIe slots mapping to a vacant CPU socket are unavailable. Table 5-20 PCIe slot description PCIe PCIe Conne Port...
  • Page 80 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description PCIe PCIe Conne Port Root Device Slot Standa ctor Port (B/D/F Slot Width Size (B/D/F Width specific cable ations used by mainbo ard: ⚫ Slot1 CPU 1 PCIe 3-sl Port1A...
  • Page 81 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description PCIe PCIe Conne Port Root Device Slot Standa ctor Port (B/D/F Slot Width Size (B/D/F Width dule with 2.5" driv card Slot3 CPU 1 PCIe ⚫ 3-sl Port2C 4A/04/ 4C/00/ FHHL ⚫...
  • Page 82 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description PCIe PCIe Conne Port Root Device Slot Standa ctor Port (B/D/F Slot Width Size (B/D/F Width ⚫ dule with 2.5" driv card Slot5 CPU 2 PCIe ⚫ 3-sl Port1A B0/02/...
  • Page 83 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description PCIe PCIe Conne Port Root Device Slot Standa ctor Port (B/D/F Slot Width Size (B/D/F Width ⚫ dule with 2.5" driv card ⚫ Slot7 CPU 2 PCIe 2-sl Port3A E2/02/0 E3/00/0 FHHL ⚫...

  • Page 84: Psus

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description PCIe PCIe Conne Port Root Device Slot Standa ctor Port (B/D/F Slot Width Size (B/D/F Width ⚫ The full-height full-length (FHFL) PCIe slots are compatible with FHFL PCIe cards, full-height half-length (FHHL) PCIe cards, and half-height half-length (HHHL) PCIe cards.

  • Page 85: Fan Modules

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description 5.9 Fan Modules ⚫ The server supports four fan modules. ⚫ The fan modules are hot-swappable. ⚫ N+1 redundancy is supported. That is, the server can work properly when a single fan fails.

  • Page 86: Boards

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description 5.10 Boards 5.10.1 Mainboard Figure 5-41 5288 V6 mainboard PCIe riser 2 slot (PCIE Debug pin (J103) RISER2/J51) Rear-drive backplane & BBU Screw-in RAID controller low-speed signal connector card connector (RAID (BACK HDD BP&BBU...
  • Page 87 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description (SLIMLINE7/J31) CONN/J109) Built-in storage expansion 2 x USB 3.0 ports (USB3.0 port (SD CARD/J87) CONN/J88) Rear VGA port (VGA Serial port (COM/J6020) CONN/J60) BMC management network BMC management board port (BMC_GE /J6019) LCD connector (LCD OCP 3.0 network adapter 1...

  • Page 88: Drive Backplane

    FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description (J102) FAN1/J67) Left mounting ear connector LP slimline 4 connector (LCIA BOARD/J106) (SLIMLINE4/J12) LP slimline 3 connector Power connector for the (SLIMLINE3/J85) built-in-drive backplane (INNER HDD PWR/J22) Drive backplane power...
  • Page 89 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description Figure 5-42 24 x 3.5" drive EXP backplane Indicator signal connector Mini-SAS HD connector (REAR BP0/J32) (PORT B/J29) Mini-SAS HD connector Mini-SAS HD connector (PORT A/J28) (REAR PORT/J31) Backplane signal connector...
  • Page 90 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description BP/J1) Backplane power connector (INNER HDD PWR/J2) Rear-Drive Backplane ⚫ 2 x 2.5" drive backplane Figure 5-44 2 x 2.5" drive backplane Power connector (BP Indicator signal cable PWR/J1) connector (REAR BP/J5)
  • Page 91 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description connector (REAR BP/J5) (REAR PORT/J2) Power connector (BP PWR/J1) ⚫ 4 x 2.5" drive backplane Figure 5-46 4 x 2.5" drive backplane LP slimline 4 connector Power connector (SLIM_4/J1001) (POWR/J2502)
  • Page 92 FusionServer 5288 V6 Server Technical White Paper 5 Hardware Description mini-SAS HD connector Backplane signal cable (PORT B/J4) connector (HDD BP/J6) mini-SAS HD connector Indicator signal cable (PORT A/J3) connector (REAR BP1/J8) Power connector (POWER/J1) ⚫ 12 x 3.5" drive EXP backplane Figure 5-48 12 x 3.5"...

  • Page 93: Product Specifications

    FusionServer 5288 V6 Server Technical White Paper 6 Product Specifications Product Specifications 6.1 Technical Specifications 6.2 Environmental Specifications 6.3 Physical Specifications 6.1 Technical Specifications Table 6-1 Technical specifications Component Specifications Form Factor 4U rack server ® Chipset Intel C621A Processor Supports one or two processors.
  • Page 94 FusionServer 5288 V6 Server Technical White Paper 6 Product Specifications Component Specifications − RDIMM and LRDIMM support − Max. 3200 MT/s memory speed − The DDR4 memory modules of different types (RDIMM and LRDIMM) and specifications (capacity, bit width, rank, and height) cannot be used together.
  • Page 95 FusionServer 5288 V6 Server Technical White Paper 6 Product Specifications Component Specifications The NVMe drives support: ⚫ Before using the VMD function, contact technical support engineers of the OS vendor to check whether the OS supports the VMD function. If yes, check whether the VMD driver needs to be manually installed and check the installation method.

  • Page 96: Environmental Specifications

    FusionServer 5288 V6 Server Technical White Paper 6 Product Specifications Component Specifications − One DB15 VGA port ⚫ Ports on the rear panel: − Two USB 3.0 ports − One DB15 VGA port − One RJ45 serial port − One RJ45 management network port ⚫...
  • Page 97 FusionServer 5288 V6 Server Technical White Paper 6 Product Specifications Category Specifications (ASHRAE Classes A1 to A3 compliant) Storage temperature (within three months): –30° C to +60° C ⚫ (–22° F to 140° F) Storage temperature (within six months): –15° C to +45° C ⚫...

  • Page 98: Physical Specifications

    FusionServer 5288 V6 Server Technical White Paper 6 Product Specifications Category Specifications accordance with ISO 7779 (ECMA 74) and declared in accordance with ISO 9296 (ECMA 109). ⚫ Idle: − LWAd: 6.56 Bels − LpAm: 51.2 dBA ⚫ Operating: −...
  • Page 99 FusionServer 5288 V6 Server Technical White Paper 6 Product Specifications Item Description NOTE See Figure 6-1 for methods in measuring physical dimensions of the chassis. Installation dimension ⚫ Requirements for cabinet installation: requirements Cabinet compliant with the International Electrotechnical Commission (IEC) 297 standard −...

  • Page 100: Software And Hardware Compatibility

    FusionServer 5288 V6 Server Technical White Paper 7 Software and Hardware Compatibility Software and Hardware Compatibility Use the Compatibility Checker to obtain information about the operating systems and hardware supported. ⚫ If incompatible components are used, the device may be abnormal. This fault is beyond the scope of technical support and warranty.

  • Page 101: Safety Instructions

    FusionServer 5288 V6 Server Technical White Paper 8 Safety Instructions Safety Instructions 8.1 Security 8.2 Maintenance and Warranty 8.1 Security General Statement ⚫ Comply with local laws and regulations when installing devices. These Safety Instructions are only a supplement. ⚫...
  • Page 102 FusionServer 5288 V6 Server Technical White Paper 8 Safety Instructions Figure 8-1 Safety work wear ⚫ Before touching a device, wear ESD clothing and gloves (or wrist strap), and remove any conductive objects (such as watches and jewelry). Figure 8-2 shows conductive objects that must be removed before you touch a device.
  • Page 103 FusionServer 5288 V6 Server Technical White Paper 8 Safety Instructions Figure 8-3 Wearing an ESD wrist strap ⚫ Exercise caution when using tools. ⚫ If the installation position of a device is higher than the shoulders of the installation personnel, use a vehicle such as a lift to facilitate installation. Prevent the device from falling down and causing personal injury or damage to the device.

  • Page 104: Maintenance And Warranty

    FusionServer 5288 V6 Server Technical White Paper 8 Safety Instructions ⚫ Transport each device in its original packaging. ⚫ If the original packaging is unavailable, package heavy, bulky parts (such as chassis and blades) and fragile parts (such as PCIe cards and optical modules) separately.

  • Page 105: System Management

    FusionServer 5288 V6 Server Technical White Paper 9 System Management System Management This product integrates the new-generation Intelligent Baseboard Management Controller (iBMC), which complies with Intelligent Platform Management Interface 2.0 (IPMI 2.0) specifications and provides reliable hardware monitoring and management.
  • Page 106 FusionServer 5288 V6 Server Technical White Paper 9 System Management ⚫ System maintenance interface − The virtual KVM and virtual media functions facilitate remote maintenance. − The iBMC supports out-of-band RAID monitoring and configuration to improve RAID configuration efficiency and management capabilities.

  • Page 107: Certifications

    FusionServer 5288 V6 Server Technical White Paper 10 Certifications Certifications Country/Region Certification Standards Europe WEEE 2012/19/EU Europe REACH EC NO. 1907/2006 Europe Safety: EN 62368-1:2014+A11:2017 EMC: EN 55032:2015+A11:2020 CISPR 32:2015+A1:2019 EN IEC 61000-3-2:2019+A1:2021 EN 61000-3-3:2013+A1:2019 EN 55035:2017+A11:2020 CISPR 35:2016 EN 55024:2010+A1:2015 CISPR 24:2010+A1:2015 ETSI EN 300 386 V1.6.1:2012...
  • Page 108 FusionServer 5288 V6 Server Technical White Paper 10 Certifications Country/Region Certification Standards EN 55032:2015+A11:2020 CISPR 32:2015+A1:2019 EN IEC 61000-3-2:2019+A1:2021 EN 61000-3-3:2013+A1:2019 EN 55035:2017+A11:2020 CISPR 35:2016 EN 55024:2010+A1:2015 CISPR 24:2010+A1:2015 ETSI EN 300 386 V1.6.1:2012 ETSI EN 300 386 V2.1.1:2016 RoHS:...

  • Page 109: A Appendix

    FusionServer 5288 V6 Server Technical White Paper A Appendix Appendix A.1 Chassis Label The label information and location are for reference only. For details, see the actual product. A.1.1 On the Front Top Figure A-1 Chassis head label Nameplate Certificate...
  • Page 110 FusionServer 5288 V6 Server Technical White Paper A Appendix device. A.1.1.1 Nameplate Figure A-2 Nameplate example Table A-1 Nameplate description Description Server Model For details, see A.4 Nameplate. Device names Power Supply Requirements Vendor Information Authentication ID A.1.1.2 Certificate Figure A-3 Sample certificate of conformity...
  • Page 111 FusionServer 5288 V6 Server Technical White Paper A Appendix Table A-2 Certificate of conformity description Description Order NOTE For details, see Figure A-4 and Table A-3. QC inspector Production date No. Barcode Figure A-4 Sample certificate number Table A-3 Certificate No. Description Description "P", fixed...
  • Page 112 FusionServer 5288 V6 Server Technical White Paper A Appendix Description ⚫ Letters A to H indicate 10 to 17:00. ⚫ Letters J to N indicate 18 to 22:00. ⚫ Letters P to Q indicate 23 to 24:00. Serial number (2 digits) Manufacturing serial number (5 digits).
  • Page 113 FusionServer 5288 V6 Server Technical White Paper A Appendix A.1.2 Chassis Tail Label Figure A-6 Chassis tail label For details about the warning label, see Server Security Information. A.1.3 Chassis Internal Label Figure A-7 Chassis internal label ⚫ The quick guide is located on the inside of the chassis cover. It describes how to remove the mainboard components, important components of the chassis, precautions, and QR codes of technical resources.
  • Page 114 FusionServer 5288 V6 Server Technical White Paper A Appendix Figure A-8 SN example Table A-5 SN description Description ESN ID (two characters), which can only be 21. Material ID (eight characters), that is, the processing code. Vendor code (two characters), that is, the code of the processing place.
  • Page 115 FusionServer 5288 V6 Server Technical White Paper A Appendix Configuration Maximum Maximum Maximum Operating Operating Operating Temperature 30° C Temperature 35° C Temperature 40° C (86° F) (95° F) (104° F) (with built-in 8362/8368/8380 /6346/6348/6354/8 drives) processors are not 351N/8352S/8352 supported.
  • Page 116 FusionServer 5288 V6 Server Technical White Paper A Appendix Configuration Maximum Maximum Maximum Operating Operating Operating Temperature 30° C Temperature 35° C Temperature 40° C (86° F) (95° F) (104° F) whose capacity is are not supported. 100Gbit/s rate or...
  • Page 117 FusionServer 5288 V6 Server Technical White Paper A Appendix Sensor Description Component PCH Temp PCH bridge temperature Mainboard CPUN Core Rem CPU core temperature CPUN N indicates the CPU number. The value is 1 or 2. CPUN DTS Difference between the...
  • Page 118 FusionServer 5288 V6 Server Technical White Paper A Appendix Sensor Description Component number. The value is 1 or 2. CPUN P1V8 CPU P1V8 voltage Mainboard N indicates the CPU number. The value is 1 or 2. CPUN VCCIO CPU VCCIO voltage...
  • Page 119 FusionServer 5288 V6 Server Technical White Paper A Appendix Sensor Description Component number. The value ranges FANN R Status from 1 to 4. DIMMN DIMM status DIMM N N indicates the DIMM slot number. RTC Battery RTC battery status. An...
  • Page 120 FusionServer 5288 V6 Server Technical White Paper A Appendix Sensor Description Component number. The value is 1 or 2. PSN Fan Status PSU fan fault status PSU N N indicates the PSU number. The value is 1 or 2. PSN Temp Status...
  • Page 121 FusionServer 5288 V6 Server Technical White Paper A Appendix Sensor Description Component BMC management chip PS$ IIn PSU input current Power supply unit (PSU) PS$ IOut PSU output current Power supply unit (PSU) PS$ Pout PSU output power Power supply unit (PSU)
  • Page 122 FusionServer 5288 V6 Server Technical White Paper A Appendix Sensor Description Component restart. Check the background logs. ACPI State ACPI status SysFWProgress Software process and system startup errors SysRestart Cause of system restart Boot Error Boot error CPU Usage CPU usage.

  • Page 123: B Glossary

    FusionServer 5288 V6 Server Technical White Paper B Glossary Glossary B.1 A-E The baseboard management controller (BMC) complies with the Intelligent Platform Management Interface (IPMI). It collects, processes, and stores sensor signals, and monitors the operating status of components. The BMC provides the...
  • Page 124 FusionServer 5288 V6 Server Technical White Paper B Glossary hot swap Replacing or adding components without stopping or shutting down the system. B.3 K-O A hardware device that provides public video, keyboard and mouse (KVM). B.4 P-T panel An external component (including but not limited to ejector levers, indicators, and ports) on the front or rear of the server.
  • Page 125 FusionServer 5288 V6 Server Technical White Paper B Glossary system event log Event records stored in the system used for subsequent fault (SEL) diagnosis and system recovery. B.5 U-Z A unit defined in International Electrotechnical Commission (IEC) 60297-1 to measure the height of a cabinet, chassis, or subrack.

  • Page 126: C Acronyms And Abbreviations

    FusionServer 5288 V6 Server Technical White Paper C Acronyms and Abbreviations Acronyms and Abbreviations C.1 A-E alternating current Advanced Encryption Standard New Instruction Set Address Resolution Protocol Advanced Vector Extensions backup battery unit BIOS Basic Input/Output System baseboard management controller...
  • Page 127 FusionServer 5288 V6 Server Technical White Paper C Acronyms and Abbreviations direct current DDR4 Double Data Rate 4 DDDC double device data correction DEMT Dynamic Energy Management Technology DIMM dual in-line memory module DRAM dynamic random-access memory digital video disc...
  • Page 128 FusionServer 5288 V6 Server Technical White Paper C Acronyms and Abbreviations high availability hard disk drive high-performance computing HTTP Hypertext Transfer Protocol HTTPS Hypertext Transfer Protocol Secure iBMC intelligent baseboard management controller Industry Canada ICMP Internet Control Message Protocol Internet Data Center...
  • Page 129 FusionServer 5288 V6 Server Technical White Paper C Acronyms and Abbreviations LRDIMM load-reduced dual in-line memory module light emitting diode LAN on motherboard media access control module management controller next business day NC-SI Network Controller Sideband Interface Open Compute Project C.4 P-T...
  • Page 130 FusionServer 5288 V6 Server Technical White Paper C Acronyms and Abbreviations reliability, availability and serviceability RDIMM registered dual in-line memory module REACH Registration Evaluation and Authorization of Chemicals RJ45 registered jack 45 RoHS Restriction of the Use of Certain Hazardous Substances in...
  • Page 131 FusionServer 5288 V6 Server Technical White Paper C Acronyms and Abbreviations Trusted Execution Technology TransFlash module TFTP Trivial File Transfer Protocol TCP offload engine trusted platform module C.5 U-Z UDIMM unbuffered dual in-line memory module UEFI Unified Extensible Firmware Interface unit identification light Underwriter Laboratories Inc.

This manual is also suitable for:

02313lsk

Table of Contents
