xFusion Digital Technologies FusionServer 2488 V5 Manual

Technical white paper
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FusionServer 2488 V5 Server
Technical White Paper
Issue
06
Date
2023-12-12
xFusion Digital Technologies Co., Ltd.

Advertisement

Table of Contents
loading

Related Manuals for xFusion Digital Technologies FusionServer 2488 V5

Summary of Contents for xFusion Digital Technologies FusionServer 2488 V5

  • Page 1 FusionServer 2488 V5 Server Technical White Paper Issue Date 2023-12-12 xFusion Digital Technologies Co., Ltd.
  • Page 2 Notice In this document, "xFusion" is used to refer to "xFusion Digital Technologies Co., Ltd." for concise description and easy understanding, which does not mean that "xFusion" may have any other meaning. Any "xFusion" mentioned or described hereof may not be understood as any meaning other than "xFusion Digital Technologies Co., Ltd.", and xFusion Digital Technologies Co., Ltd.

  • Page 3: About This Document

    Technical White Paper About This Document About This Document Purpose This document describes the FusionServer 2488 V5 rack server in terms of features, structure, specifications, and component hardware and software compatibility. Intended Audience This document is intended for pre-sales engineers.
  • Page 4 U.2 drives. ● Updated CE, UKCA, and CCC certification standards in Certifications. ● Added A.1 Chassis Label. 2022-03-18 Added Certifications [2488 V5-BP]. 2021-12-20 This issue is the first official release. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 5: Table Of Contents

    5.4.1.6 Memory Protection Technologies......................27 5.5 Storage..............................28 5.5.1 Drive Configurations..........................28 5.5.2 Drive Numbering.............................29 5.5.3 Drive Indicators............................29 5.5.4 RAID Controller Card..........................32 5.6 Network..............................32 5.6.1 LOMs ..............................32 5.7 I/O Expansion............................35 Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 6 A.2 Product SN..............................69 A.3 Operating Temperature Limitations......................70 A.4 Nameplate ..............................71 A.5 RAS Features............................72 A.6 Sensor List..............................74 B Glossary......................... 80 B.1 A-E................................80 B.2 F-J................................80 B.3 K-O................................81 Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 7 FusionServer 2488 V5 Server Technical White Paper Contents B.4 P-T................................81 B.5 U-Z................................82 C Acronyms and Abbreviations..................83 C.1 A-E................................83 C.2 F-J................................84 C.3 K-O................................86 C.4 P-T................................86 C.5 U-Z................................88 Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 8: Product Introduction

    1 Product Introduction Product Introduction FusionServer 2488 V5 (2488 V5) is a 2U 4-socket rack server developed for Internet data center (IDC), cloud computing, enterprise, and telecom service applications. The 2488 V5 is ideal for applications such as databases, cloud computing, virtualization, and in-memory computing.

  • Page 9: Features

    The server supports double data rate 4 (DDR4) registered dual in-line memory modules (RDIMMs) and load-reduced DIMMs (LRDIMMs) with error checking and correcting (ECC). A server fully configured with thirty-two 2933 MT/s Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 10 Lockable server chassis panel ensures security of local data. ● Intel Execute Disable Bit (EDB) function prevents certain types of malicious buffer overflow attacks when working with a supported OS. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 11 Low-voltage Intel Xeon Scalable processors consume less energy, ideally suited for data centers and telecommunications environments constrained by power and thermal limitations. ● SSDs consume 80% less power than HDDs. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 12: Physical Structure

    Power supply unit (PSU) PSU backplane Cable organizer Chassis Air duct Drive Backplane Fan module bracket Drive DVD drive (or LCD) Fan module VGA board Processor Mainboard TPM/TCM Memory Heat sink Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 13: Logical Structure

    The CPUs (processors) interconnect with each other through three UPI links at a speed of up to 10.4 GT/s. ● The server provides nine standard PCIe 3.0 slots of various specifications. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 14 The server provides low-speed I/O ports, such as the VGA port, USB 3.0 ports, and serial ports (RJ45). ● The server provides four LOM ports, including two 10GE optical ports and two GE electrical ports. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 15: Hardware Description

    5.5 Storage 5.6 Network 5.7 I/O Expansion 5.8 PSUs 5.9 Fans 5.10 LCD 5.11 Boards 5.1 Front Panel 5.1.1 Appearance ● 8 x 2.5" SAS/SATA drive configuration Figure 5-1 Front view Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 16: Indicators And Buttons

    Slide-out label plate (with an SN label) 5.1.2 Indicators and Buttons Indicator and Button Positions ● 8 x 2.5" SAS/SATA drive configuration Figure 5-4 Indicators and buttons on the front panel Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 17 UID button/indicator Power button/indicator NMI button Note: There are eight NVMe drives (four NVMe drives on each of the left and right sides). ● 25 x 2.5" SAS/SATA drive configuration Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 18 Fault ● ---: The device is operating properly. diagnosis LED ● Error code: A component is faulty. For details about error codes, see the FusionServer Rack Server iBMC Alarm Handling. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 19 ● Blinking red at 1 Hz: A major alarm has been generated on the system. ● Blinking red at 5 Hz: A critical alarm has been generated on the system. ● Steady green: The device is operating properly. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 20: Ports

    5.1.3 Ports Port Positions ● 8 x 2.5" SAS/SATA drive configuration Figure 5-7 Ports on the front panel USB 2.0 ports USB 3.0 port Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 21 Type Note Description Quantity VGA port DB15 Used to connect a display terminal, such as a monitor or KVM. USB port USB 2.0 Used to connect to a USB device. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 22: Rear Panel

    5.2 Rear Panel 5.2.1 Appearance Figure 5-10 Rear view PCIe slot 1 PCIe slot 2 PCIe slot 3 PCIe slot 4 PCIe slot 5 PCIe slot 6 PSU 1 PSU 2 Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 23: Indicators

    UID Indicator PSU indicator Indicator Description Table 5-3 Description of indicators on the rear panel Indicator Description LOM port indicator For details, see 5.6.1 LOMs Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 24 ● Steady green: The network port is properly connected. management network port Data transmission ● Off: No data is being transmitted. status indicator of the ● Blinking yellow: Data is being transmitted. management network port Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 25: Ports

    10GE LOM service port (optical) and GE service port 1000BASE-T (electrical). For details, see 5.6.1 LOMs VGA port DB15 Used to connect a display terminal, such as a monitor or KVM. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 26: Processor

    If two processors are required, install them in sockets CPU1 and CPU2. ● The same model of processors must be used in a server. ● Contact your local sales representative or use the Compatibility Checker determine the components to be used. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 27: Memory

    Figure 5-13 Processor positions 5.4 Memory 5.4.1 DDR4 Memory 5.4.1.1 Memory Identifier You can determine the memory module properties based on the label attached to the memory module. Figure 5-14 Memory identifier Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 28: Memory Subsystem Architecture

    Table 5-5 Memory channels Memory Channel Memory Slot CPU 1 A (primary) DIMM000(A) DIMM001(G) DIMM010(B) Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 29 DIMM140(E) DIMM150(F) CPU 3 A (primary) DIMM200(A) DIMM201(G) DIMM210(B) DIMM220(C) D (primary) DIMM230(D) DIMM231(H) DIMM240(E) DIMM250(F) CPU 4 A (primary) DIMM300(A) DIMM301(G) DIMM310(B) DIMM320(C) D (primary) DIMM330(D) DIMM331(H) DIMM340(E) DIMM350(F) Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 30: Memory Compatibility

    Number of DIMMs supported by each channel ≤ Number of ranks supported by each memory channel/Number of ranks supported by each DIMM ● A memory channel supports more than eight ranks for LRDIMMs. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 31: Dimm Installation Rules

    Observe the following when configuring DDR4 memory modules in specific operating mode: – Memory sparing mode ▪ Comply with the general installation guidelines. ▪ Each memory channel must have a valid online spare configuration. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 32: Memory Installation Positions

    NO TICE At least one DDR4 DIMM must be installed in the memory slots corresponding to CPU 1. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 33 FusionServer 2488 V5 Server Technical White Paper 5 Hardware Description Figure 5-15 Memory slots Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 34: Memory Protection Technologies

    Figure 5-16 DDR4 memory installation guidelines (2 processors) Figure 5-17 DDR4 memory installation guidelines (4 processors) 5.4.1.6 Memory Protection Technologies The following memory protection technologies are supported: ● ● Full mirroring ● Address range mirroring Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 35: Storage

    ● PCIe RAID controller SATA) support only SAS/ card: must be installed SATA drives. in slot 7. Note:Contact your local sales representative or use the Compatibility Checker determine the components to be used. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 36: Drive Numbering

    24 x 2.5" (16 x SAS/SATA + 8 x NVMe) drive configuration Figure 5-19 Drive numbering ● 25 x 2.5" drive configuration (25 x SAS/SATA) Figure 5-20 Drive numbering 5.5.3 Drive Indicators SAS/SATA Drive Indicators Figure 5-21 SAS/SATA drive indicators Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 37 The NVMe drive is working properly. Blinking at 2 Hz Data is being read from or written to the NVMe SSD. Steady on Blinking at 2 Hz The NVMe drive is being located. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 38 ● Off: The M.2 FRU is running properly. ● Blinking yellow: The M.2 FRU is being located, or RAID is being rebuilt. ● Steady yellow: The M.2 FRU is faulty or not detected. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 39: Raid Controller Card

    Supported Rates Not Negotiatio Rates Supported n Mode X722 10GE Auto- 10000M 10/100/100 optical port negotiation 10,000 Mbit/s (full duplex) Auto- 1000M 10/100M electrical negotiation port 1000 Mbit/s (full duplex) Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 40 WebUI. Figure 5-24 LOM port GE electrical port (LOM GE electrical port (LOM port 1) port 2) 10GE optical port (LOM 10GE optical port (LOM port 4) port 3) Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 41 10GE optical port Data transmission rate ● Off: The network port is not connected. indicator for a 10GE ● Steady green: The data transmission rate is 10 Gbit/s. optical port Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 42: I/O Expansion

    When IB cards are used to build an IB network, ensure that the IPoIB modes of the IB cards at both ends of the network are the same. For details, contact technical support. 5.7.2 PCIe Slots PCIe Slots Figure 5-26 PCIe slots Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 43: Pcie Slot Description

    CPU 3 PCIe Port2A 0xA2/0/ HHHL Slot 7 CPU 1 PCIe Port2A 0x24/0/ HHHL Slot 8 CPU 3 PCIe Port3C 0xB1/2/ HHHL Slot 9 CPU 3 PCIe Port1A 0x83/0/ HHHL Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 44: Psus

    When one or two 1500 W AC Platinum PSUs are configured, When the input voltage ranges from 100 V AC to 127 V AC, the output power decreases to 1000 W. Figure 5-27 PSU positions Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 45: Fans

    IP address of the iBMC management network port on the server. The LCD and the server iBMC form an LCD subsystem. The LCD directly obtains device information from the iBMC. The LCD subsystem does not store device data. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 46 Displays the IP address and MAC address of the iBMC management network port, MAC addresses of host LOM ports, device SNs, asset information, and firmware version. Setting Sets the IP address of the iBMC management network port. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 47: Lcd Software Environment

    FusionServer 2488 V5 Server Technical White Paper 5 Hardware Description For details about how to use the LCD, see FusionServer 2488 V5 Server LCD User Guide. 5.10.1 LCD Software Environment 5.11 Boards 5.11.1 Mainboard Figure 5-31 2488 V5 mainboard UID Indicator...
  • Page 48 Left mounting ear (corresponding to CPU 3) connector (LEFT EAR CONN BOARD/J115) Drive backplane power PSU backplane power connector (BP PWR/J128) connectors (J209/J210) PSU backplane signal VROC key port (J144) connector (J208) Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 49: Drive Backplane

    (J24) ● 24 x 2.5" drive EXP backplane (16 x SAS/SATA + 8 x NVMe) Figure 5-33 24 x 2.5" drive EXP backplane (16 x SAS/SATA + 8 x NVMe) Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 50 Figure 5-34 25 x 2.5" drive EXP backplane (25 x SAS/SATA) SAS cable connector SAS cable connector (PORT A/J28) (PORT B/J29) SAS cable connector Backplane signal cable (J31) connector (J1) Power connector (J24) Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 51: Psu Backplane

    FusionServer 2488 V5 Server Technical White Paper 5 Hardware Description 5.11.3 PSU Backplane Figure 5-35 2488 V5 PSU backplane Power connector (J303) Power connector (J304) Signal connector (J306) Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 52: Product Specifications

    ● Max. 3.8 GHz ● Min. 1.375 MB L3 cache per core ● Max. 205 W TDP NOTE The preceding information is for reference only. Use the Compatibility Checker to obtain specific information. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 53 (RDIMM and LRDIMM) and specifications (capacity, bit width, rank, and height) cannot be used together. NOTE The preceding information is for reference only. Use the Compatibility Checker to obtain specific information. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 54 RAID controller cards supported. – The RAID controller card supports RAID configuration, RAID level migration, and drive roaming. – The PCIe RAID controller card occupies one standard PCIe slot. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 55 IPoIB modes of the IB cards at both ends of the network are the same. For details, contact technical support. NOTE The preceding information is for reference only. Use the Compatibility Checker to obtain specific information. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 56 VGA port is connected to a monitor, the display effect may be affected. System management ● Supports UEFI. ● Supports iBMC. ● Supports NC-SI. ● Supports integration with third-party management systems. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 57: Environmental Specifications

    ● Storage humidity (within six months): 8% to 80% ● Storage humidity (within one year): 20% to 75% ● Maximum change rate: 20%/h Air volume ≥ 198 cubic feet per minute (CFM) Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 58 – LpAm: 38.5 dBA ● Operating: – LWAd: 6.1 Bels – LpAm: 45.2 dBA NOTE The noise generated during operation varies depending on the server configuration, load, and ambient temperature. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 59: Physical Specifications

    86.1 mm x 447 mm x 748 mm (3.39 in. x 17.60 in. x 29.45 in.) Figure 6-1 Physical dimensions NOTE Figure 6-1 for methods in measuring physical dimensions of the chassis. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 60 ● Packaging materials: 5 kg (11.02 lb) Energy consumption The power consumption parameters vary with server configurations, including the configurations complying with energy-related products (ErP) requirements. Use the Power Calculator to obtain specific information. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 61: Software And Hardware Compatibility

    ● If the customer has requirements on hardware performance consistency, specify the specific configuration requirements (for example, specific drive models, RAID controller cards, or firmware versions) in the pre-sales phase. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 62: Safety Instructions

    Discontinue any dangerous operations and take protective measures. Report anything that could cause personal injury or device damage to a project supervisor. ● Do not move devices or install racks and power cables in hazardous weather conditions. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 63 Tighten the strap buckle and ensure that the ESD wrist strap is in contact with your skin. Insert the ground terminal attached to the ESD wrist strap into the jack on the grounded rack or chassis. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 64 Transportation precautions include but are not limited to: ● The logistics company engaged to transport the device must be reliable and comply with international standards for transporting electronics. Ensure that the Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 65: Maintenance And Warranty

    For more information about safety instructions, see Server Safety Information. 8.2 Maintenance and Warranty For details about the maintenance policy, visit Customer Support Service. For details about the warranty policy, visit Warranty. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 66: System Management

    Integrates with any standard management system through the following interfaces: ● IPMI ● CLI ● HTTPS ● SNMP ● Redfish Fault Detection Detects and accurately locates faults in a field replaceable unit (FRU). Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 67 IPv6 Supports IPv6 to help build an all-IPv6 environment. Network Controller Supports NC-SI, allowing access to the iBMC Sideband Interface (NC-SI) through the service network port. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 68: Certifications

    EN IEC 61000-3-2:2019+A1:2021 EN 61000-3-3:2013+A1:2019 EN 55035:2017+A11:2020 CISPR 35:2016 EN 55024:2010+A1:2015 CISPR 24:2010+A1:2015 ETSI EN 300 386 V1.6.1:2012 ETSI EN 300 386 V2.1.1:2016 RoHS: EN IEC 63000:2018 ErP: Commission Regulation(EU) 424/2019 Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 69 RoHS: BS EN IEC 63000:2018 ErP: Commission Regulation(EU) 424/2019 China GB 17625.1-2022 GB 4943.1-2022 GB/T 9254.1-2021 (Class A) China RoHS SJ/T-11364 GB/T 26572 Japan VCCI VCCI 32-1 Global IEC 62368-1:2014 Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 70: Waste Product Recycling

    FusionServer 2488 V5 Server Technical White Paper 11 Waste Product Recycling Waste Product Recycling If product users need product recycling service provided by xFusion after products are scrapped, contact technical support for services. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 71: A Appendix

    The label information and location are for reference only. For details, see the actual product. A.1.1 On the Front Top Figure A-1 Chassis head label Nameplate Certificate Quick access tag NOTE For details, see A.2 Product Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 72: Nameplate

    A.1.1.1 Nameplate Figure A-2 Nameplate example Table A-1 Nameplate description Description Server Model For details, see A.4 Nameplate Device names Power Supply Requirements Enterprise Standard No. Vendor Information Authentication ID Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 73: Certificate

    The value for this digit is P, which is fixed. The value for this digit is Z, which is fixed. ● Y: indicates a server. ● B: indicates a semi-finished server. ● N: indicates a spare part. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 74: Sample Quick Access Tags

    A.1.1.3 Sample Quick Access Tags Figure A-5 Sample quick access tags Table A-4 Quick access tab description Description IP address of the iBMC management network port Subnet mask of the iBMC management network port Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 75: Chassis Tail Label

    A.1.2 Chassis Tail Label Figure A-6 Chassis tail label NO TE For details about the warning label, see Server Safety Information. A.1.3 Chassis Internal Label Figure A-7 Chassis internal label Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 76: Product Sn

    ESN ID (two characters), which can only be 21. Material ID (eight characters), that is, the processing code. Vendor code (two characters), that is, the code of the processing place. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 77: Operating Temperature Limitations

    ● Options not ● Options not supported: supported: – NVMe – NVMe cards in cards in slots 1 slots 1 to 6 to 6 – GPU – GPU cards cards Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 78: Nameplate

    If a single fan is faulty, the maximum operating temperature is 5°C (9°F) lower than the rated value. A.4 Nameplate Certified Model Usage Restrictions H24M-05 Global 2488 V5 Global Note: The nameplate depends on the actual product. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 79: Ras Features

    PCIe Advanced Error Provides a PCIe advanced error Reporting reporting mechanism to improve server serviceability. Intel UPI Link Level Retry Provides a retry mechanism to improve the reliability of UPI links. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 80 BIOS-based Predictive The OS takes the lead. The BIOS Failure Analysis (PFA) provides information about physical memory error units. The OS tracks, predicts, and handles the errors. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 81: Sensor List

    U4351 and U4355 on the mainboard. CPU 4: Components in positions U4359 and U4363 on the mainboard. N indicates the CPU number. The value ranges from 1 to 4. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 82 PSU. N indicates the PSU number. The value is 1 or PSN Temp Status PSU presence PSN Status PSU status Power Button Power button Right mounting ear UID Button UID button status Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 83 Security log full or clearing events CPU Usage CPU usage Memory Usage Memory usage PCIeN Card BBU BBU fault or low voltage on a PCIe card BMC Time Hopping Time hopping Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 84 Standby 1.5V Mainboard standby 1.5 V voltage Standby 1.0V Mainboard standby 1.0 V voltage CPUN VCore 1.8 V CPU voltage CPUN DDR VDDQ CPU DIMM voltage CPUN DDR VDDQ2 Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 85 M.2 drives of the RAID controller card PCIe Status PCIe status PwrOn TimeOut Power-on timeout PwrCap Status Power capping status HDD Backplane Drive backplane entity presence HDD BP Status Drive backplane health status Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 86 (N 1. 2. 3.4 ) System Notice Hot restart notice. Collect error information for the fault diagnosis program. System Error System suspension or restart. Check the background logs Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 87: B Glossary

    Ethernet standards. It is compatible with 10M and 100M Ethernet and complies with IEEE 802.3z standards. hot swap Replacing or adding components without stopping or shutting down the system. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 88: K-O

    A special computer that provides services for clients over a network. system event log Event records stored in the system used for subsequent (SEL) fault diagnosis and system recovery. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 89: U-Z

    A unit defined in International Electrotechnical Commission (IEC) 60297-1 to measure the height of a cabinet or chassis. 1 U = 44.45 mm UltraPath A point-to-point processor interconnect developed by Interconnect (UPI) Intel. Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 90: C Acronyms And Abbreviations

    Advanced Encryption Standard New Instruction Set Address Resolution Protocol Advanced Vector Extensions backup battery unit BIOS Basic Input/Output System calendar day Conformite Europeenne Common Information Model command-line interface Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 91: F-J

    Execute Disable Bit European Efficiency enterprise resource planning European Telecommunication Standards C.2 F-J FB-DIMM Fully Buffered DIMM Fiber Channel Federal Communications Commission FCoE Fibre Channel over Ethernet File Transfer Protocol Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 92 Institute of Electrical and Electronics Engineers IGMP Internet Group Message Protocol IOPS input/output operations per second Internet Protocol intelligent power capability IPMB Intelligent Platform Management Bus IPMI Intelligent Platform Management Interface Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 93: K-O

    NC-SI Network Controller Sideband Interface C.4 P-T PCIe Peripheral Component Interconnect Express power distribution unit physical layer PMBUS power management bus power OK pulse-width modulation Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 94 SMTP Simple Mail Transfer Protocol SNMP Simple Network Management Protocol serial over LAN SONCAP Standards Organization of Nigeria-Conformity Assessment Program solid-state drive Streaming SIMD Extensions Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.

  • Page 95: U-Z

    Unified Extensible Firmware Interface unit identification light Underwriter Laboratories Inc. Universal Serial Bus VCCI Voluntary Control Council for Interference by Information Technology Equipment Video Graphics Array VLAN virtual local area network voltage regulator-down Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
  • Page 96 FusionServer 2488 V5 Server Technical White Paper C Acronyms and Abbreviations WEEE waste electrical and electronic equipment WSMAN Web Service Management Issue 06 (2023-12-12) Copyright © xFusion Digital Technologies Co., Ltd.
