  • Page 1 FusionServer 2288 V5 Server Technical White Paper Issue Date 2022-11-11 xFusion Digital Technologies Co., Ltd.
  • Page 2 Notice In this document, "xFusion" is used to refer to "xFusion Digital Technologies Co., Ltd." for concise description and easy understanding, which does not mean that "xFusion" may have any other meaning. Any "xFusion" mentioned or described hereof may not be understood as any meaning other than "xFusion Digital Technologies Co., Ltd.", and xFusion Digital Technology Co., Ltd.

  • Page 3: Table Of Contents

    FusionServer 2288 V5 Server Technical White Paper Contents Contents About This Document ........................v 1 Product Introduction ........................7 2 Features ............................8 3 Physical Structure ........................11 4 Logical Structure ......................... 13 5 Hardware Description ........................ 14 5.1 Front Panel .................................. 14 5.1.1 Appearance ................................
  • Page 4 FusionServer 2288 V5 Server Technical White Paper Contents 5.7 I/O Expansion ................................39 5.7.1 PCIe Cards ................................39 5.7.2 PCIe Slots ................................39 5.7.3 PCIe Slot Description .............................. 42 5.8 PSUs ................................... 44 5.9 Fans ..................................... 45 5.10 Boards ..................................46 5.10.1 Mainboard ................................

  • Page 5: About This Document

    Technical White Paper About This Document About This Document Overview This document describes the FusionServer 2288 V5 rack server in terms of features, structure, specifications, and component hardware and software compatibility. Intended Audience This document is intended for pre-sales engineers.
  • Page 6 FusionServer 2288 V5 Server Technical White Paper About This Document Change History Issue Date Description 2022-11-11 ⚫ Updated 6.3 Physical Specifications . ⚫ Updated 8.1 Security. 2022-08-12 Optimized 6.3 Physical Specifications . 2022-06-25 ⚫ Added a figure that shows how to measure dimensions.

  • Page 7: Product Introduction

    1 Product Introduction Product Introduction FusionServer 2288 V5 (2288 V5) is a new-generation 2U 2-socket rack server designed for Internet, Internet Data Center (IDC), cloud computing, enterprise, and telecom applications. The 2288 V5 is ideal for IT core services, cloud computing, high-performance computing, distributed storage, big data processing, enterprise or telecom applications, and other complex workloads.

  • Page 8: Features

    FusionServer 2288 V5 Server Technical White Paper 2 Features Features Performance and Scalability ® ® ⚫ Powered by Intel Xeon Scalable Skylake or Cascade Lake processors, the server provides up to 20 cores, 3.8 GHz frequency, a 38.5 MB L3 cache, and two 10.4 GT/s UPI links between the processors which deliver supreme processing performance.
  • Page 9 FusionServer 2288 V5 Server Technical White Paper 2 Features ® ® ⚫ With Intel integrated I/O, the Intel Xeon Scalable processors integrate the PCIe 3.0 controller to shortens I/O latency and improve overall system performance. ⚫ The server supports up to six PCIe 3.0 slots.
  • Page 10 FusionServer 2288 V5 Server Technical White Paper 2 Features Energy Efficiency ⚫ The 80 Plus Platinum power supply units (PSUs) of multiple power ratings provide 94% power efficiency at 50% load. ⚫ The server supports active/standby power supplies and high-voltage DC (HVDC) for improved power supply efficiency.

  • Page 11: Physical Structure

    FusionServer 2288 V5 Server Technical White Paper 3 Physical Structure Physical Structure Figure 3-1 Physical structure of a 2288 V5 with 12 x 3.5" drives (example) I/O module 1 I/O module 2 PSUs Filler panel Chassis Supercapacitor holder Air duct...
  • Page 12 FusionServer 2288 V5 Server Technical White Paper 3 Physical Structure (TPM) Processors Heat sinks 2022-11-11...

  • Page 13: Logical Structure

    FusionServer 2288 V5 Server Technical White Paper 4 Logical Structure Logical Structure Figure 4-1 2288 V5 logical structure ® ® ⚫ The server supports one or two Intel Xeon Scalable processors. ⚫ The server supports up to 16 memory modules.

  • Page 14: Hardware Description

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Hardware Description 5.1 Front Panel 5.2 Rear Panel 5.3 Processor 5.4 Memory 5.5 Storage 5.6 Network 5.7 I/O Expansion 5.8 PSUs 5.9 Fans 5.10 Boards 5.1 Front Panel 5.1.1 Appearance ⚫...

  • Page 15: Indicators And Buttons

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description ⚫ 12 x 3.5" drive configuration Figure 5-2 Front view Drives Slide-out label plate (with an SN label) ⚫ 25 x 2.5" drive configuration Figure 5-3 Front view Drives Slide-out label plate (with an SN label) 5.1.2 Indicators and Buttons...
  • Page 16 FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Figure 5-4 Indicators and buttons on the front panel 10GE LOM port connection GE LOM port 1 connection status indicator status indicator NOTE The 10GE indicator is unavailable. GE LOM port 2 connection...
  • Page 17 FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Figure 5-6 Indicators and buttons on the front panel 10GE LOM port connection GE LOM port 1 connection status indicator status indicator NOTE The 10GE indicator is unavailable. GE LOM port 2 connection...

  • Page 18: Ports

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Silkscreen Indicator/Butt Description ⚫ When the device is powered on, holding down this button for 6 seconds will forcibly power off the device. ⚫ When the power indicator is steady yellow, you can press this button to power on the device.
  • Page 19 FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Figure 5-7 Ports on the front panel USB 2.0 ports ⚫ 12 x 3.5" drive configuration Figure 5-8 Ports on the front panel USB 2.0 ports ⚫ 25 x 2.5" drive configuration Figure 5-9 Ports on the front panel USB 2.0 ports...

  • Page 20: Rear Panel

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Port Type Quantity Description functions properly. The server may operate abnormally if an abnormal USB device is connected. 5.2 Rear Panel 5.2.1 Appearance Figure 5-10 Rear view I/O module 1...

  • Page 21: Indicators

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description 5.2.2 Indicators Indicator Positions Figure 5-11 Indicators on the rear panel LOM port indicator Management network port data transmission status indicator Management network port UID Indicator connection status indicator PSU Indicator...

  • Page 22: Ports

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Indicator Description ⚫ Short-circuit protection ⚫ Device failure (excluding failure of all devices) UID Indicator The UID indicator helps identify and locate a device. ⚫ Off: The device is not being located.

  • Page 23: Processor

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Port Type Quantity Description For details, see 5.6.1 LOMs . VGA port DB15 Used to connect a display terminal, such as a monitor or KVM. Serial port RJ45 Default operating system serial port used for debugging.

  • Page 24: Memory

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Figure 5-13 Processor positions 5.4 Memory 5.4.1 DDR4 Memory 5.4.1.1 Memory Identifier You can determine the memory module properties based on the label attached to the memory module. Figure 5-14 Memory identifier...

  • Page 25: Memory Subsystem Architecture

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Callout Description Definition ⚫ Capacity of the memory module 8 GB ⚫ 16 GB ⚫ 32 GB ⚫ 64 GB ⚫ 128 GB Number of ranks of the memory ⚫...

  • Page 26: Memory Compatibility

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Memory Channel Memory Slot DIMM031(J) DIMM040(E) DIMM050(F) CPU 2 A (primary) DIMM100(A) DIMM101(G) DIMM110(B) DIMM120(C) D (primary) DIMM130(D) DIMM131(J) DIMM140(E) DIMM150(F) 5.4.1.3 Memory Compatibility Observe the following rules when configuring DDR4 DIMMs: ⚫...
  • Page 27 FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description The total memory capacity cannot exceed the maximum memory capacity supported by the CPUs. ⚫ Use the Compatibility Checker to determine the capacity type of a single memory module. ⚫...

  • Page 28: Dimm Installation Rules

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Parameters Specifications sales representative. 5.4.1.4 DIMM Installation Rules ⚫ Observe the following when configuring DDR4 memory modules: − Install memory modules only when corresponding processors are installed. − Do not install LRDIMMs and RDIMMs in the same server.
  • Page 29 FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Figure 5-15 Memory slots Figure 5-16 DDR4 memory installation guidelines (1 processor) 2022-11-11...

  • Page 30: Memory Protection Technologies

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Figure 5-17 DDR4 memory installation guidelines (2 processors) 5.4.1.6 Memory Protection Technologies The following memory protection technologies are supported: ⚫ ⚫ Full mirroring ⚫ Address range mirroring ⚫ SDDC ⚫...

  • Page 31: Storage

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description 5.5 Storage 5.5.1 Drive Configurations Table 5-7 Drive configurations Configuration Maximum Front Maximum Rear Drive Drives Drives Management Mode ⚫ 8 x 2.5" drive Front drives: 8 x 1 x RAID controller configuration 2.5"...

  • Page 32: Drive Numbering

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description 5.5.2 Drive Numbering ⚫ 8 x 2.5" drive configuration Figure 5-18 Drive numbering ⚫ 12 x 3.5" drive configuration Figure 5-19 Drive numbering ⚫ 25 x 2.5" drive configuration 2022-11-11...

  • Page 33: Drive Indicators

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Figure 5-20 Drive numbering 5.5.3 Drive Indicators SAS/SATA Drive Indicators Figure 5-21 SAS/SATA drive indicators Table 5-8 Description of SAS/SATA drive indicators Activity Indicator Fault Indicator Description (Green) (Yellow) The drive is not in position.

  • Page 34: Raid Controller Card

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description M.2 FRU Indicators Figure 5-22 M.2 FRU indicators Table 5-9 M.2 FRU indicator description Indicator Description M.2 FRU fault indicator ⚫ Off: The M.2 FRU is running properly. ⚫ Blinking yellow: The M.2 FRU is being located, or RAID is being rebuilt.
  • Page 35 FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Table 5-10 LOM description Chip Port Type Rate Supported Rates Not Type Model Negotiati Rates Supported on Mode Ports X722 GE electrical Auto-negot 1000 Mbit/s 10 Mbit/s or port iation 1000...

  • Page 36: Flexio Cards

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Indicator Positions Figure 5-24 LOM indicators GE electrical port GE electrical port connection transmission status indicator status indicator Indicator Description Table 5-11 LOM indicators Indicator Description GE electrical port ⚫...
  • Page 37 FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description NIC Model Chip Model Port Type Number of Support Ports NC-SI/WOL/ √ SM210 5719 GE electrical port √ SM211 i350 GE electrical port √ SM212 i350 GE electrical port √...
  • Page 38 FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Figure 5-27 SM233 network port indicators ⚫ SM251 with two 56G IB optical ports Figure 5-28 SM251 network port indicators ⚫ SM252 with one 56G IB optical port Figure 5-29 SM252 network port indicators...

  • Page 39: I/O Expansion

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Port Type Indicator Description indicator ⚫ Blinking green: Data is being transmitted. ⚫ Steady green: The network port is properly connected. 56 Gbit/s IB optical Connection status ⚫ Off: No physical link is set up.
  • Page 40 FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description ⚫ I/O module 1 provides slots 1 to 3. If a dual-slot PCIe riser module is used, slot 2 is unavailable. ⚫ I/O module 2 provides slots 4 to 6. If a dual-slot PCIe riser module is used, slot 5 is unavailable.
  • Page 41 FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Figure 5-32 PCIe riser module 2 ⚫ PCIe riser module 3 (for PCIe SSD cards only) − Provides PCIe slots 1, 2, and 3 when installed in I/O module 1.

  • Page 42: Pcie Slot Description

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Figure 5-33 PCIe riser module 3 5.7.3 PCIe Slot Description The PCIe slots mapping to a vacant CPU socket are unavailable. Table 5-14 PCIe slot description PCIe PCIe Conne Port...
  • Page 43 FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description PCIe PCIe Conne Port Root Device Slot Slot Standa ctor Width Port (B/D/F Size Width (B/D/F riser ⚫ 3-sl ⚫ Slot 2 CPU 1 PCIe 2-sl Port2C 3A/02/ 3E/00/0 FHFL ⚫...

  • Page 44: Psus

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description PCIe PCIe Conne Port Root Device Slot Slot Standa ctor Width Port (B/D/F Size Width (B/D/F Slot 6 CPU 2 PCIe Port2C AE/02/ B0/00/ FHHL ⚫ The B/D/F (Bus/Device/Function Number) values are the default values when the server is fully configured with PCIe devices.

  • Page 45: Fans

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Figure 5-34 PSU positions 5.9 Fans ⚫ The server supports four fan modules. ⚫ The fan modules are hot-swappable. ⚫ The server tolerates failure of a single fan. ⚫ The fan speed can be adjusted.

  • Page 46: Boards

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description 5.10 Boards 5.10.1 Mainboard Figure 5-36 2288 V5 mainboard USB 3.0 port (USB 3.0 UID indicator (LED24) CONN/USB1) Serial port (J47) Management network port GE electrical port GE electrical port...

  • Page 47: Drive Backplane

    FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description PWR2/J22) SATA signal connector 2 SATA signal connector 1 (SATA2/J15) (SATA1/J14) Rear-drive backplane power USB 3.0 port (FRONT USB connector 1 (REAR BP 3.0/USB 2) PWR1/J20) Right mounting ear connector...
  • Page 48 FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Figure 5-37 8 x 2.5" drive backplane (BOM: 03022HXW) Backplane signal cable mini-SAS HD connector connector (J1) (PORT B/J29) mini-SAS HD connector Power connector (J24) (PORT A/J28) ⚫ 12 x 3.5" drive EXP backplane Figure 5-38 12 x 3.5"...
  • Page 49 FusionServer 2288 V5 Server Technical White Paper 5 Hardware Description Figure 5-39 25 x 2.5" drive EXP backplane (BOM: 03024MSH) Indicator signal cable mini-SAS HD connector connector (J32) (PORT A/J28) mini-SAS HD connector mini-SAS HD connector (PORT B/J29) (REAR PORT/J31)

  • Page 50: Product Specifications

    FusionServer 2288 V5 Server Technical White Paper 6 Product Specifications Product Specifications 6.1 Technical Specifications 6.2 Environmental Specifications 6.3 Physical Specifications 6.1 Technical Specifications Table 6-1 Technical specifications Components Specifications Form factor 2U rack server ® Chipset Intel C621 Supports one or two processors.
  • Page 51 FusionServer 2288 V5 Server Technical White Paper 6 Product Specifications Components Specifications ⚫ RDIMM and LRDIMM support ⚫ The DDR4 memory modules of different types (RDIMM and LRDIMM) and specifications (capacity, bit width, rank, and height) cannot be used together.
  • Page 52 FusionServer 2288 V5 Server Technical White Paper 6 Product Specifications Components Specifications performance and data security. NOTE If the BIOS is in legacy mode, the 4K drive cannot be used as the boot drive. Network Supports expansion capability of multiple types of networks.

  • Page 53: Environmental Specifications

    FusionServer 2288 V5 Server Technical White Paper 6 Product Specifications Components Specifications − One DB15 VGA port − One RJ45 serial port − One RJ45 system management port − Two GE electrical ports ⚫ Built-in ports: − One USB 3.0 port −...
  • Page 54 FusionServer 2288 V5 Server Technical White Paper 6 Product Specifications Category Specifications (5° F to 113° F) Storage temperature (within one year): –10° C to +35° C ⚫ (14° F to 95° F) ⚫ Maximum rate of temperature change: 20° C (36° F) per hour, 5°...

  • Page 55: Physical Specifications

    FusionServer 2288 V5 Server Technical White Paper 6 Product Specifications Category Specifications − LpAm: 42.2 dBA ⚫ Operating: − LWAd: 6.08 Bels − LpAm: 46.8 dBA NOTE The noise generated during operation varies depending on the server configuration, load, and ambient temperature.
  • Page 56 FusionServer 2288 V5 Server Technical White Paper 6 Product Specifications Item Description NOTE ⚫ See Figure 6-1 for methods in measuring physical dimensions of the chassis. ⚫ Methods measuring 3.5" and 2.5" drive chassis are the same. The 3.5" drive chassis is used as an example.
  • Page 57 FusionServer 2288 V5 Server Technical White Paper 6 Product Specifications Item Description information. 2022-11-11...

  • Page 58: Software And Hardware Compatibility

    FusionServer 2288 V5 Server Technical White Paper 7 Software and Hardware Compatibility Software and Hardware Compatibility Use the Compatibility Checker to obtain information about the operating systems and hardware supported. ⚫ If incompatible components are used, the device may be abnormal. This fault is beyond the scope of technical support and warranty.

  • Page 59: Safety Instructions

    FusionServer 2288 V5 Server Technical White Paper 8 Safety Instructions Safety Instructions 8.1 Security 8.2 Maintenance and Warranty 8.1 Security General Statement ⚫ Comply with local laws and regulations when installing devices. These Safety Instructions are only a supplement. ⚫...
  • Page 60 FusionServer 2288 V5 Server Technical White Paper 8 Safety Instructions Figure 8-1 Safety work wear ⚫ Before touching a device, wear ESD clothing and gloves (or wrist strap), and remove any conductive objects (such as watches and jewelry). Figure 8-2 shows conductive objects that must be removed before you touch a device.
  • Page 61 FusionServer 2288 V5 Server Technical White Paper 8 Safety Instructions Figure 8-3 Wearing an ESD wrist strap ⚫ Exercise caution when using tools. ⚫ If the installation position of the device is higher than the shoulders of the installation personnel, use a vehicle such as a lift to facilitate installation. Prevent the equipment from falling down and causing personal injury or damage to the equipment.

  • Page 62: Maintenance And Warranty

    FusionServer 2288 V5 Server Technical White Paper 8 Safety Instructions transported is always kept upright. Take necessary precautions to prevent collisions, corrosion, package damage, damp conditions and pollution. ⚫ Transport the equipment in its original packaging. ⚫ If the original packaging is unavailable, package heavy, bulky parts (such as chassis and blades) and fragile parts (such as PCIe GPUs and SSDs) separately.

  • Page 63: System Management

    FusionServer 2288 V5 Server Technical White Paper 9 System Management System Management The server uses the next-generation Intelligent Baseboard Management Controller (iBMC) to implement remote server management. The iBMC complies with IPMI 2.0 and provides highly reliable hardware monitoring and management.
  • Page 64 FusionServer 2288 V5 Server Technical White Paper 9 System Management Specifications Description Setting of boot device Supports out-of-band configuration for the boot device. Alarm management Supports alarm management and reports alarms using the SNMP trap, SMTP, and syslog service to ensure 24/7 operating.

  • Page 65: A Appendix

    FusionServer 2288 V5 Server Technical White Paper A Appendix Appendix A.1 Chassis Label The label information and location are for reference only. For details, see the actual product. A.1.1 On the Front Top Figure A-1 Chassis head label Nameplate Certificate...
  • Page 66 FusionServer 2288 V5 Server Technical White Paper A Appendix device. A.1.1.1 Nameplate Figure A-2 Nameplate example Table A-1 Nameplate description Description Server Model For details, see A.4 Nameplate . Device names Power Supply Requirements Vendor Information Authentication ID A.1.1.2 Certificate...
  • Page 67 FusionServer 2288 V5 Server Technical White Paper A Appendix Table A-2 Certificate description Description Order NOTE For details, see Figure A-4 and Table A-3. QC inspector Production date No. Barcode Figure A-4 Sample certificate No. Table A-3 Certificate No. Description Description The value for this digit is P, which is fixed.
  • Page 68 FusionServer 2288 V5 Server Technical White Paper A Appendix Description ⚫ Letters A to H indicate 10:00 to 17:00. ⚫ Letters J to N indicate 18:00 to 22:00. ⚫ Letters P to Q indicate 23:00 to 24:00. Indicates the serial number (two digits).
  • Page 69 FusionServer 2288 V5 Server Technical White Paper A Appendix A.1.2 Chassis Tail Label Figure A-6 Chassis tail label For details about the warning label, see Server Safety Information. A.1.3 Chassis Internal Label Figure A-7 Chassis internal label ⚫ The quick guide is located on the inside of the chassis cover. It describes how to remove the mainboard components, important components of the chassis, precautions, and QR codes of technical resources.
  • Page 70 FusionServer 2288 V5 Server Technical White Paper A Appendix Figure A-8 Example SN Table A-5 SN description Description ESN ID (two characters), which can only be 21. Material ID (eight characters), that is, the processing code. Vendor code (two characters), that is, the code of the processing place.
  • Page 71 FusionServer 2288 V5 Server Technical White Paper A Appendix Configuration Max. 35° C (95° F) Max. 40° C (104° F) ⚫ Rear drives ⚫ PCIe SSD cards 12 x 3.5" drive ⚫ All options supported Options not supported: ⚫ Platinum 8156 and Gold...
  • Page 72 FusionServer 2288 V5 Server Technical White Paper A Appendix Module Feature Description Memory Thermal Throttling Automatically adjusts the memory temperature to prevent the memory from being damaged due to overheat. Rank Sparing Uses some memory ranks for backup to prevent the system from breaking down due to uncorrectable errors.
  • Page 73 FusionServer 2288 V5 Server Technical White Paper A Appendix Module Feature Description error unit, improving system availability. Error Injection Support Implements fault injection to verify RAS features. Machine Check Architecture Provides a software repair function to (MCA) rectify uncorrectable errors to improve system availability.
  • Page 74 FusionServer 2288 V5 Server Technical White Paper A Appendix Sensor Description Component number. The value is 1 or 2. CPUN VRD Temp CPU VRD temperature Mainboard N indicates the CPU number. The value is 1 or 2. CPUN MEM Temp...
  • Page 75 FusionServer 2288 V5 Server Technical White Paper A Appendix Sensor Description Component FANN Speed Fan speed sensor Fan module N N indicates the fan module FANN R Speed number. The value ranges from 1 to 4. Power Server input power...
  • Page 76 FusionServer 2288 V5 Server Technical White Paper A Appendix Sensor Description Component button Watchdog2 Watchdog timer Mainboard Mngmnt Health Management subsystem Management module health status UID Button UID button status Mainboard PwrOk Sig. Drop Voltage dip status Mainboard PwrOn TimeOut...
  • Page 77 FusionServer 2288 V5 Server Technical White Paper A Appendix Sensor Description Component number. The value is 1 or 2. DISKN Drive status Drive N N indicates the drive slot number. The value ranges from 0 to 24 or from 36 to...

  • Page 78: B Glossary

    FusionServer 2288 V5 Server Technical White Paper B Glossary Glossary B.1 A-E ejector lever A part on the panel of a device used to facilitate installation or removal of the device. Ethernet A baseband local area network (LAN) architecture developed by Xerox Corporation by partnering with Intel and DEC.
  • Page 79 FusionServer 2288 V5 Server Technical White Paper B Glossary B.3 K-O A hardware device that provides public keyboard, video and mouse (KVM). B.4 P-T panel An external component (including but not limited to ejector levers, indicators, and ports) on the front or rear of the server.
  • Page 80 FusionServer 2288 V5 Server Technical White Paper B Glossary B.5 U-Z A unit defined in International Electrotechnical Commission (IEC) 60297-1 to measure the height of a cabinet or chassis. 1 U = 44.45 mm UltraPath A point-to-point processor interconnect developed by Intel.

  • Page 81: C Acronyms And Abbreviations

    FusionServer 2288 V5 Server Technical White Paper C Acronyms and Abbreviations Acronyms and Abbreviations C.1 A-E alternating current Advanced Encryption Standard New Instruction Set Address Resolution Protocol Advanced Vector Extensions backup battery unit BIOS Basic Input/Output System calendar day Conformite Europeenne...
  • Page 82 FusionServer 2288 V5 Server Technical White Paper C Acronyms and Abbreviations DDR3 Double Data Rate 3 DDR4 Double Data Rate 4 DDDC double device data correction DEMT Dynamic Energy Management Technology DIMM dual in-line memory module DRAM dynamic random-access memory...
  • Page 83 FusionServer 2288 V5 Server Technical White Paper C Acronyms and Abbreviations high availability hard disk drive high-performance computing HTTP Hypertext Transfer Protocol HTTPS Hypertext Transfer Protocol Secure iBMC intelligent baseboard management controller Industry Canada ICMP Internet Control Message Protocol Internet Data Center...
  • Page 84 FusionServer 2288 V5 Server Technical White Paper C Acronyms and Abbreviations LAN on motherboard media access control module management controller next business day NC-SI Network Controller Sideband Interface C.4 P-T PCIe Peripheral Component Interconnect Express power distribution unit physical layer...
  • Page 85 FusionServer 2288 V5 Server Technical White Paper C Acronyms and Abbreviations REACH Registration Evaluation and Authorization of Chemicals RJ45 registered jack 45 RoHS Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Serial Attached Small Computer System Interface...
  • Page 86 FusionServer 2288 V5 Server Technical White Paper C Acronyms and Abbreviations TFTP Trivial File Transfer Protocol TCP offload engine trusted platform module C.5 U-Z UDIMM unbuffered dual in-line memory module UEFI Unified Extensible Firmware Interface unit identification light Underwriter Laboratories Inc.
