FusionServer 2488H V7 Server

Technical White Paper

Issue

Date

2024-11-21

xFusion Digital Technologies Co., Ltd.

Need help?

Do you have a question about the FusionServer 2488H V7 and is the answer not in the manual?

Questions and answers

Summary of Contents for xFusion Digital Technologies FusionServer 2488H V7

Page 1 FusionServer 2488H V7 Server Technical White Paper Issue Date 2024-11-21 xFusion Digital Technologies Co., Ltd.
Page 2 Notice In this document, "xFusion" is used to refer to "xFusion Digital Technologies Co., Ltd." for concise description and easy understanding, which does not mean that "xFusion" may have any other meaning. Any "xFusion" mentioned or described hereof may not be understood as any meaning other than "xFusion Digital Technologies Co., Ltd.", and xFusion Digital Technologies Co., Ltd.
Page 3 About This Document Purpose This document describes the appearance, features, performance parameters, and hardware and software compatibility of FusionServer 2488H V7, so that users can have an in-depth and detailed understanding of FusionServer 2488H V7. Intended Audience This document is intended for pre-sales engineers.
Page 4 Updated 5.2.2 Indicators and 6.2 Environmental Specifications. 2023-12-04 Added 11 Waste Product Recycling. 2023-10-30 Updated A.4 Nameplate. ⚫ ⚫ Updated 10 Certifications. 2023-09-01 This issue is the first official release. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 5 5.5.1.2 12 x 2.5" Drive Pass-Through Configuration ..................32 5.5.1.3 16 x 2.5" Drive Pass-Through Configuration ..................35 5.5.1.4 25 x 2.5" Drive EXP Configuration ....................37 5.5.2 Drive Indicators ..........................39 5.5.3 RAID Controller Card .........................41 Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 6 8.2 Maintenance and Warranty........................67 9 System Management ....................68 10 Certifications ....................... 70 11 Waste Product Recycling ................... 72 A Appendix ........................73 B Glossary ........................91 C Acronyms and Abbreviations ..................94 Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 7 Technical White Paper 1 Overview Overview FusionServer 2488H V7 (2488H V7) is a 2U 4-socket rack server designed for the Internet Data Center (IDC), cloud computing, enterprise business, and telecom. This product is ideal for various applications, such as databases, cloud computing, virtualization, and in-memory computing.
Page 8 LCD touch panel. The iBMC Web management interface provides key component status indications. The iBMC web management interface helps technical personnel quickly find faulty components or the components with risk Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 9 BIOS firmware upgrade. The flash security protection mechanism is supported to prevent − unauthorized modification of the flash in the OS. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 11 I/O module 1 PCIe cards I/O module 2 Chassis Power shelf PSU backplane Mezzanine RAID controller card or M.2 SSD Air duct Supercapacitor Intrusion sensor Fan board Fan module bracket Fan modules Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 12 ⚫ Note 2: On the drive assembly, a red mark indicates that the assembly is hot- swappable, and a triangular mark indicates the removal direction of the hot- swappable assembly. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 13 (Sapphire Rapids). It supports 64 DDR5 DIMMs. ⚫ The processors interconnect with each other through three UltraPath ⚫ Interconnect (UPI) links at a speed of up to 16 GT/s. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 14 Supports low-speed I/O ports, such as VGA, USB 3.0, and serial port (RJ45). ⚫ The BMC card integrates the BMC management chip and provides external ⚫ video graphic array (VGA), management network port, and serial port. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 15 5.7 I/O Expansion 5.8 PSUs 5.9 Fan Modules 5.10 LCD 5.11 Boards 5.1 Front Panel 5.1.1 Appearance 8 x 2.5" drive pass-through configuration (8 x SAS/SATA) ⚫ Figure 5-1 Front view Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 16 Figure 5-3 Front view SAS/SATA drive Slide-out label plate (with an SN label) 5.1.2 Indicators and Buttons Indicator and Button Positions 8 x 2.5" drive pass-through configuration (8 x SAS/SATA) ⚫ Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 17 Fault diagnosis LED FlexIO card presence iBMC direct connect indicator management port indicator 25 x 2.5" drive EXP configuration (25 x SAS/SATA) ⚫ Figure 5-6 Indicators and buttons on the front panel Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 18 ⚫ Blinking or steady blue: The device is being ⚫ located. UID button: You can control the UID indicator status by ⚫ pressing the UID button or using the iBMC. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 19 5.1.3 Ports Port Positions 8 x 2.5" drive pass-through configuration (8 x SAS/SATA) ⚫ Figure 5-7 Ports on the front panel USB 3.0 port iBMC direct connect management port VGA port Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 20 USB Type-C Used to connect to a local PC connect using a USB Type-C cable to NOTE management monitor and manage the The USB 2.0 port system. protocol is Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 21 CD/DVD drives, an external power supply is required. 5.2 Rear Panel 5.2.1 Appearance Server with drive modules or PCIe riser modules on the rear panel ⚫ Figure 5-10 Rear view Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 22 Table 5-3 Indicators on the rear panel Silkscreen Indicator Description Data transmission ⚫ Off: No data is being transmitted. status indicator of Blinking yellow: Data is being ⚫ the management transmitted. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 23 ⚫ has been generated on the system. Blinking red at 5 Hz: A critical alarm ⚫ has been generated on the system. Steady green: The device is ⚫ operating properly. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 24 The port is a 3-wire serial communication port, and its default baud rate is 115,200 bit/s. VGA port DB15 Used to connect a display terminal, such as a monitor or KVM. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 25 Processors of the same model must be used in a server. ⚫ For details about the optional components, consult the local sales representative ⚫ or see "Search Parts" in the compatibility list on the technical support website. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 26 Figure 5-13 Positions of the processors 5.4 Memory 5.4.1 DDR5 Memory 5.4.1.1 Memory Identifier You can determine the memory module properties based on the label attached to the memory module. Figure 5-14 Memory identifier Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 27 Install the memory modules in the primary memory channels first. If the primary memory channel is not populated, the memory modules in secondary memory channels cannot be used. Table 5-5 Memory channels Channel Memory Slot CPU 1 A (primary) DIMM000(A) Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 28 DIMM100(A) DIMM101(I) B (primary) DIMM110(B) DIMM111(J) C (primary) DIMM120(C) DIMM121(K) D (primary) DIMM130(D) DIMM131(L) E (primary) DIMM140(E) DIMM141(M) F (primary) DIMM150(F) DIMM151(N) G (primary) DIMM160(G) DIMM161(O) H (primary) DIMM170(H) DIMM171(P) Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 29 A (primary) DIMM300(A) DIMM301(I) B (primary) DIMM310(B) DIMM311(J) C (primary) DIMM320(C) DIMM321(K) D (primary) DIMM330(D) DIMM331(L) E (primary) DIMM340(E) DIMM341(M) F (primary) DIMM350(F) DIMM351(N) G (primary) DIMM360(G) DIMM361(O) H (primary) DIMM370(H) Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 30 Table 5-6 DDR5 memory specifications Parameter Specifications Capacity per DDR5 DIMM (GB) Type RDIMM RDIMM RDIMM RDIMM- RDIMM- Rated speed (MT/s) 4800 4800 4800 4800 4800 Operating voltage (V) Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 31 Observe the memory module installation rules when configuring memory modules. For details, see the memory configuration guide on the technical support website. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 33 FusionServer 2488H V7 Server Technical White Paper 5 Hardware Description Figure 5-16 Recommended slots for DDR5 memory modules (2 processors) Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 34 FusionServer 2488H V7 Server Technical White Paper 5 Hardware Description Figure 5-17 Recommended slots for DDR5 memory modules (4 processors) Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 35 SATA drives. 8 x 2.5" drive ⚫ Front drive ⚫ 1 x PCIe pass-through (8 x 2.5"): plug-in configuration RAID Slots 0 − controller to 7 card support Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 36 Drive numbering of the 8 x 2.5" drive pass-through configuration 1 in Table 5-7. ⚫ Figure 5-18 Drive numbering Table 5-8 Drive numbering Drive No. Drive Number Displayed on the iBMC WebUI Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 37 Drive Number Identified on the iBMC WebUI by the RAID Controller Card Drive numbering of the 8 x 2.5" drive NVMe hard RAID configuration 1 (8 x ⚫ NVMe) in Table 5-7. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 38 (12 x 2.5"): drive: PCH configuration pass- Slots 0 − through to 3 support ⚫ NVMe only drive: CPU SATA pass- drives. through Slots 4 − to 7 support SATA/N Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 39 RAID controller card. This section uses the drive numbers identified by a RAID controller card that adopts the default cabling described in "Internal Cabling" in the Server Maintenance and Service Guide. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 40 Table 5-12 Drive numbering Drive No. Drive Number Displayed on the iBMC WebUI Drive numbering of the 12 x 2.5" drive pass-through configuration 2 in Table 5- ⚫ Figure 5-22 Drive numbering Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 41 NVMe drives. For details about the optional components, consult the local sales ⚫ representative or see "Search Parts" in the compatibility list on the technical support website. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 42 Drive numbering of the 16 x 2.5" drive NVMe hard RAID configuration (16 x ⚫ NVMe) inTable 5-14. Figure 5-23 Drive numbering Table 5-15 Drive numbering Drive No. Drive Number Displayed on the iBMC WebUI Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 43 RAID controller card that adopts the default cabling described in "Internal Cabling" in the Server Maintenance and Service Guide. Drive numbering of the 25 x 2.5" drive EXP configuration in Table 5-16 ⚫ Figure 5-24 Drive numbering Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 44 FusionServer 2488H V7 Server Technical White Paper 5 Hardware Description Table 5-17 Drive numbering Drive No. Drive Number Displayed Drive Number Identified on the iBMC WebUI by the RAID Controller Card Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 45 Data on the secondary drive is being Hz synchronously rebuilt. Red steady on A drive in a RAID array is removed. Steady on Red steady on The drive is faulty. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 46 The NVMe drive is not detected. Steady on The NVMe drive is detected and operating properly. Blinking at 4 Hz Data is being read from or written to the NVMe drive. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 47 When IB cards are used to build an IB network, ensure that the IPoIB modes of ⚫ the IB cards at both ends of the network connection are the same. For details, contact technical support. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 48 Provides PCIe slots 1, 2, and 3 when installed in I/O module 1. − Provides PCIe slots 7, 8, and 9 when installed in I/O module 2. − Figure 5-28 I/O module 1 or IO module 2 Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 49 The bandwidth of the PCIe slot cannot be less than that of the inserted PCIe card. The full-height full-length (FHFL) PCIe slots are compatible with FHFL PCIe ⚫ cards, full-height half-length (FHHL) PCIe cards, and half-height half-length (HHHL) PCIe cards. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 50 DC power supply that has passed the CCC certification. For details about the optional components, consult the local sales representative ⚫ or see "Search Parts" in the compatibility list on the technical support website. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 51 Supports N+1 redundancy. The server runs properly when one fan fails. ⚫ Supports intelligent fan speed adjustment. ⚫ Fan modules of the same part number (P/N code) must be used in a server. ⚫ Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 52 IP address of the iBMC management network port on the server. The LCD and the server iBMC form an LCD subsystem. The LCD directly obtains device information from the iBMC. The LCD subsystem does not store device data. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 54 FusionServer 2488H V7 Server Technical White Paper 5 Hardware Description 5.11 Boards 5.11.1 Mainboard Figure 5-32 Mainboard Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 55 M.2 low-speed signal Fan low-speed signal connector (M.2 MIS/J51) connector (FANBOARD/J6077) LCD connector (LCD PCH SATA PORT (A-B) CONN/J17702) connector (J14901) UBC1-1B connector (UBC1- UBC1-1A connector 1B CONN/J40) (UBC1-1A CONN/J39) Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 56 Figure 5-33 8 x 2.5" drive pass-through backplane Connector Managed Drive Slot Backplane signal cable connector (HDD BP/J12) Power connector (HDD_POWER/J14) mini-SAS HD connector Slot 0 to 3 (PORT A/J28) Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 57 Cascade backplane low-speed connector (HDD_BP_S/J22)) Backplane low-speed connector (HDD_BP_S/J20) Power connector (HDD_POWER/J21) UBC connector 1 (UBC1/J2) Slot 0~3 Mini-SAS HD connector (PORT A/J6) Slot 0~3 UBC connector 2 (UBC2/J3) Slot 4~7 Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 58 Slot6~Slot7 (UBC2/J2) UBC connector 1 Slot4~Slot5 (UBC1/J1) Backplane signal connector (HDD BP/J19) Power connector (HDD_POWER/J21) mini-SAS HD connector Slot 0 to 3 (PORT A/J28) mini-SAS HD connector Slot4~Slot7 (PORT B/J601) Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 59 (FAN/J10) connector (J4/J5/J6) Power board signal Drive backplane connector connector (J1) (BP/J15) 5.11.4 Fan Board Figure 5-37 Fan board Fan board signal connector Fan board power (MISC CONN/J3) connector (POWER Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 60 Fan connector (FAN3/J7) Fan connector (FAN4/J8) Fan connector (FAN5/J9) Fan connector (FAN6/J10) 5.11.5 M.2 SSD Adapter Board Figure 5-38 M.2 SSD adapter board Signal connector High-speed connector (M.2CONN/J1) (Simline X8/J2) Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 61 The preceding information is for reference only. For details, see "Search Parts" in the compatibility list on the technical support website. Memory 64 memory slots. ⚫ Up to 64 DDR5 DIMMs Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 62 When the VMD function is disabled, orderly hot swap is ⚫ supported. Support a variety of RAID controller cards. For ⚫ details,see "Search Parts" in the Compatibility List on Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 63 One USB Type-C iBMC direct connect − management port Two USB 3.0 ports − One DB15 VGA port − Ports on the rear panel: ⚫ Two USB 3.0 ports − One DB15 VGA port − Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 64 Operating temperature: 5º C to 45º C (41º F to 113º F) (ASHRAE Classes A1 to A4 compliant) Storage temperature (within three months): –30° C to ⚫ +60° C (–22° F to +140° F) Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 65 Silver corrosion rate test: 200 Å/month ⚫ Particle contaminant Meets the requirements of ISO 14664-1 Class 8. ⚫ ⚫ There is no explosive, conductive, magnetic, or corrosive dust in the equipment room. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 66 86.1 mm (3.39 in.) × 447 mm (17.60 in.) × 898 mm (35.35 in.) Installation space Requirements for cabinet installation: ⚫ Cabinet compliant with the International Electrotechnical Commission (IEC) 297 standard Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 67 Packing materials: 6.0 kg ⚫ Power consumption The power consumption parameters vary with hardware configurations (including the configurations complying with EU ErP). For details, see Power Calculator on the technical support website. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 68 If the customer has requirements on hardware performance consistency, specify ⚫ the specific configuration requirements (for example, specific drive models, RAID controller cards, or firmware versions) in the presales phase. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 69 Do not carry the weight that exceeds the maximum load per person allowed by ⚫ local laws or regulations. Before moving a device, check the maximum device weight and arrange required personnel. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 70 Fasten the strap buckle and ensure that the ESD wrist strap is in contact with your skin. Insert the ground terminal attached to the ESD wrist strap into the jack on the grounded cabinet or chassis. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 71 Ground a device before powering it on. Otherwise, high voltage leakage current ⚫ may cause device damage. Transportation Precautions Improper transportation may damage equipment. Contact the manufacturer for precautions before attempting transportation. Transportation precautions include but are not limited to: Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 72 General Administration of Quality Male: 15/33.08 ⚫ Supervision, Inspection and Quarantine Female: 10/22.05 ⚫ of the People's Republic of China (AQSIQ) For more information about security instructions, see the server Safety Information. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 73 For details about maintenance, visit the Technical Support Website > Service Support Center > Customer Support Service. For details about warranty, visit the Technical Support Website > Service Support Center > Warranty. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 74 Security management methods ⚫ Software image backup improves system security. Even if the running − software completely breaks down, the system can be started from the backup image. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 75 License management allows advanced features to be used by authorized users. The advanced edition of the iBMC provides the following features: Use Redfish to deploy the OS. − Use Redfish to collect raw data for intelligent diagnosis. − Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 76 CISPR 35:2016 EN 55024:2010+A1:2015 CISPR 24:2010+A1:2015 ETSI EN 300 386 V1.6.1:2012 ETSI EN 300 386 V2.1.1:2016 RoHS: EN IEC 63000:2018 ErP: Commission Regulation(EU) NO. 2019/424 UKCA Safety: EN 62368-1:2014+A11:2017 EMC: Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 77 BS EN IEC 63000:2018 ErP: Commission Regulation(EU) NO. 2019/424 Japan VCCI VCCI 32-1 North America NRTL UL 62368-1:2019 CSA C22.2 NO.62368-1:19 Canada ICES-003 FCC PART 15 Global IEC 62368-1:2014 IEC 62368-1:2018 Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 78 Technical White Paper 11 Waste Product Recycling Waste Product Recycling If you have xFusion products at the end of their lifecycle and need xFusion's product recycling service, contact xFusion technical support. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 79 Figure A-1 Chassis head label Nameplate Certificate Quick access tag Product SN NOTE For details, see A.2 Product SN. Slide-out label plate Product SN NOTE The location of the slide-out label Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 80 A.1.1.1 Nameplate Figure A-2 Nameplate example Table A-1 Nameplate description Description Server model NOTE For details, see A.4 Nameplate. Device name Power supply requirements Enterprise Standard Number Vendor information Certification marks Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 81 No. barcode Figure A-4 Certificate number example Table A-3 Certificate number description Description P: a fixed value for this digit Z: a fixed value for this digit Y: a server ⚫ Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 82 Letters J to N indicate 18:00 to 22:00. Letters P to Q indicate 23:00 to 24:00. ⚫ Serial number (two characters) Manufacturing serial number (five characters) A.1.1.3 Quick Access Label Figure A-5 Quick access label example Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 83 QR codes of technical resources. The pictures are for reference only. For details, see the actual product. The quick start guide is optional. For details, see the actual product. ⚫ Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 84 SN ID (two characters), which is 21. Material identification code (eight characters), that is, the processing code. Vendor code (two characters), that is, the code of the processing place. Year and month (two characters) Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 85 Digits 1 to 9 indicate years 2001 to 2009 respectively. − Letters A to H indicate years 2010 to 2017 respectively. − Letters J to N indicate years 2018 to 2022 respectively. − Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 86 Description QR code. For details, see Figure A-12. BOM code (10 digits). Product model (13 characters). Product SN (12 characters). For details, see Table A-8. RoHS compliance code (one character). Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 87 Table A-9 QR code scanning result example description Description Fixed representation symbol (three characters). Product SN (12 characters). For details, see Table A-8. Data identifier for the material code (two characters). BOM code (10 digits). Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 88 ⚫ NICs with greater ⚫ GPU cards 100GE than 270 each of ports or which has ports of a capacity higher rate of or more are not than 128 Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 89 NICs with than 270 W than 185 W greater 100GE than 185 W ports or supported supported are not ports of supported ⚫ ⚫ OCP 3.0 higher rate Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 90 CPU models with TDP that equals to or is lower than 185 W: 6418H/6416H When a single fan is faulty, the highest operating temperature is 5°C (9°F) lower than the ⚫ rated value. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 91 PwrOn TimeOut Power-on timeout Mainboard PwrCap Status Power capping status Mainboard AreaIntrusion Listening to the Mainboard unpacking action CPU Power CPU consumption of the Mainboard memory module in the power-on state Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 92 CPUN Prochot CPU Prochot CPUN N indicates CPU number. The value ranges from 1 to 4. CPUN Status CPU status detection CPUN N indicates CPU number. The value ranges from 1 Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 93 PSN Status PSU fault status PSU N N indicates PSU number. The value ranges from 1 to 2. PSN Fan Status PSU fan fault status PSU N N indicates PSU number. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 94 M.2 adapter card temperature M2DiskN Status of the M.2 drive on M.2 drive N the riser card N indicates M.2 drive number RAID Status RAID controller card RAID controller card health status Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 95 N indicates PCIe slot number OCP1 Temp OCP card chip OCP 3.0 NIC temperature sensor CPU Usage CPU usage Memory Usage Memory usage ACPI State ACPI status SysFWProgress Software processes and Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 96 Hot restart reminder and fault diagnosis program information collection System Error System shutdown or restart. Check the background logs. Boot Error Boot error SEL Status SEL full or events being cleared Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 97 B.2 F-J Gigabit Ethernet (GE) An extension and enhancement of traditional shared media Ethernet standards. It is compatible with 10 Mbit/s and 100 Mbit/s Ethernet and complies with IEEE 802.3z standards. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 98 A storage technology that combines multiple physical independent disks drives into a logical unit for the purposes of data (RAID) redundancy and performance improvement. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 99 A unit defined in International Electrotechnical Commission (IEC) 60297-1 to measure the height of a cabinet, chassis, or subrack. 1U = 44.45 mm (1.75 in). UltraPath A point-to-point processor interconnect developed by Interconnect (UPI) Intel. Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 100 Advanced Encryption Standard New Instruction Set Address Resolution Protocol Advanced Vector Extensions backup battery unit BIOS Basic Input/Output System baseboard management controller China Compulsory Certification calendar day Conformite Europeenne Common Information Model command-line interface Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 101 European Telecommunication Standards C.2 F-J FB-DIMM Fully Buffered DIMM Fiber Channel Federal Communications Commission FCoE Fibre Channel over Ethernet File Transfer Protocol Gigabit Ethernet GPIO General Purpose Input/Output Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 102 Internet Group Message Protocol IOPS input/output operations per second Internet Protocol Intelligent Power Capability IPMB Intelligent Platform Management Bus IPMI Intelligent Platform Management Interface C.3 K-O keyboard, video, and mouse Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 103 Network Controller Sideband Interface Open Compute Project C.4 P-T PCIe Peripheral Component Interconnect Express power distribution unit physical layer PMBUS power management bus Power OK pulse-width modulation Preboot Execution Environment Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 104 LAN SONCAP Standards Organization of Nigeria-Conformity Assessment Program solid-state drive Streaming SIMD Extension TACH tachometer signal Turbo Boost Technology Trusted Computing Group trusted cryptography module total cost of ownership Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
Page 105 Voluntary Control Council for Interference by Information Technology Equipment Video Graphics Array VLAN virtual local area network voltage regulator-down VROC Virtual RAID on CPU WEEE waste electrical and electronic equipment WSMAN Web Service Management Issue 05 (2024-11-21) Copyright © xFusion Digital Technologies Co., Ltd.
