ABOS-9XXC Series

15.6", 21.5" Button-Integrated Panel PC

User Manual

Release Date

Revision

Jun. 2024

V1.3

®2024 Aplex Technology, Inc.

Published in Taiwan

Aplex Technology, Inc.

15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan

Tel: 886-2-82262881

Fax: 886-2-82262883

email:

aplex@aplex.com

URL:

http://www.aplex.com

ABOS-9XXC Series User Manual

Need help?

Do you have a question about the ABOS-9 C Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Aplex ABOS-9 C Series

Page 1 15.6”, 21.5” Button-Integrated Panel PC User Manual Release Date Revision Jun. 2024 V1.3 ®2024 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881...
Page 2 Revision History Reversion Date Description 2024/01/19 Official Version 2024/6/15 2024/8/10 2024/9/24 ABOS-9XXC Series User Manual...
Page 3 This information in this document is subject to change without notice. In no event shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials.
Page 4 Always check and tighten the pressure testing screw upon receiving the system, ensuring its stability before deployment. Neglecting this step may compromise the functionality of your ABOS series system. For any questions or concerns regarding this procedure, please contact APLEX Technology's customer support. ABOS-9XXC Series User Manual...
Page 5 Table of Contents Revision History………………………………………………………………………………….1 Warning!………………………………………………………………………………….……..….2 Disclaimer……………………….……………………………………………….…………………2 Logistic Statement…………..……………………………………………….…………………3 Chapter 1 Getting Started 1.1 Features…………………………………………………..…………………………….6 1.2 Specifications…………………………………………………………………………6 1.3 Dimensions……………………...……………...…..………………………….…9 1.4 Brief Description of ABOS-9XXCP…………..……………………….10 Chapter 2 Hardware 2.1 Motherboard Introduction………….…..….…..……………….….13 2.2 Specifications and Dimensions……………………………..……….……13 2.3 Jumpers and Conmectors Location………………………..……….……15 Chapter 3 BIOS Setup 3.1 System Test and Installation…………………………………………..…16 3.2 AMI BIOS Setup………………………………………………………………….16...
Page 6 Figures Figure 1.1: Dimensions of ABOS-916CP(H)…..…………….…………..…9 Figure 1.2: Dimensions of ABOS-921CP(H)……...……………….……….9 Figure 1.3: Front View of ABOS-916CP………………......10 Figure 1.4: Rear View of ABOS-916CP………………..……..……….……..11 Figure 1.5: Front View of ABOS-921CP………………......11 Figure 1.6: Rear View of ABOS-921CP………………..……..……….……..12 Figure 2.1: Motherboard Dimensions.………………………………………15 Figure 2.2: Jumpers and Connectors Locations-Board Top…….….15 ABOS-9XXC Series User Manual...
Page 7 Chapter 1 Getting Started 1.1 Features  15.6”/21.5” FHD TFT LCD Panel PC  Intel® 11 Gen. (Tiger Lake-UP3) Processors  16:9 Widescreen with P-CAP Multi-touch Control  Built-in Functional Buttons for Intuitive Operation  Gap-free sealing and Slim Front Frame architecture at front bezel ...
Page 8 Expansion Slot 1 x M.2 2230 E-Key (PCIex2+USB2.0) socket for WIFI/BT and Antenna at rear side (option) 1 x Full-size mPCIe/mSATA (mSATA as default, select by BIOS) 1 x Nano SIM Card Functional Buttons: Supports RAFI RAFIX-22-FS Series For the push button extensions can be used to control the central functions of a machine or system such as emergency stop, start or stop by means of electromechanical keys and are already mounted ex factory.
Page 9 Viewing 170/170 174/174 Angle(H/V) Backlight Lifetime 50,000hrs 30,000hrs Option Optical bonding Touch Screen Type Projected capacitive touch screen Interface Light Projected capacitive touch screen: over 90% Transmission Power Power Input DC 9~36V onboard Power MAX:34.99W MAX:34.05W Consumption Mechanical Construction Aluminum CNC enclosure Rear Housing: Stainless Steel 304 Mounting SWING ARM (support CP-40 Rittal)
Page 10 1.3 Dimensions Figure 1.1: Dimensions of ABOS-916CP(H) Figure 1.2: Dimensions of ABOS-921CP(H) ABOS-9XXC Series User Manual...
Page 11 1.4 Brief Description of ABOS-9XXC Series The ABOS-9XXC series is a state-of-the-art stainless steel panel PC featuring Intel 11th Gen (Tiger Lake-UP3) technology. With an IP65 rating, Swing ARM kits, and 15.6”/21.5” TFT LCD displays, it excels in versatility. Robust Aluminum CNC and Stainless Steel 304 construction, wide DC power input, and options for high brightness LCD and optical bonding make it adaptable for diverse environments.
Page 12 Figure 1.4: Rear View of ABOS-916CP Figure 1.5: Front View ABOS-921CP ABOS-9XXC Series User Manual...
Page 13 Figure 1.6: Rear View of ABOS-921CP ABOS-9XXC Series User Manual...
Page 14 Chapter 2 Hardware 2.1 Motherboard Introduction Standard 3.5" subcompact board developed on the basis of Intel 11 Generation Core™/Celeron Processor, which provides abundant peripheral interfaces to meet the needs of different customers. Also, it features one mPCIe/mSATA, dual GbE ports, 2-COM and 4 x USB3.2 Gen 2 Ports; one HDMI, one VGA and one LVDS interface.
Page 15 4-bit digital Output Battery Lithium Battery 3V/240mAh SMBus/I2C I2C/SMBus x 1 (Default: SMBus) Nano-SIM x 1 Audio Support Audio via Realtek ALC897/892 audio codec Audio Interface: Line-in/Line-out/MIC 1x Audio Header Expansion Bus 1 x Full-size mPCIe/mSATA slot (mSATA as default, , select by BIOS) M.2 M-Key 2280 x 1 (PCIe [x4]) M.2 E-Key 2230 x 1 (PCIe, USB2.0)
Page 16 2.3 Jumpers and Connectors Location Figure 2.2: Jumpers and Connectors Location- Board Top Figure 2.3: Jumpers and Connectors Location- Board Bottom ABOS-9XXC Series User Manual...
Page 17 Chapter 3 BIOS Setup 3.1 System Test and Initialization The board uses certain routines to perform testing and initialization during the boot up sequence . Ifan error, fatal or non-fatal, is encountered, the module will output a few short beeps or display an error message. The module can usually continue the boot up sequence with non-fatal errors.
Page 18 Boot-Boot options including 8BS priority and Quiet Boot options Save & Exit --Save your changes and ext the program 3.3 Setup Submenu:Main 3.4 Setup Submenu: Advanced ABOS-9XXC Series User Manual...
Page 19 3.4.1 Graphics Configuration ABOS-9XXC Series User Manual...
Page 20 3.4.1.1 LVDS Panel Configuration ABOS-9XXC Series User Manual...
Page 21 ABOS-9XXC Series User Manual...
Page 22 3.4.2 CPU Configuration ABOS-9XXC Series User Manual...
Page 23 3.4.3 Memory Configuration 3.4.4 Hardware Monitor 3.4.4.1 Smart Fan Mode Configuration ABOS-9XXC Series User Manual...
Page 24 ABOS-9XXC Series User Manual...
Page 25 3.4.5 PCH-FW Configuration 3.4.5.1 Firmware Update Configuration ABOS-9XXC Series User Manual...
Page 26 3.4.6 Power Management ABOS-9XXC Series User Manual...
Page 27 3.4.7 BIOS Robot ABOS-9XXC Series User Manual...
Page 28 3.4.7.1 Device Detecting Configuration ABOS-9XXC Series User Manual...
Page 29 ABOS-9XXC Series User Manual...
Page 30 3.4.7.1.1 Device# Detecting Configuration ABOS-9XXC Series User Manual...
Page 31 ABOS-9XXC Series User Manual...
Page 32 ABOS-9XXC Series User Manual...
Page 33 ABOS-9XXC Series User Manual...
Page 34 ABOS-9XXC Series User Manual...
Page 35 ABOS-9XXC Series User Manual...
Page 36 ABOS-9XXC Series User Manual...
Page 37 ABOS-9XXC Series User Manual...
Page 38 ABOS-9XXC Series User Manual...
Page 39 ABOS-9XXC Series User Manual...
Page 40 3.4.8 TSN GBE Configuration ABOS-9XXC Series User Manual...
Page 41 3.5 Setup Submenu: System I/O 3.5.1 PCI Express Configuration ABOS-9XXC Series User Manual...
Page 42 3.5.2 Storage Configuration ABOS-9XXC Series User Manual...
Page 43 3.5.2.1 NVME Configuration 3.5.3 HD Audio Subsystem Configuration Settings ABOS-9XXC Series User Manual...
Page 44 3.5.4 Digital IO Port Configuration 3.5.5 Legacy Logical Devices Configuration ABOS-9XXC Series User Manual...
Page 45 3.5.5.1 Serial Port1 Configuration 3.5.5.2 Serial Port2 Configuration ABOS-9XXC Series User Manual...
Page 46 3.5.5.3 Serial Port3 Configuration ABOS-9XXC Series User Manual...
Page 47 3.5.5.4 Serial Port4 Configuration ABOS-9XXC Series User Manual...
Page 48 3.5.6 Legacy Logical Devices Configuration ABOS-9XXC Series User Manual...
Page 49 3.5.6.1 Console Redirection Settings ABOS-9XXC Series User Manual...
Page 50 ABOS-9XXC Series User Manual...
Page 51 ABOS-9XXC Series User Manual...
Page 52 3.5.7 PCH-IO Configuration ABOS-9XXC Series User Manual...
Page 53 3.6 Setup Submenu: Security ABOS-9XXC Series User Manual...
Page 54 3.6.1 Trusted Computing ABOS-9XXC Series User Manual...
Page 55 3.6.2 Secure Boot ABOS-9XXC Series User Manual...
Page 56 3.6.2.1 Key Management ABOS-9XXC Series User Manual...
Page 57 ABOS-9XXC Series User Manual...
Page 58 3.7 Setup Submenu: Boot 3.7.1 BBS Priorities ABOS-9XXC Series User Manual...
Page 59 3.8 Setup Submenu: Save & Exit ABOS-9XXC Series User Manual...
Page 60 Chapter 4 Installation of Drivers Intel® Chipset Device Software To install the Intel® Chipset Device Software, please follow the steps below. Step 1. Here is welcome page. Please make sure you save and exit all programs before install. Click Next. Step2.
Page 61 Step3. Click Install to begin the installation. Step5. Click Finish to finish installation. ABOS-9XXC Series User Manual...
Page 62 ABOS-9XXC Series User Manual...
Page 63 Intel® VGA Chipset To install the Intel® VGA Chipset, please follow the steps below. Step1. Click Next. Step2. Read the license agreement. Click Yes to accept all of the terms of the license agreement. ABOS-9XXC Series User Manual...
Page 64 Step3. Click Next to continue. Step4. Click Next to continue the program. ABOS-9XXC Series User Manual...
Page 65 Step5. Select Yes, I want to restart this computer now. Click Finish to complete installation. ABOS-9XXC Series User Manual...
Page 66 4.3 Realtek Audio Driver To install the Realtek Audio Driver, please follow the steps below. Step1. Select setup language you need. Click Next to continue. Step2. Click Finish to complete the installation. ABOS-9XXC Series User Manual...
Page 67 4.4 Intel® LAN Driver To install the Intel® LAN Driver, please follow the steps below. Step1. Here is welcome page. Please wait for program setup process. Step2. Read the license agreement. Select I accept the terms in the license agreement and click Yes to accept all of the terms of the license agreement. ABOS-9XXC Series User Manual...
Page 68 Step3. Click Next to continue. Step4. Click Install to begin the installation. ABOS-9XXC Series User Manual...
Page 69 Step5. Click Install to begin the installation. ABOS-9XXC Series User Manual...
Page 70 Chapter 5 Button Pin Setting 5.1 Loosen Swing ARM screws Use screwdriver to loosen 6 pcs of screws at the side of the swing arm as pointed in picture below. Note: After you have gained access to the push button extension boards, you can wire the push button extension.
Page 71 CN4_20P CN3_20P S5_N/O contact S5_N/O contact S8_N/O contact S8_N/O contact S5_N/C contact S5_N/C contact S8_N/C contact S8_N/C contact S4_N/O contact S4_N/O contact S8_LED(+24V) S8_LED(GND) S4_N/C contact S4_BN/C contact S7_N/O contact S7_N/O contact S4_LED(+24V) S4_LED(GND) S7_N/C contact S7_N/C contact S3_N/O contact S3_N/O contact S7_LED(+24V) S7_LED(GND)
