ARCHMI-9XX Series
th
12.1", 15", 15.6", 17", 18.5", 19", and 21.5" Intel 4
Gen. Core i3/i5,
Fanless Industrial Compact Size Panel PC
User Manual
Release Date
Revision
Oct.2018
V1.6
®2018 Aplex Technology, Inc.
All Rights Reserved.
Published in Taiwan
Aplex Technology, Inc.
15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan
Tel: 886-2-82262881 Fax: 886-2-82262883
URL:
www.aplextec.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARCHMI-9 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aplex ARCHMI-9 Series

Summary of Contents for Aplex ARCHMI-9 Series

  • Page 1 Fanless Industrial Compact Size Panel PC User Manual Release Date Revision Oct.2018 V1.6 ®2018 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan Aplex Technology, Inc. 15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan Tel: 886-2-82262881 Fax: 886-2-82262883 URL: www.aplextec.com...

  • Page 2: Revision History

    Revision History Reversion Date Description 2015/04/22 For Preliminary Release 2015/05/27 Modify Motherboard Description 2015/07/21 Official Version, add 12.1” and Mount Description 2016/02/02 Modify CPU Spec. to i3/i5, 15” and 17” LCD Spec., AMT driver to MEI driver, Dimension, and OS Support Spec.; Add Power Consumption and Net Weight Specification, and add UPS battery for option 2016/02/26...

  • Page 3: Warning!/Caution/Disclaimer

    This information in this document is subject to change without notice. In no event shall Aplex Technology Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or misuse of information in this document or in any related materials.

  • Page 4: Packing List

    Packing List Accessories (as ticked) included in this package are: □ Adaptor □ Driver & manual CD disc □ Other.___________________(please specify) ARCHMI-9XX Series User Manual...

  • Page 5: Safety Precautions

    Safety Precautions Follow the messages below to prevent your systems from damage: ◆ Avoid your system from static electricity on all occasions. ◆ Prevent electric shock. Don‘t touch any components of this card when the card is power-on. Always disconnect power when the system is not in use.

  • Page 6: Table Of Contents

    Table of Contents Revision History…………………………………………………………………………………………………….1 Warning!/Caution/Disclaimer......…………………………….……………………2 Packing List…………………………………….…………………………………………………....3 Safety Precautions…………………………………………………..…..……………………....4 Chapter 1 Getting Started 1.1 Features……..…………………..………………………...…………………………..7 1.2 Specifications…..………………...………………………………………………….7 1.3 Dimensions……..…………………..………………………………………...….10 1.4 Brief Description of ARCHMI-9XX…..….…..……………………….……14 1.5 Installation of HDD………….…………..………..…...…………………..…..18 1.6 VESA Mounting……………….…………..………..…...…………………..…..20 1.7 Panel Mounting…..………….…………..………..…...…………………..…..20 Chapter 2 Hardware 2.1 Mainboard Introduction……………………..…………………………..20 2.2 Specifications…………………………..…………..………………………………20 2.3 Jumpers and Connectors Location……….……………………………...24 2.4 Jumpers Setting and Connectors…………..………………………..……25...
  • Page 7 Chapter 5 Touch Screen Installation 5.1 Windows 7/8/8.1 Universal Driver Installation for PenMount 6000 Series…………………………………………………………………………85 5.2 Software Functions……………………..……………………………………..95 Figures Figure 1.1: Dimensions of ARCHMI-912(P)……….……….………………………….10 Figure 1.2: Dimensions of ARCHMI-915(P)……….……….……………………….…10 Figure 1.3: Dimensions of ARCHMI-916(P)………………….……..………….….…11 Figure 1.4: Dimensions of ARCHMI-917(P)……………………………………………11 Figure 1.5: Dimensions of ARCHMI-918(P)……………………………………………12 Figure 1.6: Dimensions of ARCHMI-919(P)……………………………………………12 Figure 1.7: Dimensions of ARCHMI-921(P)……………………………………………13 Figure 1.8: Front View of ARCHMI-9XX Series………………………………………14...

  • Page 8: Getting Started

    Chapter 1 Getting Started 1.1 Features  12.1” 15”/15.6”/17”/18.5”/19”/21.5” Industrial Compact Size Panel PC  Flat front panel touch screen and fanless design  Aluminum die-casting chassis for ARCHMI-916(P)  Intel 4th Gen. Core i3 CPU built-in/i5(option)  Onboard 4GB DDR 3L 1600 MHz/8GB(option) ...
  • Page 9 Storage Space Storage 1 x 2.5” SATA HDD bay for SATA HDD (Easy Accessible) Expansion Expansion Slot 1 x Internal Mini-PCIe slot full size Touch Screen – Resistive Touch Window Type TS Control PenMount 6000 on Board Interface Light Transmission Over 80% Touch Screen –...
  • Page 10 ARCHMI-912(P) ARCHMI-915(P) ARCHMI-916(P) ARCHMI-917(P) Display Display Type 12.1” TFT LCD 15” TFT LCD 15.6” TFT LCD 17” TFT LCD Max. Resolution 800 x 600 1024 x 768 1366 x 768 1280 x 1024 Max. Color 16.2M 16.7M 16.7M 16.2M Luminance(cd/m²) Contrast Ratio 800 : 1 800 : 1...

  • Page 11: Dimensions

    1.3 Dimensions Figure 1.1: Dimensions of ARCHMI-912(P) Figure 1.2: Dimensions of ARCHMI-915(P) ARCHMI-9XX Series User Manual...

  • Page 12: Figure 1.3: Dimensions Of Archmi-916(P)

    Figure 1.3: Dimensions of ARCHMI-916(P) Figure 1.4: Dimensions of ARCHMI-917(P) ARCHMI-9XX Series User Manual...

  • Page 13: Figure 1.5: Dimensions Of Archmi-918(P)

    Figure 1.5: Dimensions of ARCHMI-918(P) Figure 1.6: Dimensions of ARCHMI-919(P) ARCHMI-9XX Series User Manual...

  • Page 14: Figure 1.7: Dimensions Of Archmi-921(P)

    Figure 1.7: Dimensions of ARCHMI-921(P) ARCHMI-9XX Series User Manual...

  • Page 15: Brief Description Of Archmi-9Xx

    1.4 Brief Description of ARCHMI-9XX There are 12.1”, 15”, 15.6”, 17”, 18.5”, 19” and 21.5” Industrial Compact Size Panel PC in ARCHMI-9XX series, which comes with flat front panel touch screen and fanless design. It is powered by Intel 4 Gen.

  • Page 16: Figure 1.9: Rear View Of Archmi-912(P)

    Figure 1.9: Rear View of ARCHMI-912(P) Figure 1.10: Rear View of ARCHMI-915(P) ARCHMI-9XX Series User Manual...

  • Page 17: Figure 1.11: Rear View Of Archmi-916(P)

    Figure 1.11: Rear View of ARCHMI-916(P) Figure 1.12: Rear View of ARCHMI-917(P) ARCHMI-9XX Series User Manual...

  • Page 18: Figure 1.13: Rear View Of Archmi-918(P)

    Figure 1.13: Rear View of ARCHMI -918(P) Figure 1.14: Rear View of ARCHMI -919(P) Figure 1.15: Rear View of ARCHMI-921(P) ARCHMI-9XX Series User Manual...

  • Page 19: Installation Of Hdd

    1.5 Installation of HDD Step 1 There are 2 screws to deal with when enclosing or removing the chassis. Gently remove 2 screws. Step 2 You can put or remove HDD into the machine by pulling the HDD bracket. Step 3 You can remove HDD by unscrewing 4 screws in the HDD bracket.

  • Page 20: Vesa Mounting

    1.6 VESA Mounting The ARCHMI series is designed to be VESA mounted as shown in Picture. Just carefully place the unit through the hole and tighten the given screws from the rear to secure the mounting. Figure 1.16: ARCHMI Series VESA Mounting 1.7 Panel Mounting There are four holes located along the four sides of the HMI.

  • Page 21: Chapter 2 Hardware

    Chapter 2 Hardware 2.1 Motherboard Introduction SBC-7110 is a 4" industrial motherboard developed on the basis of Intel Haswell-U Processors, which provides abundant peripheral interfaces to meet the needs of different customers. Also, it features dual GbE ports, 5-COM ports and one Mini PCIE configuration, one eDP port, one HDMI port, one LVDS interface.
  • Page 22 Ethernet 2 x PCIe Gbe LAN by Intel 82574L 2 x USB 3.0 (type A)stack ports (USB3) (USB 3.0: USB3-1/USB3-2, USB 2.0: USB1/USB2) 2 x USB 2.0 Pin header for CN3 (USB3/USB4) 1 x USB 2.0 Pin header for CN2 (USB5) 1 x USB 2.0 Pin header for CN1 (USB7 or Touch, option) 1 x USB 2.0 for MPCIE1 (USB8) 1 x RS232/RS422/RS485 port, DB9 connector for external (COM1)
  • Page 23 1 x HDD LED status (CN2) 1 x Power LED status (CN1) 1 x Buzzer External I/O port 2 x COM Ports (COM1/COM2) 2 x USB 3.0 Ports (stack) 2 x RJ45 GbE LAN Ports 1 x HDMI Port 1 x Stack audio Jack (Line out) Watchdog Timer Software programmable 1–255 level by Super I/O (Reserve) Operating: -20℃...

  • Page 24: Figure 2.1: Motherboard Dimensions

    (units :mm) Figure 2.1: Motherboard Dimensions ARCHMI-9XX Series User Manual...

  • Page 25: Jumpers And Connectors Location

    2.3 Jumpers and Connectors Location Figure 2.2: Jumpers and Connectors Location- Board Top Figure 2.3: Jumpers and Connectors Location- Board Bottom ARCHMI-9XX Series User Manual...

  • Page 26: Jumpers Setting And Connectors

    2.4 Jumpers Setting and Connectors 1. CPU1: (FCBGA1168) onboard Intel Haswell-U Processors. Model Processor Number Cores/Threads Remarks SBC-7110-i34010-4G I3-4010U 1.7GHz 2 / 4 SBC-7110-i34010P-4G i3-4010U 1.7GHz 2 / 4 Option SBC-7110-i54310-4G i5-4310U 2.0 up to 3.0GHz 2 / 4 Option SBC-7110-i54310P-4G i5-4310U 2.0 up to 3.0GHz...
  • Page 27 Model Memory SBC-7110-i34010-4G SBC-7110-i34010P-4G 4GB (option) SBC-7110-i54310-4G 4GB (option) SBC-7110-i54310P-4G 4GB (option) SBC-7110-i74510-4G 4GB (option) SBC-7110-i74510P-4G 4GB (option) 5. S-422 (PIN6): (Switch), ATX Power and Auto Power on jumper setting. S-422(Switch) Mode Pin6 (Off) ATX Power Pin6 (On) Auto Power on (Default) 6.
  • Page 28 Procedures of CMOS clear: a) Turn off the system and unplug the power cord from the power outlet. b) To clear the CMOS settings, use the jumper cap to close pins 1 and 2 for about 3 seconds then reinstall the jumper clip back to pins open. c) Power on the system again.
  • Page 29 Pin2 BAT2_LED- Pin3 Ground Pin4 RST_EC 11. DC_IN1: (5.08mm Pitch 1x3 Pin Connector), DC9V~36V System power input connector. Pin# Signal Name Pin1 DC+9V~36V Pin2 Ground Pin3 Model DC_IN1 SBC-7110-i34010U-4G 180°Connector SBC-7110-I54310U-4G 180°Connector SBC-7110-I74510U-4G 180°Connector SBC-7110-I34010UP-4G 45°Connector SBC-7110-I54310UP-4G 45°Connector SBC-7110-I74510UP-4G 45°Connector 12.
  • Page 30 15. JP6: (2.0mm Pitch 2x2 Pin Header),LVDS jumper setting. Function (CN1) Pin1-Pin2 (Close) Signal channel LVDS Pin1-Pin2 (Open) Dual channel LVDS (Default) Pin3-Pin4 (Close) 8/24 bit (Default) Pin3-Pin4 (Open) 6/18 bit 16. U22: AT24C02-DIP8,The EEPROM IC（U22）is the set of LVDS resolution. If you need other resolution settings, please upgrade U22 data.
  • Page 31 18. CN1: (1.25mm Pitch 2x20 Connector, DF13-40P), For 18/24-bit LVDS output connector, Fully supported by Parad PS8625(DP to LVDS), the interface features dual channel 24-bit output. Low Voltage Differential Signaling, A high speed, low power data transmission standard used for display connections to LCD panels.
  • Page 32 Ground Ground EDP_BKLT_EN EDP_TXN_1 EDP_BKLT_CTRL EDP_TXP_1 EDP_VDD_EN Ground EDP_TXN_2 EDP_TXN_0 EDP_TXP_2 EDP_TXP_0 Ground Ground EDP_TXN_3 EDP_AUX_N EDP_TXP_3 EDP_AUX_P EDP_DISP_UTIL 12C1_SCL EDP_HP_CN 12C1_SDA Ground Ground USB7 (option) USB7 USB7_P USB7_N (option) 5V_S5_USB 5V_S5_USB Power LED PWR_LED+ Ground Power LED 20. JP4: (2.0mm Pitch 2x2 wafer Pin Header), USB3(CN1) or Touch jumper setting.
  • Page 33 22. LED1: LED1: LED STATUS. Green LED for Touch Power status. 23. JP1: (2.0mm Pitch 2x3 Pin Header), COM1 jumper setting, pin 1~6 are used to select signal out of pin 9 of COM1 port. JP1 Pin# Function Close 1-2 COM1 RI (Ring Indicator) (default) Close 3-4 COM1 Pin9: DC+5V...
  • Page 34 RS232 (Default) Pin# Signal Name DCD# (Data Carrier Detect) RXD (Received Data) TXD (Transmit Data) DTR (Data Terminal Ready) Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) JP1 select Setting (RI/5V/12V) BIOS Setup: Advanced/F81216 Super IO Configuration/Serial Port 0 Configuration 【RS-232】...
  • Page 35 485- 485+ Ground BIOS Setup: Advanced/F81216 Super IO Configuration/Serial Port 0 Configuration 【RS-485】 27. JP2: (2.0mm Pitch 2x3 Pin Header), COM2 jumper setting, pin 1~6 are used to select signal out of pin 9 of COM2 port. JP2 Pin# Function Close 1-2 COM2 RI (Ring Indicator) (default) Close 3-4...
  • Page 36 29. SATA_P: (2.5mm Pitch 1x2 box Pin Header), One onboard 5V output connector are reserved to provide power for SATA devices. Pin# Signal Name +DC5V Ground Note: Output current of the connector must not be above 1A. 30. SATA2: (SATA 7Pin), SATA Connectors, one SATA connector are provided, with transfer speed up to 6.0Gb/s.
  • Page 37 FRONT_JD LINE1_JD LINE-IN-L LINE-IN-R MIC-IN-L MIC-IN-R GND_AUD MIC1_JD 35. LINE_OUT: (Diameter 3.5mm Jack), HD Audio port, An onboard Realtek ALC662-VD codec is used to provide high quality audio I/O ports. Line Out can be connected to a headphone or amplifier. 36.
  • Page 38 39. CN2: (DF13-30P Connector), For expand output connector, It provides eight GPIO, one RS422 or RS485, one USB2.0, one Power on/off, one Reset. Function Signal Name Pin# Pin# Signal Name Function 5V_S5 5V_S5 PCH_GPIO49 GPIO_IN2 GPIO_IN1 PCH_GPIO48 PCH_GPIO51 GPIO_IN4 GPIO_IN3 PCH_GPIO50 PCH_GPIO53 GPIO_OUT2...
  • Page 39 EC_GPIO8 3.3V_ALLS_EC 41. CN3: (1.27mm Pitch 2X30 Female Header), For expand output connector,It provides four GPIO, two USB 2.0,one PS/2 mouse, one PS/2 keyboard, two uart, one PCIex1, one SMbus. It’s connected to the TB-528 riser Card Function Signal Name Pin# Pin# Signal Name...
  • Page 40 3P3V_S5 3P3V_S5 12V_S0 12V_S0 42. TB-528C2ME1 (option): SBC-7110 Riser Card, TB-528C2ME1 CN3 connect to SBC-7110 CN3 pin Header. TB-528C2ME1 Top: CN3: (1.27mm Pitch 2x30 Pin Header), connect to SBC-7110 CN3 pin Header. M-PCIE1: (Socket 52Pin), mini PCIe socket, it is located at the top, it supports mini PCIe devices with USB2.0 (USB3), Smbus, SIM and PCIe signal.
  • Page 41 LED1: Mini PCIe devices LED Status. SIM1: (SIM Socket 6 Pin), Support SIM Card devices. PS2: (2.0mm Pitch 1x6 Pin Wafer), PS/2 keyboard and mouse port, the port can be connected to PS/2 keyboard or mouse via a dedicated cable for direct used. Pin# Signal Name KBDATA...
  • Page 42 USB4_P USB3_P (option, NC) Ground Ground Ground Note: Before connection, make sure that pinout of the USB Cable is in accordance with that of the said tables. Any inconformity may cause system down and even hardware damages. JP5: (2.0mm Pitch 2x3 Pin Header), COM3 setting jumper, pin 1~6 are used to select signal out of pin 9 of COM3 port.
  • Page 43 Pin3-4: 5V Standby power (option) Pin5-6: 12V Standby power (option) JP6: (2.0mm Pitch 2x3 Pin Header), COM4 setting jumper, pin 1~6 are used to select signal out of pin 9 of COM4 port. JP6 Pin# Function Close 1-2 RI (Ring Indicator) (default) Close 3-4 COM4 Pin9=+5V...
  • Page 44 Signal Name Pin# Pin# Signal Name Ground JP6 Setting: RI/5V/12V 43. TB-528C2 (option): SBC-7110 Riser Card, TB-528C2 CN3 connect to SBC-7110 CN3 pin Header. TB-528C2 Top: CN3: (1.27mm Pitch 2 x 30 Pin Header), connect to SBC-7110 CN3 pin Header. LED1: Mini PCIe devices LED Status.
  • Page 45 MSCLK GPIO1: (2.0mm Pitch 2x5 Pin Header), General-purpose input/output port, it provides a group of self-programming interfaces to customers for flexible use. Signal Name Pin# Pin# Signal Name Ground SMB_DATA_R SMB_CLK_R PCH-GPIO56 PCH-GPIO57 PCH-GPIO59 PCH-GPIO58 USB_23: (2.0mm Pitch 2x5 Pin Header), Front USB connector, it provides one USB port via a dedicated USB cable, speed up to 480Mb/s.
  • Page 46 JP5. Pin# Signal Name DCD# (Data Carrier Detect) RXD (Received Data) TXD (Transmit Data) DTR (Data Terminal Ready) Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) JP5 Setting: Pin1-2: RI (Ring Indicator) (default) Pin3-4: 5V Standby power (option) Pin5-6: 12V Standby power (option) COM6(SBC-7110/COM3)：...
  • Page 47 Pin3-4: 5V Standby power (option) Pin5-6: 12V Standby power (option) COM_6 (option, SBC-7110/COM3) : (2.0mm Pitch 2X5 Pin Header), COM6 Port, up to one standard RS232 port are provided. They can be used directly via COM cable connection. Signal Name Pin# Pin# Signal Name...
  • Page 48 30x50.95mm. Signal Name Function support PCIe 1X USB2.0 (USB3) NC (option) SMBus H1/H2: MPCIE1 SCREW HOLES, H2 for mini PCIE card (30mmx30mm) assemble. H1 for mini PCIE card (30mmx50.95mm) assemble. LED1： Mini PCIe devices LED Status. SIM1（option）： (SIM Socket 6 Pin), Support SIM Card devices. PS_ON1：...
  • Page 49 Signal Name Pin# Pin# Signal Name Ground SMB_DATA_R SMB_CLK_R PCH-GPIO56 PCH-GPIO57 PCH-GPIO59 PCH-GPIO58 USB23(SBC-7110 USB3/USB4)： (Double stack USB type A), Rear USB connector, it provides up to 2 USB2.0 ports, speed up to 480Mb/s. USB_23（option）： (2.0mm Pitch 2x5 Pin Header), Front USB connector, it provides one USB port via a dedicated USB cable, speed up to 480Mb/s.
  • Page 50 Close 5-6 COM3 Pin9: +12V (option) COM5(SBC-7110/COM3): (Type DB9), serial port, standard DB9 serial port is provided to make a direct connection to serial devices. COM5 port is controlled by pins No.1~6 of JP5, select output Signal RI or 5V or 12v, for details, please refer to description of JP5.
  • Page 51 Pin# Signal Name DCD# (Data Carrier Detect) RXD (Received Data) TXD (Transmit Data) DTR (Data Terminal Ready) Ground DSR (Data Set Ready) RTS (Request To Send) CTS (Clear To Send) JP6 Setting: Pin1-2: RI (Ring Indicator) (default) Pin3-4: 5V Standby power (option) Pin5-6: 12V Standby power (option) S1：...
  • Page 52 CN3： (1.27mm Pitch 2X30 Pin Header), connect to SBC-7110 CN3 pin Header. M-PCIE1： (Socket 52Pin), mini PCIe socket, it is located at the top, it supports mini PCIe devices with Smbus, USB2.0,SIM and PCIe signal. MPCIe card size is 30x30mm or 30x50.95mm.
  • Page 53 Pin# Signal Name KBDATA MSDATA Ground KBCLK MSCLK USB_IN（option）： (2.0mm Pitch 2x5 Pin Header) ,Front USB connector, it provides two USB port via a dedicated USB cable, speed up to 480Mb/s. Signal Name Pin# Pin# Signal Name 5V_USB34 5V_USB34 NC (USB4_N) NC (USB3_N) NC (USB4_P) NC (USB3_P)
  • Page 54 Close 3-4 COM4 Pin9: +5V (option) Close 5-6 COM4 Pin9: +12V (option) COM6(SBC-7110/COM4)： (2.0mm Pitch 2X5 Pin Header), COM6 Port, up to one standard RS232 port are provided. They can be used directly via COM cable connection. Signal Name Pin# Pin# Signal Name Ground...
  • Page 55 JP1： (2.0mm Pitch 1x2 Pin Header), Reserve. JP2： (2.0mm Pitch 1x2 Pin Header), Reserve. CAN1/CAN2： (3.5mm Pitch 1x10 Pin connector), it provides two CAN-bus Interface. Pin# Channel Signal Name Function CANL2 CAN bus Signal L Terminal resistor R-(internally connected to CANL2) CAN2 Shield cable (FG) Terminal resistor R+(internally connected to CANH2)
  • Page 56 CN3： (1.27mm Pitch 2X30 Pin Header), connect to SBC-7110 CN3 pin Header. USB23(SBC-7110 USB3/USB4)： (Double stack USB type A), Rear USB connector, it provides up to 2 USB2.0 ports, speed up to 480Mb/s. ARCHMI-9XX Series User Manual...

  • Page 57: Bios Setup

    Chapter 3 BIOS Setup 3.1 Operations after POST Screen After CMOS discharge or BIOS flashing operation, press [Delete] key to enter CMOS Setup. After optimizing and exiting CMOS Setup, the POST screen displayed for the first time is as follows and includes basic information on BIOS, CPU, memory, and storage devices.

  • Page 58: Main Settings

    3.3 Main Settings System Time: Set the system time, the time format is: Hour : 0 to 23 Minute : 0 to 59 Second : 0 to 59 System Date: Set the system date, the date format is: Day: Note that the ‘Day’ automatically changes when you set the date. Month: 01 to 12 Date: 01 to 31...

  • Page 59: Advanced Settings

    3.4 Advanced Settings 3.4.1 ACPI Settings Enable ACPI Auto Conf: [Disabled] [Enabled] Enable Hibernation: [Enabled] [Disabled] ACPI Sleep State: [S1 only (CPU Stop Clock) ] [S3 (Suspend to RAM)] [Suspend Disabled] [Both S1 and S3 available for OS to choose from] Lock Legacy Resources: [Disabled] [Enabled]...
  • Page 60 S3 Video Repost: [Disabled] [Enabled] ACPI Low Power SO Idle: [Disabled] [Enabled] 3.4.2 CPU Configuration Intel(R) Core(TM) i5-4310U @ 2.00GHz CPU Signature 40651 Processor Family Microcode Patch FSB Speed 100 MHz Max CPU Speed 2000 MHz Mix CPU Speed 800 MHz CPU Speed 2400 MHz Processor Cores...
  • Page 61 EIST [Enabled] Turbo Mode [Enabled] …… 3.4.3 SATA Configuration SATA Configuration(S) [Enabled] [Disabled] SATA Mode Selection [AHCI] [RAID] SATA Test Mode [Disabled] [Enabled] Aggressive LPM Support [Enabled] [Disabled] SATA Controller Speed [Default] [Gen1] [Gen2] [Gen3] Software Feature Mask Configuration Serial ATA Port 0 Empty Software Preserve Unknown Serial ATA Port 1...
  • Page 62 [Enabled] [Disabled] XHCI Hand-off: [Enabled] [Disabled] EHCI Hand-off: [Disabled] [Enabled] USB Mass Storage Driver Support [Enabled] [Disabled] USB hardware delays and time-outs: USB transfer time-out: [20 sec] [10 sec] [5 sec] [1 sec] Device reset time-out: [20 sec] [10 sec] [30 sec] [40 sec] Device power-up delay...

  • Page 63: Chipset Settings

    3.4.6 F81216 Second Super IO Configuration Super IO chip F81216 Second IO Serial Port 0 Configuration UART1 Mode Selection: [RS-232] [RS-485] [RS-422] Serial Port 1 Configuration Change Settings [Auto] Serial Port 2 Configuration Change Settings [Auto] Serial Port 3 Configuration Change Settings [Auto] 3.4.7 Intel (R) 82574L Gigabit Network Configuration-70:B3:D5:E7...
  • Page 64 3.5.1 PCH-IO Configuration Intel PCH RC Version 1.8.0.0 Intel PCH SKU Name Premium SKU Intel PCH Rev ID 04/B2 PCH Express Configuration PCI Express Clock Gating [Enabled] DMI Link ASPM Control [Enabled] DMI Link Extended Synch Control [Disabled] PCIe-USB Glitch W/A [Disabled] PCIE Root Port Function Swapping [Disabled]...

  • Page 65: Boot Settings

    3.6 Boot Settings 3.6.1 Administrator Password 3.6.2 User Password Type the password with up to 20 characters and then press Enter key. This will clear all previously typed CMOS passwords. You will be requested to confirm the password. Type the password again and press Enter key.

  • Page 66: Security Settings

    up. A confirmation message will be shown on the screen as to whether the password will be disabled. You will have direct access to BIOS setup without typing any password after system reboot once the password is disabled. Once the password feature is used, you will be requested to type the password each time you enter BIOS setup.

  • Page 67: Save & Exit Settings

    [On] [off] Quiet Boot [Disabled] [Enabled] Fast Boot [Disabled] [Enabled] Boot Option Priorities Boot Option #1 Sets the system boot order Hard Drive BBS Priorities [SATA PM:*** … ] Boot Option #1 SATA PM:***… ****** Disabled 3.8 Save & Exit Settings ARCHMI-9XX Series User Manual...
  • Page 68 Save Changes and Exit Save & Exit Setup save Configuration and exit ? [Yes] [No] Discard Changes and Ext Exit Without Saving Quit without saving? [Yes] [No] Save Changes and Reset Save & reset Save Configuration and reset? [Yes] [No] Discard Changes and Reset Reset Without Saving Reset without saving? [Yes]...

  • Page 69: Chapter 4 Installation Of Drivers

    Chapter 4 Installation of Drivers This chapter describes the installation procedures for software and drivers under the windows 7. The software and drivers are included with the motherboard. The contents include Intel CORE TM SoC chipset driver, VGA driver, LAN drivers, Audio driver, USB 3.0 Driver, Intel®...

  • Page 70: Intel(R) Core Tm Soc Chipset

    4.1 Intel(R) CORE TM SoC Chipset To install the Intel chipset driver, please follow the steps below. Step 1. Select Intel (R) CORE TM SoC Chipset from the list Step 2. Click Next to setup program. ARCHMI-9XX Series User Manual...
  • Page 71 Step 3. Read the license agreement. Click Accept to accept all of the terms of the license agreement. Step 4. Click Install to begin the installation. ARCHMI-9XX Series User Manual...

  • Page 72: Intel(R) Vga Chipset

    Step 5. Click Finish to complete the setup process. 4.2 Intel(R) VGA Chipset To install the VGA drivers, follow the steps below to proceed with the installation. Step 1.Select Intel(R) VGA Chipset from the list. ARCHMI-9XX Series User Manual...
  • Page 73 Step 2. Click Automatically run WinSAT and enable the Windows Aero desktop theme(if supported). Click Next. Step 3. Read license agreement. Click Yes. ARCHMI-9XX Series User Manual...
  • Page 74 Step 4. Click Next to continue. Step 5. Click Next to continue. ARCHMI-9XX Series User Manual...

  • Page 75: Intel(R) Lan Driver

    Step 6. Select Yes, I want to restart this computer now. Then click Finish to complete the installation. 4.3 Intel(R) LAN Driver To install the Intel (R) LAN driver, please follow the steps below. Step 1. Select Intel(R) 82574L LAN Driver from the list. ARCHMI-9XX Series User Manual...
  • Page 76 Step 2. . Click Next. Step 3. Read license agreement. Click I accept the terms in the license agreement. Click Next. ARCHMI-9XX Series User Manual...
  • Page 77 Step 4. Click Next to continue. Step 5. Click Install to begin the installation. ARCHMI-9XX Series User Manual...

  • Page 78: Realtek Alc662 Hd Audio Driver

    Step 6. Click Finish to exit the wizard. 4.4 Realtek ALC662 HD Audio Driver To install the Realtek ALC662 HD Audio Driver, please follow the steps below. Step 1. Select Realtek AL662 HD Audio Driver from the list ARCHMI-9XX Series User Manual...
  • Page 79 Step 2. Click Next to continue. Step 3. Click Yes, I want to restart my computer now. Click Finish to complete the installation. ARCHMI-9XX Series User Manual...

  • Page 80: Usb 3.0 Driver

    4.5 USB 3.0 Driver To install the USB 3.0 Driver, please follow the steps below. Step 1. Select USB 3.0 Driver from the list Step 2. Click Next to continue. ARCHMI-9XX Series User Manual...
  • Page 81 Step 3. Read the license agreement. Then click Yes to continue. Step 4. Click Next to continue. ARCHMI-9XX Series User Manual...
  • Page 82 Step 5. Click Next to continue. Step 6. Select Yes, I want to restart this computer now. Then click Finish to complete the installation. ARCHMI-9XX Series User Manual...

  • Page 83: Intel(R) Mei Driver

    4.6 Intel(R) MEI Driver To install the Intel(R) MEI Driver, please follow the steps below. Step 1. Select Intel(R) MEI Driver from the list. Step 2. Click Next to continue. ARCHMI-9XX Series User Manual...
  • Page 84 Step 3. Read the License Agreement and then click Yes to continue. Step 4. Click Next to continue. ARCHMI-9XX Series User Manual...
  • Page 85 Step 5. Select Yes, I want to restart this computer now. Then click Finish to complete the installation. ARCHMI-9XX Series User Manual...

  • Page 86: Chapter 5 Touch Screen Installation

    Chapter 5 Touch Screen Installation This chapter describes how to install drivers and other software that will allow your touch screen work with different operating systems. 5.1 Windows 7/8/8.1 Universal Driver Installation for PenMount 6000 Series Before installing the Windows 7/8/8.1 driver software, you must have the Windows 7/8/8.1 system installed and running on your computer.
  • Page 87 Step 2. Select Resistive Touch. Step 3. Click Next to continue. ARCHMI-9XX Series User Manual...
  • Page 88 Step 4. Read the license agreement. Click I Agree to agree the license agreement. Step 5. Choose the folder in which to install PenMount Windows Universal Driver. Click Install to start the installation. ARCHMI-9XX Series User Manual...
  • Page 89 Step 6. Click Yes to continue. Step 7. Click Finish to complete installation. ARCHMI-9XX Series User Manual...
  • Page 90 5.1.2 Installing Software (Projected Capacitive) Step 1. Insert the product CD, the screen below would appear. Click touch panel driver from the list. Step 2. Select Projected Capacitive. ARCHMI-9XX Series User Manual...
  • Page 91 Step 3. Click Next to continue. Step 4. Select I accept the terms of the license agreement. Click Next. ARCHMI-9XX Series User Manual...
  • Page 92 Step.5. Click Next to continue. Step 6. Click Install RS232 interface driver. Then click Next to continue. ARCHMI-9XX Series User Manual...
  • Page 93 Step 7. Select None. Click Next. Step 8. Click OK to continue. Step 9. Click Support Muti-Monitor System. Click Next. ARCHMI-9XX Series User Manual...
  • Page 94 Step 10. Go to C:\Program Files\eGalaxTouch. Click Next. Step 11. Click Next. ARCHMI-9XX Series User Manual...
  • Page 95 Step 12. Click Create a eGalaxTouch Utility shortcut on desktop. Click Next. Step 13. Wait for installation. ARCHMI-9XX Series User Manual...

  • Page 96: Software Functions

    Step 14. Click Yes to do 4 point calibration. 5.2 Software Functions 5.2.1 Software Functions(Resistive Touch) Upon rebooting, the computer automatically finds the new 6000 controller board. The touch screen is connected but not calibrated. Follow the procedures below to carry out calibration.
  • Page 97 Calibrate This function offers two ways to calibrate your touch screen. ‘Standard Calibration’ adjusts most touch screens. ‘Advanced Calibration’ adjusts aging touch screens. Standard Calibration Click this button and arrows appear pointing to red squares. Use your finger or stylus to touch the red squares in sequence.
  • Page 98 Step 2.Click “Standard Calibration” to start calibration procedure NOTE: The older the touch screen, the more Advanced Mode calibration points you need for an accurate calibration. Use a stylus during Advanced Calibration for greater accuracy. Please follow the step as below: ARCHMI-9XX Series User Manual...
  • Page 99 Step 3. Select Device to calibrate, then you can start to do Advanced Calibration. NOTE: Recommend to use a stylus during Advanced Calibration for greater accuracy. Plot Calibration Data Check this function and a touch panel linearity comparison graph appears when you have finished Advanced Calibration.
  • Page 100 Setting Touch Mode This mode enables and disables the mouse’s ability to drag on-screen icons – useful for configuring POS terminals. Mouse Emulation – Select this mode and the mouse functions as normal and allows dragging of icons. Click on Touch – Select this mode and mouse only provides a click function, and dragging is disables.
  • Page 101 Edge Compensation You can use Edge Compensation to calibrate more subtly. ARCHMI-9XX Series User Manual...
  • Page 102 About This panel displays information about the PenMount controller and driver version. Multiple Monitors Multiple Monitors support from two to six touch screen displays for one system. The PenMount drivers for Windows 7/8/8.1 support Multiple Monitors. This function supports from two to six touch screen displays for one system. Each monitor requires its own PenMount touch screen control board, either installed inside the display or in a central unit.
  • Page 103 1. Check the Enable Multiple Monitor Support box; then click Map Touch Screens to assign touch controllers to displays. 2. When the mapping screen message appears, click OK. 3. Touch each screen as it displays “Please touch this monitor”. Following this sequence and touching each screen is called mapping the touch screens.
  • Page 104 6. “Touch this screen to start its calibration” appears on one of the screens. Touch the screen. 7. “Touch the red square” messages appear. Touch the red squares in sequence. 8. Continue calibration for each monitor by clicking Standard Calibration and touching the red squares.
  • Page 105 PenMount Monitor has the following function Control Panel Open Control Panel Windows Beep Setting Beep function for each device Right Button When you select this function, a mouse icon appears in the right-bottom of the screen. Click this icon to switch between Right and Left Button functions.
  • Page 106 5.2.2 Software Functions(Projected Capacitive) General In this window, you can see there is USB Controller. Click OK to continue. Monitor Mapping to adjust touch panel to search for device ARCHMI-9XX Series User Manual...
  • Page 107 Setting Beep Beep On Touch Beep On Release Beep From System Beep Beep From Sound Card Linearization Style 9 points 25 points Double Click Time Shorter Longer Double Click Area Smaller Bigger Normal mode Simulate the mouse mode ARCHMI-9XX Series User Manual...
  • Page 108 Option Function Enable Constant Touch Enable Auto Right Click Enable Touch Enable Cursor Stabilization Constant Touch Area Auto Right Click Time ARCHMI-9XX Series User Manual...
  • Page 109 Tools Click OK to continue the settings. 4 Points Calibration Do 4 points alignment to match display. Clear and Calibrate Clear linearization parameter and do 4 points alignment. Linearization Do 9 points linearization for better touchscreen linearity. Draw Test Do draw test to verify the touch accuracy. ARCHMI-9XX Series User Manual...
  • Page 110 Display In this window, it shows the mode of display. Enable Multiple Monitors. Map to main display if system has only one display monitor Full Screen Lower Screen Left Screen Upper Screen Right Screen ARCHMI-9XX Series User Manual...
  • Page 111 Other Other mode of display. Quarter1~4 and Customized area. Active Area Drag active area to enable Active Area Function. ARCHMI-9XX Series User Manual...
  • Page 112 Hardware Saturn Hardware Configuration ARCHMI-9XX Series User Manual...
  • Page 113 About To display information about eGalaxTouch and its version. ARCHMI-9XX Series User Manual...
