Page 1 T3DSO1000HD Digital Oscilloscope User Manual...
Page 2 This page is intentionally blank. T3DSO1000HD User Manual...
Page 3 Declaration © 2024 Teledyne LeCroy, Inc. All rights reserved. Teledyne Test Tools is a brand and trademark of Teledyne LeCroy, Inc. Other product or brand names are trademarks or requested trademarks of their respective holders. Specifications, prices, availability and delivery subject to change without notice.
Page 4 Contents COPYRIGHT INFORMATION ..............3 ABOUT THE T3DSO1000HD SERIES ........... 11 GENERAL SAFETY SUMMARY ............12 SAFETY TERMS AND SYMBOLS ............13 GENERAL CARE AND CLEANING ............14 GENERAL INSPECTION ................ 15 QUICK START ..................16 MECHANICAL DIMENSION ............16 ADJUST THE SUPPORTING LEGS ..........
Page 5 MOUSE AND KEYBOARD OPERATION ........60 CHOOSING THE LANGUAGE ............60 FRONT PANEL ..................61 VERTICAL CONTROL ..............62 HORIZONTAL CONTROL .............. 63 TRIGGER CONTROL ..............63 MULTIPLE APPROACHES TO RECALL FUNCTIONS....... 66 MENU BAR ..................66 T3DSO1000HD User Manual...
Page 6 TRIGGER MODE ................110 TRIGGER TYPE ..................112 EDGE TRIGGER ................113 SLOPE TRIGGER ................114 PULSE TRIGGER ................117 VIDEO TRIGGER ................119 WINDOW TRIGGER ..............124 INTERVAL TRIGGER ..............126 DROPOUT TRIGGER ..............127 RUNT TRIGGER ................128 T3DSO1000HD User Manual...
Page 7 CURSORS ....................170 CURSORS MODE ................171 CURSORS TYPE ................172 SELECT AND MOVE CURSORS ..........177 MEASUREMENT .................. 179 SET PARAMETERS ............... 182 TYPE OF MEASUREMENT ............185 TREND.................... 192 TRACK ................... 193 DISPLAY MODE ................194 T3DSO1000HD User Manual...
Page 8 11 ABSOLUTE ..................214 12 SIGN....................215 13 EXP10 ..................... 216 14 LG....................217 15 INTERPOLATE ................218 16 FILTER .................... 219 17 FREQUENCY ANALYSIS ............. 222 18 REFERENCE .................. 235 19 SEARCH ..................237 20 NAVIGATE ..................240 T3DSO1000HD User Manual...
Page 9 11 SOA ....................280 BODE PLOT ................... 283 CONFIGURATION ................ 284 SWEEP .................... 285 DISPLAY ..................288 DATA ANALYSIS ................291 DISPLAY ..................294 ARBITRARY WAVEFORM GENERATOR .......... 303 OUTPUT ..................305 WAVE TYPE ................... 305 OTHER SETTING ................307 T3DSO1000HD User Manual...
Page 10 SCREEN TEST ................331 KEYBOARD TEST ................ 332 LED TEST ..................333 SELF-CALIBRATION ..............334 QUICK CAL ................... 335 REMOTE CONTROL ..............335 WEB BROWSER ................336 10 OTHER CONNECTIVITY ............. 338 TROUBLESHOOTING ................339 COMPLIANCE INFORMATION ............342 T3DSO1000HD User Manual...
Page 11 About the T3DSO1000HD Series Teledyne Test Tools T3DSO1000HD Digital Oscilloscopes are available in bandwidths of 100 MHz and 200 MHz, have maximum record length of 100 Mpts/ch, and display 4 analog channels + 16 digital channels mixed signal analysis ability.
Page 12 Inadequate ventilation may cause an increase in temperature, which may eventually damage the instrument. Maintain suitable ventilation and inspect the fan and intake regularly. Avoid Exposed Circuits and Components Do not touch exposed contacts or components when the instrument's power is on. T3DSO1000HD User Manual...
Page 13 Indicates potential injury or hazards that may happen. CAUTION Indicates potential damage to the instrument or other property that may happen. Symbols used in this product. These symbols may appear on the product: Hazardous Protective Earth Warning Earth Power Switch Voltage Ground Ground T3DSO1000HD User Manual...
Page 14 To avoid damage to the surface of the instrument and probe, please do not use any corrosive liquid or chemical cleansers. Make sure that the instrument is completely dry before restarting it to avoid potential short circuits or personal injury. T3DSO1000HD User Manual...
Page 15 The consigner or carrier will be responsible for damages to the instrument resulting from shipment. TELEDYNE LECROY would not provide free maintenance or replacement if the instrument has been damaged in shipment. 2. Inspect the instrument If there are instruments found damaged, defective or failure in electrical and mechanical tests, please contact TELEDYNE LECROY.
Page 16 Quick Start Mechanical Dimension Front View Top View T3DSO1000HD User Manual...
Page 17 Adjust the Supporting Legs Adjust the supporting legs properly to use them as stands to tilt the oscilloscope upwards for stable placement as well as easier operation and observation of the instrument. T3DSO1000HD User Manual...
Page 18 The standard power supply for the instrument is 100~240 V, 50/60 Hz. Please use the power cord provided with the instrument to connect it to AC power. 3.1.1 Power The T3DSO1000HD provides two ways for power on. Auto Power-on When the “Auto Power-on” option is enabled, once the oscilloscope is connected to the AC power supply through the power cord, the oscilloscope boots automatically.
Page 19 The power cord should be unplugged from the AC outlet if the scope is not to be used for an extended period. System Information Follow the steps below to examine the software and hardware versions of the oscilloscope. Utility > Menu > System Info See the section “System Information” for details. T3DSO1000HD User Manual...
Page 20 Front Panel Includes knobs and buttons. See "Front Probe Compensation / Ground Terminal USB 2.0 Host Ports Connect to USB storage devices for data transfer or USB Digital Input Connector Analog Input Connectors Power Switch Supporting Legs T3DSO1000HD User Manual...
Page 21 10M/100M LAN Port Connect the port to the network for remote control USB 2.0 Device Connects with a PC for remote control USB 2.0 Host Connect with a USB storage device or USB mouse/keyboard AC Power Input Keyhole Handle T3DSO1000HD User Manual...
Page 22 Check the displayed waveforms and compare them with the following figure. Under Compensated Over Compensated Compensated Correctly Use a nonmetallic flat-head screwdriver to adjust the low-frequency compensation adjustment hole on the probe until the waveform matches the “Compensated Correctly” waveform above. T3DSO1000HD User Manual...
Page 23 Dialog Box is the main area to select the parameters for a chosen specific function Trigger Delay Indicator locates where the trigger is on the horizontal axis Trigger Level Indicator shows the level where the waveform triggers Cursors show where measurement points have been set T3DSO1000HD User Manual...
Page 24 Coupling and Input Impedance Vertical Scale Vertical Offset Bandwidth Information Probe Attenuation Factor Timebase and Trigger Descriptor Boxes Trigger delay Horizontal scale (timebase ） # Samples Sample Rate Trigger source Trigger coupling Trigger mode Trigger level Trigger type Trigger slope T3DSO1000HD User Manual...
Page 25 Scroll bar. When parameters are more than the displayed range, the blue scrollbar will be displayed. By sliding the dialog area up and down, or rolling the mouse wheel, it can scroll to the area not displayed T3DSO1000HD User Manual...
Page 26 To Set Parameters The T3DSO1000HD series provides several ways to set parameters: Switch – sets parameters with two states, such as to enable or disable a function. Touch the switch region to change from one state to the other. List – sets parameters with more than two options, such as the coupling mode of channels.
Page 27 Drag the waveform up and down to move it on the vertical axis Pinch and spread the waveform vertically to re-scale the vertical gain Touch and drag the cursor to move it T3DSO1000HD User Manual...
Page 28 Draw a rectangular box to create a zone or a histogram region. At the beginning of the gesture keep the angle close to 45° so it can be recognized as the drawing box gesture T3DSO1000HD User Manual...
Page 29 When it is lighted the functionality is enabled Rotate the universal knob to set the value of the activated parameter, or to move the selected cursor. Push to select a different cursor Choosing the Language Utility ＞ Menu ＞ System setting ＞ Language T3DSO1000HD User Manual...
Page 30 Touch the channel descriptor box and then touch the Off button to disable it. T3DSO1000HD User Manual...
Page 31 Rotate the knob to adjust the vertical scale (volts/div). Push to switch to alternate between coarse and fine adjustments Rotate the knob to adjust the DC offset or vertical position of the channel. Push to set the offset to zero T3DSO1000HD User Manual...
Page 32 Copy the setting of the current channel to another channel Quickly select the current channel as the source of a specified operation ( Trigger, FFT, Measure, Cursor, Search, DVM and Counter ) Disable the channel Hide the trace T3DSO1000HD User Manual...
Page 33 Users can customize the text and display of the label Quickly apply a specified operation (Cursor, Measure, FFT, Search, DVM, Histogram and Mask Test) to the current channel Impedance Units for the channel Deskew Enable / disable invert Trace visible / hidden T3DSO1000HD User Manual...
Page 34 ▲ to increase and ▼ to decrease the trigger delay Set the trigger delay to zero Set the trigger point to the left part of the screen Set the trigger point to the right part of the screen Open the Acquire dialog box T3DSO1000HD User Manual...
Page 35 Select the acquisition mode (Normal / Peak / Average / ERES) Select the Memory Management mode (Auto, Fixed Sample Rate, and Fixed Memory) Select the maximum memory depth Enter the sequence menu XY mode on / off T3DSO1000HD User Manual...
Page 36 The region without the gray background in the main window is the portion of trace that is magnified in the zoom window. Please refer to the User Manual for detailed operation instructions of Zoom mode. T3DSO1000HD User Manual...
Page 37 50% of the waveform Ready LED, lighted when ready for trigger; Trig'd LED, lighted when a trigger event happens Indicators Relative to Trigger Horizontal 0 position Horizontal 0 position Trigger level Indicator Indicator (out of screen) Indicator T3DSO1000HD User Manual...
Page 38 Reject) Enable / disable Noise Rejection. When Noise Reject is on, the trigger hysteresis is increased, so the noise immunity of the trigger circuit is better. As a compromise, the trigger sensitivity degrades Set the Zone trigger T3DSO1000HD User Manual...
Page 39 Touch + > Func1 / Func2, or push the button on the front panel to create a math trace and open math setup dialog box Math trace Math setup dialog box Selects the trace (F1 ~ F2) Selects the operator and source (C1~C4, Z1~Z4, F1~F2) T3DSO1000HD User Manual...
Page 40 Measurement parameters and statistics display area. If select the mode as “Simple”, the "Simple" parameter area is displayed. Touch the button on the front panel to reset the statistics Measure dialog box T3DSO1000HD User Manual...
Page 41 User Manual. Push the button to open the cursors setup dialog box Rotate the knob to move the selected cursor; push to select different cursor The display mode of cursors Following Fixed T3DSO1000HD User Manual...
Page 42 Set the label text of the reference trace Save the waveform specified in to the specified location in The reference waveforms（.ref）can be saved to an external storage device. See “ Save / Recall ” for details. T3DSO1000HD User Manual...
Page 43 Save/Recall Touch Utility Save/Recall to save / recall a setup, picture, waveform data or ＞ reference waveform. Choose Save or Recall operation Select the object type Recall the File Manager for further operations T3DSO1000HD User Manual...
Page 44 Specifications are not guaranteed during the warm- up period. Whenever the oscilloscope is used in an environment outside 23 ± 5 °C, or when it has been more than one month since the previous calibration, a self-calibration is recommended. T3DSO1000HD User Manual...
Page 45 Changing vertical scale or channel interleaving mode will initiate the same ADC calibration procedure in the background. This is always enabled, regardless of the status of Quick Cal. Touch Utility ＞ Menu ＞ Maintenance ＞ Quick Cal to set Quick Cal. T3DSO1000HD User Manual...
Page 46 Touch Screen Display Overview The entire T3DSO1000HD display is a capacitive touch screen. Use your fingers to touch, drag, pinch, spread, or draw a selection box. Many controls that display information also work as “buttons” to access other functions. If you are using a mouse, you can click anywhere that you can touch to activate a control.
Page 47 You can enter most menus by using the front panel or parameter description labels instead of the menu bar. However, the following operations can only be accessed through the menu bar: Utility > Help Utility > Reboot Display Acquire T3DSO1000HD User Manual...
Page 48 When the trigger position is outside the screen, the direction of the triangle points outside the screen as well. Channel Offset Indicator with a channel number shows the offset position of the corresponding channel. T3DSO1000HD User Manual...
Page 49 Touching the boxes creates a dialog box. See chapter “Vertical Setup” for more details. Below is an example for analog channel 1: Channel Index Coupling and Input Impedance Vertical Scale Vertical Offset Bandwidth Information Probe Attenuation Factor T3DSO1000HD User Manual...
Page 50 1.00 V/div, the full scale of the oscilloscope is 1.00 V/div * 8 div=8 V. Vertical Offset: The offset of the channel in the vertical direction. When the vertical offset is 0, the channel offset indicator is located in the middle of the vertical axis. T3DSO1000HD User Manual...
Page 51 ：1:1 attenuation, suitable for direct coaxial cable connection or passive probes with 1X attenuation ：10:1 attenuation, suitable for general passive probes or active probes with 10X attenuation ：100:1 attenuation, suitable for some high-voltage probes ：Custom attenuation factor T3DSO1000HD User Manual...
Page 52 500 us/div * 10 div = 5 ms. # Samples: The number of sample points on the current screen. Sample Rate: The current sample rate. The Trigger Descriptor box shows the parameters of the trigger setting. See chapter “Trigger” for detailed information. T3DSO1000HD User Manual...
Page 53 • LFR: The signal is coupled through a capacitive high-pass filter network, DC is rejected and low frequencies are attenuated. For stable triggering on medium to high-frequency signals. See the datasheet for details of the cut-off frequency. T3DSO1000HD User Manual...
Page 54 Trigger level: The source voltage level or levels that mark the threshold for the trigger to fire. Trigger levels specified in Volts normally remain unchanged when the vertical gain or offset is modified. Trigger type: See the chapter "Trigger" for details. T3DSO1000HD User Manual...
Page 55 Scroll bar. When parameters are more than the displayed range, the blue scrollbar will be displayed. By sliding the dialog area up and down, or rolling the mouse wheel, it can scroll to the area not displayed. T3DSO1000HD User Manual...
Page 56 To Set Parameters The T3DSO1000HD provides a couple of different ways to input/select parameters: Switch: Sets parameters with two states, such as to enable or disable a function. Touch the switch region to change from one state to the other.
Page 57 The dialog box can be set to be hidden automatically. When the instrument is not operated beyond the set time, the dialog box will be automatically hidden. Follow the steps below: Display > Menu > Hide Menu Menu style = Floating, Dialog box is hidden and Dialog box is displayed T3DSO1000HD User Manual...
Page 58 Menu style = Embedded, and Dialog box is displayed T3DSO1000HD User Manual...
Page 59 Pinch and spread the waveform vertically to on the vertical axis re-scale the vertical gain Touch and drag the cursor to move it. Touch and drag the cursor information region to move the pair of cursors simultaneously. T3DSO1000HD User Manual...
Page 60 Mouse and Keyboard Operation The T3DSO1000HD user interface features mouse control as well as a touch screen. If the oscilloscope is connected to a USB mouse, you can click on the object with the mouse instead of touching the object. Similarly, if a USB keyboard is connected, you can use the keyboard to input characters instead of using the virtual keyboard.
Page 61 All the knobs on the front panel are multi-function. They can be pushed as well as rotated. Pushing a knob quickly recalls a specific function, which is indicated by the silkscreen near the knob. T3DSO1000HD User Manual...
Page 62 Rotate the knob to adjust the DC offset or vertical position of the activated trace. Push to set the offset to zero. When the digital channel is active, rotate the knob to change the position of the selected digital channel T3DSO1000HD User Manual...
Page 63 Single mode: Triggers once when all conditions are met Normal mode: Triggers repeatedly when all conditions are met Trigger level adjustment: Push to set the level to 50% of the waveform Trigger status LED, Ready and Trig'd T3DSO1000HD User Manual...
Page 64 When the parameter setting area is highlighted, the Universal Knob can be used to adjust the parameter. Press the knob to select an option from the list. The default function of the Universal Knob is to adjust the intensity of the waveform traces. T3DSO1000HD User Manual...
Page 65 Recalls the Wave Gen dialog box. The LED on the button lights to indicate the output of the AWG is enabled. The preset functions can be called quickly through this button. See the section "Quick Action" for details T3DSO1000HD User Manual...
Page 66 For example, to open the trigger setup dialog box, you can follow the steps below: Trigger > Menu The operations can be completed either by touch or by mouse clicks. T3DSO1000HD User Manual...
Page 67 Most of the functions of the oscilloscope can be recalled directly by the shortcut buttons on the front panel. See the chapter "Front Panel" for details. To open the trigger setup dialog box, press the Setup button in the trigger control area on the front panel. T3DSO1000HD User Manual...
Page 68 Auto Setup will not work on all signal types, especially time-varying bursts or slow signals (< 100 Hz). If Auto Setup cannot achieve desired settings, manually adjustment of the vertical, horizontal, and trigger systems is preferred. See the chapters "Vertical Setup", "Horizontal and Acquisition Setup" and "Trigger" for details. T3DSO1000HD User Manual...
Page 69 Touch the + button and then select the expected channel to turn it on, and its channel descriptor box and a dialog box will appear on the display. Touch the channel descriptor box and then touch the Off button to disable it. Turn on C1 Turn off C1 T3DSO1000HD User Manual...
Page 70 The vertical scale can be adjusted in coarse or fine mode. Fine mode can reach the full- scale display as close as possible, which gets the best measurement accuracy in the vertical direction. The oscilloscope automatically switches to fine mode when the vertical scale is controlled by touch gestures. T3DSO1000HD User Manual...
Page 71 GND: The channel is grounded by an internal switch. GND coupling is used to observe the zero offset error of the analog channels or determine the source of noise in the waveform (from signal or from oscilloscope itself) T3DSO1000HD User Manual...
Page 72 When the frequency component of the signal is very low, better signal-to-noise ratios (SNR) can be obtained by turning on a bandwidth limit. The T3DSO1000HD provides two hardware bandwidth limit options: Full or 20 MHz.
Page 73 With this setting, some common functions such as Trigger, FFT, Simple Measure, Cursor, Search, Mask Test, Counter, and Wave Gen can be quickly applied to the selected channel. Once a function is specified, it will switch directly to the function menu and automatically set that channel as the source. T3DSO1000HD User Manual...
Page 74 Warning: The 50 Ω input setting is not a high-power input. Damage can occur if the input exceeds the published specifications. See the datasheet for more details. Unit Voltage unit "V" or current unit "A”. When using the current probe, the unit should be set to "A". T3DSO1000HD User Manual...
Page 75 Before deskew After deskew Note: When the channel with deskew compensation is the trigger source, the trigger delay indicator does not change as the deskew value changes. T3DSO1000HD User Manual...
Page 76 When invert is enabled, the waveform is rotated 180 degrees around earth potential (0 Volts). Before invert After invert Trace When the trace is hidden, the channel waveform is no longer displayed on the screen, while the acquisition is still running in the background. Trace visible Trace hidden T3DSO1000HD User Manual...
Page 77 The 16 digital channels are separated into two groups and each group has its threshold, making it possible to simultaneously view data from different logic families. Note: To avoid personal injury or damage to the logic probe and any associated equipment, the following safety precautions should be noted. T3DSO1000HD User Manual...
Page 78 The equipment shall be used only for the purposes specified by the manufacturer. The T3DSO1000-LS probe is used only for Teledyne Test Tools' special series of oscilloscopes. Protection mechanisms can be compromised if the way the devices connected by the T3DSO1000-LS are not used for their intended purpose.
Page 79 Digital channel indicators. Up to 16 digital channels are organized in two groups with different thresholds: D15~D8 and D7~D0. Every channel can be turned on or off individually. Labels can be set to data, address, or custom characters. Digital bus T3DSO1000HD User Manual...
Page 80 Click + at the bottom of the display and select the "Digital" to turn it on. Click the digital channel descriptor box, and select Off on the pop-up menu to turn it off. Refer to the operation in the chapter "Vertical Setup" for details. T3DSO1000HD User Manual...
Page 81 ▲ to increase and ▼ to decrease the number of divisions occupied by the digital channels Reset the height to the default value Turn off the digital channels Open the digital dialog box on the right side Height=8div, Position=0div Height=4div, Position=1div T3DSO1000HD User Manual...
Page 82 Custom option. Logic threshold of D15~D8 Set the channels to be displayed Deskew setting, the same as setting analog channels Bus setting System information and firmware upgrade. Remove T3DSO1000-LS probe. T3DSO1000HD User Manual...
Page 83 ‘1’. The configurable logical level includes TTL, CMOS, LVCMOS 3.3 V, LVCMOS 2.5 V, and Custom. The setting range of the custom threshold is -10.0 V to + 10.0 V. T3DSO1000HD User Manual...
Page 84 Set the bit width of the digital bus Set the digital bus data Reset the digital bus data to the default state Enable/disable the display of the digital bus Set the vertical position of the bus Return to the previous menu T3DSO1000HD User Manual...
Page 85 In this dialog, the mapping relationship between the bus bits and the digital channels is shown as Bit.x[Dy]. For example, Bit.0[D15] means that bit 0 of the bus is D15. Touch Bit.x[Dy] to assign the digital channel D0-D15 to the specified bit x. T3DSO1000HD User Manual...
Page 86 ▲ to increase and ▼ to decrease the trigger delay Set the trigger delay to zero Set the trigger delay to the left part of the screen Set the trigger delay to the right part of the screen Open the Acquire dialog box T3DSO1000HD User Manual...
Page 87 Detect). See the section "Acquisition" for details. Select the Memory Management mode (Auto and Fixed Sample Rate). See the section "Memory Management" for details. Select the maximum memory depth Enter the sequence menu. See the section “Sequence” for details XY mode on/off T3DSO1000HD User Manual...
Page 88 But for step signals/fast rise times, it will introduce false overshoot due to the Gibbs phenomenon. X Interpolation Sinc Interpolation Acq Mode: "Fast" is the default setting. The T3DSO1000HD provides a very high waveform update rate in fast mode. "Slow" mode will slow down the waveform update on purpose. T3DSO1000HD User Manual...
Page 89 T3DSO1000HD can obtain the best waveform refresh rate with the Memory Depth of 1 kpts. Under the full Memory Depth, T3DSO1000HD can still operate at full speed sampling at timebases < 10 ms/div which provides high resolution captures for long time duration events.
Page 90 (200 ns) is much larger than the pulse width (6.8 ns), it is difficult to capture the narrow pulses in normal mode, but peak mode can ensure that each pulse is captured. Normal mode Peak mode T3DSO1000HD User Manual...
Page 91 Nyquist sample theorem with respect to the highest frequency of the input signal. If the set sample rate is less than twice the maximum frequency of the input signal, distorted signals will be obtained due to sampling aliasing. T3DSO1000HD User Manual...
Page 92 If you would like to stop the display in Roll mode, press the Run/Stop button. To clear the display and restart an acquisition in Roll mode, press the Run/Stop button again. ： Zoom is only supported after Stop in Roll mode. Note T3DSO1000HD User Manual...
Page 93 If sequence mode is enabled, the display will not update until all the sequences have been acquired. The T3DSO1000HD can achieve a minimum 2 us trigger interval in Sequence mode, corresponding to a waveform update rate of 500,000 wfm/s.
Page 94 200 ns; pulse width is 200 ns, and amplitude is 3.2 Vpp. Press the AutoSetup button on the front panel. Set the coupling mode of C1 to DC50Ω, and vertical scale to 500 mV/div, vertical offset to 0. Set the trigger level to 0. T3DSO1000HD User Manual...
Page 95 (45976 in this example, up to 80,000 depending on the number of samples at the current time base). Wait patiently until the acquisition completes, then all the waveforms satisfying the trigger conditions are displayed on the screen. T3DSO1000HD User Manual...
Page 96 During acquisition, there is a counter on the screen indicating the number of segments that have been acquired. In the example, 45976 pulses can be obtained with the sample rate of 2 GS/s at the maximum memory depth. T3DSO1000HD User Manual...
Page 97 Turn on or off the list List time type Set the playing mode Play backward, pause, and play forward Set the time interval between two frames when playing automatically List displays the frame index and time label for each frame. T3DSO1000HD User Manual...
Page 98 To enable history mode, touch the Frame No . area twice, then the virtual numeric keypad pops up. Input the number "5412" to specify the 5412th segment (frame). Observing the 5412th frame captured by Sequence in history mode T3DSO1000HD User Manual...
Page 99 In addition to manually specifying a frame, history mode supports autoplay: Press the softkey to replay the waveform from the current frame to the first. Press the softkey to stop replay. Press the softkey to replay the waveform from the current frame to the last. T3DSO1000HD User Manual...
Page 100 When a measurement is enabled in history mode, if the Interval Time is set to small (e.g. in us) the speed of automatic play may not meet the setting, because measurements may take a longer time for each frame. T3DSO1000HD User Manual...
Page 101 Zoom The T3DSO1000HD supports waveform zoom in the horizontal and vertical directions. Press down the horizontal knob or the button on the front panel to turn on the zoom function. When the Zoom function is on, the waveform area is divided into upper and lower parts. The area of about 1/3 height above is the main window, and the area of about 2/3 height below is the zoom window.
Page 102 The gestures for changing the setting in the vertical direction are similar. Adjust the horizontal position of the zoom area by dragging left and right in the zoom area of the main window or waveform in the Zoom window. T3DSO1000HD User Manual...
Page 103 Adjust the horizontal scale of the Zoom window by horizontal pinch and spread in the zoom area of the main window or the Zoom window T3DSO1000HD User Manual...
Page 104 Adjust the horizontal/ vertical scale of the main window by using a pinching or spreading gesture in the gray area of the main window Note: Zoom traces (Z1~Z4) can be used as the source of Measurement, Math and Mask tests. T3DSO1000HD User Manual...
Page 105 Arm: The pre-trigger buffer is not full, and the oscilloscope does not respond to any trigger events. Ready: The pre-trigger buffer is full, and the oscilloscope is waiting for the trigger event. Trig’d: A trigger event is detected and the oscilloscope starts to fill the post-trigger buffer. T3DSO1000HD User Manual...
Page 106 You need to have some knowledge of the signal-under-test to quickly capture the desired waveform. T3DSO1000HD User Manual...
Page 107 Set the trigger mode to "Normal", which is equivalent to pressing the Normal button on the front panel Set the trigger mode to “Force”, no key control, see the chapter “Trigger Mode” for details. T3DSO1000HD User Manual...
Page 108 As a compromise, the trigger sensitivity degrades Trigger Related Label Trigger level Indicator Horizontal 0 position Horizontal 0 position Indicator (out of screen) Indicator T3DSO1000HD User Manual...
Page 109 In some special triggers, the system will automatically set the trigger level, such as using AC Line as the trigger source. T3DSO1000HD User Manual...
Page 110 Single： Captures and displays a single frame that satisfies the trigger conditions, and then stops. The following trigger events are ignored until the Single acquisition is restarted. Single-mode is suitable for:  One-shot events or periodic signals, such as power-on\off waveforms on a power rail  Rare events T3DSO1000HD User Manual...
Page 111 Single: After forcibly triggering a frame, return to Stop mode. Since the front panel does not have forced trigger button, a shortcut for forced trigger is added to the top trigger drop-down menu and the bottom trigger information pull-up menu. T3DSO1000HD User Manual...
Page 112 Trigger Type Overview The trigger modes of the T3DSO1000HD are digital designs. Compared with analog trigger circuits, digital triggers can not only greatly optimize trigger precision and trigger jitter, but also support multiple trigger types and complex trigger conditions. Edge -- Trigger on a rising edge, falling edge or both...
Page 113 Holdoff, coupling, and noise reject can be set in edge trigger, see the sections "Holdoff", "Trigger Coupling" and "Noise Reject" for details. Note: Press the Auto Setup button, and the oscilloscope will set the trigger type to Edge. T3DSO1000HD User Manual...
Page 114 Touch the Source area to select trigger source, and touch the Slope area to select rising or falling. Rising -- Only trigger on the positive slope Falling -- Only trigger on the negative slope T3DSO1000HD User Manual...
Page 115 The lower level should always be less than or equal to the upper level. In the trigger descriptor box, the lower level is displayed. T3DSO1000HD User Manual...
Page 116 Holdoff, coupling, and noise reject can be set in slope trigger, see the sections "Holdoff", "Trigger Coupling" and "Noise Reject" for details. T3DSO1000HD User Manual...
Page 117 Great than a time value（≥）-- Trigger when the positive or negative pulse time of the input signal is greater than the specified time value. Below is an example of a trigger condition set to a positive pulse width > 100ns T3DSO1000HD User Manual...
Page 118 Holdoff, coupling, and noise reject can be set in pulse trigger, see the sections "Holdoff", "Trigger Coupling" and "Noise Reject" for details. T3DSO1000HD User Manual...
Page 119 Source, standard, and synchronization mode can be set in the video trigger dialog box. When the synchronization mode is "Select", line and field can be specified. Touch the Standard and select the video standard. The T3DSO1000HD supports the following video standards:...
Page 120 If the "Of Lines" is set to 800, the correct relationship between them is as follows: Of Lines Interlace Of Fields Trigger Line Trigger Field 1/2/4/8 1/1~2/1~4/1~8 1/2/4/8 1/1~2/1~4/1~8 1/2/4/8 1/1~2/1~4/1~8 T3DSO1000HD User Manual...
Page 121 HDTV 1080P/50、1080P/60 1 to 563 1 to 562 HDTV 1080i/50、1080i/60 To gain familiarization with the video trigger, try these two examples: • Trigger on a specific line of video (NTSC standard) • Use “Custom” to trigger video signals T3DSO1000HD User Manual...
Page 122 Touch the Sync and select the "Select" to make the Field and Line optional, then select "1" in the "Field", and set the "Line" to "22" by using the universal knob or the virtual keypad. Trigger on a Specific Line of Video (NTSC) T3DSO1000HD User Manual...
Page 123 Select the "Select" mode, then set the specified line and the specified field to trigger the signal. Assuming that the "Field" is set to 8, you can select any field from 1 to 8, and each field can choose any line from 1 to 100. T3DSO1000HD User Manual...
Page 124  If the lower trigger level is within the waveform amplitude range while the upper trigger level is out of the waveform amplitude range, the oscilloscope will trigger on the falling edge only. T3DSO1000HD User Manual...
Page 125 200mV, it represents a range of ±200 mV, which is a 400mV window. Holdoff, coupling, and noise reject can be set in window trigger, see the sections "Holdoff", Trigger Coupling" and "Noise Reject" for details. T3DSO1000HD User Manual...
Page 126 Trigger source, slope (rising, falling), limit range, and time value can be set in the trigger dialog box. Holdoff, coupling, and noise reject can be set in interval trigger, see the sections "Holdoff", "Trigger Coupling" and "Noise Reject" for details. T3DSO1000HD User Manual...
Page 127 Trigger source, slope (rising, falling), dropout type, and time value can be set in the trigger dialog box. Holdoff, coupling, and noise reject can be set in the dropout trigger, see the sections "Holdoff", "Trigger Coupling" and "Noise Reject" for details. T3DSO1000HD User Manual...
Page 128 A negative runt pulse across through the high level but not the low level. Holdoff, coupling, and noise reject can be set in the runt trigger, see the sections "Holdoff", "Trigger Coupling" and "Noise Reject" for details. T3DSO1000HD User Manual...
Page 129 The Pattern trigger identifies a trigger condition by looking for a specified pattern. The T3DSO1000HD provides 4 patterns: logical AND, OR, NAND and NOR combination of the channels. Each channel can be set to "Low", "High" or "Don't Care". If all channels are set to "Don’t Care", the oscilloscope will not trigger.
Page 130 The logical setting of analog channels The logical setting of digital channels Limit Range This setting is particularly useful to filter the hazard signals of combinational logic. Holdoff can be set in pattern trigger, see the section "Holdoff" for details. T3DSO1000HD User Manual...
Page 131 “State”, the oscilloscope triggers on the first edge when the qualified source is in the specified state (High or Low). When the type is “State with Delay”, a time limit condition is also available. T3DSO1000HD User Manual...
Page 132 (Rising or Falling) of the qualified source; when the type is “Edge with Delay”, a time limit condition is available. Touch the Qualified Setting region to set the qualified source and threshold; Touch the Edge Setting region to set the edge trigger source, threshold, and slope. T3DSO1000HD User Manual...
Page 133 Trigger source, slope (rising, falling), idle time, and edge number can be set in the trigger dialog box. Holdoff, coupling, and noise reject can be set in the Nth edge trigger, see the sections "Holdoff", "Trigger Coupling" and "Noise Reject" for details. T3DSO1000HD User Manual...
Page 134 "and" combination of multiple channels. Touch the SourceB Setting region to set the edge trigger source, threshold, and slope. Touch the Limit Range and Upper/Lower Value region to set the delay time condition. T3DSO1000HD User Manual...
Page 135 Touch the CLK Setting region to set the clock source, threshold, and slope; Touch the Data Setting region to set the data source, threshold, and state. T3DSO1000HD User Manual...
Page 136 √ Runt √ × × × Pattern √ × × √ Serial √ × × √ Qualified √ × × × Nth Edge √ × × × Delay √ × × × Setup/Hold √ × × × T3DSO1000HD User Manual...
Page 137 You can also use holdoff to trigger on the first edge of a burst when you know the minimum time between bursts. For example, to achieve a stable trigger on the repetitive pulses shown in the figure below set the holdoff time (t) to 200ns<t<600ns. T3DSO1000HD User Manual...
Page 138  LFR: The signal is coupled through a capacitive high-pass filter network, DC is rejected and low frequencies are attenuated. For stable triggering on medium to high-frequency signals. See the datasheet for details of the cut-off frequency. T3DSO1000HD User Manual...
Page 139 Noise Reject Noise Reject adds additional hysteresis to the trigger circuitry. By increasing the trigger hysteresis, the noise immunity becomes better but the trigger sensitivity degrades. Noise Reject = Off Noise Reject = On T3DSO1000HD User Manual...
Page 140 Serial Trigger and Decode Overview The T3DSO1000HD supports serial bus trigger and decoding on the following serial bus protocols: I2C, SPI, UART, CAN, LIN, FlexRay (decoding only) and CAN FD (decoding only). Press the Setup button on the front panel or touch the trigger descriptor box, and then...
Page 141 I2C Trigger and Serial Decode • SPI Trigger and Serial Decode • UART Trigger and Serial Decode • CAN Trigger and Serial Decode • LIN Trigger and Serial Decode • FlexRay Serial Decode • CAN FD Serial Decode T3DSO1000HD User Manual...
Page 142 Set the source of SDA. In the example above, SDA is connected to C1. Set the threshold level of the SDA channel. Return to the previous menu. Threshold level line. It only appears when adjusting the threshold level. T3DSO1000HD User Manual...
Page 143 When the protocol is set to I2C, the following trigger conditions can be set: Start, Stop, Restart, No Ack, EEPROM, or an R/W frame with a specific device address and data value. Touch Trigger Setting in the I2C trigger dialog box to select the trigger condition: T3DSO1000HD User Manual...
Page 144 Limit Range . If EEPROM’s data is greater than (less than, equal to) Data1 , the oscilloscope will be triggered at the edge of the ACK bit behind the Data byte. The Data byte doesn’t need to follow the EEPROM. T3DSO1000HD User Manual...
Page 145 Frame (Start: 7-bit address: R/W: Ack) — Data1 and Data2 are set to “0xXX”. If all bits match, then trigger on the Ack bit followed by the R/W bit. Frame (Start: 7-bit address: R/W: Ack: Data: Ack: Data2)—If all bits match, then trigger on the Ack bit followed by the Data2. T3DSO1000HD User Manual...
Page 146 0x00 to 0xFF. If the data is selected as "0xXX", the data is ignored. It will always trigger on the Ack bit followed by the address.  R/W Bit can be specified as Write, Read, or Don't Care. T3DSO1000HD User Manual...
Page 147 Touch the Address Length to select "7-bits" or "10-bits" to match the address of the input signal.  Touch the Data Length and turn the universal knob or virtual keypad to set the data length to match the data length of the input signal. T3DSO1000HD User Manual...
Page 148 List display area. The decode result of multiple frames can be displayed in the list, in which each row shows the time label and decode result of a frame. Touch Result List to set the parameters of the list. Decode dialog box T3DSO1000HD User Manual...
Page 149 TIME — The horizontal offset of the current data frame head relative to the trigger position.  Address — Address value. For example, "0x2AB" means that address = 2AB with acknowledgement.  R/W — Read address or write address.  DATA — Data bytes. T3DSO1000HD User Manual...
Page 150 R/W bit is represented together with the address. For example, the address 0x4E: Write: Ack, is displayed as "0x4E (W)" when the R/W bit is not included and is displayed as "0x9C" when the R/W bit is included. T3DSO1000HD User Manual...
Page 151 In addition to specifying the source and the threshold level, for the CLK signal, it is also necessary to specify the Edge Select .  Rising–Data latched on the rising edge of the clock.  Falling–Data latched on the falling edge of the clock. T3DSO1000HD User Manual...
Page 152 SPI bus. Referring to the following figure, when the falling edge of the clock is aligned with the data, the rising edge is selected to latch the data. When the rising edge of the clock is aligned with the data, the falling edge is selected to latch the data. T3DSO1000HD User Manual...
Page 153 This setting is suitable for the case where the CS signal is not connected, or the number of oscilloscope channels is insufficient (such as two-channel oscilloscopes). The method of copying settings is the same as I2C signal settings. See "I2C Signal Settings" for details. T3DSO1000HD User Manual...
Page 154 In the SPI trigger signal menu, set the source and threshold of CLK, MISO, and CS signals, then copy the trigger settings to decoding. Adjust the timebase, so that there is a falling edge on the CS signal shown on the screen: T3DSO1000HD User Manual...
Page 155 505 us, and measure the interval between clock pulses as 0.5 us, then set the timeout to a value between 0.5 us and 505 us. In this example it is set to 4.5 us: T3DSO1000HD User Manual...
Page 156 If the data width is set to be greater than 8 bits (such as 16 bits), measure the clock idle time between 8-bit data packets as 5.05 us, and then set the timeout time to a value between 5.05 and 500 us. In this example, it is set to 80 us: T3DSO1000HD User Manual...
Page 157 Set the bit order to MSB or LSB Return to the previous menu SPI Serial Decode The configuration of SPI decoding is similar to I2C. In the Protocol Config menu, Data Length (4-32 bit) and Bit Order (LSB or MSB) are configurable. T3DSO1000HD User Manual...
Page 158 Select the number of stop bits Set the idle level Set the bit order Return to the previous menu The method of copying settings is the same as I2C signal settings. See "I2C Signal Settings" for details. T3DSO1000HD User Manual...
Page 159 Error — The oscilloscope performs a parity check on the data according to the parity type set by the user, and triggers if the check value is incorrect. UART Serial Decode The configuration of UART decoding is similar to that of I2C decoding. T3DSO1000HD User Manual...
Page 160 In Protocol Config menu of trigger and decode, baud rate can be set to: 5 kb/s, 10 kb/s, 20 kb/s, 50 kb/s, 100 kb/s, 125 kb/s, 250 kb/s, 500 kb/s, 800 kb/s, 1 Mb/s or Custom. The method of copying settings is the same as I2C signal settings. See "I2C Signal Settings" for details. T3DSO1000HD User Manual...
Page 161 ID + Data —The oscilloscope triggers on the data frame that matches the specified ID  and data.ID, ID Bits (11-bit or 29-bit), Curr ID Byte (1st, 2nd, 3rd, or 4th byte), Data1, and Data2 can be set.  Error—The oscilloscope triggers on the error frame. T3DSO1000HD User Manual...
Page 162 CRC is displayed in blue.  The red point at the end of a segment indicates there is not enough space on the display to show the complete content of a frame and some content is hidden. T3DSO1000HD User Manual...
Page 163 “R”.  ID — ID of the frame, 11-bits or 29-bits ID are automatically detected.  Length — Data length.  Data — Data values.  CRC — Cycle redundancy check.  Ack — Acknowledge bit. T3DSO1000HD User Manual...
Page 164 0x00 to 0x3f.  ID & Data—The oscilloscope triggers on the frame that matches the specified ID and data.ID, Data1, and Data2 can be set. Data Error —The oscilloscope will trigger when a data error happens.  T3DSO1000HD User Manual...
Page 165 Time — The horizontal offset of the current data frame head relative to the trigger position.  ID — ID of the frame. Data length — Data length.   ID Parity — ID parity check. Data — Data values.   Checksum — Data checksum. T3DSO1000HD User Manual...
Page 166 CYC (cycle) is displayed in the frame and displayed in light yellow.  D (data) is displayed in the frame and displayed in white.  FCRC (Data Check Code) is displayed in the frame and displayed in blue. T3DSO1000HD User Manual...
Page 167  FID— Frame ID, the symbol occupies a single line of the list.  PL— Valid Data Length  HCRC— Head Check Code  CYC— Cycle count  Data— Data values  FCRC— Data Check Code T3DSO1000HD User Manual...
Page 168 Ack is displayed in pink.  The red point at the end of a segment indicates there is not enough space on the display to show the complete content of a frame and some content is hidden. T3DSO1000HD User Manual...
Page 169 "FD", the extended frame is represented by "Ext" and the remote frame is represented by "RTR".  ID— Frame ID.  Length— Data length.  Data— Data bytes.  CRC— Cycle redundancy check.  Ack— Acknowledge bit. T3DSO1000HD User Manual...
Page 170 Y cursor reference (Offset or Position), this option is supported only in "Manual" mode.  Offset measures the cursor position relative to the Vertical/Offset position  Position measures the cursor position relative to the vertical center of the display T3DSO1000HD User Manual...
Page 171 Track -- The cursor type is automatically set to "horizontal + vertical". In this mode, only horizontal cursors are adjustable, while the vertical cursors automatically attach to the cross-point of the cursor and the source waveform.  Measure – Automatically indicates the measured item using cursors Manual Mode Track Mode Measure Mode T3DSO1000HD User Manual...
Page 172 X1 and X2 simultaneously. Y（vertical）– Horizontal dotted lines that measure vertical voltage or current (depending on the unit of the selected channel). When the cursor's source is the math function, the units will match the math function. T3DSO1000HD User Manual...
Page 173 Y1- Y2 — The difference between Y1 and Y2. After this option is selected, turn the  universal knob to move both Y1 and Y2 simultaneously. X+Y (horizontal + vertical) -- Both the X cursors and Y cursors are enabled. T3DSO1000HD User Manual...
Page 174 Y cursors reference:  Fixed Offset– When the vertical scale is changed, the value of Y- cursors remain fixed.  Fixed Position– When the vertical scale is changed, the Y-cursors remain fixed to the grid position on the display. T3DSO1000HD User Manual...
Page 175 Take X cursors reference as an example to demonstrate the scaling effect of different settings: Timebase=50ns/div，X1=-50ns=-1div，X2=100ns=2div Fixed position, timebase is changed to 100 ns/div, the grid number of X cursors (-1div, 2div) remains fixed. The value of X1 and X2 is changed to -100 ns, 200 ns. T3DSO1000HD User Manual...
Page 176 Fixed delay, timebase is changed to 100 ns/div, the value of X cursors (-50 ns, 100 ns) remains fixed. The grid number of X cursors is changed to -0.5div, 1div. T3DSO1000HD User Manual...
Page 177 Touch the display area of △X (or △Y) in M1 mode and drag it to move the two cursors simultaneously, as shown in the figure below. This is equivalent to the operation on the cursor type X1-X2 or Y1-Y2. T3DSO1000HD User Manual...
Page 178 Dialog Box Touch the cursor value area of the dialog box, and then rotate the universal knob to adjust the position. T3DSO1000HD User Manual...
Page 179 The T3DSO1000HD features a strong automatic measurement list. These parameters can be automatically measured without cursors and include common measurements such as rise time, fall time, peak-peak, and period. The T3DSO1000HD can also measure multiple channels at the same time, showing up to 5 parameter measurements with statistics while in the M1 display mode and up to 12 parameters in the M2 mode.
Page 180 The waveform display area automatically compresses when the other windows are displayed Measurement parameters and statistics display area. If select the mode as “Simple”, the "Simple" parameter area is displayed Statistics histogram display area Measure dialog box T3DSO1000HD User Manual...
Page 181 Clear all the selected measurements Select measurement parameters Tools including Trend, Track, and Measure Cursor Turn on or off statistics Statistics settings: count limit, AIM limit, reset statistics, and histogram T3DSO1000HD User Manual...
Page 182 For example, to add Pk-Pk measurements for C1 and Period measurements for C2, follow the steps below: Source > C1 > Vertical > Pk-Pk Source > C2 > Horizontal > Period T3DSO1000HD User Manual...
Page 183 Touch – in the upper right corner of each parameter to close the parameter. Touch × in the upper right corner of the area to close measurement. Touch Clear in the dialog box to close all parameters. T3DSO1000HD User Manual...
Page 184 For example, to add Pk-Pk to the “Favorite” tab: Advanced > Type > Vertical > Pk-Pk > Add to favorite To remove Period from the “Favorite” tab: Advanced > Type > Favorite > Period > Delete from favorite T3DSO1000HD User Manual...
Page 185 Type of Measurement 2.1.1.1 Vertical Measurement Vertical measurement includes 19 parameters: T3DSO1000HD User Manual...
Page 186 Median: Value at which 50% of the measurements are above and 50% are below  Cycle Median: Median of the first cycle  Overshoot (FOV): Overshoot following a falling edge; 100%* (base- min)/amplitude  Overshoot (ROV): Overshoot following rising edge; 100%*(max- top)/amplitude T3DSO1000HD User Manual...
Page 187  Preshoot (FPRE): Overshoot before a falling edge. Equal to 100 %*( max- top)/amplitude.  Preshoot (RPRE): Overshoot before a rising edge. Equal to 100 %*( base- min)/amplitude.  L@T: Level measured at trigger position T3DSO1000HD User Manual...
Page 188 2.1.2 Horizontal Measurement Horizontal measurement includes 17 parameters: T3DSO1000HD User Manual...
Page 189  Fall Time: Duration of falling edge from upper threshold to lower threshold  10-90%Rise: Duration of rising edge from 10-90%  90-10%Fall: Duration of falling edge from 90-10%  CCJ: The difference between two continuous periods T3DSO1000HD User Manual...
Page 190 Edges: Number of edges in a waveform  Ppulses: Number of positive pulses in a waveform  Npulses: Number of negative pulses in a waveform  PSlope: The slope of the rising edge  NSlope: The slope of the falling edge T3DSO1000HD User Manual...
Page 191 Tsu@R: Data setup time before the clock rising edge  Tsu@F: Data setup time before the clock falling edge  Th@R: Data hold time after the clock rising edge  Th@F: Data hold time after the clock falling edge T3DSO1000HD User Manual...
Page 192 Maximum value Minimum value Average value Count number Reset statistics Press the Clear Sweeps button or touch Reset Statistics in the measure dialog box, or touch the symbol in the statistics display area to clear and restart statistics. T3DSO1000HD User Manual...
Page 193 Track is enabled. The upper limit of the statistic number in a frame is set in Statistics > AIM Limit , which means the values exceeding the limit will not be shown in the track plot. T3DSO1000HD User Manual...
Page 194 In advanced measurement mode, two display modes are supported: M1 and M2. In M1 mode, up to 5 parameter measurements are displayed at a time. When statistics are enabled, they are listed under the measurement items. Touch a column to add or replace a measurement. T3DSO1000HD User Manual...
Page 195 In M2 mode, up to 12 parameter measurements are displayed at a time. When statistics are enabled, they are distributed on the right side of the measurement item. Touch a row to add or replace a measurement. Note: In M2 mode histogram display is not supported. T3DSO1000HD User Manual...
Page 196 "Unlimited". The setting range is 1 ~ 25,000 Clear and restart the statistics. Pressing the Clear Sweeps button on the front panel has an equivalent effect Turn the histogram on or off Return to the previous menu T3DSO1000HD User Manual...
Page 197 When the oscilloscope detects the trace under test is clipped, an extra overflow indicator will appear after the measurement value: Waveform clipped at the top Waveform clipped at the bottom Waveform clipped at both top and bottom T3DSO1000HD User Manual...
Page 198 Histogram display area. The X-axis represents measured values and Y-axis represents the probability. Count of statistics Current value The bin that includes the maximum value and the probability of a value falling into it Close the enlarged histogram T3DSO1000HD User Manual...
Page 199 The oscilloscope only measures the parameters of the data between A and B, ignoring the data outside the range. The setting of gate cursors is similar to that of ordinary cursors. See "Select and Move Cursors" for details. T3DSO1000HD User Manual...
Page 200 The figure below shows a scenario in which the gate function is used to measure the peak- peak parameter of the trough of an amplitude modulated waveform: T3DSO1000HD User Manual...
Page 201 Return to the previous menu T3DSO1000HD User Manual...
Page 202 Touch Config > Threshold in the measure dialog box to recall the threshold dialog box: Set measurement threshold source Set the type of threshold Set the upper value Set the middle value Set the lower value Return to the previous menu T3DSO1000HD User Manual...
Page 203 2 times the input frequency, the results will be incorrect. The hardware frequency counter does not have this limitation. Its result is always shown at the top-right of the display as shown below: T3DSO1000HD User Manual...
Page 204 Math Overview The T3DSO1000HD supports 4 math traces and multiple operators. Arithmetic operators: Addition (+), subtraction (-), multiplication (x), division (/), average, ERES, identity, negation, maxhold, minhold; Algebra operators: differential (d/dt), integral (∫dt), square root (√), absolute (|y|), sign, exp, ln, Lg, interpolate; and FFT, as well as a formula editor. The math traces are labeled with icons “F1 ~ F4”...
Page 205 (-y) d/dt V/s (Volt/second) or A/s (A/second) ∫dt VS (Volt*second) or AS (A*second) 0.5 or A √ ∧ ∧ V, A Sign V, A Exp or Exp10 V, A Ln or lg V, A Intrp V, A T3DSO1000HD User Manual...
Page 206 Arithmetic The T3DSO1000HD supports Addition, Subtraction, Multiplication, Division, Average, ERES, Identity, Negation, Max-hold, and Min-hold. Addition / Subtraction / Multiplication / Division The T3DSO1000HD can perform arithmetic operations including addition, subtraction, multiplication, or division on any two analog input channels, and the values of Source A and Source B are computed point-by-point.
Page 207 Identity / Negation The values of Source A are computed point-by-point when identity or negation operation is chosen in any analog channel. The following figure shows an example of F1 = -C1: T3DSO1000HD User Manual...
Page 208 Average / ERES can be set in acquisition mode and arithmetic function as well, but with different compute methods. Average and ERES in acquisition mode is computed by hardware with a higher speed and sampling rate than computed by software in the arithmetic mode. T3DSO1000HD User Manual...
Page 209 ERES: Reduce bandwidth random noise on the measured sgnal and improve signal-to-noise ratio by filtering the sampling point. T3DSO1000HD User Manual...
Page 210 The value of Max-hold and Min-hold are based on statistical calculations from multiple frames. The following figure shows the Max-hold result. Algebra The T3DSO1000HD can perform algebraic operations including differential (d/dt), integral (∫dt), square root (√), absolute(|x|), sign, exp (�� ...
Page 211 The differential equation is: Where: d = Differential result y = Values of source data i = Data point index dx = Differential interval The range of “dx” in the d/dt menu is 4~ number of samples pts. T3DSO1000HD User Manual...
Page 212 Small DC offsets in the input signal (or even small offset errors of the oscilloscope itself) may cause the integral output waveform to "ramp" up or down, as shown below: Integral without Offset Integral with Offset T3DSO1000HD User Manual...
Page 213 Gate function, then set Gate A and Gate B to define the gate. The setting of the gate cursors is similar to that of normal cursors. See "Select and Move Cursors" for details. T3DSO1000HD User Manual...
Page 214 Square root （√） calculates the square root of the selected source. If the waveform value is negative (the waveform is below the ground level), the result is displayed as zero. Absolute Absolute（|x|）calculates the absolute value of the selected trace. T3DSO1000HD User Manual...
Page 215 The sign function of a real number x is defined as follows: Sign(x) = -1, if x < 0; = 0, if x = 0; = 1, if x > 0. T3DSO1000HD User Manual...
Page 216 Exp10 �� The exponential operation includes the exponential operation �� based on constant e and �� the exponential operation 10 based on 10. �� For example: y(x) = �� T3DSO1000HD User Manual...
Page 217 (the waveform is below the ground level), the result is displayed as zero. �� For example F1 = �� , where x is the trigonometric wave function. F2 = ln (F1). T3DSO1000HD User Manual...
Page 218 Between the adjacent sampling points, the waveform is interpolated according to the selected interpolation method and interpolation coefficient. Touch Acquire > Menu > Interpolation to set the interpolation method, and the interpolation coefficient can be set to 2, 5, 10, or 20. Coefficient = 2 Coefficient = 20 T3DSO1000HD User Manual...
Page 219 Filter The filter operation in the T3DSO1000HD provides FIR (Finite Impulse Response) filtering with the following types: Low pass, High pass, Band Pass, and Band Reject. The filters have up to 200 taps which can reach roll-off as fast as 0.01*fs. Users just need to set the filter type and corner frequency(s), then the instrument will automatically calculate the coefficients needed for the filtering.
Page 220 The 200-tap FIRs applied in the T3DSO1000HD provide roll-off as fast as 0.01*fs (where fs is the sample rate), this means some limitations in the setting of corner frequency at a specified sample rate. The figures below show the limitations in detail: ≥0.01fs...
Page 221 Be aware that when the corner frequency is set very low the sample rate may not satisfy the Nyquist Theorem (i.e. fs is no longer greater than or equal to twice the highest frequency of the input). Keep the sample rate reasonable at all times. T3DSO1000HD User Manual...
Page 222 The horizontal axis of the FFT display is labeled using frequency (Hz) units instead of time (seconds). In addition, the vertical axis provides the option of logarithmic scaling (dBVrms/dBArms or dBm). Time-domain waveform display area Spectrum (FFT) waveform display area FFT parameter display area Dialog box T3DSO1000HD User Manual...
Page 223  FFT points (Curr): The current FFT points, which is an integer power of 2. The T3DSO1000HD supports up to 2 M points (2097152, to be exact).  Frequency interval (△f): The frequency interval between two adjacent points in the FFT sequence, which is proportional to the frequency resolution.
Page 224 Select the display mode (Split, Full Screen, and Exclusive) Select the FFT mode (Normal, Average, and Max- Hold) Set the average count in average mode Reset average Return to the previous menu T3DSO1000HD User Manual...
Page 225 17.1.2 Windows Spectral leakage in FFTs can be considerably decreased when a window is used. T3DSO1000HD provides five windows that have different characteristics and apply to different scenarios. For example, for a two-tone signal with a very close frequency interval, it is suitable to use a Rectangle window with the best frequency resolution.
Page 226  Full Screen: Time-domain waveform and frequency-domain waveform are displayed together.  Exclusive: Only the frequency-domain waveform is displayed. Split Mode, Zoom off Split Mode, Zoom on Full-Screen Mode Exclusive Mode T3DSO1000HD User Manual...
Page 227 FFT mode is set as Average, Average will appear under FFT Mode . The average count can be set here, ranging from 4 to 1024. Press the Clear Sweeps on the front panel or touch Reset in the dialog box to restart the average counter. T3DSO1000HD User Manual...
Page 228 Set the external load, which is used to calculate the correct dBm result Return to the previous menu Set the sweep mode: Linear or Decade Set the center-span frequencies and start-end frequencies of the FFT waveform T3DSO1000HD User Manual...
Page 229 Touch Start to set the start frequency by the universal knob or the virtual keypad. Touch End to set the end frequency by the universal knob or the virtual keypad. The relationship between Center, Span, Start, and End is: Center = (Start + End)/2 Span = End – Start T3DSO1000HD User Manual...
Page 230 17.1.8 FFT Tools The T3DSO1000HD provides two tools for the FFT waveform: Peaks and Markers. The peaks tool can automatically search the qualified peak points and mark them on the FFT waveform. Up to 10 peaks are supported. Based on the peak tool, the markers tool can automatically search the qualified harmonics, and users can control the position of each marker.
Page 231 Return to the previous menu Note: The FFT dialog box is longer than the display. Slide the dialog box area up and down by gestures, or scroll the mouse wheel to the view non-displayed areas. T3DSO1000HD User Manual...
Page 232 Note: DC components in the signal may show a large amplitude near 0 Hz. If your application does not require measurement of the DC component, it is recommended to set the coupling mode of the source channel to "AC". T3DSO1000HD User Manual...
Page 233 Operation source. Cx represents analog trace, Zx represents zoomed trace and Fx represents math trace The keyboard area contains the basic arithmetic operators addition (+), subtraction (-), multiplication (*), division (/) Confirm button. After the formula is input, press the button to apply it T3DSO1000HD User Manual...
Page 234 The following is an example of implementing nested operations between operators through the formula editor: In this example, F1=d (C1)/dt and F2=FFT (d (C1/dt) are equivalent to F2=FFT (F1), which is equivalent to performing FFT analysis on the differential operation results of C1 waveform. T3DSO1000HD User Manual...
Page 235 (REFA/REFB/REFC/REFD) in the built-in nonvolatile memory. The saved reference waveform can be recalled to be compared with the current waveform. Channel waveform Reference waveform Reference vertical and horizontal information display area The reference dialog box, hidden in this figure T3DSO1000HD User Manual...
Page 236 Adjust the Reference Waveform Set the vertical position of the reference waveform by the offset knob on the front panel, and set the vertical scale of the reference waveform by the scale knob. T3DSO1000HD User Manual...
Page 237 Search The T3DSO1000HD can search for the specified events in a frame. The location of the events is displayed with white triangle indicators. In YT mode or Roll mode with the acquisition stopped, up to 1000 events are supported. In Roll mode with the acquisition running, the number of search events is unlimited.
Page 238 The current event is the one in the center of the display. Touch the menu Analysis > Search to recall the search dialog box and turn on it. T3DSO1000HD User Manual...
Page 239 19.1.1 Setup Menu Select and set the search type in the Setup Menu . The T3DSO1000HD provides five search conditions: Edge, Slope, Pulse, Interval, and Runt. Search Type Setup Description Edge Slope: Rising, Falling, Either Slope Slope: Rising, Falling Limit Range setting is available...
Page 240 Navigate Touch the menu Analysis > Navigate to recall the navigate dialog box. The T3DSO1000HD provides three navigate types: Search Event, Time, and History Frame. Navigate by Time The oscilloscope automatically adjusts the trigger delay according to the direction set by the user.
Page 241 Touch the Event List Switch area to turn on or off the list. The list contains time labels for each event. Touching a row in the list automatically jumps to the corresponding event. This operation is equivalent to specifying an event in the Event Num area. T3DSO1000HD User Manual...
Page 242 Set the display type of the event column in the list. Touch Playing Mode to set the search event playing mode. Touch Interval Time to set the playing interval by the universal knob or the virtual keypad. T3DSO1000HD User Manual...
Page 243 20 ms there is a dwarf pulse with a height of 1/3 of the normal amplitude: First, set the trigger type to Runt to trigger on the dwarf pulse. See the section “Runt Trigger” for details. T3DSO1000HD User Manual...
Page 244 Set the horizontal scale to 10 ms/div, then 5 markers with ~20 ms interval are shown on the display, indicating that a total of 5 dwarf pulses were found in the full screen of 100 ms time range: T3DSO1000HD User Manual...
Page 245 Turn on the Zoom function to observe the full view of the frame and the detail of the third dwarf pulse at the same time: T3DSO1000HD User Manual...
Page 246 Press the Run/Stop button on the front panel to stop the acquisition, and then follow the steps Navigate > Type to select “Search Event”. The following figure shows the first dwarf pulse. In this example, the list is enabled and the time labels of a partial event are shown in the list. T3DSO1000HD User Manual...
Page 247 Mask area in green. Any dot violating the rule is highlighted in red, instead of the normal waveform color. Pass/Fail information display area, including the count of passed frames, failed frames, total frames, and the fail rate. Dialog box T3DSO1000HD User Manual...
Page 248 Turn on/off “Capture on Fail”. When it is "on", the failure waveform is detected, and the screenshot with the failure frame will be stored in the external U disk. Turn on/off the sound prompt when a failure occurs. T3DSO1000HD User Manual...
Page 249 Set the vertical spacing of the mask around the currently displayed trace. The units are parts of the vertical division setting. Create the mask based on settings in Save the mask Return to the previous menu T3DSO1000HD User Manual...
Page 250 0.04~4.00 div. X = 0.2 div, Y = 0.2 div X = 1 div, Y = 1 div Saving and recalling mask files (*.msk) is similar to the operation of setup files, see the chapter "Save/Recall” for details. T3DSO1000HD User Manual...
Page 251 Coordinate edit area. Set the X ordinate and Y ordinate by the virtual keypad and then touch the “Input” button the perform the ordinate update Display or hide the coordinates of the polygon vertices on the display Exit the tool T3DSO1000HD User Manual...
Page 252 Create Polygon: Creates a polygon based on the drawn vertices by the operation Draw  Undo  Redo  Insert Point: Inserts a vertex on a selected side  Edit Polygon: Edits a polygon. Vertices, sides, and the polygon are all editable object  Delete Polygon: Deletes selected polygon T3DSO1000HD User Manual...
Page 253 For a side, the value is for its middle point. For a polygon, the ordinate is for its geometric center. Select a vertex (point Select a side (line segment) Select a polygon T3DSO1000HD User Manual...
Page 254 Touch Operation to start/stop the test. Stopping a test in progress and restarting the test will clear the count of the passed frames, failed frames, total frames, and the fail rate. Pressing the Clear Sweeps button on the front panel can also clear the count information. T3DSO1000HD User Manual...
Page 255 Select the mode: frequency, period, and totalizer Select the source (C1~C4) Set the level of the counter Turn on or off statistics Clear and restart the statistics. Pressing the Clear Sweeps button on the front panel has an equivalent effect T3DSO1000HD User Manual...
Page 256 Stdv – The standard deviation of all historical counts, used to judge the distribution of historical count parameters Count – Number of counts obtained Level – Counter level Press the Clear Sweeps button or touch Reset Statistics in the measure dialog box to clear and restart statistics. T3DSO1000HD User Manual...
Page 257 The counter provides 3 modes. Touch Mode in the counter dialog box to open the mode selection window:  Frequency: Average frequency over a set period  Period: The reciprocal of the average frequency over a set period  Totalizer: Cumulative count T3DSO1000HD User Manual...
Page 258 When the gate type is level, set the polarity (Positive or Negative) of the gate source. When the gate type is edge, set the slope (Rising or Falling edge) of the gate source. Set the gate level Return to the previous menu T3DSO1000HD User Manual...
Page 259 Power Analysis Overview The T3DSO1000HD supports a power analysis function as standard. Power analysis can help users quickly and easily analyze and debug switching power supply designs. It automatically calculates Power Quality, Current Harmonics, Inrush Current, Switching Loss, Slew Rate, Modulation, Turn On/Turn Off, Transient Response, PSRR, Power Efficiency, Output Ripple, etc.
Page 260 S: Apparent Power = Vrms * Irms Q: Reactive Power = √Apparent Power − Active Power φ: Power Phase Angle: Phase difference between voltage and current cos φ: Power Factor, which is the ratio of active power and apparent power. T3DSO1000HD User Manual...
Page 261 I_Crest = Ipeak / Irms Signal Settings Touch Input Signal to recall signal settings dialog box: Set the input voltage source Set the input current source Set the periods displayed View the connection guide Return to the previous menu T3DSO1000HD User Manual...
Page 262 Touch Signal > Connection Guide to recall the connection guide of power quality, as shown in the figure below. Please follow the instructions in this figure for correct connections. Touch the icon on the top right of the guide to close. T3DSO1000HD User Manual...
Page 263  Class A: Balanced 3-phase equipment, household appliances excluding equipment identified as class D, tools, excluding portable tools, dimmers for incandescent lamps, audio equipment, and all other equipment, except that stated in one of the following classes. T3DSO1000HD User Manual...
Page 264 / fail state. When the value is greater than 85% of the limit but less than 100% of the limit, it is defined as a critical state. √X +⋯+X ， where X �� Total Harmonic Distortion（THD）= 100% ∗ is the nth harmonic, and X is the basic component. T3DSO1000HD User Manual...
Page 265 Set the maximum effective input voltage (Vrms), the range is 1 V ~ 1 kV. The oscilloscope will set the vertical scale of the voltage channel to maximum input voltage/6 View the connection guide Return to the previous menu T3DSO1000HD User Manual...
Page 266 C. Make sure the switch S1 on the deskew fixture is set to the appropriate side of the fixture (either “small loop” or “large loop”) D. Connect the deskew fixture to a USB port on your oscilloscope or a PC using a USB cable. The USB port supplies power to the deskew fixture T3DSO1000HD User Manual...
Page 267 Touch Input Setup to enter the input setup menu. Select the corresponding input channel, and then touch Auto Deskew to perform the calibration. When the process completes, a message will pop up indicating whether the deskew operation was successful or not. Before deskew calibration After deskew calibration T3DSO1000HD User Manual...
Page 268 This value is used to determine the threshold hysteresis of the switch edge Set the conduction type (Waveform, Rds(on) or Vce(sat)) Set Rds(on) resistance Set Vce voltage Return to the previous menu T3DSO1000HD User Manual...
Page 269 Touch Input Setup > Connection Guide to recall the connection guide of switching loss, as shown in the figure below. Please follow the instructions in this figure for connection. Touch the icon on the top right of the guide to close. T3DSO1000HD User Manual...
Page 270 Touch Input Setup > Connection Guide to recall the connection guide of slew rate, as shown in the figure below. Please follow the instructions in this figure for connection. Touch the icon on the top right of the guide to close. T3DSO1000HD User Manual...
Page 271 Touch Input Setup > Connection Guide to recall the connection guide of modulation, as shown in the figure below. Please follow the instructions in this figure for connection. Touch the icon on the top right of the guide to close. T3DSO1000HD User Manual...
Page 272 Touch Input Setup > Connection Guide to recall the connection guide of output ripple, as shown in the figure below. Please follow the instructions in this figure for connection. Touch the icon on the top right of the guide to close. T3DSO1000HD User Manual...
Page 273 Set the stable output voltage value, the range is -30 V ~ 30 V. The oscilloscope will set the vertical scale of the output voltage channel to stable output voltage / 6 View the connection guide Return to the previous menu T3DSO1000HD User Manual...
Page 274 T1 = When the input voltage finally falls to a certain percentage (usually 10%) of its maximum amplitude T2 = When the output DC voltage finally falls to a certain percentage (usually 10%) of its maximum amplitude T3DSO1000HD User Manual...
Page 275 Touch Input Setup > Connection Guide to recall the connection guide of turn on/turn off, as shown in the figure below. Please follow the instructions in this figure for connection. Touch the icon on the top right of the guide to close. T3DSO1000HD User Manual...
Page 276 Set the overshoot percentage of output voltage, which can be used to determine the stable band value of transient response and adjust the vertical scale of the oscilloscope View the connection guide Return to the previous menu T3DSO1000HD User Manual...
Page 277 Touch Input Setup > Connection Guide to recall the connection guide of transient response, as shown in the figure below. Please follow the instructions in this figure for connection. Touch the icon on the top right of the guide to close. T3DSO1000HD User Manual...
Page 278 Touch Input Setup > Connection Guide to recall the connection guide of PSRR, as shown in the figure below. Please follow the instructions in this figure for connection. Touch the icon on the top right of the guide to close. T3DSO1000HD User Manual...
Page 279 Touch Input Setup > Connection Guide to recall the connection guide of power efficiency, as shown in the figure below. Please follow the instructions in this figure for connection. Touch the icon on the top right of the guide to close. T3DSO1000HD User Manual...
Page 280 Touch the icon on the top right of the guide to close. Perform a Deskew operation between the voltage and current input channels before Note: the test. See section “Switching Loss” for more details on deskewing. T3DSO1000HD User Manual...
Page 281 Turn on Test State . The oscilloscope will begin to acquire the voltage and current waveforms, and display the SOA measurement, showing if the measured stresses are in the SOA or not. Users can adjust horizontal, vertical, and trigger settings during the test for best observation. T3DSO1000HD User Manual...
Page 282 Voltage and current waveforms on the MOSFET at power-up SOA, in which the mask is created according to the voltage limit, current limit, and power limit. The result shows “Pass” because all the stresses are within the mask. T3DSO1000HD User Manual...
Page 283 Bode Plot Overview The T3DSO1000HD supports an automatic Bode Plot function. This function provides a frequency response curve of the device-under-test as well as the interface for output sweep parameter control and data display settings. At this time, either the T3DSO1000- FGMOD-A waveform generator or one of the T3AFG series of Function Generators are supported.
Page 284 Arbitrary waveform generator connection settings. Touch Interface to select the connection type. When selecting LAN, it needs to Set IP and Save it. Touch Test to confirm whether the arbitrary waveform generator is connected correctly. T3DSO1000HD User Manual...
Page 285 Set the amplitude of the sweep signal Set the offset of the sweep signal Set the signal amplitude unit. When it is set to dB, reference level and load need to be set Set the load T3DSO1000HD User Manual...
Page 286 Set the offset of the sweep signal Set the signal amplitude unit. When it is set to dB, reference level and load need to be set Variable level signal display area Touch Edit to turn on the profile editor T3DSO1000HD User Manual...
Page 287 Touch the cell in the table area to set the frequency and amplitude of the corresponding node. Touch to activate the cell, adjust the value through the universal knob, or touch the cell again to call up the virtual keypad for setting. T3DSO1000HD User Manual...
Page 288 Arbitrary dB); when the mode is Vout/Vin, it needs to set the amplitude axis type (Linear or Logarithmic). Auto-Set. According to the output signal amplitude curve, the oscilloscope automatically sets the scale and reference level Return to the previous menu T3DSO1000HD User Manual...
Page 289 Return to the previous menu Cursors T3DSO1000HD can use the cursor to measure the Bode plot curve. The cursor of the Bode plot is similar to the ordinary cursor, see the chapter "Cursors" for details. Touch Display > Cursors to recall the cursor setting dialog box.
Page 290 Users can turn on/off other scanning curves to observe the details of specific curves. Touch Display > Trace Visibility to recall the setting dialog box. T3DSO1000HD User Manual...
Page 291 Bode plot curve: upper cut-off frequency (UF), lower cut-off frequency (LF), bandwidth (BW), gain margin (GM), phase margin (PM). Data list display area Cursors Data point location line Cursor information display area Measurement parameters display area Bode plot dialog box T3DSO1000HD User Manual...
Page 292 Set the data source Save/Recall the data. Saving and recalling the Bode plot data (*.csv) is similar to the operation of setup files, see the chapter "Save/Recall" for details Return to the previous menu T3DSO1000HD User Manual...
Page 293 Clear the current measurement Close the measurement configuration window For example, to add UF measurements for C2 and GM measurements for C3, follow the steps below: Measure > Position > Source > UF Measure > Position > Source > GM T3DSO1000HD User Manual...
Page 294 Select the grid type (Full Grid, Light Grid, and No Grid) Set the trace intensity (0~100%) Set LCD Brightness (0~100%) Set the graticule brightness (0~100%) Display the axis labels Set the font displayed by the system T3DSO1000HD User Manual...
Page 295 Vectors: The samples are connected by lines (i.e. interpolated) and displayed. The interpolation methods include linear interpolation and sin(x)/x interpolation. See the section of "Acquisition Setup" for details of interpolation.  Dots: Displays the raw sample directly. Vector Display T3DSO1000HD User Manual...
Page 296 Therefore, what is seen using the dots display is not the discrete sampling points, but the display effect similar to equivalent sampling. Stop the acquisition to view the original samples of each frame separately. Dots display in Run state T3DSO1000HD User Manual...
Page 297 The smaller probability, the colder the color temperature of that pixel. The picture below shows the change of color from cold to warm. Color grade On Color grade Off T3DSO1000HD User Manual...
Page 298 New acquisitions are shown in their normal color with normal intensity. In combination with T3DSO1000HD's high waveform update rate and persist function, in some cases anomalies in the waveform can be found in a short time without complex trigger settings to improve test efficiency.
Page 299 Set Grid  Full Grid: Display 8*10 grid  Light Grid: Display 2*2 grid  No Grid: Display without grid Full Grid Light Grid T3DSO1000HD User Manual...
Page 300 No Grid T3DSO1000HD User Manual...
Page 301 Moving mode: When moving the waveform, the position of the axes moves with the waveform, while the coordinates remain fixed.  Fixed mode: The position of the axes remain fixed, while the coordinates update as the waveform is moving. Moving mode T3DSO1000HD User Manual...
Page 302 Fixed mode Window Setting Set the display font of the system in window setting menu T3DSO1000HD User Manual...
Page 303 ± 3 V. Its output terminals are isolated from the ground of the oscilloscope. Connect the T3DSO1000-FGMOD-A to any USB host port of T3DSO1000HD using a standard USB cable. Users can edit and import arbitrary waveforms using EasyWave software or import edited waveforms through a U-disk.
Page 304 Turn on/off the output of AWG Select the waveform type (Sine, Square, Ramp, Pulse, Noise, DC, and Arb) Set the frequency Set the amplitude Set the offset Other AWG settings: Output load, overvoltage protection, and so on. System information and firmware upgrade T3DSO1000HD User Manual...
Page 305 The following table shows all waveform types and corresponding parameters. Wave Type Parameters Sine Frequency, Amplitude, Offset Square Frequency, Amplitude, Offset, Duty Ramp Frequency, Amplitude, Offset, Symmetry Pulse Frequency, Amplitude, Offset, Duty Offset Noise Stdev, Mean Frequency, Amplitude, Offset, Arb Type T3DSO1000HD User Manual...
Page 306 Common, Math, Engine, Window, and Trigo. Stored waveforms are located in the Stored menu. Users can edit arbitrary waveforms using EasyWaveX PC software, send the stored waveforms to the instrument through the remote interface, or import the stored waveforms through a U disk. T3DSO1000HD User Manual...
Page 307 When the Sync Output is turned on, the Aux In/Out port of AWG outputs a CMOS signal with the same frequency as the basic waveform (except Noise and DC) and arbitrary waveform. The maximum supported frequency is 10 MHz. T3DSO1000HD User Manual...
Page 308 Measure and set the parameter to the Mean of CH2. Press Manual and rotate the universal knob to adjust the compensation value, until the mean value of CH2 is within ±1 mV, and then press Save . T3DSO1000HD User Manual...
Page 309 Upgrade The firmware here refers to the firmware of the T3DSO1000-FGMOD-A module. The T3DSO1000HD supports firmware and configuration file upgrades for the T3DSO1000- FGMOD-A via a U disk. Follow the steps below: 1. Copy the upgrade file (*.ADS) to the U disk.
Page 310 Save/Recall The T3DSO1000HD supports saving setups, reference waveforms, screenshots, and waveform data files to internal storage, external USB storage devices (e.g. U disk), or network storage. Saved setups and reference waveforms can be recalled as needed. For details of network storage, refer to the section “SMB File Share”.
Page 311 “Factory”, the factory default setting will be recalled by pressing the Default button on the front panel; When the Default Type is set to “Current”, the last setting saved by the “To Default Key” operation will be recalled by pressing the Default button on the front panel. T3DSO1000HD User Manual...
Page 312 The following table shows the relationship between the save types and save/recall operations. Type Save Recall External Setup √ √ Reference √ √ √ × √ × √ × Binary Data √ × CSV Data √ × Matlab Data √ × FileConverter √ × T3DSO1000HD User Manual...
Page 313 File Manager The T3DSO1000HD's file manager has a similar style and operation to the Windows© operating systems. Address bar Navigation panel File list Toolbar File type Close the file manager T3DSO1000HD User Manual...
Page 314 Table 1.1 Description of icons in the file manager Icon Description Icon Description Back Forward Up level Root directory Save Recall Save as New directory New file Paste Copy Rename Delete Move T3DSO1000HD User Manual...
Page 315 Touch File Manager to open the file manager 3. Select the “\Udisk0\” directory in the file manager: 4. Touch Save As , click the pop-up text box to recall the virtual keyboard and input the file name, and then touch OK : T3DSO1000HD User Manual...
Page 316 The default naming strategy is to add an incremental number at the end of the first saved filename. Note: A saved picture can be browsed on the oscilloscope by opening it in the File Manager. T3DSO1000HD User Manual...
Page 317 Touch File Manager to open the file manager 3. Select the “\Udisk0\” directory in the file manager, and then select the setup file "T3DSO1204HD_Setup_1.xml" 4. Touch the Recall icon and wait for the oscilloscope to finish recalling the setup. T3DSO1000HD User Manual...
Page 318 Utility System Information Operate Utility > Menu > System Info to check the system status. System information includes the contents shown below. T3DSO1000HD User Manual...
Page 319 System Setting 2.1.1 Language The T3DSO1000HD supports multiple languages, including Simplified Chinese, Traditional Chinese, English, French, Japanese, German, Spanish, Russian, Italian, Portuguese, and so Operate Utility > Menu > System Setting > Language , and select the language in the list.
Page 320 2.1.5 Date/Time The T3DSO1000HD has an RTC clock, which helps to record absolute time information for screenshots, history frames, and so on. Operate Utility > Menu > System Setting > Date/Time to open the Date/Time dialog box: Touch the text box of Hour, Minute, Second, Day, Month, and Year to edit these fields.
Page 321 Fixed Position: When the vertical scale is changed, the vertical offset remains fixed to the grid position on the display. As the vertical scale is changed, the waveform expands/contracts around the position of the vertical ground position on the display. T3DSO1000HD User Manual...
Page 322 Timebase = 10 ns/div, Horizontal Delay = -20 ns = - 2 div Fixed position, timebase is changed to 5 ns/div, the grid number of delay (2div) remains fixed, while the horizontal delay changes to -10 ns T3DSO1000HD User Manual...
Page 323 Fixed delay, timebase is changed to 5 ns/div, the horizontal delay value remains fixed, while the grid number of delay changes to 4div T3DSO1000HD User Manual...
Page 324 (.bmp/.png/.jpg). Touch Utility > Save Button to set the file type and path. Select the save type: Screenshot or Save to When the save type is “Save to”, set the save type referred to in the chapter "Save/ Recall” T3DSO1000HD User Manual...
Page 325 When set as “Display”, the button can be preset to change some display parameters such as color grade and persistence Set the action of this button under the selected category T3DSO1000HD User Manual...
Page 326 After setting the LAN, the LXI welcome page can be loaded through the browser, refer to the section “LAN” and “Web Browser” for details. When starting instrument identification in the web server, the LXI image in the upper right corner will flash continuously. T3DSO1000HD User Manual...
Page 327 When is not checked, set the DNS IP address manually. When accessing more than two Teledyne Test Tools instruments through the web browser, it is necessary to set a different VNC port number for each instrument. The range is from 5900 to 5999.
Page 328 Web Server The T3DSO1000HD includes a web server function, you can access and control the oscilloscope using a web browser. See the section "Web Browser" for details about remote control operation. Perform Utility > Menu > Service > Web to set the password to control the instrument.
Page 329 (*.ads) and is connected to the oscilloscope before performing the upgrade. Operate Utility > Menu > Maintenance > Upgrade to recall the upgrade dialog box: Click Browse to open the file manager, select the correct upgrade file and touch the Recall icon T3DSO1000HD User Manual...
Page 330 Otherwise, the oscilloscope will restart automatically to finish the upgrade. After the reboot, check if the version number is in "System Information". Warning: Do not turn off the power during upgrading. Otherwise, the oscilloscope may not boot up! T3DSO1000HD User Manual...
Page 331 Press the "Single" button to switch to red and green display mode. Observe whether there is any color distortion, bad pixels, or scratches on the screen. Press the "Run/Stop" button to exit the screen test mode. T3DSO1000HD User Manual...
Page 332 Button test: Press each button and check whether the corresponding button icon on the screen lights up in real-time. Press the "Run/Stop" button three times to exit the keyboard test. T3DSO1000HD User Manual...
Page 333 Press the "Single" button to check the next button. Press the "Single" button consecutively until all the backlights are tested. Press the "Run/Stop" button to exit the LED test. T3DSO1000HD User Manual...
Page 334 Select Continue to start the self-cal program. The oscilloscope will not respond to any operation until the self-cal is finished. After the self-cal is completed, touch the screen or press any button to exit. T3DSO1000HD User Manual...
Page 335 This is always enabled, regardless of the status of Quick Cal. ＞＞＞ Touch Utility Menu Maintenance Quick Cal to set Quick Cal. Remote Control The T3DSO1000HD provides a LAN port and a USB Device port which can be used for remote control in multiple ways. T3DSO1000HD User Manual...
Page 336 Input the IP address of the instrument on the Web Browser Instrument information Click “Instrument Control” to recall the instrument control interface T3DSO1000HD User Manual...
Page 337 Click here to save the waveform data as a CSV file and download it to the local computer Click here to download the mini-tool for converting binary files to CSV Click here to perform a firmware upgrade T3DSO1000HD User Manual...
Page 338 Other Connectivity The T3DSO1000HD also supports remote control of the instrument by sending SCPI commands via NI-VISA, Telnet, or Socket. For more information, refer to the programming guide for this product. T3DSO1000HD User Manual...
Page 339 Check whether the power switch is on. Check whether the fuse is burned out. If the fuse needs to be changed, please contact TELEDYNE LECROY timely and return the instrument to the factory for replacement by the maintenance personnel authorized by TELEDYNE LECROY.
Page 340 Check whether the mode at the trigger panel (TRIGGER) is on “Normal” or “Single” and whether the trigger level exceeds the waveform range. If yes, set the trigger level to the middle or set the mode to “Auto”. Note: Using Auto could automatically finish the above setting. T3DSO1000HD User Manual...
Page 341 Make sure that the U disk system format is FAT32. Restart the instrument and then insert the USB storage device to check it. If the USB storage device still cannot be used normally, please contact TELEDYNE LECROY. T3DSO1000HD User Manual...
Page 342 Unless otherwise specified, all the materials and processes are compliant with the Restriction of Hazardous Substances (RoHS) Directive 2011/65/EU in its entirety, inclusive of any further amendments or modifications of said Directive. T3DSO1000HD User Manual...
Page 343 The product has been certified by TUV SUD to conform to the following Canadian safety standards. CAN/CSA-C22.2 No. 61010-1-12 – Safety requirements for electrical equipment for measurement, control and laboratory use. CAN/CSA-C22.2 No. 61010-2-030:18 – Particular requirements for equipment having testing or measuring circuits. T3DSO1000HD User Manual...
Page 344 RS Components Pty Ltd. RS Components Ltd. Suite 326 The Parade West Units 30 & 31 Warehouse World Kent Town, South Australia 5067 761 Great South Road Penrose, Auckland, New Zealand * Visit teledynelecroy.com/support/contact for the latest contact information. T3DSO1000HD User Manual...
Page 345 The instrument is subject to disposal and recycling regulations that vary by country and region. Many countries prohibit the disposal of waste electronic equipment in standard waste receptacles. For more information about proper disposal and recycling of your Teledyne LeCroy product, please visit teledynelecroy.com/recycle.
Page 346 汞镉六价铬多溴联苯多溴二苯醚 (Pb) (Hg) (Cd) (Cr6+) (PBB) (PBDE) PCBAs 机械硬件金属片塑料部件电缆组件显示器电源风扇电池电源线外部电源(如有) 探头(如有) 熔丝(如有) 产品外壳(如有) 适配器/模块(如有) 鼠标(如有) O: 表明该有毒有害物质在该部件所有均质材料中的含量均在SJ/T11364-2014标准规定的限量要求之下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出SJ/T11364-2014标准规定的限量要求。 EFUP (对环境友好的使用时间): 30年。使用条件：参阅用户手册“环境条件”部分的规定。探头EFUP: 10年。 T3DSO1000HD User Manual...
Page 347 SJ/T11364- 2014. EFUP (Environmental Friendly Use Period): 30 years. Use Conditions: Refer to the environmental conditions stated in the User Manual. EFUP for Probes: 10 years. T3DSO1000HD User Manual...
Page 348 © 2024 Teledyne Test Tools is a brand and trademark of Teledyne LeCroy Inc. All rights reserved.Specifi cations,prices,availability and delivery subject to change without notice. Product brand or brand names are trademarks or requested trademarks of their respective holders.
