  • Page 1 T3DSO2000HD Digital Oscilloscope User Manual...
  • Page 2 This page is intentionally blank. T3DSO2000HD User Manual...

  • Page 3: Copyright Information

    Declaration © 2023 Teledyne LeCroy, Inc. All rights reserved. Teledyne Test Tools is a brand and trademark of Teledyne LeCroy, Inc. Other product or brand names are trademarks or requested trademarks of their respective holders. Specifications, prices, availability and delivery subject to change without notice.

  • Page 4: Table Of Contents

    Contents COPYRIGHT INFORMATION ..............3 ABOUT THE T3DSO2000HD SERIES .............12 GENERAL SAFETY SUMMARY ...............13 SAFETY TERMS AND SYMBOLS ............14 GENERAL CARE AND CLEANING ............15 GENERAL INSPECTION ................16 QUICK START ..................17 MECHANICAL DIMENSION ..............17 ADJUST THE SUPPORTING LEGS ..........18 CONNECTING TO POWER SUPPLY ..........18 FRONT OF OSCILLOSCOPE ............19...
  • Page 5 CHOOSING THE LANGUAGE ............58 FRONT PANEL ..................59 VERTICAL CONTROL ...............60 HORIZONTAL CONTROL ..............61 TRIGGER CONTROL ................61 MULTIPLE APPROACHES TO RECALL FUNCTIONS ......64 MENU BAR ..................64 DESCRIPTOR BOX ................65 SHORTCUT BUTTON ON THE FRONT PANEL ......65 QUICKLY CAPTURE THE SIGNAL ............66 T3DSO2000HD User Manual...
  • Page 6 SLOPE TRIGGER ................113 PULSE TRIGGER ................116 VIDEO TRIGGER ................118 WINDOW TRIGGER ...............123 INTERVAL TRIGGER ..............125 DROPOUT TRIGGER ..............126 RUNT TRIGGER ................127 PATTERN TRIGGER ...............128 QUALIFIED TRIGGER ...............130 NTH EDGE TRIGGER ...............132 DELAY TRIGGER ..............133 T3DSO2000HD User Manual...
  • Page 7 SENT TRIGGER AND SERIAL DECODE ........187 MANCHESTER SERIAL DECODE ..........194 CURSORS ....................197 CURSORS MODE ................198 CURSORS TYPE ................200 SELECT AND MOVE CURSORS ............205 MEASUREMENT ..................208 SET PARAMETERS ................ 211 TYPE OF MEASUREMENT ............215 TREND ....................222 TRACK .....................223 DISPLAY MODE ................223 T3DSO2000HD User Manual...
  • Page 8 MAX-HOLD / MIN-HOLD ..............237 ALGEBRA ..................237 DIFFERENTIAL ................238 INTEGRAL ..................239 SQUARE ROOT .................241 ABSOLUTE ................241 SIGN...................242 EXP10 ..................243 LG ....................244 INTERPOLATE ................245 FREQUENCY ANALYSIS ............246 PARAMETER DISPLAY AREA ..........247 WINDOWS .................249 DISPLAY MODE.................250 FFT MODE .................251 UNIT ...................253 T3DSO2000HD User Manual...
  • Page 9 TYPE ....................292 REGION SETTING ................293 HISTOGRAM STATISTICS..............293 REGION SETTING ................295 POWER ANALYSIS ................298 POWER QUALITY ................299 TURN ON/TURN OFF ..............312 TRANSIENT RESPONSE ...............315 PSRR ....................317 POWER EFFICIENCY ..............318 SOA ....................319 BODE PLOT ....................322 CONFIGURATION ................323 SWEEP ....................324 T3DSO2000HD User Manual...
  • Page 10 SYSTEM SETTING .................358 I/O SETTING ...................365 LXI ....................365 LAN ....................366 NETWORK STORAGE ..............367 WEB SERVER .................368 MAINTENANCE ..................369 UPGRADE ..................369 SELF-TEST ..................371 SCREEN TEST................371 KEYBOARD TEST ................372 LED TEST ..................373 SELF-CALIBRATION ...............374 QUICK CAL ..................375 REMOTE CONTROL ...............375 T3DSO2000HD User Manual...
  • Page 11 WEB BROWSER ................376 OTHER CONNECTIVITY ............377 TROUBLESHOOTING ................378 COMPLIANCE INFORMATION ..............380 T3DSO2000HD User Manual...

  • Page 12: About The T3Dso2000Hd Series

    4 analog channels + 16 digital mixed signal analysis ability on MS configured models. The T3DSO2000HD series employs the latest technology which features a maximum waveform capture rate of up to 100,000 wfm/ s (normal mode, up to 500,000 wfm/s in Sequence mode), 256-level intensity grading display function plus a color temperature display mode.

  • Page 13: General Safety Summary

    Always ground both the internal and external conductors of the cable to release a static charge before connecting. Maintain Adequate Ventilation Inadequate ventilation may cause an increase in temperature, which may eventually damage the instrument. Maintain suitable ventilation and inspect the fan and intake regularly. T3DSO2000HD User Manual...

  • Page 14: Safety Terms And Symbols

    Indicates potential injury or hazards that may happen. CAUTION Indicates potential damage to the instrument or other property that may happen. Symbols used in this product. These symbols may appear on the product: Hazardous Protective Warning Earth Power Voltage Earth Ground Ground Switch T3DSO2000HD User Manual...

  • Page 15: General Care And Cleaning

    To avoid damage to the surface of the instrument and probe, please do not use any corrosive liquid or chemical cleansers. Make sure that the instrument is completely dry before restarting it to avoid potential short circuits or personal injury. T3DSO2000HD User Manual...

  • Page 16: General Inspection

    The consigner or carrier will be responsible for damages to the instrument resulting from shipment. TELEDYNE LECROY would not provide free maintenance or replacement if the instrument has been damaged in shipment. 2. Inspect the instrument If there are instruments found damaged, defective or failure in electrical and mechanical tests, please contact TELEDYNE LECROY.

  • Page 17: Quick Start

    Quick Start 1 Mechanical Dimension Front View Top View T3DSO2000HD User Manual...

  • Page 18: Adjust The Supporting Legs

    The only way to fully power down the instrument is to unplug the AC power cord or otherwise turn off the AC power supply. We recommend unplugging the instrument if it will remain unused for a long period of time. T3DSO2000HD User Manual...

  • Page 19: Front Of Oscilloscope

    See "User Interface" for transfer or USB more details mouse/keyboard for control Front Panel Includes knobs Digital Input Connector and buttons. See "Front Panel" Analog Input Connectors for more details Probe Compensation / Power Switch Ground Terminal Supporting Legs T3DSO2000HD User Manual...

  • Page 20: Back Of Oscilloscope

    USB storage device or USB Output mouse/keyboard Auxiliary Out Outputs the trigger indicator. When Mask AC Power Input Test is enabled, outputs the Handle pass / fail signal 100M LAN Port Connect the port to the network for remote control T3DSO2000HD User Manual...

  • Page 21: Probe Compensation

    2. Check the displayed waveforms and compare them with the following figure. Under Compensated Over Compensated Correctly Compensated 3. Use a nonmetallic flat-head screwdriver to adjust the low-frequency compensation adjustment hole on the probe until the waveform matches the “Compensated Correctly” waveform above. T3DSO2000HD User Manual...

  • Page 22: User Interface

    Dialog Box is the main area to select the parameters for a chosen specific function Trigger Delay Indicator locates where the trigger is on the horizontal axis Trigger Level Indicator shows the level where the waveform triggers Cursors show where measurement points have been set T3DSO2000HD User Manual...

  • Page 23: Channel Descriptor Box

    Vertical Scale Vertical Offset Bandwidth Information Probe Attenuation Factor 9 Timebase and Trigger Descriptor Boxes Trigger delay Horizontal scale (timebase ） # Samples Sample Rate Trigger source Trigger coupling Trigger mode Trigger level Trigger type Trigger slope T3DSO2000HD User Manual...

  • Page 24: Dialog Box

    Scroll bar. When parameters are more than the displayed range, the blue scrollbar will be displayed. By sliding the dialog area up and down, or rolling the mouse wheel, it can scroll to the area not displayed T3DSO2000HD User Manual...

  • Page 25: To Set Parameters

    11 To Set Parameters The T3DSO2000HD series provides several ways to set parameters: Switch – sets parameters with two states, such as to enable or disable a function. Touch the switch region to change from one state to the other.

  • Page 26: Touch Gestures

    Drag the waveform up and down to move it on the vertical axis Pinch and spread the waveform vertically to re-scale the vertical gain Touch and drag the cursor to move it T3DSO2000HD User Manual...
  • Page 27 Draw a rectangular box to create a zone or a histogram region. At the beginning of the gesture keep the angle close to 45° so it can be recognized as the drawing box gesture T3DSO2000HD User Manual...

  • Page 28: Front Panel

    Rotate the universal knob to set the value of the activated parameter, or to move the selected cursor. Push to select a different cursor 14 Choosing the Language Utility ＞ Menu ＞ System setting ＞ Language T3DSO2000HD User Manual...

  • Page 29: Basic Operations

    Touch the channel descriptor box and then touch the Off button to disable it. T3DSO2000HD User Manual...

  • Page 30: Vertical System

    Rotate the knob to adjust the vertical scale (volts/div). Push to switch to alternate between coarse and fine adjustments Rotate the knob to adjust the DC offset or vertical position of the channel. Push to set the offset to zero T3DSO2000HD User Manual...

  • Page 31: Channel Setup

    Copy the setting of the current channel to another channel Quickly select the current channel as the source of a specified operation ( Trigger, FFT, Measure, Cursor, Search, DVM and Counter ) Disable the channel Hide the trace T3DSO2000HD User Manual...
  • Page 32 Users can customize the text and display of the label Quickly apply a specified operation (Cursor, Measure, FFT, Search, DVM, Histogram and Mask Test) to the current channel Impedance Units for the channel Deskew Enable / disable invert Trace visible / hidden T3DSO2000HD User Manual...

  • Page 33: Horizontal System

    ▲ to increase and ▼ to decrease the trigger delay Set the trigger delay to zero Set the trigger point to the left part of the screen Set the trigger point to the right part of the screen Open the Acquire dialog box T3DSO2000HD User Manual...

  • Page 34: Acquisition System

    Select the acquisition mode (Normal / Peak / Average / ERES) Select the Memory Management mode (Auto, Fixed Sample Rate, and Fixed Memory) Select the maximum memory depth Enter the sequence menu XY mode on / off T3DSO2000HD User Manual...

  • Page 35: Zoom

    The region without the gray background in the main window is the portion of trace that is magnified in the zoom window. Please refer to the User Manual for detailed operation instructions of Zoom mode. T3DSO2000HD User Manual...

  • Page 36: Trigger

    50% of the waveform Ready LED, lighted when ready for trigger; Trig'd LED, lighted when a trigger event happens Indicators Relative to Trigger Trigger level Horizontal 0 position Horizontal 0 position Indicator Indicator (out of screen) Indicator T3DSO2000HD User Manual...
  • Page 37 Reject) Enable / disable Noise Rejection. When Noise Reject is on, the trigger hysteresis is increased, so the noise immunity of the trigger circuit is better. As a compromise, the trigger sensitivity degrades Set the Zone trigger T3DSO2000HD User Manual...

  • Page 38: Math

    Touch + > Func1 / Func2, or push the button on the front panel to create a math trace and open math setup dialog box Math trace Math setup dialog box Selects the trace (F1 ~ F2) Selects the operator and source (C1~C4, Z1~Z4, F1~F2) T3DSO2000HD User Manual...

  • Page 39: Measure & Statistics

    Measurement parameters and statistics display area. If select the mode as “Simple”, the "Simple" parameter area is displayed. Touch button on the front panel to reset the statistics Measure dialog box T3DSO2000HD User Manual...

  • Page 40: Cursors

    For more information, please refer to the User Manual. Push the button to open the cursors setup dialog box Rotate the knob to move the selected cursor; push to select different cursor The display mode of cursors Following Fixed T3DSO2000HD User Manual...

  • Page 41: Reference Waveforms

    Set the label text of the reference trace Save the waveform specified in to the specified location in The reference waveforms（.ref）can be saved to an external storage device. See “ Save / Recall ” for details. T3DSO2000HD User Manual...

  • Page 42: Save/Recall

    12 Save/Recall Touch Utility Save/Recall to save / recall a setup, picture, waveform data or ＞ reference waveform. Choose Save or Recall operation Select the object type Recall the File Manager for further operations T3DSO2000HD User Manual...

  • Page 43: Quickly Save

    Specifications are not guaranteed during the warm-up period. Whenever the oscilloscope is used in an environment outside 23 ± 5 °C, or when it has been more than one month since the previous calibration, a self-calibration is recommended. T3DSO2000HD User Manual...

  • Page 44: Quick Cal

    Changing vertical scale or channel interleaving mode will initiate the same ADC calibration procedure in the background. This is always enabled, regardless of the status of Quick Cal. Touch Utility ＞ Menu ＞ Maintenance ＞ Quick Cal to set Quick Cal. T3DSO2000HD User Manual...

  • Page 45: Touch Screen Display

    Touch Screen Display Overview The entire T3DSO2000HD display is a capacitive touch screen. Use your fingers to touch, drag, pinch, spread, or draw a selection box. Many controls that display information also work as “buttons” to access other functions. If you are using a mouse, you can click anywhere that you can touch to activate a control.

  • Page 46: Menu Bar

    You can enter most menus by using the front panel or parameter description labels instead of the menu bar. However, the following operations can only be accessed through the menu bar: Utility > Help Utility > Reboot Display Acquire T3DSO2000HD User Manual...

  • Page 47: Grid Area

    When the trigger position is outside the screen, the direction of the triangle points outside the screen as well. Channel Offset Indicator with a channel number shows the offset position of the corresponding channel. T3DSO2000HD User Manual...

  • Page 48: Channel Descriptor Box

    Touching the boxes creates a dialog box. See chapter “Vertical Setup” for more details. Below is an example for analog channel 1: 1. Channel Index 2. Coupling and Input Impedance 3. Vertical Scale 4. Vertical Offset 5. Bandwidth Information 6. Probe Attenuation Factor T3DSO2000HD User Manual...
  • Page 49 ：AC coupling, 50 Ω impedance ：Ground Vertical Scale: The scale of each grid in the vertical direction. For example, when the vertical scale is 1.00 V/div, the full scale of the oscilloscope is 1.00 V/div * 8 div=8 V. T3DSO2000HD User Manual...
  • Page 50 ：1:1 attenuation, suitable for direct coaxial cable connection or passive probes with 1X attenuation ：10:1 attenuation, suitable for general passive probes or active probes with 10X attenuation ：100:1 attenuation, suitable for some high-voltage probes ：Custom attenuation factor T3DSO2000HD User Manual...

  • Page 51: Timebase And Trigger Descriptor Boxes

    500 us/div * 10 div = 5 ms. # Samples: The number of sample points on the current screen. Sample Rate: The current sample rate. The Trigger Descriptor box shows the parameters of the trigger setting. See chapter “Trigger” for detailed information. T3DSO2000HD User Manual...
  • Page 52 • LFR: The signal is coupled through a capacitive high-pass filter network, DC is rejected and low frequencies are attenuated. For stable triggering on medium to high-frequency signals. See the datasheet for details of the cut-off frequency. T3DSO2000HD User Manual...
  • Page 53 Trigger level: The source voltage level or levels that mark the threshold for the trigger to fire. Trigger levels specified in Volts normally remain unchanged when the vertical gain or offset is modified. Trigger type: See the chapter "Trigger" for details. T3DSO2000HD User Manual...

  • Page 54: Dialog Box

    C. Scroll bar. When parameters are more than the displayed range, the blue scrollbar will be displayed. By sliding the dialog area up and down, or rolling the mouse wheel, it can scroll to the area not displayed. T3DSO2000HD User Manual...
  • Page 55 To Set Parameters The T3DSO2000HD provides a couple of different ways to input/select parameters: Switch: Sets parameters with two states, such as to enable or disable a function. Touch the switch region to change from one state to the other.
  • Page 56 The dialog box can be set to be hidden automatically. When the instrument is not operated beyond the set time, the dialog box will be automatically hidden. Follow the steps below: Display > Menu > Hide Menu Menu style = Floating, Dialog box is hidden and Dialog box is displayed T3DSO2000HD User Manual...

  • Page 57: Touch Gestures

    Pinch and spread the waveform vertically to it on the vertical axis re-scale the vertical gain Touch and drag the cursor to move it. Touch and drag the cursor information region to move the pair of cursors simultaneously. T3DSO2000HD User Manual...

  • Page 58: Mouse And Keyboard Operation

    7 Mouse and Keyboard Operation The T3DSO2000HD user interface features mouse control as well as a touch screen. If the oscilloscope is connected to a USB mouse, you can click on the object with the mouse instead of touching the object.

  • Page 59: Front Panel

    All the knobs on the front panel are multi-function. They can be pushed as well as rotated. Pushing a knob quickly recalls a specific function, which is indicated by the silkscreen near the knob. T3DSO2000HD User Manual...

  • Page 60: Vertical Control

    Rotate the knob to adjust the DC offset or vertical position of the activated trace. Push to set the offset to zero. When the digital channel is active, rotate the knob to change the position of the selected digital channel T3DSO2000HD User Manual...

  • Page 61: Horizontal Control

    C. Single mode: Triggers once when all conditions are met D. Normal mode: Triggers repeatedly when all conditions are met E. Trigger level adjustment: Push to set the level to 50% of the waveform F. Trigger status LED, Ready and Trig'd T3DSO2000HD User Manual...
  • Page 62 When the parameter setting area is highlighted, the Universal Knob can be used to adjust the parameter. Press the knob to select an option from the list. The default function of the Universal Knob is to adjust the intensity of the waveform traces. T3DSO2000HD User Manual...
  • Page 63 Recalls the Wave Gen dialog box. The LED on the button lights to indicate the output of the AWG is enabled. The preset functions can be called quickly through this button. See the section "Quick Action" for details T3DSO2000HD User Manual...

  • Page 64: Multiple Approaches To Recall Functions

    For example, to open the trigger setup dialog box, you can follow the steps below: Trigger > Menu The operations can be completed either by touch or by mouse clicks. T3DSO2000HD User Manual...

  • Page 65: Descriptor Box

    Most of the functions of the oscilloscope can be recalled directly by the shortcut buttons on the front panel. See the chapter "Front Panel" for details. To open the trigger setup dialog box, press the Setup button in the trigger control area on the front panel. T3DSO2000HD User Manual...

  • Page 66: Quickly Capture The Signal

    Auto Setup will not work on all signal types, especially time-varying bursts or slow signals (< 100 Hz). If Auto Setup cannot achieve desired settings, manually adjustment of the vertical, horizontal, and trigger systems is preferred. See the chapters "Vertical Setup", "Horizontal and Acquisition Setup" and "Trigger" for details. T3DSO2000HD User Manual...

  • Page 67: Vertical Setup

    Touch the + button and then select the expected channel to turn it on, and its channel descriptor box and a dialog box will appear on the display. Touch the channel descriptor box and then touch the Off button to disable it. Turn on C1 Turn off C1 T3DSO2000HD User Manual...
  • Page 68 The vertical scale can be adjusted in coarse or fine mode. Fine mode can reach the full- scale display as close as possible, which gets the best measurement accuracy in the vertical direction. The oscilloscope automatically switches to fine mode when the vertical scale is controlled by touch gestures. T3DSO2000HD User Manual...
  • Page 69 Users can customize the text and display of the label F. Quickly apply a specified operation (Trigger, FFT, Simple Measure, Cursor, Search, DVM, Histogram, Mask Test, Counter, and AWG) to the current channel G. Impedance H. Units for the channel Deskew Enable/disable invert K. Trace visible/hidden T3DSO2000HD User Manual...
  • Page 70 When the frequency component of the signal is very low, better signal-to-noise ratios (SNR) can be obtained by turning on a bandwidth limit. The T3DSO2000HD provides two hardware bandwidth limit options: 20 MHz and 200 MHz.
  • Page 71 Search, DVM, Histogram, Mask Test, Counter, and AWG can be quickly applied to the selected channel. Once a function is specified, it will switch directly to the function menu and automatically set that channel as the source. T3DSO2000HD User Manual...
  • Page 72 Warning: The 50 Ω input setting is not a high-power input. Damage can occur if the input exceeds the published specifications. See the datasheet for more details. Unit Voltage unit "V" or current unit "A”. When using the current probe, the unit should be set to "A". T3DSO2000HD User Manual...
  • Page 73 Before deskew After deskew Note: When the channel with deskew compensation is the trigger source, the trigger delay indicator does not change as the deskew value changes. T3DSO2000HD User Manual...
  • Page 74 When invert is enabled, the waveform is rotated 180 degrees around earth potential (0 Volts). Before invert After invert Trace When the trace is hidden, the channel waveform is no longer displayed on the screen, while the acquisition is still running in the background. Trace visible Trace hidden T3DSO2000HD User Manual...

  • Page 75: Digital Channels

    The equipment shall be used only for the purposes specified by the manufacturer. The T3DSO2000-LS probe is used only for Teledyne Test Tools' special series of oscilloscopes. Protection mechanisms can be compromised if the way the devices connected by the T3DSO2000-LS are not used for their intended purpose.
  • Page 76 Enable/Disable the Digital Channels Turning on or off the digital channels is similar to analog channels. Digital data can be stored as waveform files. Horizontal cursors and most horizontal measurements also apply to digital waveforms. T3DSO2000HD User Manual...
  • Page 77 Click + at the bottom of the display and select the "Digital" to turn it on. Click the digital channel descriptor box, and select Off on the pop-up menu to turn it off. Refer to the operation in the chapter "Vertical Setup" for details. T3DSO2000HD User Manual...

  • Page 78: Digital Channel Setup

    E. ▲ to increase and ▼ to decrease the number of divisions occupied by the digital channels F. Reset the height to the default value G. Turn off the digital channels H. Open the digital dialog box on the right side Height=8div, Position=0div Height=4div, Position=1div T3DSO2000HD User Manual...
  • Page 79 Custom option. D. Logic threshold of D15~D8 E. Set the channels to be displayed F. Deskew setting, the same as setting analog channels G. Bus setting T3DSO2000HD User Manual...
  • Page 80 ‘1’. The configurable logical level includes TTL, CMOS, LVCMOS 3.3 V, LVCMOS 2.5 V, and Custom. The setting range of the custom threshold is -10.0 V to + 10.0 V. T3DSO2000HD User Manual...
  • Page 81 D. Set the digital bus data E. Reset the digital bus data to the default state F. Enable/disable the display of the digital bus G. Set the vertical position of the bus H. Return to the previous menu T3DSO2000HD User Manual...
  • Page 82 In this dialog, the mapping relationship between the bus bits and the digital channels is shown as Bit.x[Dy]. For example, Bit.0[D15] means that bit 0 of the bus is D15. Touch Bit.x[Dy] to assign the digital channel D0-D15 to the specified bit x. T3DSO2000HD User Manual...

  • Page 83: Horizontal And Acquisition Setup

    E. Set the trigger delay to zero F. Set the trigger delay to the left part of the screen G. Set the trigger delay to the right part of the screen H. Open the Acquire dialog box T3DSO2000HD User Manual...

  • Page 84: Acquisition Setup

    D. Select the Memory Management mode (Auto, Fixed Sample Rate, and Fixed Memory). See the section "Memory Management" for details. E. Select the maximum memory depth F. Enter the sequence menu. See the section “Sequence” for details G. XY mode on/off T3DSO2000HD User Manual...
  • Page 85 But for step signals/fast rise times, it will introduce false overshoot due to the Gibbs phenomenon. Acq Mode: "Fast" is the default setting. The T3DSO2000HD provides a very high waveform update rate in fast mode. "Slow" mode will slow down the waveform update on purpose.
  • Page 86 T3DSO2000HD can obtain the best waveform refresh rate with the Memory Depth of 1 kpts. Under the full Memory Depth, T3DSO2000HD can still operate at full speed sampling at timebases < 10 ms/div which provides high resolution captures for long time duration events.

  • Page 87: Acquisition

    (250 ns) is much larger than the pulse width (3.4 ns), it is difficult to capture the narrow pulses in normal mode, but peak mode can ensure that each pulse is captured. T3DSO2000HD User Manual...
  • Page 88 The more frames that are accumulated, the lower the noise is. For the T3DSO2000HD, average processing is implemented by the hardware engine, so it can still maintain a high waveform update rate when the acquisition mode is set to average.
  • Page 89 (ENOB) of the oscilloscope. The ERES processing of T3DSO2000HD is realized by the hardware engine, so it can still maintain a high waveform refresh rate when eres is turned on.

  • Page 90: Memory Management

    Fixed Sample Rate: The sample rate is fixed as set, and the oscilloscope automatically adjusts memory depth according to the time base. The time of acquisition is the time corresponding to the full display (i.e. 10 horizontal divisions). T3DSO2000HD User Manual...

  • Page 91: Roll Mode

    If you would like to stop the display in Roll mode, press the Run/Stop button. To clear the display and restart an acquisition in Roll mode, press the Run/Stop button again. ： Zoom is only supported after Stop in Roll mode. Note T3DSO2000HD User Manual...

  • Page 92: Sequence

    If sequence mode is enabled, the display will not update until all of the sequences have been acquired. The T3DSO2000HD can achieve a minimum 2 us trigger interval in Sequence mode, corresponding to a waveform update rate of 500,000 wfm/s.
  • Page 93 100 ns; pulse width is 108 ns, and amplitude is 1.6 Vpp. Press the AutoSetup button on the front panel. Set the coupling mode of C1 to DC50Ω, and vertical scale to 500 mV/div, vertical offset to 0. Set the trigger level to 0. T3DSO2000HD User Manual...
  • Page 94 (74403 in this example, up to 80,000 depending on the number of samples at the current time base). Wait patiently until the acquisition completes, then all the waveforms satisfying the trigger conditions are displayed on the screen. T3DSO2000HD User Manual...
  • Page 95 During acquisition, there is a counter on the screen indicating the number of segments that have been acquired. In the example, 74403 pulses can be obtained with the sample rate of 2 GSa/s at the maximum memory depth. T3DSO2000HD User Manual...

  • Page 96: History

    Continue with the example in the section above. In Sequence mode, all waveforms that satisfy the trigger conditions are mapped to the display. If you need to observe a single frame, you can use history mode. T3DSO2000HD User Manual...
  • Page 97 To enable history mode, touch the Frame No . area twice, then the virtual numeric keypad pops up. Input the number "5412" to specify the 5412th segment (frame). Observing the 5412th frame captured by Sequence in history mode T3DSO2000HD User Manual...
  • Page 98 Delta T is the acquisition time interval between adjacent two frames, it is shown as 50ms in the following diagram, which is consistent with the period of the actual waveform. Acq Time label Delta T label T3DSO2000HD User Manual...
  • Page 99 Note: When a measurement is enabled in history mode, if the Interval Time is set to small (e.g. in us) the speed of automatic play may not meet the setting, because measurements may take a longer time for each frame. T3DSO2000HD User Manual...

  • Page 100: Zoom

    Zoom The T3DSO2000HD supports waveform zoom in the horizontal and vertical directions. Press down the horizontal knob or the button on the front panel to turn on the zoom function. When the Zoom function is on, the waveform area is divided into upper and lower parts. The area of about 1/3 height above is the main window, and the area of about 2/3 height below is the zoom window.
  • Page 101 The operations above can also be performed by different gestures. Below is the example of changing the setting in the horizontal direction by gestures. The gestures for changing the setting in the vertical direction are similar. T3DSO2000HD User Manual...
  • Page 102 Double click a location in the main window to quickly set the center of the zoom area Adjust the horizontal position of the waveform by dragging left and right in the gray area of the main window T3DSO2000HD User Manual...
  • Page 103 Adjust the horizontal/ vertical scale of the main window by using a pinching or spreading gesture in the gray area of the main window Note: Zoom traces (Z1~Z4) can be used as the source of Measurement, Math Mask tests, and Histogram. T3DSO2000HD User Manual...

  • Page 104: Trigger

    Arm: The pre-trigger buffer is not full, and the oscilloscope does not respond to any trigger events. Ready: The pre-trigger buffer is full, and the oscilloscope is waiting for the trigger event. Trig’d: A trigger event is detected and the oscilloscope starts to fill the post-trigger buffer. T3DSO2000HD User Manual...
  • Page 105 You need to have some knowledge of the signal-under-test to quickly capture the desired waveform. T3DSO2000HD User Manual...

  • Page 106: Trigger Setup

    E. Set the trigger mode to "Single", which is equivalent to pressing the Single button on the front panel F. Set the trigger mode to "Normal", which is equivalent to pressing the Normal button on the front panel T3DSO2000HD User Manual...
  • Page 107 As a compromise, the trigger sensitivity degrades G. Set the Zone trigger Trigger Related Label Trigger level Indicator Horizontal 0 position Horizontal 0 position Indicator (out of screen) Indicator T3DSO2000HD User Manual...

  • Page 108: Trigger Level

    In some special triggers, the system will automatically set the trigger level, such as using AC Line as the trigger source. T3DSO2000HD User Manual...

  • Page 109: Trigger Mode

    One-shot events or periodic signals, such as power-on\off waveforms on a power rail  Rare events Force：The oscilloscope performs an acquisition regardless of whether the input signal meets the trigger conditions or not. Press Single twice to perform a force trigger. T3DSO2000HD User Manual...

  • Page 110: Trigger Type

    Trigger Type Overview The trigger modes of the T3DSO2000HD are digital designs. Compared with analog trigger circuits, digital triggers can not only greatly optimize trigger precision and trigger jitter, but also support multiple trigger types and complex trigger conditions. Edge -- Trigger on a rising edge, falling edge or both...
  • Page 111 Delay --Trigger when the delay time between source A and source B meets the limit condition Setup/Hold --Trigger when the setup time or hold time meets the limit condition T3DSO2000HD User Manual...

  • Page 112: Edge Trigger

    Holdoff, coupling, and noise reject can be set in edge trigger, see the sections "Holdoff", "Trigger Coupling" and "Noise Reject" for details. Note: Press the Auto Setup button, and the oscilloscope will set the trigger type to Edge. T3DSO2000HD User Manual...

  • Page 113: Slope Trigger

    Touch the Source area to select trigger source, and touch the Slope area to select rising or falling. Rising -- Only trigger on the positive slope Falling -- Only trigger on the negative slope T3DSO2000HD User Manual...
  • Page 114 The lower level should always be less than or equal to the upper level. In the trigger descriptor box, the lower level is displayed. T3DSO2000HD User Manual...
  • Page 115 Holdoff, coupling, and noise reject can be set in slope trigger, see the sections "Holdoff", "Trigger Coupling" and "Noise Reject" for details. T3DSO2000HD User Manual...

  • Page 116: Pulse Trigger

    Great than a time value（≥）-- Trigger when the positive or negative pulse time of the input signal is greater than the specified time value. Below is an example of a trigger condition set to a positive pulse width > 100ns T3DSO2000HD User Manual...
  • Page 117 Holdoff, coupling, and noise reject can be set in pulse trigger, see the sections "Holdoff", "Trigger Coupling" and "Noise Reject" for details. T3DSO2000HD User Manual...

  • Page 118: Video Trigger

    Source, standard, and synchronization mode can be set in the video trigger dialog box. When the synchronization mode is "Select", line and field can be specified. Touch the Standard and select the video standard. The T3DSO2000HD supports the following video standards:...
  • Page 119 If the "Of Lines" is set to 800, the correct relationship between them is as follows: Of Lines Interlace Of Fields Trigger Line Trigger Field 1/2/4/8 1/1~2/1~4/1~8 1/2/4/8 1/1~2/1~4/1~8 1/2/4/8 1/1~2/1~4/1~8 T3DSO2000HD User Manual...
  • Page 120 HDTV 1080P/50、1080P/60 1 to 563 1 to 562 HDTV 1080i/50、1080i/60 To gain familiarization with the video trigger, try these two examples: • Trigger on a specific line of video (NTSC standard) • Use “Custom” to trigger video signals T3DSO2000HD User Manual...
  • Page 121 Touch the Sync and select the "Select" to make the Field and Line optional, then select "1" in the "Field", and set the "Line" to "22" by using the universal knob or the virtual keypad. Trigger on a Specific Line of Video (NTSC) T3DSO2000HD User Manual...
  • Page 122 Select the "Select" mode, then set the specified line and the specified field to trigger the signal. Assuming that the "Field" is set to 8, you can select any field from 1 to 8, and each field can choose any line from 1 to 100. T3DSO2000HD User Manual...

  • Page 123: Window Trigger

     If the lower trigger level is within the waveform amplitude range while the upper trigger level is out of the waveform amplitude range, the oscilloscope will trigger on the falling edge only. T3DSO2000HD User Manual...
  • Page 124 200mV, it represents a range of ±200 mV, which is a 400mV window. Holdoff, coupling, and noise reject can be set in window trigger, see the sections "Holdoff", Trigger Coupling" and "Noise Reject" for details. T3DSO2000HD User Manual...

  • Page 125: Interval Trigger

    Trigger source, slope (rising, falling), limit range, and time value can be set in the trigger dialog box. Holdoff, coupling, and noise reject can be set in interval trigger, see the sections "Holdoff", "Trigger Coupling" and "Noise Reject" for details. T3DSO2000HD User Manual...

  • Page 126: Dropout Trigger

    Trigger source, slope (rising, falling), dropout type, and time value can be set in the trigger dialog box. Holdoff, coupling, and noise reject can be set in the dropout trigger, see the sections "Holdoff", "Trigger Coupling" and "Noise Reject" for details. T3DSO2000HD User Manual...

  • Page 127: Runt Trigger

    A negative runt pulse across through the high level but not the low level. Holdoff, coupling, and noise reject can be set in the runt trigger, see the sections "Holdoff", "Trigger Coupling" and "Noise Reject" for details. T3DSO2000HD User Manual...

  • Page 128: Pattern Trigger

    The Pattern trigger identifies a trigger condition by looking for a specified pattern. The T3DSO2000HD provides 4 patterns: logical AND, OR, NAND and NOR combination of the channels. Each channel can be set to "Low", "High" or "Don't Care". If all channels are set to "Don’t Care", the oscilloscope will not trigger.
  • Page 129 The logical setting of analog channels The logical setting of digital channels Limit Range This setting is particularly useful to filter the hazard signals of combinational logic. Holdoff can be set in pattern trigger, see the section "Holdoff" for details. T3DSO2000HD User Manual...

  • Page 130: Qualified Trigger

    “State”, the oscilloscope triggers on the first edge when the qualified source is in the specified state (High or Low). When the type is “State with Delay”, a time limit condition is also available. T3DSO2000HD User Manual...
  • Page 131 (Rising or Falling) of the qualified source; when the type is “Edge with Delay”, a time limit condition is available. Touch the Qualified Setting region to set the qualified source and threshold; Touch the Edge Setting region to set the edge trigger source, threshold, and slope. T3DSO2000HD User Manual...

  • Page 132: Nth Edge Trigger

    Trigger source, slope (rising, falling), idle time, and edge number can be set in the trigger dialog box. Holdoff, coupling, and noise reject can be set in the Nth edge trigger, see the sections "Holdoff", "Trigger Coupling" and "Noise Reject" for details. T3DSO2000HD User Manual...

  • Page 133: Delay Trigger

    "and" combination of multiple channels. Touch the SourceB Setting region to set the edge trigger source, threshold, and slope. Touch the Limit Range and Upper/Lower Value region to set the delay time condition. T3DSO2000HD User Manual...

  • Page 134: Setup/Hold Trigger

    Touch the CLK Setting region to set the clock source, threshold, and slope; Touch the Data Setting region to set the data source, threshold, and state. T3DSO2000HD User Manual...

  • Page 135: Serial Trigger

    √ Runt √ × × × Pattern √ × × √ Serial √ × × √ Qualified √ × × √ Nth Edge √ × × √ Delay √ × × √ Setup/Hold √ × × √ T3DSO2000HD User Manual...

  • Page 136: Holdoff

    You can also use holdoff to trigger on the first edge of a burst when you know the minimum time between bursts. For example, to achieve a stable trigger on the repetitive pulses shown in the figure below set the holdoff time (t) to 200ns<t<600ns. T3DSO2000HD User Manual...
  • Page 137 Last Trig Time--The initial position of holdoff is the time of the last trigger. In the example above, the last trigger position is at the second rising edge of the pulse sequence and the second holdoff starts from that point. T3DSO2000HD User Manual...

  • Page 138: Trigger Coupling

     LFR: The signal is coupled through a capacitive high-pass filter network, DC is rejected and low frequencies are attenuated. For stable triggering on medium to high-frequency signals. See the datasheet for details of the cut-off frequency. T3DSO2000HD User Manual...

  • Page 139: Noise Reject

    18 Noise Reject Noise Reject adds additional hysteresis to the trigger circuitry. By increasing the trigger hysteresis, the noise immunity becomes better but the trigger sensitivity degrades. Noise Reject = Off Noise Reject = On T3DSO2000HD User Manual...

  • Page 140: Zone Trigger

    19 Zone Trigger The T3DSO2000HD includes a zone trigger to help isolate elusive glitches. There are two user-defined areas: Zone1 and Zone2. Users can set the property of each zone as “intersect” or “not intersect” as an additional condition to further isolate the interesting event quickly.
  • Page 141 Gesture When the zone trigger is turned on, touch-and-hold on any position within the waveform area and draw a rectangular box, as shown in the following figure: T3DSO2000HD User Manual...
  • Page 142 Once a zone is created, it can be moved by dragging. Just touch and hold the zone box and use a dragging gesture. Select C1 as the source, turn on zone1, Select C1 as the source, turn on zone1, and set the property as "Intersect" and set the property as "Not Intersect" T3DSO2000HD User Manual...
  • Page 143 Touch the regions above to set the value by the universal knob or the virtual keypad. Note: If zone1 and zone2 are both turned on, the result of the "AND" operation in two zones becomes the qualified condition of triggering. T3DSO2000HD User Manual...
  • Page 144 With a simple edge trigger, it is unlikely to trigger consistently on this anomaly. Thanks to the high waveform update rate of the T3DSO2000HD, we can confirm there is bus contention happening by enabling the persistence display, as shown in the figure below:...
  • Page 145 In this case zone trigger is a quick and simple way to capture the waveform. Enable the zone trigger, and draw a box to intersect with the bus contention part, as shown in the figure below: T3DSO2000HD User Manual...
  • Page 146 Now, we can accurately capture the exact bus contention waveform: T3DSO2000HD User Manual...

  • Page 147: Serial Trigger And Decode

    Serial Trigger and Decode Overview The T3DSO2000HD supports serial bus trigger and decoding on the following serial bus protocols: I2C, SPI, UART, CAN, LIN, FlexRay, CAN FD, I2S, MIL-STD-1553B, SENT, and Manchester. Press the Setup button on the front panel or touch the trigger descriptor box, and then...
  • Page 148 LIN Trigger and Serial Decode  FlexRay Trigger and Serial Decode  CAN FD Trigger and Serial Decode  I2S Trigger and Serial Decode  MIL-STD-1553B Trigger and Serial Decode  SENT Trigger and Serial Decode  Manchester Serial Decode T3DSO2000HD User Manual...

  • Page 149: I2C Trigger And Serial Decode

    The signal settings of decode and trigger are independent. If you want to synchronize the settings between decode and trigger, please perform Protocol Copy in the decode dialog box. T3DSO2000HD User Manual...
  • Page 150 C. Set the source of SDA. In the example above, SDA is connected to C1. D. Set the threshold level of the SDA channel. E. Return to the previous menu. F. Threshold level line. It only appears when adjusting the threshold level. T3DSO2000HD User Manual...
  • Page 151 When the protocol is set to I2C, the following trigger conditions can be set: Start, Stop, Restart, No Ack, EEPROM, or an R/W frame with a specific device address and data value. Touch Trigger Setting in the I2C trigger dialog box to select the trigger condition: T3DSO2000HD User Manual...
  • Page 152 Limit Range . If EEPROM’s data is greater than (less than, equal to) Data1 , the oscilloscope will be triggered at the edge of the ACK bit behind the Data byte. The Data byte doesn’t need to follow the EEPROM. T3DSO2000HD User Manual...
  • Page 153 Frame (Start: 7-bit address: R/W: Ack) — Data1 and Data2 are set to “0xXX”. If all bits match, then trigger on the Ack bit followed by the R/W bit. Frame (Start: 7-bit address: R/W: Ack: Data: Ack: Data2)—If all bits match, then trigger on the Ack bit followed by the Data2. T3DSO2000HD User Manual...
  • Page 154 10 Address & Data — If all bits match, then trigger on the Ack bit followed by the Data. Frame (Start: Address 1st byte: R/W: Ack: Address 2nd byte: Ack: Data) T3DSO2000HD User Manual...
  • Page 155 Touch the Address Length to select "7-bits" or "10-bits" to match the address of the input signal.  Touch the Data Length and turn the universal knob or virtual keypad to set the data length to match the data length of the input signal. T3DSO2000HD User Manual...
  • Page 156 C. List display area. The decode result of multiple frames can be displayed in the list, in which each row shows the time label and decode result of a frame. Touch Result List to set the parameters of the list. D. Decode dialog box T3DSO2000HD User Manual...
  • Page 157 TIME — The horizontal offset of the current data frame head relative to the trigger position.  Address — Address value. For example, "0x2AB" means that address = 2AB with acknowledgement.  R/W — Read address or write address.  DATA — Data bytes. T3DSO2000HD User Manual...
  • Page 158 R/W bit is represented together with the address. For example, the address 0x4E: Write: Ack, is displayed as "0x4E (W)" when the R/W bit is not included and is displayed as "0x9C" when the R/W bit is included. T3DSO2000HD User Manual...

  • Page 159: Spi Trigger And Serial Decode

    In addition to specifying the source and the threshold level, for the CLK signal, it is also necessary to specify the Edge Select .  Rising–Data latched on the rising edge of the clock.  Falling–Data latched on the falling edge of the clock. T3DSO2000HD User Manual...
  • Page 160 SPI bus. Referring to the following figure, when the falling edge of the clock is aligned with the data, the rising edge is selected to latch the data. When the rising edge of the clock is aligned with the data, the falling edge is selected to latch the data. T3DSO2000HD User Manual...
  • Page 161 This setting is suitable for the case where the CS signal is not connected, or the number of oscilloscope channels is insufficient (such as two-channel oscilloscopes). The method of copying settings is the same as I2C signal settings. See "I2C Signal Settings" for details. T3DSO2000HD User Manual...
  • Page 162 In the SPI trigger signal menu, set the source and threshold of CLK, MISO, and CS signals, then copy the trigger settings to decoding. Adjust the timebase, so that there is a falling edge on the CS signal shown on the screen: T3DSO2000HD User Manual...
  • Page 163 150 us, and measure the interval between clock pulses as 1.28 us, then set the timeout to a value between 1.28 us and 150 us. In this example it is set to 5 us: T3DSO2000HD User Manual...
  • Page 164 If the data width is set to be greater than 8 bits (such as 16 bits), measure the clock idle time between 8-bit data packets as 11.28 us, and then set the timeout time to a value between 11.28 and 150 us. In this example, it is set to 20 us: T3DSO2000HD User Manual...
  • Page 165 F. Set the bit order to MSB or LSB G. Return to the previous menu SPI Serial Decode The configuration of SPI decoding is similar to I2C. In the Protocol Config menu, Data Length (4-32 bit) and Bit Order (LSB or MSB) are configurable. T3DSO2000HD User Manual...

  • Page 166: Uart Trigger And Serial Decode

    D. Select the number of stop bits E. Set the idle level F. Set the bit order G. Return to the previous menu The method of copying settings is the same as I2C signal settings. See "I2C Signal Settings" for details. T3DSO2000HD User Manual...
  • Page 167 Error — The oscilloscope performs a parity check on the data according to the parity  type set by the user, and triggers if the check value is incorrect. UART Serial Decode The configuration of UART decoding is similar to that of I2C decoding. T3DSO2000HD User Manual...

  • Page 168: Can Trigger And Serial Decode

    In Protocol Config menu of trigger and decode, baud rate can be set to: 5 kb/s, 10 kb/s, 20 kb/s, 50 kb/s, 100 kb/s, 125 kb/s, 250 kb/s, 500 kb/s, 800 kb/s, 1 Mb/s or Custom. The method of copying settings is the same as I2C signal settings. See "I2C Signal Settings" for details. T3DSO2000HD User Manual...
  • Page 169 ID + Data —The oscilloscope triggers on the data frame that matches the specified ID  and data.ID, ID Bits (11-bit or 29-bit), Curr ID Byte (1st, 2nd, 3rd, or 4th byte), Data1, and Data2 can be set.  Error—The oscilloscope triggers on the error frame. T3DSO2000HD User Manual...
  • Page 170 CRC is displayed in blue.  The red point at the end of a segment indicates there is not enough space on the display to show the complete content of a frame and some content is hidden. T3DSO2000HD User Manual...
  • Page 171 “R”.  ID — ID of the frame, 11-bits or 29-bits ID are automatically detected.  Length — Data length.  Data — Data values.  CRC — Cycle redundancy check.  Ack — Acknowledge bit. T3DSO2000HD User Manual...

  • Page 172: Lin Trigger And Serial Decode

    0x00 to 0x3f.  ID & Data—The oscilloscope triggers on the frame that matches the specified ID and data.ID, Data1, and Data2 can be set.  Data Error —The oscilloscope will trigger when a data error happens. T3DSO2000HD User Manual...
  • Page 173 Time — The horizontal offset of the current data frame head relative to the trigger position.  ID — ID of the frame. Data length — Data length.   ID Parity — ID parity check. Data — Data values.   Checksum — Data checksum. T3DSO2000HD User Manual...

  • Page 174: Flexray Trigger And Serial Decode

    In the Protocol Config menu of the trigger and decode, the baud rate can be set to: 2.5 Mb/s, 5.0 Mb/s, 10.0 Mb/s, or Custom. The method of copying settings is the same as I2C signal settings. See "I2C Signal Settings" for details. T3DSO2000HD User Manual...
  • Page 175  Errors— The oscilloscope will trigger when a data error happens, including errors on FSS, BSS, FES, Header CRC, and Frame CRC. FlexRay Serial Decode The configuration of FlexRay decoding is similar to that of I2C decoding. T3DSO2000HD User Manual...
  • Page 176 CYC (cycle) is displayed in the frame and displayed in light yellow.  D (data) is displayed in the frame and displayed in white.  FCRC (Data Check Code) is displayed in the frame and displayed in blue. T3DSO2000HD User Manual...
  • Page 177  FID— Frame ID, the symbol occupies a single line of the list.  PL— Valid Data Length  HCRC— Head Check Code  CYC— Cycle count  Data— Data values  FCRC— Data Check Code T3DSO2000HD User Manual...

  • Page 178: Can Fd Trigger And Serial Decode

    ISO C. When the "Frame Type" is CAN FD, set the BRS (Bit Rate Switch) to Both, Normal or FD D. Trigger Condition: Start, Remote, ID, ID + Data, Error E. Return to the previous menu T3DSO2000HD User Manual...
  • Page 179 Ack is displayed in pink.  The red point at the end of a segment indicates there is not enough space on the display to show the complete content of a frame and some content is hidden. T3DSO2000HD User Manual...
  • Page 180 "FD", the extended frame is represented by "Ext" and the remote frame is represented by "RTR".  ID— Frame ID.  Length— Data length.  Data— Data bytes.  CRC— Cycle redundancy check.  Ack— Acknowledge bit. T3DSO2000HD User Manual...

  • Page 181: I2S Trigger And Serial Decode

    Low– Select the left channel when WS is low and the right channel when WS is high.  High– Select the right channel when WS is low and the left channel when WS is high. The method of copying settings is the same as I2C signal settings. See "I2C Signal Settings" for details. T3DSO2000HD User Manual...
  • Page 182 1 to 32 bits G. When the "Trigger Condition" is Data, set the compare type to =, ＞, ＜ H. When the "Trigger Condition" is Data, set the data value Return to the previous menu T3DSO2000HD User Manual...
  • Page 183 Falling Edge — Trigger on signals less than the Threshold setting value. o Touch Threshold to set the threshold by the universal knob or virtual keypad. The range of values is related to the number of Data Bits . T3DSO2000HD User Manual...
  • Page 184 Time— The horizontal offset of the current data frame head relative to the trigger position.  Type— Channel type, the left channel is represented by "Left CH" and the right channel is represented by "Right CH".  Data— Data bytes  Error— Error T3DSO2000HD User Manual...

  • Page 185: Mil-Std-1553B Trigger And Serial Decode

     The data word is displayed in yellow and the data is displayed in the frame and displayed in white.  The Check Code is displayed in the frame and displayed in blue. T3DSO2000HD User Manual...
  • Page 186 List:  Time— The horizontal offset of the current data frame head relative to the trigger position.  RTA— The RT address  Type— Type of the word  Data— Data values  Error— Error type T3DSO2000HD User Manual...

  • Page 187: Sent Trigger And Serial Decode

    Message CRCs are always calculated using the 2010 format, but for the Fast Channel Messages, and for Short Serial Message CRCs, the chosen setting is used E. Specify whether there is a pause pulse between Fast Channel Messages F. Return to the previous menu T3DSO2000HD User Manual...
  • Page 188 You can select the type of message: Fast Channel Message, Slow Channel Message, or any. Fast Channel — The oscilloscope will be triggered on a Fast Channel Message when the Status & Communication nibble and the data nibbles match the specified values. T3DSO2000HD User Manual...
  • Page 189 Frame (short serial message) — The 16-bit message consists of a 4-bit Message ID nibble, 2 nibbles (1 byte) of data, and a CRC checksum nibble. If ID and data match, then trigger on the end of CRC bit. T3DSO2000HD User Manual...
  • Page 190 No. 8): Frame (enhanced serial message with 4bits ID) —16-bit data and 4-bit message ID, the configuration bit is 1. Frame (enhanced serial message with 8bits ID) —12-bit data and 8-bit message ID, the configuration bit is 0. T3DSO2000HD User Manual...
  • Page 191 Fast Channel CRC Error: Triggers on any Fast Channel Message CRC error.  Slow Channel CRC Error: Triggers on any Slow Channel Message CRC error.  All CRC Errors: Triggers on any CRC error, Fast or Slow. T3DSO2000HD User Manual...
  • Page 192 The configuration of SENT decoding is similar to that of I2C decoding. Bus: For Fast Channel:  SYNC is displayed in pink  STATE is displayed in green  DATA is displayed in white  CRC and Pause pulse are displayed in blue T3DSO2000HD User Manual...
  • Page 193 State — Status & Communication nibble (only fast channel)  ID — ID of the frame. (only slow channel)  Data — Data values  CRC — Cycle redundancy check  Pause — Pause ticks  Error — Error type T3DSO2000HD User Manual...

  • Page 194: Manchester Serial Decode

    Connect the Manchester signal to the oscilloscope, set the mapping relation between channels and signals, and then set the threshold level of the signal. The process of specifying the source and threshold is similar to "I2C Signal Settings" T3DSO2000HD User Manual...
  • Page 195 Set the number of words in the data field, from 1 to 255 K. Set the data word size, from 2 to 8 Set the trailer size, from 0 to 32 M. Return to the previous menu T3DSO2000HD User Manual...
  • Page 196 DATA is displayed in white  The trailer is displayed in blue List:  Time — The horizontal offset of the current data frame head relative to the trigger position.  Data — Data words  Error — Error type T3DSO2000HD User Manual...

  • Page 197: Cursors

    Y cursor reference (Offset or Position), this option is supported only in "Manual" mode.  Offset measures the cursor position relative to the Vertical/Offset position  Position measures the cursor position relative to the vertical center of the display T3DSO2000HD User Manual...

  • Page 198: Cursors Mode

    Track -- The cursor type is automatically set to "horizontal + vertical". In this mode, only horizontal cursors are adjustable, while the vertical cursors automatically attach to the cross-point of the cursor and the source waveform.  Measure – Automatically indicates the measured item using cursors T3DSO2000HD User Manual...
  • Page 199 Manual Mode Track Mode easure Mode T3DSO2000HD User Manual...

  • Page 200: Cursors Type

    X1 and X2 simultaneously. Y（vertical）– Horizontal dotted lines that measure vertical voltage or current (depending on the unit of the selected channel). When the cursor's source is the math function, the units will match the math function. T3DSO2000HD User Manual...
  • Page 201 Y1- Y2 — The difference between Y1 and Y2. After this option is selected, turn the  universal knob to move both Y1 and Y2 simultaneously. X+Y (horizontal + vertical) -- Both the X cursors and Y cursors are enabled. T3DSO2000HD User Manual...
  • Page 202 Fixed Offset– When the vertical scale is changed, the value of Y- cursors remain fixed.  Fixed Position– When the vertical scale is changed, the Y-cursors remain fixed to the grid position on the display. Take X cursors reference as an example to demonstrate the scaling effect of different settings: T3DSO2000HD User Manual...
  • Page 203 Timebase=50ns/div，X1=-50ns=-1div，X2=100ns=2div Fixed position, timebase is changed to 100 ns/div, the grid number of X cursors (-1div, 2div) remains fixed. The value of X1 and X2 is changed to -100 ns, 200 ns. T3DSO2000HD User Manual...
  • Page 204 Fixed delay, timebase is changed to 100 ns/div, the value of X cursors (-50 ns, 100 ns) remains fixed. The grid number of X cursors is changed to -0.5div, 1div. T3DSO2000HD User Manual...

  • Page 205: Select And Move Cursors

    Touch the display area of △X (or △Y) in M1 mode and drag it to move the two cursors simultaneously, as shown in the figure below. This is equivalent to the operation on the cursor type X1-X2 or Y1-Y2. T3DSO2000HD User Manual...
  • Page 206 Gestures move the cursor quickly but not precisely, while the knob moves the cursor precisely but not as quickly. You can use both in combination to suit your needs: First, a rough adjustment is achieved by using gestures, and then the fine adjustment is achieved by using the universal knob. T3DSO2000HD User Manual...
  • Page 207 Dialog Box Touch the cursor value area of the dialog box, and then rotate the universal knob to adjust the position. T3DSO2000HD User Manual...

  • Page 208: Measurement

    The T3DSO2000HD features a strong automatic measurement list. These parameters can be automatically measured without cursors and include common measurements such as rise time, fall time, peak-peak, and period. The T3DSO2000HD can also measure multiple channels at the same time, showing up to 5 parameter measurements with statistics while in the M1 display mode and up to 12 parameters in the M2 mode.
  • Page 209 A. The waveform display area automatically compresses when the other windows are displayed B. Measurement parameters and statistics display area. If select the mode as “Simple”, the "Simple" parameter area is displayed C. Statistics histogram display area D. Measure dialog box T3DSO2000HD User Manual...
  • Page 210 D. Clear all the selected measurements E. Select measurement parameters F. Tools including Trend, Track, and Measure Cursor G. Turn on or off statistics H. Statistics settings: count limit, AIM limit, reset statistics, and histogram T3DSO2000HD User Manual...

  • Page 211: Set Parameters

    For example, to add Pk-Pk measurements for C1 and Period measurements for C2, follow the steps below: Source > C1 > Vertical > Pk-Pk Source > C2 > Horizontal > Period T3DSO2000HD User Manual...
  • Page 212 Touch – in the upper right corner of each parameter to close the parameter. Touch × in the upper right corner of the area to close measurement. Touch Clear in the dialog box to close all parameters. T3DSO2000HD User Manual...
  • Page 213 20 items can be stored in it. Long-press an item to add or remove it from the “Favorite” tab. For example, to add Pk-Pk to the “Favorite” tab: Advanced > Type > Vertical > Pk-Pk > Add to favorite T3DSO2000HD User Manual...
  • Page 214 To remove Period from the “Favorite” tab: Advanced > Type > Favorite > Period > Delete from favorite T3DSO2000HD User Manual...

  • Page 215: Type Of Measurement

    2 Type of Measurement 2.1.1.1 Vertical Measurement Vertical measurement includes 19 parameters: T3DSO2000HD User Manual...
  • Page 216 Median: Value at which 50% of the measurements are above and 50% are below  Cycle Median: Median of the first cycle  Overshoot (FOV): Overshoot following a falling edge; 100%* (base- min)/amplitude  Overshoot (ROV): Overshoot following rising edge; 100%*(max- top)/amplitude T3DSO2000HD User Manual...
  • Page 217  Preshoot (FPRE): Overshoot before a falling edge. Equal to 100 %*( max- top)/amplitude.  Preshoot (RPRE): Overshoot before a rising edge. Equal to 100 %*( base- min)/amplitude.  L@T: Level measured at trigger position T3DSO2000HD User Manual...
  • Page 218 2.1.1.2 Horizontal Measurement Horizontal measurement includes 17 parameters: T3DSO2000HD User Manual...
  • Page 219  Fall Time: Duration of falling edge from upper threshold to lower threshold  10-90%Rise: Duration of rising edge from 10-90%  90-10%Fall: Duration of falling edge from 90-10%  CCJ: The difference between two continuous periods T3DSO2000HD User Manual...
  • Page 220 Edges: Number of edges in a waveform  Ppulses: Number of positive pulses in a waveform  Npulses: Number of negative pulses in a waveform  PSlope: The slope of the rising edge  NSlope: The slope of the falling edge T3DSO2000HD User Manual...
  • Page 221 Tsu@R: Data setup time before the clock rising edge  Tsu@F: Data setup time before the clock falling edge  Th@R: Data hold time after the clock rising edge  Th@F: Data hold time after the clock falling edge T3DSO2000HD User Manual...

  • Page 222: Trend

    F. Minimum value G. Average value H. Reset statistics Press the Clear Sweeps button or touch Reset Statistics in the measure dialog box, or touch the symbol in the statistics display area to clear and restart statistics. T3DSO2000HD User Manual...

  • Page 223: Track

    In advanced measurement mode, two display modes are supported: M1 and M2. In M1 mode, up to 5 parameter measurements are displayed at a time. When statistics are enabled, they are listed under the measurement items. Touch a column to add or replace a measurement. T3DSO2000HD User Manual...
  • Page 224 In M2 mode, up to 12 parameter measurements are displayed at a time. When statistics are enabled, they are distributed on the right side of the measurement item. Touch a row to add or replace a measurement. Note: In M2 mode histogram display is not supported. T3DSO2000HD User Manual...

  • Page 225: Measurement Statistics

    1 ~ 25,000 C. Clear and restart the statistics. Pressing the Clear Sweeps button on the front panel has an equivalent effect D. Turn the histogram on or off E. Return to the previous menu T3DSO2000HD User Manual...
  • Page 226 When the oscilloscope detects the trace under test is clipped, an extra overflow indicator will appear after the measurement value: Waveform clipped at the top Waveform clipped at the bottom Waveform clipped at both top and bottom T3DSO2000HD User Manual...
  • Page 227 B. Histogram display area. The X-axis represents measured values and Y-axis represents the probability. C. Count of statistics D. Current value E. The bin that includes the maximum value and the probability of a value falling into it F. Close the enlarged histogram T3DSO2000HD User Manual...

  • Page 228: Simple Measurements

    The oscilloscope only measures the parameters of the data between A and B, ignoring the data outside the range. The setting of gate cursors is similar to that of ordinary cursors. See "Select and Move Cursors" for details. T3DSO2000HD User Manual...
  • Page 229 The figure below shows a scenario in which the gate function is used to measure the peak- peak parameter of the trough of an amplitude modulated waveform: T3DSO2000HD User Manual...
  • Page 230 D. Return to the previous menu T3DSO2000HD User Manual...
  • Page 231 Touch Config ＞ Threshold in the measure dialog box to recall the threshold dialog box: A. Set measurement threshold source B. Set the type of threshold C. Set the upper value D. Set the middle value E. Set the lower value F. Return to the previous menu T3DSO2000HD User Manual...
  • Page 232 2 times the input frequency, the results will be incorrect. The hardware frequency counter does not have this limitation. Its result is always shown at the top-right of the display as shown below: T3DSO2000HD User Manual...
  • Page 233 Math Overview The T3DSO2000HD supports 2 math traces and multiple operators. Arithmetic operators: Addition (+), subtraction (-), multiplication (x), division (/), average, ERES, identity, negation, maxhold, minhold; Algebra operators: differential (d/dt), integral (∫dt), square root (√), absolute (|y|), sign, exp, ln, interpolate; and FFT, as well as a formula editor. The math traces are labeled with icons “F1 ~ F2”...
  • Page 234 Vrms, dBArms, Arms, dBm d/dt V/s (Volt/second) or A/s (A/second) ∫dt VS (Volt*second) or AS (A*second) √ 0.5 or A ∧ ∧ V, A Sign V, A Exp or Exp10 V, A Ln or lg V, A Intrp V, A T3DSO2000HD User Manual...

  • Page 235: Addition / Subtraction / Multiplication / Division

    2 Arithmetic The T3DSO2000HD supports Addition, Subtraction, Multiplication, Division, Average, ERES, Identity, Negation, Max-hold, and Min-hold. 3 Addition / Subtraction / Multiplication / Division The T3DSO2000HD can perform arithmetic operations including addition, subtraction, multiplication, or division on any two analog input channels, and the values of Source A and Source B are computed point-by-point.
  • Page 236 Average / ERES can be set in acquisition mode and arithmetic function as well, but with different compute methods. Average and ERES in acquisition mode is computed by hardware with a higher speed and sampling rate than computed by software in the arithmetic mode. T3DSO2000HD User Manual...
  • Page 237 The value of Max-hold and Min-hold are based on statistical calculations from multiple frames. The following figure shows the Max-hold result. 7 Algebra The T3DSO2000HD can perform algebraic operations including differential (d/dt), integral (∫dt), square root (√), absolute(|x|), sign, exp (�� ��...
  • Page 238 The range of “dx” in the d/dt menu is 4~ number of samples pts. Note: Differentiation is sensitive to noise. It is helpful to set the acquisition mode to “Average” or “ERES” to help minimize the visible effects of additional noise. T3DSO2000HD User Manual...
  • Page 239 Small DC offsets in the input signal (or even small offset errors of the oscilloscope itself) may cause the integral output waveform to "ramp" up or down, as shown below: Integral without Offset Integral with Offset T3DSO2000HD User Manual...
  • Page 240 Gate function, then set Gate A and Gate B to define the gate. The setting of the gate cursors is similar to that of normal cursors. See "Select and Move Cursors" for details. T3DSO2000HD User Manual...

  • Page 241: Square Root

    Square root （√） calculates the square root of the selected source. If the waveform value is negative (the waveform is below the ground level), the result is displayed as zero. 11 Absolute Absolute（|x|）calculates the absolute value of the selected trace. T3DSO2000HD User Manual...
  • Page 242 The sign function of a real number x is defined as follows: Sign(x) = -1, if x < 0; = 0, if x = 0; = 1, if x > 0. T3DSO2000HD User Manual...
  • Page 243 13 exp10 �� The exponential operation includes the exponential operation �� based on constant e and �� the exponential operation 10 based on 10. �� For example: y(x) = �� T3DSO2000HD User Manual...
  • Page 244 (the waveform is below the ground level), the result is displayed as zero. �� For example F1 = �� , where x is the trigonometric wave function. F2 = ln (F1). T3DSO2000HD User Manual...
  • Page 245 Between the adjacent sampling points, the waveform is interpolated according to the selected interpolation method and interpolation coefficient. Touch Acquire ＞ Interpolation to set the interpolation method, and the interpolation coefficient can be set to 2, 5, 10, or 20. coefficient = 2 coefficient = 20 T3DSO2000HD User Manual...

  • Page 246: Frequency Analysis

    (seconds). In addition, the vertical axis provides the option of logarithmic scaling (dBVrms/dBArms or dBm). A. Time-domain waveform display area B. Spectrum (FFT) waveform display area C. FFT parameter display area D. Dialog box T3DSO2000HD User Manual...
  • Page 247  FFT points (Curr): The current FFT points, which is an integer power of 2. The T3DSO2000HD supports up to 2 M points (2097152, to be exact).  Frequency interval (△f): The frequency interval between two adjacent points in the FFT sequence, which is proportional to the frequency resolution.
  • Page 248 E. Select the display mode (Split, Full Screen, and Exclusive) F. Select the FFT mode (Normal, Average, and Max-Hold) G. Set the average count in average mode H. Reset average Return to the previous menu T3DSO2000HD User Manual...
  • Page 249 18 Windows Spectral leakage in FFTs can be considerably decreased when a window is used. T3DSO2000HD provides five windows that have different characteristics and apply to different scenarios. For example, for a two-tone signal with a very close frequency interval, it is suitable to use a Rectangle window with the best frequency resolution.
  • Page 250  Full Screen: Time-domain waveform and frequency-domain waveform are displayed together.  Exclusive: Only the frequency-domain waveform is displayed. Split Mode, Zoom off Split Mode, Zoom on Full-Screen Mode Exclusive Mode T3DSO2000HD User Manual...

  • Page 251: Fft Mode

    FFT mode is set as Average, Average will appear under FFT Mode . The average count can be set here, ranging from 4 to 1024. Press the Clear Sweeps on the front panel or touch Reset in the dialog box to restart the average counter. T3DSO2000HD User Manual...
  • Page 252 Ext Load value set in area C. Set the external load, which is used to calculate the correct dBm result D. Return to the previous menu E. Set the center-span frequencies F. Set the start-end frequencies T3DSO2000HD User Manual...
  • Page 253 Touch Scale to set the vertical scale of the FFT waveform by the universal knob or the virtual keypad. It can also be set by the scale knob shared by Decode, Digital, Math, and Ref on the front panel. The reference point for vertical scale scaling is the reference level. T3DSO2000HD User Manual...
  • Page 254 Touch Start to set the start frequency by the universal knob or the virtual keypad. Touch End to set the end frequency by the universal knob or the virtual keypad. The relationship between Center, Span, Start, and End is: Center = (Start + End)/2 Span = End – Start T3DSO2000HD User Manual...
  • Page 255 24 FFT Tools The T3DSO2000HD provides two tools for the FFT waveform: Peaks and Markers. The peaks tool can automatically search the qualified peak points and mark them on the FFT waveform. Up to 10 peaks are supported. Based on the peak tool, the markers tool can automatically search the qualified harmonics, and users can control the position of each marker.
  • Page 256 Return to the previous menu Note: The FFT dialog box is longer than the display. Slide the dialog box area up and down by gestures, or scroll the mouse wheel to the view non-displayed areas. T3DSO2000HD User Manual...
  • Page 257 Note: DC components in the signal may show a large amplitude near 0 Hz. If your application does not require measurement of the DC component, it is recommended to set the coupling mode of the source channel to "AC". T3DSO2000HD User Manual...
  • Page 258 D. Operation source. Cx represents analog trace, Zx represents zoomed trace and Fx represents math trace E. The keyboard area contains the basic arithmetic operators addition (+), subtraction (-), multiplication (*), division (/) F. Confirm button. After the formula is input, press the button to apply it T3DSO2000HD User Manual...
  • Page 259 The following is an example of F1 = (C1 + C1) * C2 through the formula editor T3DSO2000HD User Manual...
  • Page 260 (REFA/REFB/REFC/REFD) in the built-in nonvolatile memory. The saved reference waveform can be recalled to be compared with the current waveform. A. Channel waveform B. Reference waveform C. Reference vertical and horizontal information display area D. The reference dialog box, hidden in this figure T3DSO2000HD User Manual...
  • Page 261 Adjust the Reference Waveform Set the vertical position of the reference waveform by the offset knob on the front panel, and set the vertical scale of the reference waveform by the scale knob. T3DSO2000HD User Manual...
  • Page 262 27 Search The T3DSO2000HD can search for the specified events in a frame. The location of the events is displayed with white triangle indicators. In YT mode or Roll mode with the acquisition stopped, up to 1000 events are supported. In Roll mode with the acquisition running, the number of search events is unlimited.
  • Page 263 The current event is the one in the center of the display. Touch the menu Analysis > Search to recall the search dialog box and turn on it. T3DSO2000HD User Manual...

  • Page 264: Setup Menu

    28 Setup Menu Select and set the search type in the Setup Menu . The T3DSO2000HD provides five search conditions: Edge, Slope, Pulse, Interval, and Runt. Search Type Setup Description Edge Slope: Rising, Falling, Either Slope Slope: Rising, Falling Limit Range setting is available...
  • Page 265 29 Navigate Touch the menu Analysis > Navigate to recall the navigate dialog box. The T3DSO2000HD provides three navigate types: Search Event, Time, and History Frame. Navigate by Time The oscilloscope automatically adjusts the trigger delay according to the direction set by the user.
  • Page 266 ◀ or ▶ on the front panel to go to the previous or next search event. Touch Playing Mode to set the search event playing mode. Touch Interval Time to set the playing interval by the universal knob or the virtual keypad. T3DSO2000HD User Manual...
  • Page 267 Touch the Event List Switch area to turn on or off the list. The list contains time labels for each event. Touching a row in the list automatically jumps to the corresponding event. This operation is equivalent to specifying an event in the Event Num area. T3DSO2000HD User Manual...
  • Page 268 Touch Interval Time to set the playing interval by the universal knob or the virtual keypad. Touch Stop On Search Event to set the stop play condition: stop when the event is searched. This setting is only valid when the search function is on. T3DSO2000HD User Manual...
  • Page 269 First, set the trigger type to Runt to trigger on the dwarf pulse. See the section “Runt Trigger” for details. Then turn on the Search function and operate Copy from Trigger in the search dialog box so that the oscilloscope searches for the dwarf pulses according to the same setting as the trigger. T3DSO2000HD User Manual...
  • Page 270 Set the horizontal scale to 10 ms/div, then 9 markers with ~10 ms interval are shown on the display, indicating that a total of 9 dwarf pulses were found in the full screen of 100 ms time range: T3DSO2000HD User Manual...
  • Page 271 Turn on the Zoom function to observe the full view of the frame and the detail of the third dwarf pulse at the same time: T3DSO2000HD User Manual...
  • Page 272 Press the Run/Stop button on the front panel to stop the acquisition, and then follow the steps Navigate > Type to select “Search Event”. The following figure shows the first dwarf pulse. In this example, the list is enabled and the time labels of a partial event are shown in the list. T3DSO2000HD User Manual...
  • Page 273 A. Mask area in green. Any dot violating the rule is highlighted in red, instead of the normal waveform color. B. Pass/Fail information display area, including the count of passed frames, failed frames, total frames, and the fail rate. C. Dialog box T3DSO2000HD User Manual...
  • Page 274 Turn on/off “Capture on Fail”. When it is "on", the failure waveform is detected, and the screenshot with the failure frame will be stored in the external U disk. Turn on/off the sound prompt when a failure occurs. T3DSO2000HD User Manual...

  • Page 275: Mask Setup

    B. Set the vertical spacing of the mask around the currently displayed trace. The units are parts of the vertical division setting. C. Create the mask based on settings in D. Save the mask E. Return to the previous menu T3DSO2000HD User Manual...
  • Page 276 0.08~4.00 div. X = 0.2 div, Y = 0.2 div X = 1 div, Y = 1 div Saving and recalling mask files (*.msk) is similar to the operation of setup files, see the chapter "Save/Recall" for details. T3DSO2000HD User Manual...
  • Page 277 E. Coordinate edit area. Set the X ordinate and Y ordinate by the virtual keypad and then touch the “Input” button the perform the ordinate update F. Display or hide the coordinates of the polygon vertices on the display G. Exit the tool T3DSO2000HD User Manual...
  • Page 278 Create Polygon: Creates a polygon based on the drawn vertices by the operation Draw  Undo  Redo  Insert Point: Inserts a vertex on a selected side  Edit Polygon: Edits a polygon. Vertices, sides, and the polygon are all editable object  Delete Polygon: Deletes selected polygon T3DSO2000HD User Manual...
  • Page 279 For a side, the value is for its middle point. For a polygon, the ordinate is for its geometric center. Select a vertex (point Select a side (line segment) Select a polygon T3DSO2000HD User Manual...

  • Page 280: Operation

    Touch Operation to start/stop the test. Stopping a test in progress and restarting the test will clear the count of the passed frames, failed frames, total frames, and the fail rate. Pressing the Clear Sweeps button on the front panel can also clear the count information. T3DSO2000HD User Manual...
  • Page 281 The DVM (Digital Voltage Meter) function can be used to measure parameters such as DC and AC amplitudes. The T3DSO2000HD measures the specified parameter of the input signal and can display it in various formats, including Bar, Histogram, and Trend. DVM is asynchronous to the acquisition system of the oscilloscope.
  • Page 282 Turn on or off the histogram diagram G. Turn on or off the trend plot H. Turn on or off Hold. DVM stops acquisition in Hold mode Turn on the overload alarm, an alarm will sound when the signal is out of range T3DSO2000HD User Manual...
  • Page 283 AC RMS: Root mean square of the data at AC coupling  Peak-Peak: Difference between maximum and minimum data value  Amplitude: Difference between top and base in a bimodal waveform. If not bimodal, the difference between max and min. T3DSO2000HD User Manual...
  • Page 284 The color of the data in the diagrams is consistent with the color of the source. The bar diagram accurately displays the current measured value. Touch Bar in the DVM dialog box to display it. A. Mode B. Current value C. Bar corresponding to the current value T3DSO2000HD User Manual...
  • Page 285 DVM dialog box to display it. A. Mode B. Histogram display area C. Current value D. The bin includes the maximum value and probability with which values fall into it E. Statistics counts F. Reset statistics T3DSO2000HD User Manual...
  • Page 286 E. Maximum value F. Minimum value G. Average value H. Reset statistics Press the Clear Sweeps button on the front panel to restart counting and statistics. Touch the symbol in the histogram and trend display areas to restart statistics. T3DSO2000HD User Manual...
  • Page 287 When all the 3 diagrams are closed, there is a simple information bar on the top-left of the waveform display area to show the current value of the DVM: T3DSO2000HD User Manual...
  • Page 288 C. Select the source (C1~C4) D. Set the level of the counter E. Turn on or off statistics F. Clear and restart the statistics. Pressing the Clear Sweeps button on the front panel has an equivalent effect T3DSO2000HD User Manual...
  • Page 289 Stdv – The standard deviation of all historical counts, used to judge the distribution of historical count parameters Count – Number of counts obtained Level – Counter level Press the Clear Sweeps button or touch Reset Statistics in the measure dialog box to clear and restart statistics. T3DSO2000HD User Manual...
  • Page 290 The counter provides 3 modes. Touch Mode in the counter dialog box to open the mode selection window:  Frequency: Average frequency over a set period  Period: The reciprocal of the average frequency over a set period  Totalizer: Cumulative count T3DSO2000HD User Manual...
  • Page 291 D. When the gate type is level, set the polarity (Positive or Negative) of the gate source. When the gate type is edge, set the slope (Rising or Falling edge) of the gate source. E. Set the gate level F. Return to the previous menu T3DSO2000HD User Manual...
  • Page 292 Histogram Overview The T3DSO2000HD supports waveform histograms for observing probability distributions of the waveform in the specified region. The statistics can be performed in both horizontal and vertical directions. The histogram continues to update as long as the acquisition is active.

  • Page 293: Region Setting

    Horizontal Vertical Both 2 Region Setting See section “Region Setting” for details. 3 Histogram Statistics When histogram statistics is turned on, the oscilloscope will show the statistical parameters of the histogram on the display. T3DSO2000HD User Manual...
  • Page 294 Mode – The value that appears most often Bin Width – The width of each bin Sigma – Standard deviation of the samples Press the Clear Sweeps button or touch Reset Histogram in the histogram dialog box to clear and restart the statistics. T3DSO2000HD User Manual...
  • Page 295 Region Setting in the dialog box. The border color of the histogram region is consistent with the color of the specified source. Gesture Touch any position of the waveform area and draw a rectangular box, as follow: T3DSO2000HD User Manual...
  • Page 296 When the finger moves out of the touch screen, a menu pops up. Select "Histogram" in the menu: After the region is created, it can be moved by dragging gesture. T3DSO2000HD User Manual...
  • Page 297 C. Set the top border of the histogram region D. Set the bottom border of the histogram region E. Return to the previous menu Touch the area above to set the value by the universal knob or the virtual keypad. T3DSO2000HD User Manual...

  • Page 298: Power Analysis

    A. Enable/Disable the test B. Select the analysis item (Power Quality, Current Harmonics, Inrush Current, Switching Loss, Slew Rate, Modulation, Turn On/Turn Off, Transient Response, PSRR, Power Efficiency, Output Ripple, etc.) C. Turn on/off the state of the analysis item T3DSO2000HD User Manual...

  • Page 299: Power Quality

    S: Apparent Power = Vrms * Irms Q: Reactive Power = √Apparent Power − Active Power φ: Power Phase Angle: Phase difference between voltage and current cos φ: Power Factor, which is the ratio of active power and apparent power. T3DSO2000HD User Manual...
  • Page 300 Signal Settings Touch Signal to recall signal settings dialog box: A. Set the input voltage source B. Set the input current source C. Set the periods displayed D. View the connection guide E. Return to the previous menu T3DSO2000HD User Manual...

  • Page 301: Connection Guide

    Touch Signal > Connection Guide to recall the connection guide of power quality, as shown in the figure below. Please follow the instructions in this figure for correct connections. Touch the icon on the top right of the guide to close. T3DSO2000HD User Manual...

  • Page 302: Current Harmonics

     Class B: Portable tools, arc welding equipment which is not professional equipment  Class C: Lighting equipment.  Class D: PC, PC monitors, radio, or TV receivers. Input power P ≤ 600 W.I T3DSO2000HD User Manual...
  • Page 303 / fail state. When the value is greater than 85% of the limit but less than 100% of the limit, it is defined as a critical state. √X +⋯+X ， where X �� is the nth harmonic, Total Harmonic Distortion（THD）= 100% ∗ and X is the basic component. T3DSO2000HD User Manual...

  • Page 304: Inrush Current

    D. Set the maximum effective input voltage (Vrms), the range is 1 V ~ 1 kV. The oscilloscope will set the vertical scale of the voltage channel to maximum input voltage/6 E. View the connection guide F. Return to the previous menu T3DSO2000HD User Manual...
  • Page 305 This is a typical oscilloscope dynamic range limitation when trying to measure weak voltage and (or) current in the presence of relatively large switching voltage and (or) current. T3DSO2000HD User Manual...
  • Page 306 3. Touch Signal to enter the signal setting menu. Select the corresponding input channel, and then touch Auto Deskew to perform the calibration. When the process completes, a message will pop up indicating whether the deskew operation was successful or not. Before deskew calibration After deskew calibration T3DSO2000HD User Manual...
  • Page 307 This value is used to determine the threshold hysteresis of the switch edge C. Set the conduction type (Waveform, Rds(on) or Vce(sat)) D. Set Rds(on) resistance E. Set Vce voltage F. Return to the previous menu T3DSO2000HD User Manual...
  • Page 308 Touch Signal > Connection Guide to recall the connection guide of switching loss, as shown in the figure below. Please follow the instructions in this figure for connection. Touch the icon on the top right of the guide to close. T3DSO2000HD User Manual...
  • Page 309 Touch Signal > Connection Guide to recall the connection guide of slew rate, as shown in the figure below. Please follow the instructions in this figure for connection. Touch the icon on the top right of the guide to close. T3DSO2000HD User Manual...
  • Page 310 Touch Signal > Connection Guide to recall the connection guide of modulation, as shown in the figure below. Please follow the instructions in this figure for connection. Touch the icon on the top right of the guide to close. T3DSO2000HD User Manual...

  • Page 311: Output Ripple

    Touch Signal > Connection Guide to recall the connection guide of output ripple, as shown in the figure below. Please follow the instructions in this figure for connection. Touch the icon on the top right of the guide to close. T3DSO2000HD User Manual...

  • Page 312: Turn On/Turn Off

    F. Set the stable output voltage value, the range is -30 V ~ 30 V. The oscilloscope will set the vertical scale of the output voltage channel to stable output voltage / 6 G. View the connection guide H. Return to the previous menu T3DSO2000HD User Manual...
  • Page 313 T1 = When the input voltage finally falls to a certain percentage (usually 10%) of its maximum amplitude T2 = When the output DC voltage finally falls to a certain percentage (usually 10%) of its maximum amplitude T3DSO2000HD User Manual...
  • Page 314 Touch Signal > Connection Guide to recall the connection guide of turn on/turn off, as shown in the figure below. Please follow the instructions in this figure for connection. Touch the icon on the top right of the guide to close. T3DSO2000HD User Manual...

  • Page 315: Transient Response

    E. Set the overshoot percentage of output voltage, which can be used to determine the stable band value of transient response and adjust the vertical scale of the oscilloscope F. View the connection guide G. Return to the previous menu T3DSO2000HD User Manual...
  • Page 316 Touch Signal > Connection Guide to recall the connection guide of transient response, as shown in the figure below. Please follow the instructions in this figure for connection. Touch the icon on the top right of the guide to close. T3DSO2000HD User Manual...
  • Page 317 Touch Signal > Connection Guide to recall the connection guide of PSRR, as shown in the figure below. Please follow the instructions in this figure for connection. Touch the icon on the top right of the guide to close. T3DSO2000HD User Manual...

  • Page 318: Power Efficiency

    Touch Signal > Connection Guide to recall the connection guide of power efficiency, as shown in the figure below. Please follow the instructions in this figure for connection. Touch the icon on the top right of the guide to close. T3DSO2000HD User Manual...
  • Page 319 Please follow the instructions in this figure for connection. Touch the icon on the top right of the guide to close. Note: Perform a Deskew operation between the voltage and current input channels before the test. See section “Switching Loss” for more details on deskewing. T3DSO2000HD User Manual...
  • Page 320 Users can adjust horizontal, vertical, and trigger settings during the test for best observation. Below is an example of testing the power-up stresses on a MOSFET and judging if the stresses are safe for the MOSFET using the SOA: Voltage and current waveforms on the MOSFET at power-up T3DSO2000HD User Manual...
  • Page 321 SOA, in which the mask is created according to the voltage limit, current limit, and power limit. The result shows “Pass” because all the stresses are within the mask. T3DSO2000HD User Manual...
  • Page 322 Bode Plot Overview The T3DSO2000HD supports an automatic Bode Plot function. This function provides a frequency response curve of the device-under-test as well as the interface for output sweep parameter control and data display settings. At this time, either the built-in waveform generator or one of the T3AFG series of Function Generators are supported.
  • Page 323 C. Arbitrary waveform generator connection settings. Touch Interface to select the connection type. When selecting LAN, it needs to Set IP and Save it. Touch Test to confirm whether the arbitrary waveform generator is connected correctly. T3DSO2000HD User Manual...
  • Page 324 E. Set the amplitude of the sweep signal F. Set the offset of the sweep signal G. Set the signal amplitude unit. When it is set to dB, reference level and load need to be set H. Set the load T3DSO2000HD User Manual...
  • Page 325 E. Set the offset of the sweep signal F. Set the signal amplitude unit. When it is set to dB, reference level and load need to be set G. Variable level signal display area H. Touch Edit to turn on the profile editor T3DSO2000HD User Manual...
  • Page 326 Touch the cell in the table area to set the frequency and amplitude of the corresponding node. Touch to activate the cell, adjust the value through the universal knob, or touch the cell again to call up the virtual keypad for setting. T3DSO2000HD User Manual...
  • Page 327 Vout/Vin, it needs to set the amplitude axis type (Linear or Logarithmic). F. Auto-Set. According to the output signal amplitude curve, the oscilloscope automatically sets the scale and reference level G. Return to the previous menu T3DSO2000HD User Manual...
  • Page 328 F. Return to the previous menu Cursors T3DSO2000HD can use the cursor to measure the Bode plot curve. The cursor of the Bode plot is similar to the ordinary cursor, see the chapter "Cursors" for details. Touch Display > Cursors to recall the cursor setting dialog box.
  • Page 329 Users can turn on/off other scanning curves to observe the details of specific curves. Touch Display > Trace Visibility to recall the setting dialog box. T3DSO2000HD User Manual...

  • Page 330: Data Analysis

    Bode plot curve: upper cut-off frequency (UF), lower cut-off frequency (LF), bandwidth (BW), gain margin (GM), phase margin (PM). A. Data list display area B. Cursors C. Data point location line D. Cursor information display area E. Measurement parameters display area F. Bode plot dialog box T3DSO2000HD User Manual...
  • Page 331 C. Set the data source D. Save/Recall the data. Saving and recalling the Bode plot data (*.csv) is similar to the operation of setup files, see the chapter "Save/Recall" for details E. Return to the previous menu T3DSO2000HD User Manual...
  • Page 332 F. Close the measurement configuration window For example, to add UF measurements for C2 and GM measurements for C3, follow the steps below: Measure > Position > Source > UF Measure > Position > Source > GM T3DSO2000HD User Manual...
  • Page 333 G. Select the grid type (Full Grid, Light Grid, and No Grid) H. Set the trace intensity (0~100%) Set the backlight (0~100%) Set the graticule brightness (0~100%) K. Set the LED brightness (10~100%) Customize the colors of waveforms M. Display the axis labels T3DSO2000HD User Manual...
  • Page 334 Vectors: The samples are connected by lines (i.e. interpolated) and displayed. The interpolation methods include linear interpolation and sin(x)/x interpolation. See the section of "Acquisition Setup" for details of interpolation.  Dots: Displays the raw sample directly. Vector Display T3DSO2000HD User Manual...
  • Page 335 Therefore, what is seen using the dots display is not the discrete sampling points, but the display effect similar to equivalent sampling. Stop the acquisition to view the original samples of each frame separately. T3DSO2000HD User Manual...
  • Page 336 The smaller probability, the colder the color temperature of that pixel. The picture below shows the change of color from cold to warm. Color grade On Color grade Off T3DSO2000HD User Manual...
  • Page 337 New acquisitions are shown in their normal color with normal intensity. In combination with T3DSO2000HD's high waveform update rate and persist function, in some cases anomalies in the waveform can be found in a short time without complex trigger settings to improve test efficiency.
  • Page 338 Set Grid  Full Grid: Display 8*10 grid  Light Grid: Display 2*2 grid  No Grid: Display without grid Full Grid Light Grid T3DSO2000HD User Manual...
  • Page 339 No Grid T3DSO2000HD User Manual...
  • Page 340 Touch the Default area to restore the default color for all channels. Select a color directly on the palette and preview its hue, saturation, light, and RGB values or directly modify the color parameters to customize the color. After the change, touch OK to confirm. T3DSO2000HD User Manual...
  • Page 341 Moving mode: When moving the waveform, the position of the axes moves with the waveform, while the coordinates remain fixed.  Fixed mode: The position of the axes remain fixed, while the coordinates update as the waveform is moving. Moving mode T3DSO2000HD User Manual...
  • Page 342 Fixed mode T3DSO2000HD User Manual...

  • Page 343: Arbitrary Waveform Generator

    Arbitrary Waveform Generator Overview The T3DSO2000HD supports a built-in arbitrary waveform/function generation. The AWG functions include:  6 basic waveforms: Sine, Square, Ramp, Pulse, Noise, and DC  45 built-in arbitrary waveforms  Output frequency up to 25 MHz ...
  • Page 344 The following table shows all waveform types and corresponding parameters. Wave Type Parameters Sine Frequency, Amplitude, Offset Square Frequency, Amplitude, Offset, Duty Ramp Frequency, Amplitude, Offset, Symmetry Pulse Frequency, Amplitude, Offset, Duty Offset Noise Stdev, Mean Frequency, Amplitude, Offset, Arb Type T3DSO2000HD User Manual...
  • Page 345 Common, Math, Engine, Window, and Trigo. Stored waveforms are located in the Stored menu. Users can edit arbitrary waveforms using EasyWaveX PC software, send the stored waveforms to the instrument through the remote interface, or import the stored waveforms through a U disk. T3DSO2000HD User Manual...
  • Page 346 When the Sync Output is turned on, the Aux In/Out port of AWG outputs a CMOS signal with the same frequency as the basic waveform (except Noise and DC) and arbitrary waveform. The maximum supported frequency is 10 MHz. T3DSO2000HD User Manual...
  • Page 347 Measure and set the parameter to the Mean of CH2. Press Manual and rotate the universal knob to adjust the compensation value, until the mean value of CH2 is within ±1 mV, and then press Save . T3DSO2000HD User Manual...
  • Page 348 "Upgrade completed. Please reconnect the AWG device." Enter the System dialog box again to check if the upgraded hardware version number is consistent with the target version. Warning: Don't cut off the power during the upgrade! T3DSO2000HD User Manual...
  • Page 349 Save/Recall The T3DSO2000HD supports saving setups, reference waveforms, screenshots, and waveform data files to internal storage, external USB storage devices (e.g. U disk), or network storage. Saved setups and reference waveforms can be recalled as needed. For details of network storage, refer to the section “Network Storage”.
  • Page 350 “Factory”, the factory default setting will be recalled by pressing the Default button on the front panel; When the Default Type is set to “Current”, the last setting saved by the “To Default Key” operation will be recalled by pressing the Default button on the front panel. T3DSO2000HD User Manual...
  • Page 351 The following table shows the relationship between the save types and save/recall operations. Type Save Recall External Setup √ √ Reference √ √ √ × √ × √ × Binary Data √ × CSV Data √ × Matlab Data √ × FileConverter √ × T3DSO2000HD User Manual...

  • Page 352: File Manager

    2 File Manager The T3DSO2000HD's file manager has a similar style and operation to the Windows© operating systems. A. Address bar B. Navigation panel C. File list D. Toolbar E. File type F. Close the file manager T3DSO2000HD User Manual...
  • Page 353 Table 2.1 Description of icons in the file manager Icon Description Icon Description Back New directory Forward New file Up level Copy Root directory Paste Save Rename Save as Delete Recall Move T3DSO2000HD User Manual...
  • Page 354 Touch File Manager to open the file manager 3. Third, select the “\Udisk0\t3dso2khd\” directory in the file manager: 4. Fourth, touch Save As , click the pop-up text box to recall the virtual keyboard and input the file name, and then touch OK : T3DSO2000HD User Manual...
  • Page 355 The default naming strategy is to add an incremental number at the end of the first saved filename. Note: A saved picture can be browsed on the oscilloscope by opening it in the File Manager. T3DSO2000HD User Manual...
  • Page 356 Touch File Manager to open the file manager 3. Third, select the “\Udisk0\” directory in the file manager, and then select the setup file "T3DSO2354HD_Setup_1.xml" 4. Fourth, touch the Recall icon and wait for the oscilloscope to finish recalling the setup. T3DSO2000HD User Manual...

  • Page 357: System Information

    Utility 1 System Information Operate Utility > Menu > System Info to check the system status. System information includes the contents shown below. T3DSO2000HD User Manual...

  • Page 358: Auto Power On

    2 System Setting 2.1.1.1 Language The T3DSO2000HD supports multiple languages, including Simplified Chinese, Traditional Chinese, English, French, Japanese, German, Spanish, Russian, Italian, Portuguese, and so Operate Utility > Menu > System Setting > Language , and select the language in the list.
  • Page 359 2.1.1.5 Date/Time The T3DSO2000HD has an RTC clock, which helps to record absolute time information for screenshots, history frames, and so on. Operate Utility > Menu > System Setting > Date/Time to open the Date/Time dialog box: Touch the text box of Hour, Minute, Second, Day, Month, and Year to edit these fields.

  • Page 360: Reference Position Setting

    As the vertical scale is changed, the waveform expands/contracts around the position of the vertical ground position on the display. Take Horizontal Ref as an example to demonstrate the scaling effect of different settings: T3DSO2000HD User Manual...
  • Page 361 Timebase = 10 ns/div, Horizontal Delay = -20 ns = - 2 div Fixed position, timebase is changed to 5 ns/div, the grid number of delay (2div) remains fixed, while the horizontal delay changes to -10 ns T3DSO2000HD User Manual...
  • Page 362 Fixed delay, timebase is changed to 5 ns/div, the horizontal delay value remains fixed, while the grid number of delay changes to 4div T3DSO2000HD User Manual...
  • Page 363 (.bmp/.png/.jpg). Touch Utility > Save Button to set the file type and path. A. Select the save type: Screenshot or Save to B. When the save type is “Save to”, set the save type referred to in the chapter "Save/Recall". T3DSO2000HD User Manual...
  • Page 364 When set as “Display”, the button can be preset to change some display parameters such as color grade and persistance C. Set the action of this button under the selected category T3DSO2000HD User Manual...
  • Page 365 After setting the LAN, the LXI welcome page can be loaded through the browser, refer to the section “LAN” and “Web Browser” for details. When starting instrument identification in the web server, the LXI image in the upper right corner will flash continuously. T3DSO2000HD User Manual...
  • Page 366 D. When is not checked, set the DNS IP address manually E. When accessing more than two Teledyne Test Tool instruments through the web browser, it is necessary to set a different VNC port number for each instrument. The range is from 5900 to 5999.

  • Page 367: Network Storage

    (Username: Guest, no password). This needs the server to permit anonymous access. D. Username and password. Check “Remember” to save them E. Check to automatically connect to the network directory at every power on F. Connect or disconnect to the network directory manually T3DSO2000HD User Manual...

  • Page 368: Web Server

    4 Web Server The T3DSO2000HD includes a web server function, you can access and control the oscilloscope using a web browser. See the section "Web Browser" for details about remote control operation. Perform Utility > Menu > I/O > Web Server to set the password to control the instrument.

  • Page 369: Maintenance

    (*.ads) and is connected to the oscilloscope before performing the upgrade. Operate Utility > Menu > Maintenance > Upgrade to recall the upgrade dialog box: Click Browse to open the file manager, select the correct upgrade file and touch the Recall icon T3DSO2000HD User Manual...
  • Page 370 Otherwise, the oscilloscope will restart automatically to finish the upgrade. After the reboot, check if the version number is in "System Information". Warning: Do not turn off the power during upgrading. Otherwise, the oscilloscope may not boot up! T3DSO2000HD User Manual...

  • Page 371: Screen Test

    The screen displays in blue at first. Press the "Single" button to switch to red and green display mode. Observe whether there is any color distortion, bad pixels, or scratches on the screen. Press the "Run/Stop" button to exit the screen test mode. T3DSO2000HD User Manual...

  • Page 372: Keyboard Test

    Button test: Press each button and check whether the corresponding button icon on the screen lights up in real-time. Press the "Run/Stop" button three times to exit the keyboard test. T3DSO2000HD User Manual...
  • Page 373 Press the "Single" button to check the next button. Press the "Single" button consecutively until all the backlights are tested. Press the "Run/Stop" button to exit the LED test. T3DSO2000HD User Manual...

  • Page 374: Self-Calibration

    Select Continue to start the self-cal program. The oscilloscope will not respond to any operation until the self-cal is finished. After the self-cal is completed, touch the screen or press any button to exit. T3DSO2000HD User Manual...

  • Page 375: Remote Control

    ＞ ＞ ＞ Touch Utility Menu Maintenance Quick Cal to set Quick Cal. 8 Remote Control The T3DSO2000HD provides a LAN port and a USB Device port which can be used for remote control in multiple ways. T3DSO2000HD User Manual...

  • Page 376: Web Browser

    A. Input the IP address of the instrument on the Web Browser B. Instrument information C. Click “Instrument Control” to recall the instrument control interface T3DSO2000HD User Manual...

  • Page 377: Other Connectivity

    F. Click here to perform a firmware upgrade 10 Other Connectivity The T3DSO2000HD also supports remote control of the instrument by sending SCPI commands via NI-VISA, Telnet, or Socket. For more information, refer to the programming guide for this product.

  • Page 378: Troubleshooting

    Check whether the power switch is on. Check whether the fuse is burned out. If the fuse needs to be changed, please contact TELEDYNE LECROY timely and return the instrument to the factory for replacement by the maintenance personnel authorized by TELEDYNE LECROY.
  • Page 379 Make sure that the U disk system format is FAT32. e) Restart the instrument and then insert the USB storage device to check it. If the USB storage device still cannot be used normally, please contact TELEDYNE LECROY. T3DSO2000HD User Manual...

  • Page 380: Compliance Information

    Unless otherwise specified, all the materials and processes are compliant with the Restriction of Hazardous Substances (RoHS) Directive 2011/65/EU in its entirety, inclusive of any further amendments or modifications of said Directive. T3DSO2000HD User Manual...

  • Page 381: Canadian Certification

    The product has been certified by TUV SUD to conform to the following Canadian safety standards. CAN/CSA-C22.2 No. 61010-1-12 – Safety requirements for electrical equipment for measurement, control and laboratory use. CAN/CSA-C22.2 No. 61010-2-030:18 – Particular requirements for equipment having testing or measuring circuits. T3DSO2000HD User Manual...
  • Page 382 RS Components Pty Ltd. RS Components Ltd. Suite 326 The Parade West Units 30 & 31 Warehouse World Kent Town, South Australia 5067 761 Great South Road Penrose, Auckland, New Zealand * Visit teledynelecroy.com/support/contact for the latest contact information. T3DSO2000HD User Manual...
  • Page 383 The instrument is subject to disposal and recycling regulations that vary by country and region. Many countries prohibit the disposal of waste electronic equipment in standard waste receptacles. For more information about proper disposal and recycling of your Teledyne LeCroy product, please visit teledynelecroy.com/recycle.
  • Page 384 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr6+) (PBB) (PBDE) PCBAs 机械硬件 金属片 塑料部件 电缆组件 显示器 电源 风扇 电池 电源线 外部电源(如有) 探头(如有) 熔丝(如有) 产品外壳(如有) 适配器/模块(如有) 鼠标(如有) O: 表明该有毒有害物质在该部件所有均质材料中的含量均在SJ/T11364-2014标准规定的限量要求之下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出SJ/T11364-2014标准规定的限量要求。 EFUP (对环境友好的使用时间): 30年。 使用条件：参阅用户手册“环境条件”部分的规定。 探头EFUP: 10年。 T3DSO2000HD User Manual...
  • Page 385 SJ/T11364- 2014. EFUP (Environmental Friendly Use Period): 30 years. Use Conditions: Refer to the environmental conditions stated in the User Manual. EFUP for Probes: 10 years. T3DSO2000HD User Manual...
  • Page 386 © 2021 Teledyne Test Tools is a brand and trademark of Teledyne LeCroyInc. All rights reserved.Specifications,prices,availability and deliverysubject to change without notice. Product brand or brand names are trademarks or requested trademarks of their respective holders. T3 stands for Teledyne Test Tools.

This manual is also suitable for:

T3dso2354hd-msT3dso2204hd-msT3dso2104hd-msT3dso2104hdT3dso2354hdT3dso2204hd

Table of Contents
