Wheel inspection
Tire specifications and pressure
Front wheel
Tire specifications
rear wheel
Front wheel
Tire pressure
rear wheel
Tire wear limit
Tire wear limit
Wheel runout limit
Wheel runout limit
120/70-1251P
130/70-12 56P
180(kPa)
220(kPa)
2.0mm
Front wheel
3.0mm
rear wheel
2.0mm
Axial
2.0mm
Radial
Spoke hub
inspection/adjustment
Inspection method:
Check whether the spoke nut is loose or broken. Use a torque wrench or pinch the spoke with
your hands to make sure it is tight and
Treatment method:
1. If there are less than 4 loose spokes, tighten the loose spokes directly to the standard
torque;
2.To replace the spokes, you need to remove the tire, use a special wrench to loosen the nuts
and replace the nuts and spokes, and adjust the spokes and rim runout.
Note:
1. Spoke torque standard: 1.5-2.5Nm
2.If a spoke is broken, the adjacent group of spokes needs to be replaced
3. Use a dial indicator to check the rim end runout and diameter runout to be less than 1mm; if
there is no dial indicator, use a steel sheet to visually check
the runout clearance
against the rim
1.If the tire pressure is too high, it will reduce the riding comfort and accelerate the wear of
various parts. If the tire pressure is too low, it will increase the rolling resistance of the
tire and increase fuel consumption. In severe
the tire and cause a tire blowout.
2. When the tire valve core is leaking, repair or replace the valve core. When the tire is
leaking, repair or replace the tire.
3. Check and adjust the wheels regularly at our authorized service center.
Maintenance
not loose.
! Danger
cases, it will cause partial delamination of
