CyClone RT2E Modern 250 User Manual page 41

Maintenance
Front and rear brake inspection
2
. 40 .
1
2
The front and rear brakes of this model adopt disc
configuration, which has the advantages of stable braking
performance, safety and reliability, labor saving and good heat
dissipation.
1.When the free travel of the brake handle is greater or less than the
standard value, it needs to be readjusted.
2.Check the oil level in the oil reservoir through the observation hole.
When the oil level in the oil reservoir is lower than the lower limit,
add brake oil to the upper limit.
3. Check the wear of the friction pad and brake disc. If the thickness
of the friction pad is less than the maintenance limit of 2.0mm and
the thickness of the brake disc is less than the limit of 3.0mm, the
friction pad and brake disc need to be replaced.
Brake handle stroke standard value: 10mm〜20mm
1. If the brake handle feels soft and loose, it means there is air in the hydraulic brake and it
and adjusted by our authorized service center.
2. Brake oil cannot be mixed with other lubricants. Replaced brake oil cannot be reused. Brake oils of different
brands cannot be mixed, otherwise the performance of the hydraulic
3.Regularly visit our company's authorized maintenance service for inspection and adjustment.
Danger
!
must be checked
brake will be seriously damaged.
