Zendure SolarFlow Smart PV Hub User Manual page 16

1. Connect the Hub 1200 to up to four solar panels using two Solar Parallel Y
Cables*.
2. Please ensure that when connecting two solar panels in parallel, they are
connected to the same PV input port. Do not connect the positive and
negative terminals of the parallel-connected solar panels to the PV1 and PV2
ports separately, as this may cause the equipment to malfunction or become
damaged.
3. please ensure that the total operating current to each PV input port from the
parallel solar panels does not exceed 13A to avoid potential overcurrent that
may cause malfunction.
* The 2-to-4 Solar Parallel Y Cable needs to be purchased from Zendure official
website
* We are not liable for any damages resulting from improper connections.
5.3.8 Download the Zendure app
The Zendure App gives users the ability to allocate the power to AB1000
and home grid and monitor power generation,the power to Microinverter
can be set in a range of 100-1200W.
Read the Zendure App user guide and access the download link here:
https://zendure.com/pages/download-center.
* Add device and Update to the latest firmware version
Using the device for the first time, you need to update the firmware via
the Zendure App.More information ,please check the Zendure App user
guide.
* Set the power to the Microinverter
The maximum solar input power of SolarFlow system is 800W, you can set
the power to Microinverter, and the excess power will be automatic stored
in the battery.For example：
If the total solar input is 800W ,you set 200W to Microinverter, and then
there will be 600W input AB1000.
Privacy Policy
By using Zendure Products, Applications and Services, you
consent to the Zendure Terms of Use and Privacy Policy,
which you can access via the "About" section of the "User"
page in the Zendure App
