Zendure SolarFlow Smart PV Hub User Manual page 7

EN
5. Getting Started
5.1 What's in The Box
1* Smart PV Hub
6* Mounting Screws
M4.7*39mm
1. Solar Cable: Used for solar panels connection.
2. Battery Cable: Used for AB1000 connection.
3. Microinverter Cable: Used for Microinverter connection.
4. Mounting Screws: Hooking up Smart PV Hub and Microinverter.
5. Flat Washeret: Used to fixed the Microinverter.
Accessory Pack
A Set of MC4 Y connectors
5.2 Product Overview
Button:
2
3
4
5
6
TOP
1
MC4 Connector PV Input 1 positive electrode
2
MC4 Connector PV Input 1 negative electrode
3
MC4 Connector PV Input 2 positive electrode
4
MC4 Connector PV Input 2 negative electrode
5
Aerial
6
PV Hub Status Indicator
7
IoT Button & Indicator
8
AB1000 Status Indicator
9
MC4 Connector Microinverter Output positive electrode
10
MC4 Connector Microinverter Output negative electrode
11
7
4* Solar Cable 3m
1* Aerial
1-to-2
1* Battery Cable
Washeret
2* Microinverter Cable
1
7 8 9
2* Microinverter
1.5m Cable 0.6m
2* Flat
User Manual
0.6m
10
11
