Advantech MIO-5375CR-S8A1 Startup Manual

MIO-5375 3.5" MI/O-Compact SBC, 11th Gen.
Intel Core™ U-series (i7/i5/i3/Celeron
®
Startup Manual
Packing List
Before you begin installing your board, please make sure
that the following items have been shipped:
• 1 x MIO-5375 SBC
• 1 x SATA cable 30cm (P/N: 1700006291)
• 1 x SATA power cable 35cm (P/N: 1700031583-01)
• 1 x USB2.0 cable 20cm (P/N: 1700030406-01)
• 1 x Audio cable 20cm (P/N: 1700019584-01)
• 2 x COM RS-232/422/485 cable 20cm (P/N: 1700030404-
01)
• 2 x COM RS-232 cable 20cm (P/N: 1700031582-01)
• 1 x Cooler (heatsink) (P/N:1970004884T001/
1970004794T001)
• 1 x Startup manual (P/N: 2046537500)
• 1 x Mini jumper (10pcs package)
• 1 x Screw kit (2 x sets screws and post for M.2 device & 4
sets of screws and stand-off)
• 1 x DeviceOn package
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Specifications
General
• CPU:
- Intel Core™ i7-1185G7E (Quad-Core, 4.40 GHz)
®
- Intel Core™ i5-1145G7E (Quad-Core, 4.10 GHz)
®
- Intel Core™ i3-1115G4E (Quad-Core, 3.90 GHz)
®
• System memory: Dual Channel/SODIMM DDR4-3200
MT/s, up to 64 GB
• BIOS: AMI EFI 256Mbit
• Watchdog timer: 65536 level, 0~65535 sec
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com.tw/
This manual is for MIO-5375.
Part No. 2046537501
Printed in China
Specifications (Cont.)
• TPM 2.0
• iManager 3.0: Yes
• Expansion interface:
- M.2:
1 x E-Key 2230 (PCIe x1, USB2.0)
1 x B-Key 3042 (USB2.0) w/Nano-SIM
1 x M-Key 2280 (PCIe x4 Gen.4 for PCIe SSD), optional
SATA
- MI/O Extension connector: 4 x PCIe x1, 1 x PCIe x4,
1 x USB 2.0, LPC, SMBus, Line-out, and 12V/5V Power
supply
• Battery: Lithium 3 V/210 mAH
• Audio: Supports High Definition Audio (HD), line-in, line-
out, and Mic-in
Display
• Controller:
- Intel
- 48-bit LVDS display output
• Maximum resolution:
- LCD:
LVDS dual channel 48-bit up to 1920x1200
Optional: eDP 1.4 up to 4096x2304@60 Hz
- HDMI/DP:
1 x Port HDMI 2.0 up to 4096x2160@60 Hz
1 x Port DP 1.4a up to 4096x2160@60 Hz
- USB Type-C:
1 x USB3.2 Gen. 2x2 20 Gbps, supports DP1.4a via alt.
mode
• Multiple display: Four simultaneous displays via 48-bit
LVDS/eDP+HDMI+DP+Type-C
Ethernet Interface
• Speed: 10/100/1000 Mbps
• Controller: GbE1 - Intel i219, GbE2 - Intel i210-AT
• Connector: RJ45 x 2
I/O
• Internal I/O: 1 x SATA 6 Gb/s, 2 x USB 2.0, 2 x
RS232/422/485, 8-bit GPIO, Inverter, SMBus, CANBus
I2C*, HD audio, LVDS, and system fan.
• Rear I/O: 4 x USB 3.2, HDMI, DP, USB type-C, 2 x RJ-45,
1 x DC-Jack (*optional).
• MI/O expansion: 4 x PCIex1, 1 x PCIe x4, USB 2.0, LPC,
SMBus, line-out, and 12 V/5 V power supply.
• Power connector type: Default support 2 x 2 pin ATX
power connector, DC jack is supported upon by request.
Mechanical and Environmental
• Dimensions (L x W): 146 x 102 mm (5.7 x 4 in)
2nd Edition
• Power supply type: ACPI support for ATX only
Feb. 2024
• Power requirements: Vin: 12 V-24 V +/- 5%
)
®
SoC integrated for HDMI/DP/Type-C display output
®
MIO-5375 Startup Manual 1
