Summary of Contents for Uplus Lighting IP PAR-12
- Page 1 User manual IP PAR-12 Please read the instructions carefully before use...
- Page 2 TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3 Technical Specifications………………………………………………………………………4 Control Menu ……………………………………………………………………………………4-5 DMX Channels …………………………………………………………………………………6-7 Trouble Shooting…………………………………………………………………………………8 Fixture Cleaning………………………………………………………… ………………………8 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...
- Page 3 1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit.
- Page 4 2.Technical Specifications Light Sources: 12 x 15W 5in1 RGBW+UV LED Power Consumption: 180W Power Voltage: AC 100-240V, 50/60Hz Beam angle:25° Dimension:298x282x157mm Net Weight: 5Kgs Control DMX Channel: 5/9/11 Channel Control Modes: DMX 512, Auto mode, Master/Slave, Sound active Construction Protection Rating: IP65 Features Outstanding color macro effect ,fade and built in programs Dimmer: 0~100% smooth dimming...
- Page 5 Display: [MENU] menu selection or return to previous menu. [UP] press [UP] through the menu list to increase/change the value of the current function. [DOWN] press [DOWN] through the menu list to decrease/change the value of the current function. [ENTER] confirm & quit out current function setting. Display panel operation instruction Main-Menu Sub-Menu 1...
- Page 6 4.DMX Channels 9 DMX channels Channel Value Function Description Dimmer 0-255 0~100% 0-255 0~100% Green 0-255 0~100% Blue 0-255 0~100% White 0-255 0~100% 0-255 0~100% 0-13 no function (0Hz) Strobe 14-255 1~20Hz 0-50 no function Different Colors output (Channel 51-100 9 to choose color) 101-109 Auto-1...
- Page 7 Red 100%, Green 0%, Blue 111-130 100-0% Red 100%, Green 0-100%, Blue 131-150 0-100% Red 100-0%, Green 100-0%, 151-170 Blue 100% Red 100%, Green 100%, Blue 171-200 100% Pre-defined colors and color temperature 201-205 Colour temperature1 206-210 Colour temperature2 211-215 Colour temperature3 216-220 Colour temperature4...
- Page 8 6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
