- Page 1 Assembly and Operating Instructions max. 150 kg ~ 90 Min. 51 kg L 106 | W 105 | H 106 SEBR2735.01.01 SKU: SEBR2735 BodyMax Leg Extension/Curl...
- Page 2 Leg Extension/Curl...
- Page 3 Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly STORAGE AND TRANSPORT General Instructions TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing...
- Page 4 Leg Extension/Curl...
- Page 5 Dear customer, Thank you for choosing training equipment from BodyMax. BodyMax is your reliable partner for home and commercial gym equipment. We are specialized in cardio and strength training machines for home and commercial use. Our products are not only strong, durable, and affordable but also designed to fit your personal needs.
- Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
- Page 7 GENERAL INFORMATION Technical Data Weight and Dimensions Article weight (gross, incl. packaging) approx.: 55.8 kg Article weight (net, excl. packaging) approx.: 51 kg Packaging dimensions (L x W x H) approx.: 100 cm x 93 cm x 27 cm Set-up dimensions (L x W x H) approx.: 105.5 cm x 104.4 cm x 105.3 cm Maximum user weight: 150 kg...
- Page 8 Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year.
- Page 9 Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts.
- Page 10 ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries.
- Page 11 Hardware Pack Manual Item No. Description Qty. Item No. Description Qty. Main Frame Seat Pad Rear Base Back Pad Front Frame Plate Side Angle Frame Roller Pad Tube Cap Ø25 Back Pad Adjustable Frame Foam Pad Ø57*Ø102*406 Adjustable Roller Pad Frame Foam Pad Ø22*Ø100*180 Right Handle Barbell Cover ASSY...
- Page 12 Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. If you have difficulty recognising the graphics, we recommend that you open and/or download the PDF instructions stored in the webshop on your end device (e.g.
- Page 13 Step 2: Assembly of the Foam Pad Attach the foam pad (39) to the swing tube (8; pre-assembled to front frame (3)) with two Ø52*Ø68*12.7 collars (37) and two M8*6 set screws (34).
- Page 14 Step 3: Assembly of the Handles and Side Angle Frame NOTICE Do not tighten bolts and nuts completely yet. Leave room for adjustments. Attach the right handle (11) and the left handle (12) to the main frame (1) with two M12*80 screws (19), four Ø13*Ø24*1.5 flat washers (18) and two M12 lock nuts (20).
- Page 15 Step 4: Assembly of the Adjustable Roller Pad Frame and Back Pad Adjustable Frame Attach the foam pads (43) to the adjustable roller pad frame (10) with two roller pad tube caps (33). Attach the adjustable roller pad frame (10) to the main frame (1) and lock it into place with the knob.
- Page 16 Step 5: Assembly of the Pads Attach the back pad (16) to the back pad adjustable frame (9) with two M10*25 screws (28) and two Ø11*Ø23*2 flat washers (27). Attach the seat pad (15) to the seat bracket (13) with four M10*25 screws (28) and four Ø11*Ø23*2 flat washers (27).
- Page 17 Step 6: Assembly of the Barbell Covers (Optional) NOTICE Only install the barbell covers (57) if you use 50 mm weight plates. For smaller weight plates with 25 mm holes, do not install the barbell covers (57). Attach one barbell cover (57) like shown and tighten the fastening screws. Step 7: Adjustment and Exercise Instructions Load and Unload Weight Plates...
- Page 18 Exercise Instructions ⚠ CAUTION Do not hyperextend the knees. If you have troubles performing the exercises, drop the weight. NOTICE The weight horn is compatible with 25 mm and 50 mm weight plates with a maximum external diameter of 450 mm. Weight plates are not included in the scope of delivery.
- Page 19 Support pad Latch to adjust the foam pad Pop pin Weight horn for storage Foam pad Weight horn for training STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented.
- Page 20 TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Safety can only be guaranteed if you check the equipment regularly for wear and damage. Replace damaged or worn components immediately.
- Page 21 Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Screw connections Cushions Legend: C = clean;...
- Page 22 RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. For training equipment like smith machines, weight benches or racks this could for example be a floor mat, which makes your fitness equipment stand more securely and also protects the floor from sweat but it could be also additional weights, handles, foot straps for leg exercises or triceps ropes.
- Page 23 The serial number of your equipment is unique. It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: BodyMax / multi gym Model Name: Leg Extension/Curl SKU: SEBR2735...
- Page 24 Parts List Name Qty. Name Qty. Main Frame Spring Clip Rear Base Grease Fitting Front Frame Pop Pin Side Angle Frame L Pin Leg Frame Roller Pad Tube Cap Φ25 Circular Plate w/shaft Set Screw M8*6 Weight Holder EZ Glide Sleeve Swing Tube Plug 44.5 Back Pad Adjustable Frame...
- Page 25 Exploded View Exploded Drawing ─ 6 ─...
- Page 26 WARRANTY Training equipment from BodyMax® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
- Page 27 Warranty Service Within the warranty period, equipment which develops faults as a result of material or manufacturing defects, will be repaired or replaced at our discretion. Ownership of equipment or parts of equipment which have been replaced is transferred to us. The warranty period is not extended nor does a new warranty period begin following repair or replacement under the warranty.
- Page 28 CONTACT TECHNIK TEKNIK OG SERVICE TECHNIQUE & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 189 530984 +49 4621 4210-945 +49 4621 42 10 933 �� +49 4621 4210-698 �� �� info@fitshop.dk info@fitshop.fr �� technik@sport-tiedje.de ��...
- Page 29 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA The Sport-Tiedje Group is Europe’s largest http://www.powerhouse-fitness.co.uk/ specialist for home fitness equipment with www.powerhouse-fitness.co.uk/blog/ currently 70 stores and one of the world’s most renowned online mail order companies for fitness equipment. https://www.facebook.com/powerhousefitness.co.uk Powerhouse Fitness is part of the Sport-Tiedje Group.
- Page 30 Notes Leg Extension/Curl...
- Page 32 BodyMax Leg Extension/Curl...
