- Page 1 Assembly and Operating Instructions max. 120 kg ~ 90 Min. 115 kg L 93 | W 204 | H 143 SEBR3427.01.01 SKU: SEBR3427 CF800 Leg Press/Hack Squat Machine...
- Page 2 CF800...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly STORAGE AND TRANSPORT General Instructions TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing... - Page 4 CF800...
- Page 5 The BodyMax headquarter is based in Rutherglen, Glasgow. Our brand was created with the intention of providing innovative exercise equipment at affordable prices for users of all training levels.
- Page 6 This notice indicates potentially hazardous situations which, if not avoided, will result in death or serious injuries! NOTICE This notice indicates further useful information. Retain these instructions in a safe place for future reference, maintenance or when ordering replacement parts. CF800...
-
Page 7: General Information
GENERAL INFORMATION Technical Data Weight and Dimensions Packgaing dimensions (L x W x H) and article weight (gross, incl. packaging) approx.: Box 1: 189 cm x 29 cm x 14 cm 37 kg / 82 lbs Box 2: 146 cm x 90 cm x 13 cm 28 kg / 62 lbs Box 3: 95 cm x 78 cm x 33 cm... -
Page 8: Personal Safety
Make sure that nobody is within the range of motion of the equipment during training so as not to endanger you or other persons. ࣑ ATTENTION Do not insert any objects of any kind into the openings of the device. CF800... -
Page 9: Set-Up Place
Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 10: Assembly
In the event of complaints, the contractual partner must be contacted directly. ⚠ CAUTION If parts of the scope of delivery are missing or damaged, the assembly must not be carried out. CF800... - Page 11 Content of Box 1 NUMBER DESCRIPTION QUANTITY Right Rail Left Rail Right Safety Stopper Left Safety Stopper Right Handle Left Handle Handle Sleeve Dia 25mm Inner Cap...
- Page 12 Content of Box 2 NUMBER DESCRIPTION QUANTITY Base Connector Rear Upright Lower Back Pad Shoulder Pad 50x50mm End Cap Pop Pin Dia 48mm Inner Cap Seat Pad Carriage Stop Tube Rubber Bumper CF800...
- Page 13 Content of Box 3 NUMBER DESCRIPTION QUANTITY Base Front Foot Platform Axle Shoulder Pad Mount Handle Sleeve Foot Platform Lower Back Pad Hinge Outer Foot Platform Adjuster Inner Foot Platform Adjuster Weight Carrier Dia 48mm Inner Cap Carriage...
- Page 14 Content of Box 3 NUMBER DESCRIPTION QUANTITY Big Wheel Small Wheel 38x38 Inner Cap 50x50 Inner Cap Long Pop Pin Leg Press Footrest Leg Press Footrest Axle 30x60 Inner Cap Upper Back Pad Head Support Pad CF800...
-
Page 15: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. If you have difficulty recognising the graphics, we recommend that you open and/or download the PDF instructions stored in the webshop on your end device (e.g. - Page 16 Attach the right rail (3) to the base front (1) with two bolts (H12-18), four washers (W12) and two nuts (N12). Attach the left rail (4) to the base front (1) with two bolts (H12-18), four washers (W12 and two nuts (N12). H12-18 H12-18 CF800...
- Page 17 Step 3: Assembly of the Foot Platform Screw one pop pin (23) into the outer foot platform adjuster (22), then insert the inner foot platform adjuster (24) into the outer foot platform adjuster (22) and lock it into place with the pop pin (23).
- Page 18 2.Mount Shoulder Pad Mount (#8) to Carriage (#6) with two bolts (H10-17), four washers (W10) and two nuts (N10). 3.Connect Carriage (#6), Shoulder Pad Mount (#8) and Weight Carrier (#9) with two bolts (H10- CF800 four washers (W10) and two nuts (N10).
- Page 19 STEP 5 Step 5: Assembly of the Rear Upright Attach two end caps (17) to the rear upright (10). Attach two rubber bumpers (38) to the sleeves of the rear upright (10). o End Caps (#17) to Rear Upright (#10). ubber Bumpers(#38) on the sleeves of Rear Upright (#10).
- Page 20 Attach the rear upright (10) to the base connector (2) with two bolts (H12-13), four washers (W12) and two nuts (N12). Attach the rear upright (10) to the right and left rails (3 & 4) with one bolt (H12-18), two washers (W12) and one nut (N12) each. H12-18 H12-13 CF800...
- Page 21 Step 7: Assembly of the Pads, Part 1 Attach the seat pad (35) to the base front (1) with two bolts (H8-12) and two washers (W8). Attach the lower back pad (13) to the lower back pad hinge (34) with four bolts (H8-3) and four Assembly Instructions washers (W8).
- Page 22 Attach the right safety stopper (11) to the right rail (3) with one bolt (H8-5), two washers (W8) and one nut (N8). Attach the left safety stopper (12) to the left rail (4) with one bolt (H8-5), two washers (w8) and one nut (N8). H8-5 CF800 H8-5...
- Page 23 Step 9: Assembly of the Pads, Part 2 Attach the upper back pad (14) to the leg press footrest (7) with four bolts (A8-7) and four washers (W8). Attach the head support pad (15) to the carriage (6) with two bolts (A8-7) and two washers (W8). Attach two shoulder pads (16) to the shoulder pad mount (8) with four bolts (H8-12) and four washers (W8).
-
Page 24: Storage And Transport
࣑ ATTENTION Make sure that the equipment is protected from moisture, dust and dirt in the selected storage location. The storage location should be dry and well ventilated and have a constant ambient temperature between 10°C and 35°C. CF800... -
Page 25: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 26: Maintenance And Inspection Calendar
The materials can be recycled as per their symbols. Through the reuse, recycling of materials or other forms of recovery of old equipment, you make an important contribution to the protection of the environment. CF800... -
Page 27: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. For training equipment like smith machines, weight benches or racks this could for example be a floor mat, which makes your fitness equipment stand more securely and also protects the floor from sweat but it could be also additional weights, handles, foot straps for leg exercises or triceps ropes. -
Page 28: Ordering Spare Parts
The serial number of your equipment is unique. It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: BodyMax / multi gym Model Name: CF800 Leg Press/Hack Squat Machine SKU: SEBR3427 CF800... -
Page 29: Parts List
Parts List Name Qty. Base Front Base Connector Right Rail Left Rail Foot Platform Carriage Leg Press Footrest Shoulder Pad Mount Weight Carrier Rear Upright Right Safety Stopper Left Safety Stopper Lower Back Pad Upper Back Pad Head Support Pad Shoulder Pad 50x50mm End Cap Right Handle... - Page 30 M10x75mm Hex Head Bolt H10-15 M10x85mm Hex Head Bolt H10-17 M10x95mm Hex Head Bolt H10-23 M10x125mm Hex Head Bolt H12-13 M12x75mm Hex Head Bolt H12-18 M12x100mm Hex Head Bolt M8 Washer M10 Washer M12 Washer M8 Nut M10 Nut M12 Nut CF800...
-
Page 31: Exploded Drawing
Exploded Drawing... - Page 32 CF800...
-
Page 34: Warranty
WARRANTY Training equipment from BodyMax® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 35 Warranty Service Within the warranty period, equipment which develops faults as a result of material or manufacturing defects, will be repaired or replaced at our discretion. Ownership of equipment or parts of equipment which have been replaced is transferred to us. The warranty period is not extended nor does a new warranty period begin following repair or replacement under the warranty.
-
