- Page 1 User manual MH1240S Please read the instructions carefully before use...
- Page 2 TABLE OF CONTENTS 1. Safety Instructions………………………………………………………………………………3 Technical Specifications…………………………………………………………………………4 Control Menu ……………………………………………………………………………………4-7 DMX Channel ……………………………………………………………………………………7-16 ………………………………………………………………………………………17 Trouble Shooting…………………………………………………………………………………18 Fixture Cleaning………………………………………………………… ………………………18 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...
- Page 3 1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. •Unpack and check carefully there is no transportation damage before using the unit. •Before operating, ensure that the voltage and frequency of power supply match the power requirements of the unit.
- Page 4 2.Technical Specifications Voltage: AC100~240V 50/60HZ Power: 500W Light Source:LED 12X40W 4IN1 LED Auxiliary light :96 RGB + 96 cool white + 96 warm white Control mode: DMX512, self-propelled, master-slave, voice control, with RDM function. Channels: CH26, CH38, CH62 CH74. CH194. Dimming: 32bit 0-100% linear dimming Zoom angle: 4.5-50°...
- Page 5 Main menu Sub menu Menu Function Description Modify the DMA address code up or down (optional range of address 1. DMA address codes 001-512), confirm to save, default to 001. 2. Encoder Modify encoder on/off up or down, confirm key to save, default to on. 1.System 3.
- Page 6 17. B Green Modify the brightness of the green light bead up or down (adjustable range 000-255), confirm to save, default to 255. 18. B Blue Modify the brightness of the blue light bead up or down (adjustable range 000-255), confirm to save, default to 255. 19.
- Page 7 004. Display, please 11. Speed Select 000/007 up or down, confirm to save, default to enter password! 000. 5.Factory Change up or 12. LOGO Select 000/001 up or down, confirm to save, default to settings down to 138, 000. then press the 13.
- Page 8 38CH Channel Value Function 000-255 electrical machinery 000-255 Motor fine adjustment 000-255 Motor speed 000-255 focusing 000-255 Dimming 000-255 Main light strobe 000-255 Main light red 000-255 Main light green 000-255 Main light blue 000-255 Main light white 000-255 Main light mode 000-255 Main optical speed 000-255...
- Page 9 62CH Channel Value Function 000-255 electrical machinery 000-255 Motor fine adjustment 000-255 Motor speed 000-255 focusing 000-255 Dimming 000-255 Main light strobe 000-255 Main light red 000-255 Main light green 000-255 Main light blue 000-255 Main light white 000-255 Main light mode 000-255 Main optical speed 000-255...
- Page 10 000-255 Auxiliary light LED3 000-255 Auxiliary light LED 4 000-255 Auxiliary light LED 5 000-255 Auxiliary light LED 6 000-255 Auxiliary light LED 7 000-255 Auxiliary light LED 8 000-255 Auxiliary light LED 9 000-255 Auxiliary light LED10 000-255 Auxiliary light LED11 000-255 Auxiliary light LED12 000-255...
- Page 11 000-255 Auxiliary light blue 000-255 Auxiliary light white 000-255 Auxiliary light yellow 000-255 Auxiliary light mode 000-255 Auxiliary light speed 000-255 Auxiliary light direction 000-255 Auxiliary light background color 000-255 Auxiliary light background color tone light 000-255 reset 000-255 Main light red 1 000-255 Main light green 1 000-255...
- Page 12 000-255 Main light white 9 000-255 Main light red 10 000-255 Main light green 10 000-255 Main light blue 10 000-255 Main light white 10 000-255 Main Light Red 11 000-255 Main light green 11 000-255 Main light blue 11 000-255 Main light white 11 000-255...
- Page 13 000-255 Main light green 1 000-255 Main light blue 1 000-255 Main light white 1 000-255 Main light red 2 000-255 Main light green 2 000-255 Main light blue 2 000-255 Main light white 2 000-255 Main light red 3 000-255 Main light green 3 000-255...
- Page 14 000-255 Main light green 12 000-255 Main light blue 12 000-255 Main light white 12 000-255 Auxiliary light red 1 000-255 Auxiliary light green 1 000-255 Auxiliary light blue 1 000-255 Auxiliary light white 1 000-255 Auxiliary light yellow 1 000-255 Auxiliary light red 2 000-255...
- Page 15 000-255 Auxiliary light green 9 000-255 Auxiliary light blue 9 000-255 Auxiliary light white 9 000-255 Auxiliary light yellow 9 000-255 Auxiliary light red 10 000-255 Auxiliary light green 10 000-255 Auxiliary light blue 10 000-255 Auxiliary light white 10 000-255 Auxiliary light yellow 10 000-255...
- Page 16 000-255 Auxiliary Light Red 18 000-255 Auxiliary Green 18 000-255 Auxiliary light blue 18 000-255 Auxiliary light white 18 000-255 Auxiliary light yellow 18 000-255 Auxiliary light red 19 000-255 Auxiliary Green 19 000-255 Auxiliary light blue 19 000-255 Auxiliary light white 19 000-255 Auxiliary light yellow 19 000-255...
- Page 17 5.Dimension...
- Page 18 6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
