MULTISPAN EM-1P-M1 Operating Manual

OPERATING MANUAL
1 PHASE ENERGY METER
EM-1P-M1
Connection
Diagram
EM-1P-M1
Technical Specification
Model
Display
Size (mm)
Panel Cutout
Voltage Input
Current Input
Active Power
(kW)
Active energy
(kWh)
Output
Power Supply
Frequency
Wiring
System
Protection
Level
(As Per Request)
Operating
Temperature
Relative
Humidity
20 19 18 17 16
-
+
A- B+
Pulse
O/P
MODBUS
EM 1P-M1-A2-00
Range:
CAT III
Voltage : 30-300V AC
Current : 30mA To 5A AC
Made in India
CT Selection up to 9999/5 Amp AC
~
100
!
270V AC
50/60 Hz
3VA
N
L
5
1 2 3 4
Page - 1
EM-1P-M1
8 digit, 7 segment, 0.5" Red display
101 (H) X 101 (W) X 43 (D) mm
92 X 92 mm
30 To 300V AC VLN CAT III
5 Amp or higher through external CT
0.000 To 9999 kW
0.000 To 99999999 kWh
RS-485 Modbus
100 To 270V AC,50/60Hz,Approx 3VA
45 To 65 Hz
1Ph-2W
IP-65 (Front side) As per IS/IEC 60529 : 2001
0°C To 50°C
Up to 95% RH Non Condensing
15 14 13 12 11
V N
P
System:
1Ø-2W
Accuracy Class:
1.0
www.multispanindia.com
5Amp
S1 S2
9
6 7 8 10
www.multispanindia.com
